Premium PRN435MW Manuel utilisateur

This product is for domestic use only

Use & care manual

Important safeguards

REFRIGERATOR

SUPER DESIGN

PRN435MW

PRN436MS

Structure Illustration

Note: If we change some small parts of the refrigerator it is for you to use it

more conveniently. Sorry for no giving notice.

1.Ice-making tray

2.Freezer compartment shelf

3.Freezer temperature control knob

4.Refrigerator temperature control knob

5.Lamp switch

6.Refrigerator compartment shelf

7.Vegetable bin

8.Freezer door rail

9.Can rack

10.

11.

12.Adjustable feet

Bottle rack(large)

Bottle rack(small)

MAX 10WMAX 10W

1.Install on a completely flat and rigid surface.

Level the refrigerator by rotating the leveling

Legs located at the front two corners.

The refrigerator is then securely positioned.

2.Leave at least 2 cm between both sides of

the refrigerator and the wall, and at least 30

cm between the top of the refrigerator and

the surface immediately above, so that the

refrigerator will not touch any of the

surrounding surfaces.

3.Choose a location which is not expose to

sunlight, relatively free from dust, heat and

humidity, and offers good ventilation.

Above 30 cm

Above 2 cm

3. Cautions for Safety

1.The power plug should have its own

socket, as adapter may cause the

socket to overheat.

2.Don't store inflammable materials

such as ether, benzine, LP gas and

glue etc in the refrigerator.

2 Instructions for installation

3. This appliance is not intended for use by persons (including children) with

reduced physical, Sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety. Children should

be supervised to ensure that they do not play with the appliance.

DANGER: Risk of child entrapment. Before you throw away your old refrigerator

or freezer-Take off door.

Leave the shelves in place so that children may not easily climb inside.

3. Cautions for Safety3. Cautions for Safety

Temperature adjustment Usually in Mid position

Freezer temperature

Refrigerator temperature

Refrigerator

temperature

Freezer

temperature

Temperature

change

Mid ColderCold Mid ColderCold

4. Usage Instructions

7.Don't splash water on the refrigerator,

for this may cause malfunction or

electric shock.

5. WARNING---The customer don't allow to replace or repair the power cord and

plug privately, only trained and qualified service personnel should repair or service

refrigerator equipment.

4. For appliances with type Y attachment:

If the supply cord is damaged, it must be replaced by the manufacturer or its

service agent or a similarly qualified person in order to avoid a hazard.

6. DANGER---Risk of child entrapment. Before you throw away your old refrigerator or

freezer:

Take off the doors

Leave the shelves in place so that children may not easily climb inside.

Temperature knob is to be used to adjust temperature of refrigerator and freezer.

Normally, You could place the knob at Mid position. When rapidly freezer food, place

the knob at Colder position.

3. Cautions for Safety

8. When gas leaks from its container,

don't pull the plug, out or in, for it

may arouse sparks and fire

calamities.

4. Usage Instructions

3. Refrigeration

4. Placement of food

There should always be some

space between food to maintain

cold air circulation.

Fruits, vegetables are to be

stored in vegetable case. Wrap

them with fresh preservation paper

to avoid drying.

Food should be wrapped tightly

to avoid them from becoming dry

and with odor.

Hot foodstuffs should be cooled

down before being placed in the

compartments. Otherwise the internal

temperature of the compartments

or electric consumption will increase.

Applying automatic defrosting system makes defrosting very convenient.

5. Automatic defrosting

Foods with rich water substance

such as bean curd and vegetable

should be stored in the front

bottom part of the refrigerator

compartment to avoid being

frozen.

care for being frozen

Meats frozen freshly can help

maintain their nourishment.

2. Freezing

4. Usage Instructions

6. Instruction for making and removing pieces of ice cubes

Fill water into the ice-making

case below the graduation line,

and ice cubes will be formed in

about 2 to 3 hours.

Pieces of ice cubes can be

removed by twisting the ice-making

case. Don't bend it up and down,

as this may cause breakage.

7. Pockets adjustment

Placement of egg case upside

down will enable the storage of

small pieces of food.

5. Cautions for Use

Over ten minutes

1.The more food stuff is put in the

refrigerator or the more frequent and

the longer the doors are opened,

the more the electric consumption

will be, intimately even leading

to malfunction.

2.It is better not to place objects

which are too heavy, pointed or

are corrosive on the refrigerator.

3. Only replug the electric power

after an interval of over ten minutes.

4. Don't store bottled drink in the

freezer, so as to prevent them from

being broken .

5.Open the doors as less as possible

during power supply breakdown.

6.Don't touch food or containers in

the interior compartment with your

wet hands so as to prevent frost.

6. Maintenance

2.Cleansers such as soap powder,

abrasive cleaning powder, alkali

cleansers, chemical cloth, thinner,

alcohol, acid petroleum product

and hot water should not be used

to clean the refrigerator as they may

damage the painted cover and

plastics.

3.The drain pan should be clean ed

at least once a year.

5.As the door gasket is easy to be

dirtied and fogged, so clean it

frequently.

1.While cleaning the refrigerator,

pull out the electric power plug, rub

carefully with a piece of cloth

socked with natural clea nser then

wipe with clean water.

4.If the refrigerator is out of use for

a long time, please pull out the

plug, clean and dry the interior

compartment, then close the doors

tightly.

6.Water would leak into the interior

compartment if the drainage pipe

is blocked, in this case, dismantle

the lamp cover and wash the

drainage pipe.

7. Installing and Removing the Accessories

8. The following cases are not malfunction

1. To dismantle the slide shelf: fold

the shelf, then pull it straight upward

flatly. Installing it just in the opposite

way.

3. To dismantle the flexible pocket:

pull out the tray first then draw the

pedestal of the pocket outward.

Don't dismantle the tray and the

pedestal at the same time.

1. The sides of refrigerator heat up. While the condenser is working, but this will not

influence on storage performance.

2. It takes a span of time for the temperature of the freezer and refrigerator compartments

to become cold while the refrigerator is working: If the temperature of the two

compartments are higher while he refrigerator is working, it takes a span of time for the

temperature of the two compartments to decrease.

3.The surface of the compressor becomes hot: It is normal for the surface of the compressor

to get hot in good working condition. Don't touch it with your hands.

4.When you hear a sound like water flowing:

The sound like water flowing is actually the refrigerant(cooling gas) flowing. It does not indicate

a malfunction.

2.If you need to replace the lamp,

pls follow to below instruction,

.Screw out the setscrews under the

lampshade.

.Turn the lampshade up at 90

degrees at the bottom gently

.Replace the used lamp with new

one.

.Turn the lampshade down to the

original position and tighten the

setscrews.

4.The drain pan is installed onto the

compressor. When uninstall the

drain pan:

a. remove the back cover;

b. pull out the drain pan horizontally.

While dismantling, don't strike

the tube to avoid causing noises

at work.

8. The following cases are not malfunction

9. Trouble Shooting

5.When condensation forms on the outside of the refrigerator:

Condensation may form on the outside when the humidity is high e.g. during a wet season.

This is the same as when ice water is poured into a glass. It does not, therefore, indicate

a failure. Wipe the surface dry with a dry cloth.

If any case of malfunction happens, please inspect and dispel it according to the methods

shown in the following table:

If the above methods does not solve the problem, please contact the service centre

for assistance without any delay.

Situation

Water leaks from

refrigerator

compartment

Noises

Compressor does

not stop working

automatically

Foods frozen in

the freezing

compartment

Not cooling

sufficiently

Not refrigerating

Inspection

Check if there is a power failure.

Check if the power cord is plugged into the power outlet.

Check that the fuse (or circuit-breaker)has not blown.

The food may be packed too tight together which block

the flow of cool air.

You may have put in something hot or a lot of foodstuffs

into the refrigerator.

The temperature control dial may not have been set properly.

The door may not have been closed properly.

The door gasket may be damaged.

The refrigerator may not be well ventilated.

There may be insufficient space between the refrigerator

and the surfaces immediate to the sides and top.

Have the freezer temperature controls of the compartment

set to "colder" position?

Is the normal surrounding temperature bellow 5 ?

Have the foodstuff been put too crowdedly?

Is the drainage pipe blocked ?

Is there any leakage from some objects stored in it?

Is the refrigerator installed firmly?

Has the refrigerator been struck by some other objects?

Is the food stored too much at one time?

Are the doors opened too frequently or too long?

Are the temperature controls of freezer and refrigerator

compartments set to "colder"position?

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Premium Réfrigérateur

Premium

Premium PRF33600MS Manuel utilisateur

Premium

Premium PRN165DX Manuel utilisateur

Premium

Premium PRN995MW Manuel utilisateur

Premium

Premium PRN438HW/S Manuel utilisateur

Premium

Premium PRF31500MW Manuel utilisateur

Premium

Premium PRF185MW Manuel utilisateur

Premium

Premium PRN12150MW Manuel utilisateur

Premium

Premium PRF047XW Manuel utilisateur

Premium

Premium PRN436MS Manuel utilisateur

Premium

Premium HC-698WEN Manuel utilisateur

Premium

Premium PRN7005HW Manuel utilisateur

Premium

Premium PRN10050MW Manuel utilisateur

Premium

Premium PRN10050MW Manuel utilisateur

Premium

Premium PRF1650MW Manuel utilisateur

Premium

Premium PRN18055KW Manuel utilisateur

Premium

Premium PRN4560MS Manuel utilisateur

Premium

Premium PRN438HW Manuel utilisateur

Premium

Premium PRF200LW Manuel utilisateur

Premium

Premium PRF52 Manuel utilisateur

Premium

Premium PRN1005MW Manuel utilisateur

Premium

Premium PRN7005HW Manuel utilisateur

Premium

Premium PRN10050MW Manuel utilisateur

Premium

Premium PRF735HW Manuel utilisateur

Premium

Premium PRF2625MW Manuel utilisateur

Manuels Réfrigérateur populaires d'autres marques

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuel utilisateur

Sharp

Sharp SJ-BA31IEXW2-EU Manuel utilisateur

CORBERO

CORBERO CC2300MCW Manuel utilisateur

KitchenAid

KitchenAid 2205264 Manuel utilisateur

Stengel

Stengel KU 1101 A++ Manuel utilisateur

NEFF

NEFF KI181 Series Manuel utilisateur

Hoshizaki

Hoshizaki Reach-In Manuel utilisateur

Amana

Amana ASD2524VES00 Manuel utilisateur

BOMANN

BOMANN KGC 213 Manuel utilisateur

Danby

Danby DAR044A1SLDD Instructions de montage

Samsung

Samsung RF323TE Manuel utilisateur

Beko

Beko CSA31022 Manuel utilisateur

IKEA

IKEA FROSTIG C 185 E Manuel utilisateur

Electrolux

Electrolux ER 6821 D Manuel utilisateur

True

True TS-28 Manuel utilisateur

Frigidaire

Frigidaire FSC23R5DW9 Manuel utilisateur

Beko

Beko LSP4579W Manuel utilisateur
