PrimeStart 650 Installation Manual

Table of Contents

Important Information...........................2

Recommended Installation Tools....................2

Recommended Procedures.......................2

Wiring Diagrams............................3

Pin Connectors.............................6

Installation Procedures...........................8

Control Unit...............................8

RangeMaster™ Super Heterodyne Receiver Module...........8

Wireloom ................................8

LED Indicator..............................9

Valet Switch...............................9

Zone

™ Impact Sensor.........................9

Additional Sensor Input.........................9

Alarm Armed Signal (-) Output.....................9

Brake Lights (Mandatory)........................10

Parking Lights.............................10

Reverse Light..............................10

Interior Light Illumination.......................11

Channel 2 Accessory Output (Trunk Release)..............11

Channel 6 Accessory Output......................11

Channel 9 Accessory Output......................11

Remote Start Armed Signal (-) Output.................11

Factory Alarm Disarm (-) Output....................12

Accessory Remote Start (-) Input....................12

Trunk Switch..............................12

Ignition Switch Connections......................12

Remote Engine Start Neutral Safety Switch Bulletin ..........14

Door Lock/Unlock...........................17

Door Lock Diagrams..........................17

Tach Wire (RPM Monitoring)......................21

Hood Switch (Mandatory) .......................21

Siren..................................22

Power and Ground Connections....................22

Mandatory RPM Programming.....................23

Programmable Features..........................24

Programming Table for System Features................25

Programming Table for Remote Controls................26

Important Information

Recommended Installation Tools

Voltmeter

Wire Strippers

Electric Drill & Bits

Phillips Screwdriver

Convoluted Tubing *

Solder Gun *

Wire Crimpers

Shrink Tube or Electrical Tape* Optional

Recommended Procedures

1.Test all circuits with a voltmeter.

2.Make all wiring connections with the supplied solderless crimp

connectors. DO NOT twist wires or use scotch-lok connectors.

3.Route the small and large RED, RED/WHITE and BLACKwires from the

control unit directly to the battery.

4.Keep extensions as short as possible. Use same gauge wires for short

extensions and larger gauge wires for longer extensions.

5.Before installing, discuss the placement of the LED indicator and valet

switch with the vehicle owner.

6.DO NOT disconnect the battery cables. Make all connections by

removing the bolts from the cable clamps without detaching the clamp.

7.Turn off dome light or remove dome light fuse to prevent battery drain.

This device complies with Part 15 of the FCC rules. Any changes or modifications

made to the system without the express approval of Prime Security, Inc. could

void the user’s authority to operate this equipment.

PrimeStart 650 Installation Manual

Main Wiring Diagram - 16 Pin

Main Wiring Diagram - 12 Pin

PrimeStart 650 Installation Manual

Satellite Relay Module Diagram

16 Pin Connector

Pin NumberWire ColorDescription

1BLUE / ORANGEAccessory Remote Start (-) Input

2YELLOWBrake Switch (+) Input

3YELLOW / BLACKReverse Light (+) Input

4TANHood Switch (-) Input

5TAN / BLACK Trunk Switch (-) Input

6GREENSecond Stage Unlock (-) Output

7PINK Ignition Switched +12 Volt Input

8WHITE / LIGHT GREENTachometer Input

9RED / WHITEParking Light Polarity Input (+) or (-) Select

10 RED / BLACKParking Light Output

11 GREEN / BLACKUnlock Switch Side

12 GREEN / WHITE Unlock Motor Side

13 GREEN / REDUnlock Polarity (+) or (-) Select

14 BLUE / BLACKLock Switch Side

15 BLUE / WHITELock Motor Side

16 BLUE / REDLock Polarity (+) or (-) Select

12 Pin Connector

Pin NumberWire ColorDescription

1GRAY Alarm Armed Signal (-) Output

2GRAY / BLACKRemote Start Activated (-) Output

3GRAY / WHITEFactory Alarm Disarm (-) Output

4DARK BLUEChannel 2 (-) Output (Trunk Release)

5LIGHT BLUEChannel 6 (-) Output

6BLUE / YELLOWChannel 9 (-) Output

7REDBattery (+)

8WHITE Door Trigger

9VIOLET Siren (-) Output

10WHITE / BLACKDoor Trigger Input Polarity (+) or (-) Select

11 BLACKBattery (-)

12 ORANGEOptional Sensor (-) Input

PrimeStart 650 Installation Manual

6 Pin Connector

Pin NumberWire ColorDescription

1YELLOWStarter Interrupt Switch Side

2GRAYHeater / AC Output

3VIOLETStarter Interrupt Starter Side

4PINKIgnition Output

5RED Battery (+)

6PINKIgnition Output

PrimeStart 650 Installation Manual

Installation Procedures

Control Unit

1.Select a location under the dash that will allow you to use the tie wraps to

securely fasten the control unit.

2.Mount the control unit as high as possible to ensure maximum security.

3.Do not mount the control unit near moving parts.

4.Avoid areas that are in the direct path of air blowing from the vents.

5.Route wires from this point, leaving slack for ease of service.

RangeMaster™ Super Heterodyne Receiver Module

1.Plug the receiver module WHITEconnector into the control unit WHITE

plug.

2. Use tie wraps to fasten the receiver module as far from the control unit as

possible.

3.Route the antenna cable behind the driver side windshield pillar, above

the headliner and behind the rear view mirror.

4.Fasten the antenna to the windshield with the attached adhesive tape.

Attach the antenna vertically so that the rubber tip on the end of the

antenna is facing downward.

Wireloom

1. Plug the wirelooms securely into the control unit and satellite relay

module.

2.Route wires from the control module and satellite relay module directly to

each connection point.

3.Separate the small and large RED , RED/WHITE, BLACK, TAN, VIOLET

and WHITE/GREENwires.

4.Sleeve these wires with vinyl tubing or electrical tape and route them

through an existing rubber grommet into the engine compartment.

5.If an existing grommet is not available, drill a hole and install a snap

grommet.
