3.
Loosen the Small Knobs (2) and
adjust the Front Bracket to fit on the
front bumper bar. NOTE: The Front
Bracket may be turned around to better
fit your spreader. Loosen the Small
Knobs and adjust the Legs as required
to lift and level the entire assembly as
shown in Fig. #5.
SMALL
KNOB
LOOSEN SMALL
KNOB AND ADJUST
LEGS
TO LEVEL THE
CALIBRATOR
FRONT
BRACKET
BUMPER
Fig. #5
HOW TO USE & MAINTENANCE
Pour enough material into hopper to allow several passes to be made without running out of
product. Use the spreader setting on the bag as a starting point. If no setting is available, use a
middle setting.
Walk the distance of the test area as previously determined making sure to open and close the
spreader at the exact start point and close at the exact end point. Walking speed should be a
constant 2 1/2 MPH. (18 feet in 5 seconds).
When test is completed, place the spreader over a newspaper to catch any overflow of material.
Remove pan and weigh material collected and record weight. Adjust the spreader as required and
repeat test until application rate is correct.
When finished with test, return leftover material to it’s original container. Wash the calibrator
thoroughly and wipe dry. Install gear covers if removed.
PSB warrants to Purchaser the following:
1. Product will be free of defects in materials and workmanship for a period of one year from date of purchase.
2. PSB will decide in its reasonable discretion if the part(s)/unit is defective.
3. The spreader or part(s) will be shipped to PSB at the customer expense with a written description of defect to the attention of PSB WARRANTY
DEPARTMENT.
4. If the spreader is used for commercial rental the Limited Warranty shall be limited to a period of 90 days.
5. All Unit and part replacement will be performed at the reasonable discretion of PSB.
6. Labor charges are not covered and the unit need not be returned to the dealer for warranty service.
7. Proof of purchase must be supplied to PSB.
PSB's sole obligation under this warranty is limited to repairing or replacing the defective part. Upon replacement of any Product or Product part, the
replaced item shall become the property of PSB. If PSB determines that the Product covered by this warranty requires service, PSB shall prepay return
shipping charges from PSB. In all other instances, such charges shall be paid by Purchaser. Except for loss or damage caused by PSB's negligence,
Purchaser relieves PSB of responsibility for all risks of loss or damage to the Product and its parts during the period the products are in transit to and
from PSB.
This warranty does not extend to any Product or parts thereof that have been allowed to corrode, subjected to misuse, neglect, accident, or modification
by anyone other than PSB or that have been affixed to any nonstandard accessory attachment or that have been used, stored, installed, maintained or
operated in violation of PSB’s instructions or standard industry practice. No agent, employee or representative of PSB has any authority to bind PSB to
any affirmation, representation or warranty concerning the Product and any affirmation, representation or warranty made by any agent, employee or
representative shall not be enforceable by Purchaser.
THIS WARRANTY EXTENDS ONLY TO THE ORIGINAL PURCHASER AND IS EXPRESSLY IN LIEU OF ANY OTHER EXPRESS OR IMPLIED
WARRANTIES, INCLUDING WITHOUT LIMITATION ANY IMPLIED WARRANTY OR MERCHANTABILITY OR FITNESS OR INTENDED USE FOR A
PARTICULAR PURPOSE AND OF ANY OTHER OBLIGATION ON THE PART OF PSB.
PSB SHALL NOT BE LIABLE FOR ANY INCIDENTAL, SPECIAL OR CONSEQUENTIAL LOSS, DAMAGE OR EXPENSE DIRECTLY OR INDI-
RECTLY ARISING FROM THE USE OF ANY OF THE PRODUCT INCLUDING, BUT NOT LIMITED TO, DAMAGE OR LOSS OF OTHER PROPERTY
OR EQUIPMENT, LOSS OF PROFITS OR REVENUE, COST OF CAPITAL, COST OF PURCHASED OR REPLACEMENT GOODS, OR CLAIMS OF
CUSTOMERS OF PURCHASER.
