Eris™Series E3.5

High-Deﬁnition Near Field Studio Monitors

Owner’s Manual

www.presonus.com

1. Overview — 1

1.1. Introduction — 1

1.2. Summary of Eris E3.5

Features — 2

1.3. What’s in the Box — 3

2. Hookup — 4

2.1. Rear Panel Connections

and Controls — 4

2.1.1. Inputs (Active

Speaker) — 4

2.1.2. Power (Active

Speaker) — 5

2.1.3. Acoustic Tuning Controls

(Active Speaker) — 5

2.1.4. Speaker

connections — 6

2.2. Active Speaker Front Panel — 6

2.3. Hookup Diagram — 7

3.0 Tutorials — 8

3.1 Monitor Placement — 8

3.2 Level Setting — 9

3.3 Equalizer Setting Suggestions — 9

4. Resources — 10

4.1. Technical Speciﬁcations — 10

4.2. Troubleshooting — 11

4.3 Warranty Information — 11

Table of Contents

1. Overview

1.1. Introduction

Eris™ Series E3.5

Owner’s Manual

1. Overview

1.1. Introduction

Thank you for purchasing the

PreSonus® Eris™ E3.5 studio monitors.

Eris E3.5 active near-ﬁeld monitors

oﬀer excellent performance at

a reasonable price for budge-

conscious personal studios, with

features normally reserved for

more expensive monitors.

PreSonus Audio Electronics

is committed to constant

product improvement, and we

value your suggestions highly.

We believe the best way to achieve our goal is by

listening to the real experts: our valued customers. We

appreciate the support you have shown us through

the purchase of this product and are conﬁdent that

you will enjoy your Eris E3.5 studio monitors!

ABOUT THIS MANUAL: We suggest that you use this manual

to familiarize yourself with the features, applications, and

connection procedures for your Eris E3.5 monitors before

connecting them to the rest of your studio gear. This will

help you avoid problems during installation and setup.

Throughout this manual you will ﬁnd Power User Tips

that can quickly make you an Eris expert. In addition

to the Power User Tips, you will ﬁnd several tutorials

that cover monitor placement, as well as setting the

input level, EQ, and Acoustic Space controls.

1. Overview

1.2. Summary of Eris E3.5 Features

Eris™ Series E3.5

Owner’s Manual

1.2. Summary of Eris E3.5 Features

•1” (22 mm) silk-dome tweeter

•3.5”Woven composite woofer

•Peak SPL: 100 dB

•Frequency response: 80 Hz to 20 kHz

•Class A/B ampliﬁer

•Balanced ¼”TRS and unbalanced RCA inputs

•1/8” headphone output

•1/8” stereo Auxiliary input

•Front-panel volume control

•Rear bass-reﬂex port

•High-frequency shelf EQ with ± 6 dB of

boost/cut centered at 10 kHz

•Low-frequency shelf EQ with +/- 6 dB of

boost/cut centered at 100 Hz

1. Overview

1.3. What’s in the Box

Eris™ Series E3.5

Owner’s Manual

1.3. What’s in the Box

In addition to this manual, your Eris E3.5

package contains the following:

•(1) PreSonus Eris E3.5 active studio monitor

•(1) PreSonus Eris E3.5 passive studio monitor

•(1) 1.5m TRS 1/8” to 2 RCA cable

•(1) 1.5m TRS 1/8” stereo cable

•(1) 2m bare-wire speaker cable

•(8) Foam feet, (4) to be placed on the bottom of each

speaker to improve isolation

•(1) Power cable

2. Hookup

2.1. Rear Panel Connections and Controls

Eris™ Series E3.5

Owner’s Manual

2. Hookup

2.1. Rear Panel Connections and Controls

Each Eris E3.5 pair consists of one active E3.5 and one

passive E3.5. Nearly every connection is located exclusively

on the active speaker. This speaker provides signal and

power for the passive speaker. The exceptions are the

bare-wire connectors, which send power and signal

from the active speaker to the passive speaker.

2.1.1. Inputs (Active Speaker)

Line-level Inputs. The Eris E3.5 active monitor provides a

choice of two pairs of inputs: left and right balanced ¼”TRS

and left and right unbalanced RCA. These inputs accept a

line-level signal from an audio source and feed that signal to

the each monitor’s built-in power ampliﬁer. These inputs are

provided to enable ﬂexible connectivity, not for connecting

multiple sources to your speakers simultaneously.

Power User Tip: The left inputs (balanced or unbalanced) send

signal to the ampliﬁer that powers the active speaker; while the

right inputs send signal to the ampliﬁer that powers the passive

speaker. Because of this, PreSonus recommends that the active

speaker be placed on the left side of your mixing space, and the

passive speaker be placed on the right. However, if you prefer

to have the controls located on your active monitor placed on

the right side of your workspace, be sure to reverse the inputs

from your audio source to maintain the correct stereo image.

2. Hookup

2.1. Rear Panel Connections and Controls

Eris™ Series E3.5

Owner’s Manual

2.1.2. Power (Active Speaker)

IEC Power Connection. The Eris E3.5 accepts a standard IEC

C7 power cord. The power switch is located on the front

panel of the active E3.5.

2.1.3. Acoustic Tuning Controls (Active Speaker)

High. Boosts or cuts all frequencies above 10 kHz by ±6 dB.

Power User Tip: The High control on the Eris E3.5 is a high-shelf

EQ and attenuates or boosts frequencies above 10 kHz. This EQ

is much like the treble control on a car stereo: It raises or lowers

the gain on all frequencies above the speciﬁed cutoﬀ frequency.

Shelving EQs can make big changes to the sound very quickly

by adding or removing an entire range of frequencies.

Low. Boosts of cuts frequencies around 100 Hz by ±6 dB

Power User Tip: The Low control is a low-shelf EQ and

attenuates or boosts frequencies below 100 Hz. This functions

much like the bass control on a car stereo: It raises or lowers the

gain on all frequencies below the speciﬁed cutoﬀ frequency.

Shelving EQs can make bit changes to the sound very quickly

by adding or removing an entire range of frequencies.

2. Hookup

2.2. Active Speaker Front Panel

Eris™ Series E3.5

Owner’s Manual

2.1.4. Speaker connections

Bare-wire connectors. This connection is used to power and

send signal to the passive E3.5. Be sure to connect the positive

and negative connections on your active E3.5 to the positive

and negative connections, respectively, on the passive E3.5

(i.e. connect positive to positive and negative to negative).

2.2. Active Speaker Front Panel

Power Switch. This is the On/Oﬀ switch. The LED above the

volume control indicates power status.

Volume. Sets the volume level of the input signal before it is

ampliﬁed. This is also the volume control for the front-panel

headphone amp.

Aux In. This stereo 1/8” jack can be used to patch in an MP3

player for a quick reference check.

Power User Tip: This input will sum with

the inputs on the back panel.

Headphone Out. This headphone output is controlled by the

Level knob.

Power User Tip: When the headphone output is connected,

audio will be muted to your E3.5 speakers. This can be

very useful when you’re recording at your desk!

E3.5 Active Speaker E3.5 Passive Speaker

2. Hookup

2.3. Hookup Diagram

Eris™ Series E3.5

Owner’s Manual

2.3. Hookup Diagram

Eris E3.5 Active Eris E3.5 Passive

R L

IN OUT

USB 2.0 PHONES

MIDI MAIN OUT

AudioBox 22VSL

3.0 Tutorials

3.1 Monitor Placement

Eris™ Series E3.5

Owner’s Manual

3.0 Tutorials

3.1 Monitor Placement

Ideally, near-ﬁeld monitors should be placed

so that the tweeters are at the same height

as your ears when you are mixing.

Eris speakers can be placed vertically or horizontally;

when placed horizontally, they should form a mirror-

image pair, with the tweeters on the outside.

The speakers should be separated so that the tweeters

form an equilateral triangle with your head. The

monitors should be “toed in,”or angled, so that they

are pointed at you, not pointed straight ahead.

60˚ 60˚
