PRECISION DIGITAL PD2-6262 Manuel utilisateur

Helios Large Display Dual Analog Input Rate/Totalizer

Instruction Manual

Precision Digital Corporation

233 South Street • HopkintonMA 01748 USA

Tel (800) 343-1001 • Fax (508) 655-8990

www.predig.com

Flow Rate/Totalizer

Large 1.80" Digits

Dual-Line 6-Digit Display

Readable from up to 100 Feet (30 Meters) Away

Superluminous Sunlight Readable Display

IP65 Rated Field Mountable Enclosure

Operating Temperature Range of -40 to 65°C (-40 to 150°F)

Dual Analog Inputs with Math Functions

Rate, Total, and Grand Total for Each Input Channel

Addition, Difference, Average, Multiplication, Division, Min, Max,

Weighted Average, Ratio, Concentration, & More

0-20 mA, 4-20 mA, 0-5 V, 1-5 V, and ±10 V Inputs

Universal 85-265 VAC, or 12-24 VDC Input Power Models

Isolated 24 VDC Transmitter Power Supply

32-Point, Square Root, or Exponential Linearization

2 or 4 Relays + Isolated 4-20 mA Output Options

Onboard USB & RS-485 Serial Communication Options

Modbus®RTU Communication Protocol Standard

Program the Meter from a PC with onboard USB and MeterView Pro

USB Install

Helios Large Display Dual Analog Input Rate/Totalizer Instruction Manual PD2-6262

Disclaimer

The information contained in this document is subject to change without notice. Precision

Digital makes no representations or warranties with respect to the contents hereof and

specifically disclaims any implied warranties of merchantability or fitness for a particular

purpose.

Caution: Read complete

instructions prior to installation and

operation of the meter.

Warning: Risk of electric shock or

personal injury.

Warning!

This product is not recommended for life support

applications or applications where malfunctioning

could result in personal injury or property loss. Anyone

using this product for such applications does so at their

own risk. Precision Digital Corporation shall not be held

liable for damages resulting from such improper use.

Limited Warranty

Precision Digital Corporation warrants this product against defects in material or

workmanship for the specified period under “Specifications” from the date of shipment from

the factory. Precision Digital’s liability under this limited warranty shall not exceed the

purchase value, repair, or replacement of the defective unit.

Registered Trademarks

MeterView®Pro is a registered trademark of Precision Digital Corporation. All other

trademarks mentioned in this document are the property of their respective owners.

www.predig.com

PD2-6262 Helios Large Display Analog Dual-Input Rate/Totalizer Instruction Manual

3


Table of Contents
Table of Contents....................................................3
Table of Figures......................................................4
Introduction .............................................................4
Ordering Information...............................................5
Specifications..........................................................5
General .......................................................................5
Dual Process Input......................................................6
Dual Rate/Totalizer .....................................................7
Relays.........................................................................7
Isolated 4-20 mA Transmitter Output ..........................8
RS485 Serial Communications Terminal ....................8
Modbus®RTU Serial Communications .......................8
Digital Input & Output Terminal...................................8
Safety Information...................................................9
Installation...............................................................9
Unpacking...................................................................9
Wall Mounting Instructions........................................10
Mounting Dimensions............................................10
Pipe Mounting Instructions........................................11
Transmitter Supply Voltage Selection (P+, P-)..........12
Connections..............................................................12
Connectors Labeling .............................................13
Power Connections...............................................13
Signal Connections ...............................................14
Modbus RTU Serial Communications ...................15
Relay Connections................................................15
Switching Inductive Loads.....................................15
RS485 Output Connections...................................16
Digital I/O Connections .........................................18
F4 Digital Input Connections.................................18
4-20 mA Output Connections................................19
Analog Output Transmitter Power Supply.............19
Interlock Relay Feature.........................................19
External Analog Output Connection......................19
Setup and Programming.......................................20
Overview...................................................................20
Programming Buttons and Status LED Indicators.....21
MeterView®Pro Software..........................................22
MeterView Pro Installation.....................................22
Display Functions & Messages.................................23
Main Menu ................................................................27
Setting Numeric Values.............................................27
Setting up the Meter (setup).....................................28
Setting the Input Signal (Input)............................29
Setting the Totalizer Features (total)..................29
Setting the Rate, Total, & Grand Total Units/Tags
(units)..................................................................30
Setting the Decimal Point (dEc pt).......................30
Programming the Rate/Totalizer (prog)................31
Setting the Display Parameter & Intensity (dsplay)
..............................................................................35
Setting the Relay Operation (relay).........................36
Setting the Relay Assignment (asSign)................37
Setting the Relay Action........................................37
Programming Set and Reset Points......................37
Setting Fail-Safe Operation...................................38
Programming Time Delay......................................38
Relay Action for Loss of 4-20 mA Input (Loop Break)
 ..............................................................................38
Relay and Alarm Operation Diagrams.......................38
High Alarm Operation (Set > Reset)......................38
Low Alarm Operation (Set < Reset).......................38
High Alarm with Fail-Safe Operation (Set > Reset)39
Low Alarm with Fail-Safe Operation (Set < Reset)39
Pump Alternation Control Operation......................39
Relay Sampling Operation.....................................40
Signal Loss or Loop Break Relay Operation..........40
Time Delay Operation............................................40
Relay Operation Details.............................................41
Overview ...............................................................41
Relays Auto Initialization .......................................41
Fail-Safe Operation ...............................................41
Front Panel LEDs..................................................41
Latching and Non-Latching Relay Operation.........42
Non-Latching Relay (Auto)....................................42
Non-Latching Relay (A-man)...............................42
Latching Relay (LatcH)..........................................42
Latching Relay (Lt-Clr)........................................42
Acknowledging Relays ..........................................43
Pump Alternation Control Applications (Altern)...43
Setting up the Interlock Relay (Force On) Feature 45
Scaling the 4-20 mA Analog Output (Aout)...............46
Reset Menu (reset)..................................................46
Control Menu (Contrl)..............................................46
Setting up the Password (pass) ................................47
Protecting or Locking the Meter.............................47
Total Reset Password & Non-Resettable Total .....47
Making Changes to a Password Protected Meter..48
Disabling Password Protection..............................48
Advanced Features Menu .........................................49
Advanced Features Menu & Display Messages....49
Noise Filter (filter).............................................51
Noise Filter Bypass (bypass) ................................51
Rounding Feature (round).....................................52
Modbus RTU Serial Communications (serial) ....52
Select Menu (SElect) ...........................................53
Signal Input Conditioning (Functn)........................53
Math Function (math) .........................................54
Math Constants (Const)........................................55
Low-Flow Cutoff (CutofF) .....................................55
Totalizer Count Up/Down (Count) .........................55
Analog Output Programming (AoutPr)..................55
Programmable Function Keys User Menu (user)..56
Internal Source Calibration (ICAL).........................58
Meter Operation....................................................59
Button Operation .......................................................59
Function Key Operation.............................................59
Digital Input Operation...............................................59
Maximum/Minimum Readings ...................................60
Troubleshooting....................................................60
Diagnostics Menu (diag)...........................................60
Determining Software Version...............................60
Reset Meter to Factory Defaults................................61
Factory Defaults & User Settings...........................61
Troubleshooting Tips.................................................63


Helios Large Display Dual Analog Input Rate/Totalizer Instruction Manual PD2-6262

4


Table of Figures
Figure 1. Meter Mounting Holes............................10
Figure 2. Meter Dimensions - Side View...............10
Figure 3. Meter Dimensions –Front View.............10
Figure 4. Vertical Pipe Mount Assembly...............11
Figure 5. Horizontal Pipe Mount Assembly...........11
Figure 6. Transmitter Supply Voltage Selection....12
Figure 7. Connector Labeling for Fully Loaded PD2-
6262 ......................................................................13
Figure 8. Power Connections................................13
Figure 9. Transmitters Powered by Internal Supply
 ..............................................................................14
Figure 10. Transmitter Powered by Ext. Supply or
Self-Powered.........................................................14
Figure 11. Voltage Input Connections...................14
Figure 12. Relay Connections..............................15
Figure 13. AC and DC Loads Protection..............15
Figure 14. Low Voltage DC Loads Protection ......15
Figure 15. RS-422 or RS-485 Wiring....................16
Figure 16. RS-485 Two-Wire Multi-Drop Wiring...17
Figure 17. Connections for RS485 Connector to
Serial Converter....................................................17
Figure 18. Three-Wire RS485 Connection...........17
Figure 19. Digital Input and Output Connections .18
Figure 20. F4 Digital Input Connections...............18
Figure 21. 4-20 mA Output Connections..............19
Figure 22. Interlock Connections..........................19
Figure 23. Acknowledge Relays w/Function Key or
Digital Input...........................................................43

Introduction
The Helios PD2-6262 is a multi-purpose, easy to use, large-display dual-input rate/totalizer ideal
for flow rate, total, and flow control applications. It features large 1.8 inch superluminous
sunlight-readable LED digits, which can be read from up to 100 feet away. It is housed in a
water-resistant, field mountable IP65 rated enclosure for convenient indoor and outdoor
installation.
The meter accepts current and voltage signals (e.g. 4-20 mA, 0-10 V) from an analog output
flowmeter. The rates, as measured by the flowmeters, are automatically aggregated into
cumulative totals and grand totals which can be displayed with the rates.
Various math functions may be applied to the rate, total, and grand total of the two channels,
including addition, difference, absolute difference, average, weighted average, multiplication,
division, minimum, maximum, draw, ratio, and concentration. This is in addition to the signal
input conditioning functions (linear, square root, programmable exponent, or round horizontal
tank calculations).
The displays, relays, and the analog output may be assigned to the rate, total, or grand total of
input channels A or B, or math result channel C. Three of the programming buttons can be set
for custom operation.
A fully loaded Helios PD2-6262 dual-input rate/totalizer comes with four (4) SPDT relays, a 4-20
mA output, two 24 VDC power supplies, five (5) digital inputs and four (4) digital outputs, and
RS485 serial communications. The four relays can be used for alarm indication or process
control applications. The 4-20 mA isolated output, Modbus RTU serial communications, and
digital I/O features make the Helios an excellent addition to any system.


PD2-6262 Helios Large Display Analog Dual-Input Rate/Totalizer Instruction Manual

Ordering Information

Standard Models

85-265 VAC Model

12-24 VDC Model

Options Installed

PD2-6262-6H0

PD2-6262-7H0

No Options

PD2-6262-6H7

PD2-6262-7H7

4 relays & 4-20 mA output

Accessories

Model

Description

PDA1011

Dual 4-20 mA expansion module

PDA6260

Pipe Mounting Kit

PDA7485-I

RS-232 to RS-422/485 isolated converter

PDA7485-N

RS-232 to RS-422/485 non-isolated converter

PDA8485-I

USB to RS-422/485 isolated converter

PDA8485-N

USB to RS-422/485 non-isolated converter

PDAPLUG2

Plastic Conduit Plug

PDX6901

Suppressor (snubber): 0.01 µF/470 , 250 VAC

Specifications

Except where noted all specifications apply to operation at +25°C.

General

Display

Main display: 1.8" (46 mm) high, red

LEDs

6 digits per line (-99999 to 999999), with

lead zero blanking

Display

Intensity

Eight user selectable intensity levels

Display

Update Rate

5/second (200 ms)

Display

Assignment

The Upper and Lower displays may be

assigned to show:

One or more rate channels: Channel A

(Ch-A), B (Ch-B), or C (Ch-C)

Toggle between rate channels: Ch-A &

Ch-B, Ch-A & Ch-C, Ch-B & Ch-C, and

Ch-A, Ch-B, & Ch-C

Total or grand total: Ch-A or Ch-B

Rate and total or grand total: Ch-A,

Ch-B

Relay set points

Max and/or min values: Ch-A, Ch-B, or

Ch-C

Toggle between any rate channel &

units

Total and units: Ch-A or Ch-B

Toggle between totals: Ch-A & Ch-B;

Ch-A, Ch-B, and sum of Ch-A and Ch-

Modbus input

The lower display may also be set to

show engineering units or be off, with no

display.

Overrange

Display flashes 999999

Underrange

Display flashes -99999

Programming

Methods

Four programming buttons, digital inputs,

PC and MeterView Pro software, or

Modbus registers.

Noise Filter

Programmable from 2 to 199 (0 will

disable filter)

Filter Bypass

Programmable from 0.1 to 99.9% of

calibrated span

Recalibration

All ranges are calibrated at the factory.

Recalibration is recommended at least

every 12 months.

Max/Min

Display

Max/min readings reached by the process

are stored until reset by the user or until

power to the meter is turned off.

Password

Three programmable passwords restrict

modification of programmed settings.

Pass 1: Allows use of function keys and

digital inputs

Pass 2: Allows use of function keys,

digital inputs and editing set/reset points

Pass 3: Restricts all programming,

function keys, and digital inputs

Total: Prevents resetting the total

manually

Gtotal: Prevents resetting the grand total

manually.

Power

Options

85-265 VAC 50/60 Hz, 90-265 VDC, 20

W max or 12-24 VDC 10%, 15 W max

Powered over USB for configuration only.

Helios Large Display Dual Analog Input Rate/Totalizer Instruction Manual PD2-6262

Isolated

Transmitter

Power

Supply

Terminals P+ & P-: 24 VDC 10%. 12-24

VDC powered models selectable for 24, 10,

or 5 VDC supply (internal P+/P- switch).

85-265 VAC models rated @ 200 mA max,

12-24 VDC powered models rated @ 100

mA max, @ 50 mA max for 5 or 10 VDC

supply.

Non-Volatile

Memory

All programmed settings are stored in

non-volatile memory for a minimum of ten

years if power is lost.

Fuse

Required external fuse: UL Recognized, 5

A max, slow blow; up to 6 meters may

share one 5 A fuse

Normal Mode

Rejection

Greater than 60 dB at 50/60 Hz

Isolation

4 kV input/output-to-power line; 500 V

input-to-output or output-to-P+ supply

Overvoltage

Category

Installation Overvoltage Category II: Local

level with smaller transient overvoltages

than Installation Overvoltage Category III.

Environmenta

Operating temperature range: -40 to

150°F (-40 to 65°C)

Storage temperature range: -40 to

185°F (-40 to 85°C)

Relative humidity: 0 to 90% non-

condensing

Connections

Removable and integrated screw terminal

blocks accept 12 to 22 AWG wire.

Enclosure

Polycarbonate & glass blended plastic

case, color: gray

Mounting

Wall Mounting: Four (4) mounting holes

provided for screwing meter into wall. See

Wall Mounting Instructions on page 10 for

additional details.

Pipe Mounting: Optional pipe mounting

kit (PDA6260) allows for pipe mounting.

Sold separately. See Pipe Mounting

Instructions on page 11 for additional

details.

Tightening

Torque

Removable Screw Terminals: 5 lb-in

(0.56 Nm)

Digital I/O and RS485 Terminals: 2.2 lb-

in (0.25 Nm)

Overall

Dimensions

10.63" x 12.59" x 4.77" (270 mm x 319.7

mm x 121.2 mm) (W x H x D)

Weight

6.10 lbs (2.76 kg)

Warranty

3 years parts & labor

Dual Process Input

Two Inputs

Two non-isolated inputs, each

separately field selectable:

0-20, 4-20 mA, 10 V (0-5, 1-5, 0-10

V), Modbus PV (Slave)

Channels

Channel A, Channel B, Channel C

(Math channel)

Math

Functi

ons

Name Function Setting

Addition (A+B+P)*F Sunm

Difference (A-B+P)*F diF

Absolute diff. ((Abs(A-B))+P)*F diFAbS

Average (((A+B)/2)+P)*F AvG

Multiplication ((A*B)+P)*F nmulti

Division ((A/B)+P)*F divide

Max of A or B ((AB-Hi)+P)*F Hi-Ab

Min of A or B ((AB-Lo)+P)*F Lo-Ab

Draw ((A/B)-1)*F drAuw

Weighted avg. ((B-A)*F)+A uw avg

Ratio (A/B)*F ratio

Concentration (A/(A+B))*F Concen

Total Addition (tA+tB+P)*F Sunm t

G. Tot. Addition (GtA+GtB+P)*F SunmGT

Total Difference (tA-tB+P)*F Dif t

G. Tot. Difference (GtA-GtB+P)*F Dif GT

Total Ratio (tA/tB)*F Tratio

Total Percent (tA/(tA+tB))*100 T PCT

Note: The F constant can be any value from

0.001 to 999.999. If the value is less than 1, it

will have the same effect as a divider. For

example, the average could also be derived

by using (A+B)*F, where F = 0.500.

Sequence of

Operations

for Input

Programmin

1. Select Input for A and B

2. Set up the rate, total, and grand

total engineering units for

channels A & B, and units for

math channel C

3. Set up rate, total, and grand total

decimal points for channels A &

B, and decimal point for math

channel C

4. Program channel A & B rate

parameters

5. Program channel A & B total and

reset parameters

6. Set up the display line 1 and line

7. Select the transfer function for A

& B (e.g. Linear)

8. Select Math function for Channel

9. Program constants for Factor (F)

and Adder (P).

10. Program cutoff values for A and B

Programmabl

e Constants

Constant P (Adder): -99.999 to

999.999, default: 0.000

Constant F (Factor): 0.001 to

999.999, default: 1.000

Accuracy

±0.03% of calibrated span ±1 count,

square root & programmable

exponent accuracy, range: 10-100%

of calibrated span

Temperature

Drift

0.005% of calibrated span/C max

from 0 to 65C ambient,

0.01% of calibrated span/C max from

-40 to 0C ambient

PD2-6262 Helios Large Display Analog Dual-Input Rate/Totalizer Instruction Manual

Signal Input

Conditioning

Linear, square root, or programmable

exponent

Multi-Point

Linearization

2 to 32 points for channel A and B

Programmabl

e Exponent

1.0001 to 2.9999

Low-Flow

Cutoff

0-999999 (0 disables cutoff function)

Decimal

Point

Up to five decimal places or none:

d.ddddd, d.dddd, d.ddd, d.dd, d.d, or

dddddd

Calibration

Range

Input Range

Minimum Span Input 1

& Input 2

4-20 mA

0.15 mA

10 V

0.01 V

An error message will appear if the

input 1 and input 2 signals are too

close together.

Input

Impedance

Voltage ranges: greater than 500 k

Current ranges: 50 - 100 

(depending on resettable fuse

impedance)

Input

Overload

Current input protected by resettable

fuse, 30 VDC max.

Fuse resets automatically after fault is

removed.

F4 Digital

Input

Contacts

3.3 VDC on contact. Connect normally

open contacts across F4 to COM.

F4 Digital

Input

Logic Levels

Logic High: 3 to 5 VDC

Logic Low: 0 to 1.25 VDC

Dual Rate/Totalizer

Rate Display

Indication

-99999 to 999999, lead zero blanking.

Total Display

& Total

Overflow

0 to 999,999; automatic lead zero

blanking. Up to 999,999,999 with total-

overflow feature. “oF” is displayed to

the left of total overflow and ▲ LED is

illuminated.

Total Decimal

Points

Up to five decimal places or none:

d.ddddd, d.dddd, d.ddd, d.dd, d.d, or

dddddd

Total decimal point is independent of

rate decimal point. Channel A and B

decimal points programmed

independently.

Dual Totalizer

Calculates total for channels A and B

based on rate and field programmable

multiplier to display total in

engineering units. Time base must be

selected according to the time units in

which the rate is displayed. Channel A

and B totalizer parameters

programmed independently.

Totalizer

Rollover

Totalizer rolls over when display

exceeds 999,999,999. Relay status

reflects display.

Total

Overflow

Override

Program total A or B total reset for

automatic with 0.1 second delay and

set point 1 for 999,999

Totalizer

Alarm

Presets

Up to eight, user selectable under

setup menu. Any set point can be

assigned to channel A or B total or

grand total (or C) and may be

programmed anywhere in the range of

the meter for total alarm indication.

Total &

Grand Total

Reset

Via front panel button, external

contact closure on digital inputs,

automatically via user selectable

preset value and time delay, or

through serial communications.

Channel A and B total and grand total

reset parameters programmed

independently.

Total Reset

Password

Total and grand total passwords may

be entered to prevent resetting the

totals or grand totals from the front

panel.

Non-

Resettable

Total

The grand totals can be programmed

as non-resettable totals by entering

the password “050873”. Both

channels are set to non-resettable

when this password is entered.

Caution!

Once the Grand Totals have

been programmed as “non-

resettable” the feature

cannot be disabled.

Programmabl

e Delay

On Release

0.1 and 999.9 seconds; applied to the

first relay assigned to total or grand

total.

If the meter is programmed to reset

total to zero automatically when the

preset is reached, then a delay will

occur before the total is reset.

Relays

Rating

2 or 4 SPDT (Form C) internal and/or

4 SPST (Form A) external; rated 3 A

@ 30 VDC and 125/250 VAC resistive

load; 1/14 HP (≈50 W) @ 125/250

VAC for inductive loads

Noise

Suppression

Noise suppression is recommended

for each relay contact switching

inductive loads; see page 15 for

details.

Deadband

0-100% of span, user programmable

High or Low

Alarm

User may program any alarm for high

or low trip point.

Unused alarm LEDs and relays may

be disabled (turn off).

Helios Large Display Dual Analog Input Rate/Totalizer Instruction Manual PD2-6262

Relay

Operation

Automatic (non-latching) and/or

manual reset

Latching (requires manual

acknowledge) with/without clear

Pump alternation control (2 to 4

relays)

Sampling (based on time)

Off (disable unused relays and enable

Interlock feature)

Manual on/off control mode

Relay Reset

User selectable via front panel buttons

or digital inputs

1. Automatic reset only (non-

latching), when the input passes

the reset point.

2. Automatic + manual reset at any

time (non-latching)

3. Manual reset only, at any time

(latching)

4. Manual reset only after alarm

condition has cleared (latching)

Note: Front panel button or digital

input may be assigned to

acknowledge relays

programmed for manual reset.

Time Delay

0 to 999.9 seconds, on & off relay time

delays

Programmable and independent for

each relay

Fail-Safe

Operation

Programmable and independent for

each relay.

Note: Relay coil is energized in non-

alarm condition. In case of

power failure, relay will go to

alarm state.

Auto

Initialization

When power is applied to the meter,

relays will reflect the state of the input

to the meter.

Isolated 4-20 mA Transmitter Output

Output

Source

Input channels A or B, rate, total, or

grand total; channel C; max or min for

channel A or B; highest or lowest max

or min of A and B; set points 1-8;

Modbus input; or manual control mode

Scaling

Range

1.000 to 23.000 mA for any display

range

Calibration

Factory calibrated: 4.000 to 20.000 =

4-20 mA output

Analog

Output

Programming

23.000 mA maximum for all

parameters:

Overrange, underrange, max, min,

and break

Accuracy

± 0.1% of span ± 0.004 mA

Temperature

Drift

0.4 µA/C max from 0 to 65C

ambient,

0.8 µA/C max from -40 to 0C

ambient

Note: Analog output drift is separate

from input drift.

Isolated

Transmitter

Power

Supply

Terminals I+ & R: 24 VDC 10%. May

be used to power the 4-20 mA output

or other devices. Refer to Figure 21

on page 19.

All models rated @ 40 mA max.

External

Loop Power

Supply

35 VDC maximum

Output Loop

Resistance

Power supply

Minimu

Maximum

24 VDC

10 

700 

35 VDC

(external)

100 

1200 

RS485 Serial Communications Terminal

Compatibility

EIA-485

Connectors

Removable screw terminal connector

Max Distance

3,937' (1,200 m) max

Status

Indication

Separate LEDs for Power (P),

Transmit (TX), and Receive (RX)

Modbus®RTU Serial Communications

Slave Id

1 –247 (Meter address)

Baud Rate

300 –19,200 bps

Transmit

Time Delay

Programmable between 0 and 199 ms

Data

8 bit (1 start bit, 1 or 2 stop bits)

Parity

Even, Odd, or None with 1 or 2 stop

bits

Byte-To-Byte

Timeout

0.01 –2.54 second

Turn Around

Delay

Less than 2 ms (fixed)

Note: Refer to the Modbus Register Tables located at

www.predig.com for details.

Digital Input & Output Terminal

Channels

4 digital inputs & 4 digital outputs

Digital Input

Logic High

3 to 5 VDC

Digital Input

Logic Low

0 to 1.25 VDC

Digital

Output Logic

High

3.1 to 3.3 VDC

Digital

Output Logic

Low

0 to 0.4 VDC

Source

Current

10 mA maximum output current

Sink Current

1.5 mA minimum input current

+5 V

Terminal

To be used as pull-up for digital inputs

only.

Connect normally open pushbuttons

across +5 V & DI 1-4.

WARNING!

DO NOT use

+5 V terminal

to power

external

devices.

PD2-6262 Helios Large Display Analog Dual-Input Rate/Totalizer Instruction Manual

Safety Information

Caution: Read complete instructions

prior to installation and operation of the

meter.

Warning: Risk of electric shock or

personal injury.

Warning!

Hazardous voltages exist within enclosure.

Installation and service should be performed only by trained

service personnel.

Installation

There is no need to open the clear plastic front cover in order to complete the installation, wiring,

and setup of the meter. All programming is done through the buttons and switches located under

the lower door panel and are accessible by removing the single securing screw. Wires should be

run through the knockout holes located on the bottom of the meter.

There are a total of four pre-drilled conduit entry holes located at the bottom of the meter. If the

need to drill additional holes arises, make sure you will have the clearance necessary for conduit

mounting hardware.

Do not disconnect the RJ45 connector found on the right side of the meter wiring board. Doing so

will disable the onboard digital I/O, RS-485 serial communications, and M-Link functionality.

Instructions are provided for changing the transmitter power supply to output 5 or 10 VDC instead

of 24 VDC, see page 11.

Unpacking

Remove the meter from box. Inspect the packaging and contents for damage. Report damages, if

any, to the carrier. If any part is missing or the meter malfunctions, please contact your supplier or

the factory for assistance.

Helios Large Display Dual Analog Input Rate/Totalizer Instruction Manual PD2-6262

Wall Mounting Instructions

The meter can be mounted to any wall using the four provided mounting holes. Note that the bottom

mounting holes are located underneath the front door panel. To mount the meter to a wall, follow these

instructions.

1. Prepare a section of wall

approximately 11” x 13” (280 mm x

330 mm) for meter mounting by

marking with a pencil the mounting

holes (shown in the image to the

right) on the wall.

2. Using a drill bit slightly smaller than

the girth of the mounting screws,

pre-drill holes at the mounting

locations previously marked.

3. Insert mounting screws into the four

mounting holes and screw them

into the pre-drilled holes. Do not

overtighten the mounting screws

as it is possible that the enclosure

could crack and become damaged. Figure 1. Meter Mounting Holes

Mounting Dimensions

Figure 2. Meter

Dimensions - Side View

Figure 3. Meter Dimensions –Front View

2.63" (67 mm)

4.77"

(121.2 mm)

MountingHole Mounting Hole

FrontDoor

PanelScrew

10.63" (270 mm)

12.59" (319.7mm)

16262

7598

MountingHole MountingHole

MountingHole

FrontDoor

Panel
