POWERCLASS™

PC2100 / PC2200 / PC2300 OWNER’S MANUAL

CONGRATULATIONS

CONTENTS

(click on a topic to view)

FEATURES / SPECIFICATIONS

INSTALLATION

WIRING

WIRING (continued)

POWER / GROUND

SPEAKER WIRING

END PLATE DIAGRAM

INPUTS

QBASS / CROSSOVER

AMPLIFIER ADJUSTMENTS

TROUBLE SHOOTING

SYSTEM DIAGRAM ONE

SYSTEM DIAGRAMTWO

SYSTEM DIAGRAMTHREE

SYSTEM DIAGRAM FOUR

BLOCK DIAGRAM

WARRANTY

for choosing

PrecisionPower

audio epuipment. At

PrecisionPower

proudly design, engineer and manufacture audio products at our facility in

Phoenix, Arizona. Our award winning engineering team utilizes innovative

technology to consistently deliver Absolutely State of the ArtTM performance,

sound quality, reliability, and value. This

PrecisionPower

product reflects

our commitment to offer you unparalleled versatility and quality for years of

dependable service and listening enjoyment.

Service

Do not attempt to service

PrecisionPower

products yourself.

Performing exploratory surgery on your audio equipment yourself

will void the warranty. Many parts of your

PrecisionPower

gear

are custom built to our specifications. Our factory parts are not

made available to anyone else nor are they for sale. Our goal

is to make sure that your

PrecisionPower

product will always

sound as good as the day it was purchased. Contact your

authorized

PrecisionPower

dealer about obtaining any warranty

service through

PrecisionPower

.(See Warranty inside back cover)

FOR YOUR RECORDS:

Model

Serial Number

Purchase Date

Caution!

The extended use of a high powered audio system may

result in hearing loss or damage. While

PrecisionPower

systems are capable of

"Concert Level"

volumes with

incredible accuracy, they are also designed for you to

enjoy at more reasonable levels all of the sonic subtleties

created by musicians. Please observe all local sound

ordinances.

Congratulations and thank you.....

BACK TO CONTENTS

Adaptive MOSFET Switching Power Supply

Fully Complimentary Darlington Output Stage

AP III

Protection Circuitry

QBASS™

Bass Boost

Two Way 90 Hz Crossover with Line Outputs

Balanced Differential Input Stage

High Voltage Input Capability with Input Attenuation Switch

Gold Plated RCA Input and Output Connectors

PowerLock

Speaker and Power Wire Connectors

Mixed Mono/Stereo Operation

ThreeYear Warranty when installed by an Authorized

PrecisionPower

Dealer

Completely Designed And Handcrafted In The USA

Specifications

Power Bandwidth: 4.5 Hz - 100 kHz

Total Harmonic Distortion: 0.02 %

Input Topology: Balanced Differential

Input Sensitivity: 120mv - 12 volts RMS

Input Impedance: 10k Ohms

Load Impedance (stereo) 2 - 8 Ohms

Load Impedance (bridged) 4 - 8 Ohms

Supply Voltage 11 - 15 volts

Damping Factor >500

Slew Rate >50 V/µS

QBASS™Equalization Up To +12dB Boost @ 40 Hz

Idle Current: .7 Amps

Crossover Specifications

Crossover Point: 90 Hz

Choice of High Pass or Low Pass at RCA outputs while opposite

is available at the Speaker Outputs.

PC2100 - Third Order (18 dB/octave), Butterworth alignment fixed at 90 Hz.

PC2200/PC2300 - Fourth Order (24 dB/octave), Linkwitz-Riley alignment

fixed at 90 Hz.

Continuous Output Power

PC2100 25 WRMS x 2 @ 4Ωper channel

50 WRMS x 2 @ 2Ωper channel

100 WRMS x 1 @ 4Ωbridged

PC2200 50 WRMS x 2 @ 4Ωper channel

100 WRMS x 2 @ 2Ωper channel

200 WRMS x 1 @ 4Ωbridged

PC2300 75 WRMS x 2 @ 4Ωper channel

150 WRMS x 2 @ 2Ωper channel

300 WRMS x 1 @ 4Ωbridged

FEATURES / SPECIFICATIONS

Dimensions

Length -

PC2100 - 7.45"

PC2200 - 9.72"

PC2300 -11.72"

Height -

All - 2.25"

Width -

All - 8.9"

1BACK TO CONTENTS

Tools/Parts needed for Installation (not supplied)

Small flat blade screwdriver

Phillips Screwdriver (#2 or medium sized)

Wire cutters

Wire strippers

4 - #6 round head screws, and 1 - #8 sheet metal screw

(or nut, bolt, and star washer)

2 - Ring connectors (large enough to accommodate your

method of grounding)

In-line fuse or circuit breaker - see fuse chart below

Power and ground wire - see Power Wire Calculator on page 3

Speaker wire - 16 gauge or larger

Grommets (sized to work with the power wire you plan to use

in your installation)

Tube of silicone sealant

INSTALLATION

You will need to install an in-line fuse or circuit breaker in

the power wire within 18" of the battery.This fuse or circuit

breaker is to protect your vehicle from fire in case the power

wire shorts to the vehicle body. If you are only using one

amplifier, use the fuse rating indicated in this chart. If you are

using more than one amplifier, add up the fuse ratings for all the

amplifiers.This sum is the rating for your fuse or circuit breaker.

You may also want to add a power distribution block near your

amplifiers to keep the wiring tidy.

Fuse requirements

Amplifier Maximum Fuse Rating

PC2100

20 Amp

PC2200

30 Amp

PC2300

35 Amp

BACK TO CONTENTS

Thefollowingisa basic formulatobeusedasa guide todetermineamperage

draw. A 50% amplifier efficiency rating is used as an average.Your new

POWERCLASS

™amplifier is more efficient, other amplifiers will probably

be less. This formula is to be used as a guideline. Using wire of a larger

gauge can only improve the current transfer of your system. Do not use

smaller gauge wire.

Total RMS output x 2 = Total Input Wattage

Total Input Wattage = Current Draw (in Amps)

Supply Voltage

Example:A

POWERCLASS

™2200 amplifier has two channels at 50 watts

per channel RMS rating into 4 Ohms (50 + 50 = 100).You would use the

formula in the following way:

100W x 2 = 200W

200W = 16.7A Total amperage draw.

12V

If the same amplifier is driven into a 2 Ohm stereo or 4 Ohm mono load,

double its4Ohm RMSrating.All

POWERCLASS

™amplifierswill effectively

double their power at this load.

100W x 2 x 2 = 400W

400W = 33.3A Total amperage draw.

12V

If you are using more than one amplifier, add up the total amperage draw

for all of them and choose the appropriate gauge based on the grand total.

Power Wire Calculator

Recommended MINIMUM Gauge

Total Current Draw Length Of Wire To Be Run

( in Amps) Upto4ft. 4 to 7ft. 7 to 10ft. 10 to 13ft. 13 to 16ft. 16 to 19ft. 19 to 22ft. 22 to 28ft.

0-20 14 12 12 10 10 8 8 8

20-35 12 10 8 8 6 6 6 4

35-50 10 8 8 6 6 4 4 4

50-65 8 8 6 4 4 4 4 2

65-85 6 6 4 4 2 2 2 0

85-105 6 6 4 2 2 2 2 0

105-125 4 4 4 2 2 0 0 0

125-150 2 2 2 2 0 0 0 00

(

NOTE: The ground wire should be the same gauge as the power wire.

WIRING

BACK TO CONTENTS

Before beginning, disconnect the negative (-) terminal of the

battery prior to working on the positive (+) terminal to prevent

a short to ground.This is important, unless you want to spend

the rest of your life with a nickname like

"Sparky,"

"Smokey."

Reconnect the negative terminal only after all connections have

been made.

Warning!

Fuse must be installed within 18" of battery

eject

VOLUME

BASS TREBLE

RIGHT

LEFT

BALANCE TRACK

REVERSE

FOWARD

1234

876

PPI MAR KET ING DPT

Trk 1

Fuse must be

installed within

18" of battery

Drill a hole in the firewall

and use a rubber grommet

to keep wire from shorting.

Run the cables under the

carpet near the side of the

vehicle. Be careful not to

drill or screw into the wires

when you replace the trim.

Run signal cables (RCAs)

and remote turn-on lead

down the opposite side of

the vehicle from the power

wire to avoid radiated noise.

Firmly attach Amp

Ground Wire to solid

metal (see page 5).

Avoid sharp edges that

could chafe through the

insulation.

Positive

Battery

Terminal

Factory Ground wire may

need to be replaced if it is

frayed or broken.

WIRING

BACK TO CONTENTS

POWER

Designed and Handcrafted in the U.S.A.

Locate an area near the amplifier(s) that is metal and clean an

area about the size of a quarter to bare metal. Inspect the

areaaroundandunderneathtobesureyouwon'tdrillintowires,

brake or fuel lines, etc.Drill a pilot hole into the middle of this

area.Terminatethegroundwirewitha ringconnectorandattach

it to the bare metal using a #8 sheet metal screw and washer

or preferably, a bolt, nut and a star washer (not supplied).We

suggest crimping and soldering this connection. After the

connection is complete, coat the area (on both sides) with

silicone or some similar material to prevent rust from

developing on the bare metal.

POWER / GROUND

Power/Ground

PowerLock

Once you have run both the power and ground wires, it's time

to connect the cables to the amplifier.Cut off excess wire and,

using wire strippers, strip the ends of the power and ground

cables approximately 1/4 inch. Locate the

PowerLock

power

andgroundconnector(supplied).With asmallflat bladedscrew

driver,loosenthescrewsbefore attemptingtoinsert thecables.

Insert the wires into the appropriate hole, and tighten the

screws.Once the wires are secure, the

PowerLock

may be

plugged into the amplifier.

Fastening screws

Connect to Amplifier

Power wires

BACK TO CONTENTS

Using 16 gauge or larger, run the speaker wires from the

amplifierlocationthroughthevehicletothespeakers.Observe

the same precautions for routing these wires that you followed

for running the power and remote turn-on wires.Cut off excess

and, using wire strippers, strip 1/4 inch of insulation. Locate

the speaker/remote turn-on

PowerLock

connector. Loosen

the four outer screws on the underside of the connector.Insert

the speaker leads into the end.Check to be sure you've

maintained proper polarity before securing each wire.

SPEAKER WIRING

Speaker/Remote

PowerLock

Right Speaker negative

Right Speaker positive

Remote turn on

Left Speaker positive

Left Speaker negative

Speaker

Power

Lock

Connector

BACK TO CONTENTS

OUTPUTS

QBASS

GAIN

INPUT -12dB

HP/LP

XOVER

ON/OFF

0 12

INPUTS

L R L- L+ REM R+ R-

ENDPLATE DIAGRAM

QBASS™Control

Rotate clockwise

to boost 40Hz up

to 12dB.

XOVER ON/OFF Button

Push this button in to turn

on the 90Hz crossover to

the speaker outputs (see

page 9).

Speaker/Remote Connector

After connecting remote and

speaker wires, plug in the

PowerLock

connector here.

INPUTS

Plug in the

RCA leads

from your

head unit

here (see

page 8).

GAIN Control

Use this control to

match the output

level of the head

unit to the input of

the amplifier

(see page 10).

HP/LP Switch

This switch

is used to

select whether

the amplifier

will provide a

highpass(in)or

lowpass (out)

signal to the

speakers.

(see page 9).

INPUTAttenuation

For use with high

level inputs

(4V up to 12V).

RCA OUTPUTS

Left and Right RCA

outputs provide either

high or low pass signal to

another amplifier. This

signal will be low pass if

you've selected high pass

for the speaker outputs,

and vice versa.

BACK TO CONTENTS

There are two sets of RCA jacks on the front end of your

amplifier.The RCA cables from your head unit go in the set

labeled INPUTS. If your head unit doesn't have RCA outputs

don't worry. Simply add a set of RCA plugs (available at your

dealer) to your front or rear set of speaker leads (see drawing

below), plug them into the input jacks, and push in the INPUT

ATTENUATION button.

Balanced Differential Inputs

This circuitry is capable of eliminating noise radiated into your

signal cables by up to 40dB.This is equivalent to a noise

reduction of approximately one hundred times what the noise

level would be without this circuitry.It provides all the benefits

of a true 'balanced' line without the need of any special cables

(see diagram below).This type of input works with any

conventional RCA cable.

(+) Positive

(-) Negative

LEFT input

(+) Positive

(-) Negative

RIGHT inpu

eject

VOLUME

BASS TREBLE

RIGHT

LEFT

BALANCE TRACK

REVERSE

FOWARD

1234

876

PPI MAR KET ING DPT

Trk 1

SOURCE Headunit

music noise

( - = 0 )

noise cancels music

NO noise

(+)

noise

( )

music noise

( + =)

music noise music

and noise

signal and ground

(+)

( )

INPUTS

WARNING:

If you are using a source unit with bridged high powered (or

"floating ground") speaker outputs, a suitable high to low level adapter must be

used. If you are unsure about your head unit see your local PrecisionPower

dealer or call 1-800-62Power

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Precision Power Amplificateur de voiture

Precision Power

Precision Power Sedona 100iQX Manuel utilisateur

Precision Power

Precision Power ProMOS-12 Manuel utilisateur

Precision Power

Precision Power A204 Manuel utilisateur

Precision Power

Precision Power Ax606.2 Manuel utilisateur

Precision Power

Precision Power Sedona 100iX Manuel utilisateur

Precision Power

Precision Power PC21400 Manuel utilisateur

Precision Power

Precision Power PCX 2400 Manuel utilisateur

Precision Power

Precision Power A100 Manuel utilisateur

Precision Power

Precision Power PPI4240 Manuel utilisateur

Precision Power

Precision Power A100.2 Manuel utilisateur

Precision Power

Precision Power DCX 1000.1 Manuel utilisateur

Precision Power

Precision Power DCX 1000.1 Manuel utilisateur

Precision Power

Precision Power Sedona S1300.1D Manuel de programmation

Precision Power

Precision Power 5075DX Manuel utilisateur

Precision Power

Precision Power TD 1250 Manuel utilisateur

Precision Power

Precision Power MA1250 Manuel utilisateur

Precision Power

Precision Power ProMOS-425 Manuel utilisateur

Precision Power

Precision Power 2025AM Manuel utilisateur

Precision Power

Precision Power DCX 600.4 Manuel utilisateur

Precision Power

Precision Power 4100AM Manuel utilisateur

Precision Power

Precision Power Sedona S200.1 Manuel de programmation

Precision Power

Precision Power MA2150 Manuel utilisateur

Precision Power

Precision Power PPI 2200M Manuel utilisateur

Precision Power

Precision Power PDX-10K Manuel utilisateur

Manuels Amplificateur de voiture populaires d'autres marques

Cyfre

Cyfre CHACDMA-819 Manuel utilisateur

MTX

MTX Thunder Marine TM904 Manuel utilisateur

MTX

MTX Thunder TA Super TA92001 Mode d’emploi

Lanier

Lanier 480-0239 Instructions d'utilisation et d'entretien

Kenwood

Kenwood KAC-642 Manuel utilisateur

Pioneer

Pioneer GM-D8500M Manuel utilisateur

Jensen

Jensen XA4150 Manuel utilisateur

Sony

Sony XM-405EQX Marketing Specifications Manuel utilisateur

Audiopipe

Audiopipe AQX-660.2 Manuel utilisateur

Clarion

Clarion APA2001 APA2001 APA2001 Guide de démarrage rapide

Sony

Sony XM-7547 Manuel utilisateur

Alpine

Alpine PDX11000 - Amplifier Manuel utilisateur

Steg

Steg Qx Mos 105.4x Manuel utilisateur

JL Audio

JL Audio HD900/5 Manuel utilisateur

Memphis

Memphis 16-MC5.700 Manuel utilisateur

Audiopipe

Audiopipe APSM-1150 Manuel utilisateur

Boss Audio Systems

Boss Audio Systems Riot GT1000M Manuel utilisateur

Kenwood

Kenwood KAC-PS811D Manuel utilisateur
