Pro-Elec PELL0348 Manuel utilisateur
1
LED Floodlight
Models: PELL0348, PELL0349,PELL0350
& PELL0351
Please read these instructions carefully before use and retain for future
reference.
This oodlights must be installed by a qualied electrician in accordance with current
building and IET wiring regulations (BS7671).
IMPORTANT SAFETY INFORMATION
• Do not use PVC cable to connect this oodlight to your wiring supply. Rubberised
cable (type H05RN-F), with three conductors of at least 1.0mm² cross-sectional
area must be used. This product must be connected to Earth.
• The front of this oodlight is made of tempered glass, replace if cracked.
• LED lamps are extremely bright. To avoid possible damage to the eyes, do not
stare into an LED beam.
• In use, avoid touching any external surface of the oodlight, due to the possibility
of high temperatures.
• Do not use near ammable materials.
• The oodlight must be positioned so that there is at least 1m between the front of
the work light and the surface to be illuminated.
• The oodlight has an IP rating of IP65.
• It is suitable for use in an ambient temperature between -30°C and +45°C.
2
The oodlight has a beam angle of 120°. It can be tilted upwards and downwards at an
angle of approximately 90°. The angle of adjustment will vary slightly between models.
INSTALLATION
The oodlight is suitable for connection to a 85-260V 50Hz earthed AC supply. It is
designed for permanent connection to xed wiring, which must be a suitable circuit
protected by an RCD with an operating current not exceeding 30mA and an MCB or
fuse of the correct rating.
Mounting the Floodlight
• Before commencing installation, check that you have all of the tools you need.
• Check that the oodlight is not damaged. If there is any damage, return it to the
place of purchase. Do not attempt to repair it yourself.
• Choose your location to x the oodlight, taking into account the guidance above.
• Use the oodlight bracket to mark the position of the xing holes.
• Drill the xing holes and x the oodlight into position using appropriate size
screws and wall plugs (not provided). Check that it is securely xed.
• This oodlight is suitable for outdoor lighting applications, for domestic use only.
• Do not use in areas where an explosive or chemical atmosphere may exist. Do not
use in areas where ventilation is restricted.
• It is suitable for mounting on plasterboard, wood or masonry surfaces. Highly
ammable surfaces such as plastic or polystyrene must not be used.
• Do not install on damp or conductive surfaces such as metal. It should be placed
away from any ammable materials.
• Before drilling any xing holes, check that there are no hidden obstructions behind
the mounting surface such as pipes or cables.
• The recommended height for installation of the oodlight is between 0.5 and 3
metres.
• Ensure that there is space around the oodlight to allow adequate circulation of air.
• Orientation of the oodlight is important as shown below:
POSITIONING
3
Wiring the Floodlight
• Ensure that the mains supply is isolated before commencing installation.
• A suitable rated connector must be used to connect the lead from the oodlight to
the mains supply.
• Connect the mains cable to the connector. Ensure that the correct polarities for
Live, Neutral and Earth are observed i.e.
- Green/yellow - Earth terminal
- Brown - Live terminal
- Blue - Neutral terminal
• After wiring, check that there are no stray strands and that all the wires have been
correctly installed.
• Before connecting power, perform the electrical tests specied in the current
Building and IET Wiring Regulation to ensure that the installation is safe and that
the wiring has been performed correctly.
• Restore the mains power supply and check that the oodlight illuminates the
required area. Tighten the oodlight using the bolts on the brackets.
CLEANING & MAINTENANCE
• Clean the oodlight only with a soft dry cloth. Do not use any chemicals, abrasives
or solvents that could damage the oodlight.
• The oodlight has a sealed LED lamp and is maintenance free. The LED lamp
cannot be replaced. When the LED lamp reaches the end of its life, the oodlight
will have to be replaced.
These produts contain a light source of energy eciency class F.
SPECIFICATION
PELL0348 PELL0349 PELL0350 PELL0351
Input Voltage 85-260V AC
50/60Hz
85-260V AC
50/60Hz
85-260V AC
50/60Hz
85-260V AC
50/60Hz
Nominal luminous ux 720lm 1450lm 2200lm 3800lm
Wattage 10W 20W 30W 50W
Beam angle 120° 120° 120° 120°
Dimmable No No No No
Nominal lifetime of the lamp
20,000h 20,000h 20,000h 20,000h
Light source SMD2385 SMD2385 SMD2385 SMD2385
Colour temperature 6000K 6000K 6000K 6000K
Colour rendering (CRI Ra) ≥80 ≥80 ≥80 ≥80
Warm up time
(60% full light)
Instant full
light
Instant full
light
Instant full
light
Instant full
light
Ingress rating IP65 IP65 IP65 IP65
Earthing Class I Class I Class I Class I
Weight 0.310kg 0.430kg 0.628kg 1.067kg
Dimensions WxHxD (mm) 124 x 95 x 30 153 x 117 x 33
185 x 139 x 39 232 x 175 x 43
4
INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF
ELECTRICAL & ELECTRONIC EQUIPMENT.
When this product has reached the end of its life it must be treated as Waste Electrical & Electronic
Equipment (WEEE). Any WEEE marked products must not be mixed with general household waste,
but kept separate for the treatment, recovery and recycling of the materials used. Contact your local
authority for details of recycling schemes in your area.
Made in China
PO Box 13362 Dublin 2
PR2 9PP
Man Rev 1.0
