User Manual
SD-Series
2
Content
Important Notices...................................................................................................................3
Features....................................................................................................................................4
Package Contents: ..................................................................................................................4
Drawing (14” – 15.6”) ...........................................................................................................5
Drawing (18.5” – 21.5”)........................................................................................................7
Remote Control........................................................................................................................9
Getting Started .....................................................................................................................10
Main Menu.............................................................................................................................. 11
Viewing Your Photos ............................................................................................................12
Listening To Your Music ......................................................................................................12
Viewing Your Videos .............................................................................................................13
Calendar and Clock Display .................................................................................................13
Feature Setup ........................................................................................................................14
3
Important Notices
1. Please keep the device away from excess temperature (50 degrees C above), too cold (-10
degrees C below) or wet places.
2. Do not grievous hit the device or place something heavy on it.
3. Only use the accessories specified by the manufacturer.
4. Please keep the device away from benzene, diluents or other chemical.
5. Keep the device away from water.
6. The product should be serviced by the professional serviceman.
7. Please unplug the power plug of the product when not in use for a long time or during the
rainstorm.
8. In order to avoid damaging the touch panel, never place the heavy or sharp objects on the
touch panel when use or transport it.
9. Arrange all cables and cords so that people and pets are not likely to trip over or
accidentally pull on them move around or walk through the area. Do not allow children to
play with cables and cords.
4
Features
❖Full HD Screen, LED Backlight
❖High Resolution
❖Width viewing angle
❖Compatible with SD/MMC Card
❖HDMI input
❖AV input
❖USB Host 2.0
❖3.5mm earphone
❖Support: MPEG2, MPEG4, H.264, RM, RMVB, MPG, MOV, AVI, MKV, TS, M2TS et.
Video Format Support up to 1920 x 1080.
❖Support: JPEG/MP# music play
❖2 x 3W speaker
❖VESA 100
❖Full function remote control
❖Auto playback and loop function for video files
Package Contents:
Full HD signage display Power adapter Power cable Remote control
Screw-in stand (SD-14”/15”) Stand (SD-10”/18”/22”) Screw (SD-10”/18”/22”)
5
Drawing (14”–15.6”)
Serial number
Function
1
Remote receiver
2
SD/MCC card slot
3
Earphone
4
AV Input
5
USB2.0
6
HDMI Input
7
DC In
6
Serial number
Function
8
Power
9
Up
10
Right
11
Menu/Play/Enter/Pause
12
Down
13
Exit
14
Left
15
Speaker
16
Keyholes for Wall-Mounting
17
VESA 100
18
Stand
19
Kensington Lock
7
Drawing (18.5”–21.5”)
Serial number
Function
1
Remote receiver
2
SD/MCC card slot
3
Earphone
4
AV Input
5
USB2.0
6
HDMI Input
7
DC In
8
Serial number
Function
8
Power
9
Up
10
Right
11
Menu/Play/Enter/Pause
12
Down
13
Exit
14
Left
15
Speaker
16
Keyholes for Wall-Mounting
17
VESA 100
18
Kensington Lock
19
Stand
9
Remote Control
Note: 1. Please remove the plastic tab between the Remote control battery door and the battery.
2. Please point the Remote control toward the Remote sensor, which is located towards
the lower right of the frame’s panel.
Zoom
Exit Zoom setup
ON/OFF
Rotate
INFO
MODE ENTER
SOURCE
Rotate
ON/OFF
INFO
Source
DMP/HMDI/AV
Play/Pause
Down
Select/Execute
Left
Right
Volume Down
Up
Volume Up
Mute
EXIT
Mode
Movie/Music/Photo
10
Getting Started
1. To set up your digital photo frame, you first need to attach the stand
2. Place the frame horizontally on a flat surface
3. Insert the power lead into the digital photo frame’s socket marked dc.
4. Turn on the digital photo frame by either pressing the power button on the back of the unit
or pressing the power button on the remote control.
