INSTRUCTION MANUAL

21" 3-in-1 Self Propelled Lawn Mower

Model # DB2194S

Have product questions or need technical support? Please feel free to contact us!

Website: www.Amerisuninc.com

www.powersmartusa.com

Toll free: 1-800-791-9458 Mon-Fri 9-5 EST

Email: [email protected]

CONTENTS

Technical data…...………………………………………………………... 3

Introduction………………………………………………………………. 4

Safety information…….………………………………………………... 4

General safety procedures ……....……………………………………… 5

Important safety instructions……………………………………………. 6

Knowing your lawn mower……………………………………………… 8

Lawn mower preparation………………………………………………... 9

Operation……………………....………………………………………… 13

Maintenance……………………………………………………………... 16

Storage……………………………………………………………………. 17

Troubleshooting…………………………………………………………. 18

Exploded view & parts list……………………………………………… 19

Warranty………………………………………………………………… 23

TECHNICAL DATA

21" 3-in-1 Self Propelled Lawn Mower Model # DB2194S

Engine type: 4 stroke, OHV, single cylinder with forced air cooling system

Displacement: 161 cc

Fuel tank capacity: 0.21 Gallon

Oil capacity: 15.2 fl.oz

Cutting width: 21 inch

Cutting height: 1.18 – 3 inch

Height adjustment: 5 Position

Drive type: Rear- wheel drive

Grass catcher capacity: 1.4 Bushels

Wheel: Front: 7 inch / Rear: 8 inch

Package dimensions (L x W x H): 33.3 x 22.6 x 17.3 inches

Weight: 75.8lb

INTRODUCTION

Thank You for Purchasing a PowerSmart®Product. This manual provides information regarding the safe

operation and maintenance of this product. Every effort has been made to ensure the accuracy of the

information in this manual. PowerSmart®reserves the right to change this product and specifications at

any time without prior notice.

Please keep this manual available to all users during the entire life of the lawn mower.

This manual contains special messages to bring attention to potential safety concerns, lawn

mower damage as well as helpful operating and servicing information. Please read all the

information carefully to avoid injury and machine damage.

QUESTIONS? PROBLEMS?

Please contact our Customer Service Dept. with any questions and/or comments, either by Email:

[email protected], or Toll Free at (800) 791-9458. We are available Mon-Fri 9am-5pm EST to

help solve any issues that you might encounter.

NOTICE REGARDING EMISSIONS

Engines that are certified to comply with U.S. EPA emission regulations for SORE (Small Off Road

Equipment), are certified to operate on regular unleaded gasoline, and may include the following

emission control systems: (EM) Engine Modifications and (TWC) Three-Way Catalyst (if so equipped).

SAFETY INFORMATION

Before operating this lawn mower, read and observe all warnings, cautions, and instructions on the lawn

mower and in this Owner’s Manual.

NOTE: The following safety information is not meant to cover all possible conditions and situations that

may occur. Read the entire Owner’s Manual for safety and operating instructions. Failure to follow

instructions and safety information could result in serious injury or death.

This safety alert symbol is used to identify safety information about hazards that can result in personal

injury.

A signal word (DANGER, WARNING, or CAUTION) is used with the alert symbol to

indicate the likelihood and the potential severity of injury. In addition, a hazard symbol may

be used to represent the type of hazard.

DANGER indicates a hazard, which, if not avoided, will result in death or serious injury.

WARNING indicates a hazard, which, if not avoided, could result in death or serious injury.

CAUTION indicates a hazard, which, if not avoided, might result in minor or moderate injury.

CAUTION when used without the alert symbol, indicates a situation that could result in damage to the

engine.

GENERAL SAFETY PROCEDURES

For any questions regarding the hazard and safety notices listed in this manual or on the product, please

call (800) 791-9458 Mon-Fri 9-5 EST before using the lawn mower..

DANGER: CARBON MONOXIDE

Using an engine indoors CAN KILL YOU IN MINUTES. Engine exhaust contains carbon

monoxide (CO). This is a poison gas you cannot see or smell. If you can smell the engine exhaust, you are

breathing CO. But even if you cannot smell the exhaust, you could be breathing CO.

NEVER use an engine inside homes, garages, crawlspaces, or other partly enclosed areas. Deadly levels

of carbon monoxide can build up in these areas. Using a fan, or opening windows and/or doors will NOT

properly vent CO nor supply adequate fresh air. ONLY use an engine outside and far away from windows,

doors, and vents. These openings can pull in engine exhaust.

Even if you use an engine correctly, CO may leak into the home. ALWAYS use a battery-powered or

battery-backup CO alarm in the home. If you start to feel sick, dizzy, or weak after the engine has been

running, move to fresh air RIGHT AWAY. See a doctor. You may have carbon monoxide poisoning.

WARNING: The exhaust from this product contains chemicals known to the State of California to cause

cancer, birth defects, or other reproductive harm.

WARNING: This engine may emit highly flammable and explosive gasoline vapors, which can cause

severe burns or even death if ignited. A nearby open flame can lead to explosion even if it isn’t directly in

contact with gasoline.

•Do not operate near an open flame.

•Do not smoke near the engine.

•Always operate on a firm, level surface.

•Always turn engine off before refueling. Allow engine to cool for at least 2 minutes before

removing fuel cap. Loosen cap slowly to relieve pressure in tank.

•Do not overfill fuel tank. Gasoline may expand during operation. Do not fill to the top of the tank.

Allow for expansion.

•Always check for spilled fuel before operating.

•Empty fuel tank before storing or transporting the engine.

WARNING: This engine produces heat when running. Temperatures near exhaust can exceed 1500F

(650C).

Do not touch hot surfaces. Pay attention to warning labels on the engine identifying hot parts of the

machine.

Allow engine to cool down after use before touching engine or areas of the engine that become hot during

use.

CAUTION: Misuse of this engine can damage it or shorten its life.

Only use engine for its intended purposes.

IMPORTANT SAFETY INSTRUCTIONS

General Operation

Read, understand, and follow all instructions on the machine and in the manual(s) before starting.

1. Do not put hands or feet near or under the machine. Keep clear of the discharge opening at all times.

2. Only allow responsible adults, who are familiar with the instructions, to operate this machine.

3. Clear the area of objects such as rocks, wire, toys, etc., which could be thrown by the blade. Stay

behind the handle when the engine is running.

4. Be sure the area is clear of bystanders before operating. Stop machine if anyone enters the area.

5. Do not operate machine barefooted or while wearing sandals. Always wear substantial footwear.

6. Do not pull machine backward unless absolutely necessary. Always look down and behind before and

while moving backward.

7. Never direct discharged material toward anyone. Avoid discharging material against a wall or

obstruction. Material may ricochet back toward the operator. Stop the blade when crossing gravel

surfaces.

8. Do not operate machine without the entire grass catcher, discharge guard, rear guard, or other safety

protective devices in place and working.

9. Never leave a running machine unattended.

10. Stop the engine and wait until the blade comes to a complete stop before cleaning the machine,

removing grass catcher, or unclogging the discharge guard.

11. Operate machine only in daylight or good artificial light.

12. Do not operate machine while under the influence of alcohol or drugs.

13. Never operate mower in wet grass. Always be sure of your footing; walk; never run.

14. Disengage the drive system, if so equipped, before starting the engine.

15. If the machine should start to vibrate abnormally, stop the engine and check for the cause

immediately. Vibration is generally a warning of trouble.

16. Always wear eye protection when operating machine.

17. See manufacturer's instructions for proper operation and installation of accessories. Only use

accessories approved by the manufacturer.

Slope Operation

Slopes are a major factor related to slip and fall accidents, which can result in severe injury. Operation on

all slopes require extra caution. If you feel uneasy on a slope, do not mow it.

1. Mow across the face of slopes; never up and down. Exercise extreme caution when changing

direction on slopes.

2. Watch for holes, ruts, bumps, rocks, or other hidden objects. Uneven terrain could cause a slip and

fall accident. Tall grass can hide obstacles.

3. Do not mow on wet grass or excessively steep slopes. Poor footing could cause a slip and fall

accident.

4. Do not mow near drop-offs, ditches, or embankments. You could lose your footing or balance.

Children

Sever injury can occur if the operator is not alert to the presence of children in the immediate area.

Children are often attracted to the mowing activity. Never assume that children will remain where you

last saw them.

1. Keep children out of the mowing area and under the watchful care of a responsible adult other than

the operator.

2. Be alert and turn mower off if a child enters the area.

3. Never allow children under the age of 16 to operate the lawn mower.

4. Use extra care when approaching blind corners, shrubs, trees, or other objects that may block your

view of a child.

Service

1. Safe Handling of Gasoline

2. To avoid personal injury or property damage, use extreme care in handling gasoline. Gasoline is

extremely flammable and the vapors are explosive.

3. Extinguish all cigarettes, cigars, pipes, and other sources of ignition.

4. Only use a US EPA approved compliant portable fuel container.

5. Never remove gas cap or add fuel with the engine running. Allow engine to cool before refueling.

6. Never attempt to refuel the lawn mower while indoors.

7. Never store the machine or fuel container where there is an open flame, spark, or pilot light such

as on a water heater or on other appliances.

8. Never fill containers inside a vehicle or on a truck or trailer bed with a plastic liner. Always place

containers on the ground away from your vehicle before filling.

9. Remove gas-powered equipment from the truck or trailer and refuel it on the ground. If this is not

possible, then refuel such equipment with a portable container, rather than from a gasoline

dispenser nozzle.

10. Keep the nozzle in contact with the rim of the fuel tank or container opening at all times until

fueling is complete. Do not use a nozzle lock-open device.

11. If fuel is spilled on clothing, change clothing immediately.

12. Never overfill fuel tank. Replace gas cap and tighten securely.

General Service

1. Never operate machine in a closed area.

2. Keep all nuts and bolts tight to be sure the equipment is in safe working condition.

3. Never tamper with safety devices. Check their proper operation regularly.

4. Keep machine free of grass, leaves, or other debris build-up. Clean up oil or fuel spillage and

remove any fuel-soaked debris. Allow machine to cool before storing

5. If you strike a foreign object, stop and inspect the machine. Repair, if necessary, before starting.

6. Never make any adjustments or repairs with the engine running. Disconnect the spark plug wire

to prevent unintended starting.

7. Check grass catcher components and the discharge guard frequently and replace with

manufacturer's recommended parts, when necessary.

8. Mower blades are sharp. Wrap the blade or wear gloves, and use extra caution when servicing

them.

9. Do not change the engine governor setting or overspeed the engine.

10. Maintain or replace safety and instruction labels, as necessary.

KNOWING YOUR LAWN MOWER

Please use the illustration below to familiarize yourself with the location and function of the components

that control of your lawn mower.

1 Recoil starter handle 9 Primer Bulb

2 Grass catcher 10 Fuel tank cap

3 Cutting height adjustment lever 11 Rear discharge door

4 Rear wheel 12 Lower handle

5 Side discharge chute 13 Upper handle

6 Oil dipstick 14 Engine start/stop lever

7 Front wheel 15 Drive control bar

8 Cutting height adjustment lever

15 14 13 12

5 6 7 8

LAWN MOWER PREPARATION

The following section describes steps necessary to prepare the lawn mower for use. If after reading this

section, you are unsure about how to perform any of the steps please call (800) 791-9458 Mon-Fri 9-5

EST for customer service. Failure to perform these steps properly can damage the lawn mower or shorten

its lifespan.

UNPACKING

Unpack the lawn mower and all its parts, and compare against the list below. Do not discard the carton or

any packaging until the lawn mower is completely assembled.

1 Side discharge chute 6 Screw M8 (2)

2 Grass Catcher 7 Flange bolts M6 (2)

3 Lawn mower with upper handle 8 Cable clip

4 Lower handle 9 Spark plug wrench

5 Knob (2)

1 2 3 4 5 6 7

8 9

ATTACH LOWER & UPPER HANDLE

1. Take lower handle and line up the hole in the lower handle with the

hole on the handle bracket.

2. Secure the lower handle with Sleeve with provided M6 Hexagonal

flange bolts on each side.

3. Pull upper handle up and lock it in position with bolts and knob on both

side.

4. Insert the recoil starter handle cable into the hook provided on the

upper handle.

Knob and screw

M6 flange bolts

Recoil starter handle

Table des matières

Autres manuels Powersmart Tondeuse à gazon

Powersmart

Powersmart DB8621P Manuel utilisateur

Powersmart

Powersmart PSM2521SH Manuel utilisateur

Powersmart

Powersmart DB8621AS Manuel utilisateur

Powersmart

Powersmart DB8631 Manuel utilisateur

Powersmart

Powersmart DB8621SH Manuel utilisateur

Powersmart

Powersmart DB2321PR Manuel utilisateur

Powersmart

Powersmart DB8621SR Manuel utilisateur

Powersmart

Powersmart DB2194SR Manuel utilisateur

Powersmart

Powersmart PS2321CR Manuel utilisateur

Powersmart

Powersmart DB8617P Manuel utilisateur

Powersmart

Powersmart PSM2521SR Manuel utilisateur

Powersmart

Powersmart DB2194C Manuel utilisateur

Powersmart

Powersmart DB2321PR Manuel utilisateur

Powersmart

Powersmart DB2321P Manuel utilisateur

Powersmart

Powersmart DB2194SH Manuel utilisateur

Powersmart

Powersmart PS76418AP Manuel utilisateur

Powersmart

Powersmart DB2194PH Manuel utilisateur

Powersmart

Powersmart DB8621PH Manuel utilisateur

Powersmart

Powersmart DB2194SH Manuel utilisateur

Powersmart

Powersmart PS76215A Manuel utilisateur

Powersmart

Powersmart PS76417AP Manuel utilisateur

Powersmart

Powersmart PSM2020 Manuel utilisateur

Powersmart

Powersmart DB2321SH Manuel utilisateur

Powersmart

Powersmart DB2194PH Manuel utilisateur

Manuels Tondeuse à gazon populaires d'autres marques

RHINO

RHINO 1958 Manuel utilisateur

Wolf Garten

Wolf Garten Compact plus 40 B Manuel utilisateur

Cub Cadet

Cub Cadet LTX 1045 Manuel utilisateur

Craftsman

Craftsman 917.378461 Manuel utilisateur

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Manuel utilisateur

Challenge

Challenge CH18V2 Instructions de fonctionnement

TALEN TOOLS

TALEN TOOLS AVR HGM30 Manuel utilisateur

DEWEZE

DEWEZE ATM-725 Manuel d'utilisation

Weed Eater

Weed Eater 180083 Manuel utilisateur

Husqvarna

Husqvarna Poulan Pro PP185A42 Manuel utilisateur

Better Outdoor Products

Better Outdoor Products Quick Series Manuel utilisateur

Cub Cadet

Cub Cadet 23HP Z-Force 60 Manuel d'utilisation

MTD

MTD 795, 792, 791, 790 Manuel utilisateur

Toro

Toro Groundsmaster 3505-D Manuel utilisateur

Dennis

Dennis FT 610 Manuel utilisateur

AIRFORCE

AIRFORCE F-15 Gen 3 Manuel utilisateur

MTD

MTD 126-220-000 Manuel utilisateur

Toro

Toro 74806 Manuel utilisateur
