Powerplus GLYDER Manuel utilisateur
Valued Customer,!
!
Thank you for purchasing a Power Plus Mobility product.
At Power Plus Mobility we manufacture top quality
“Canadian Made” products. Your wheelchair should
provide you with many years of service, but like any piece
of equipment, it will require proper care and service for it
to perform efficiently.!
!
However we suggest you regularly inspect your chair,
checking for loose fasteners, excess play and damage. We
also strongly recommend that regular maintenance be done
by your servicing dealer.!
!
Please complete your “Warranty Registration Card” and
return it to us at Power Plus Mobility.!
!
Also please read this manual to help you understand the
proper operation, safety and maintenance of your new
chair. If you have any difficulties or require additional
information contact your dealer or our customer service
department at Power Plus Mobility.!
LIMITED WARRANTY!
!
Power Plus Mobility guarantees all parts of our wheelchair to be
free of defects in workmanship and materials for a period of two
years from the date of purchase. “Wear” items such as tires,
tubes, armpads and upholsteries are excluded from this warranty.!
In addition the frame and crossbraces are guaranteed to be free
of defects in workmanship and material (to the original
purchaser) for a period of 5 years.!
!
This warranty is invalid if the chair has been damaged by
accident, misuse, neglect, improper application, unauthorized
service repair or the addition of non-factory approved
accessories.!
!
Power Plus Mobility will repair or replace defective parts as
required. A return authorization must be obtained and the parts
returned to us freight prepaid, within the warranty period.
Labour and freight charges incurred for replacements or repairs
are not covered.!
!
MAINTENANCE GUIDE!
Your wheelchair is designed to give you many years of trouble-free
use with proper care. Some servicing can be done at home, but we
recommend that periodic maintenance be performed at your dealer.!
Service frequency depends strongly on the type of use and your
dealer can best advise you on the time interval.!
CLEANING!
All chrome and painted parts can be cleaned with a mild !
non-abrasive cleaner such as window cleaner. Stubborn spots or
rust can be removed with automotive chrome cleaner.!
The arms and nylon upholstery should be cleaned with a mild soap
and water solution. Both should be rinsed well with clean water to
remove all soap residues. The molded wheels and casters should
also be cleaned with a mild soap and water solution.!
LUBRICATION!
Your wheelchair has been made with low friction plastic, steel,
aluminum and polished chrome to reduce friction and wear.
However a light use of thin lubricant, such as WD40 or silicone
spray will reduce friction and wear, making your chair easier to
use.!
SAFETY AND HANDLING!
The safe handling of your chair depends on understanding the
purpose and function of your particular wheelchair model. !
Recognizing the chairs’ limitations will increase your confidence
level. !
LEANING!
Leaning should be avoided when possible, as this weight transfer
will reduce your chair’s stability. When leaning forward or
sideways make sure the casters are turned in the direction you are
leaning as this will lengthen the wheel base, increasing stability.!
Also make sure the wheel locks are engaged, to prevent your chair
from rolling.!
!
MANOUVERING RAMPS, CURBS, STAIRS!
Lean forward in chair, putting weight over front casters when
going up inclines. When going on descending inclines do so slowly
by controlling your speed using the handrims and not the wheel.!
To mount a curb use the tipping method, pull the chair backwards
and over the curb. To descend a curb do your tipping and either
pull yourself down backwards or roll yourself forward and down
very slowly.!
It is a definite no-no to use your chair on an escalator, find the
nearest elevator instead. Going up or down stairs should be done
with at least two attendants at all times.!
!
!
TRANSFERRING IN A WHEELCHAIR!
Attendant assistance is recommended to stabilize the chair and
help in lifting you, if necessary. Transfers are best accomplished by
following these guidelines:!
Use a chair with detachable or flip back arm.!
Position your chair as close as possible to the transfer object and
engage your wheel locks to prevent movement.!
Try to transfer to objects of the same height or close to.!
!
!
!
!
OPENING AND CLOSING YOUR CHAIR!
!
To Open: !
Make sure the wheel locks are disengaged. Then push down on
one or both seat rails until they are completely open to the
chair’s maximum width. Your chair is now fully opened and
ready for use. !
!
To Close: !
Disengage wheel locks and fold both footplates up, then
remove footrest from chair if it is going to be transported.
Facing your chair, with the footrest removed, take hold of the
seat upholstery at both the front and rear centre. Then lift
straight up to fold the chair.!
!
!
Transporting: !
For larger vehicles, chair does not have to be closed, but
inside the vehicle wheel locks should be engaged to
prevent chair from rolling around. !
!
For the inside or trunk of a car, it is necessary to close
chair by following the instructions on previous page. Then
lift the chair by holding on to the seat rail, the push
handles and place in vehicle. To make chair easier to lift
or store, remove the footrest, the arms, the wheels
(optional quick release axles). To remove chair from
vehicle, lift out again holding on the the seat rail and the
push handles. !
!
!
!
!
To Lift:!
Fold both footplates up, then close chair following
instructions on the previous page. Engage wheel locks to
prevent wheels from rotating, and lift chair by holding on
to the seat rail and push handle. Do not lift chair by holding
on to any detachable or moving parts. !
ANTI-TIPPERS!
!
Your Anti-Tippers are used to prevent your chair from tipping over !
while in tilt. These can be removed. However, they must never be removed
when using chair.!
To remove Anti-Tippers: !
Loosen the bolt (1) and remove it from the frame!
!
To adjust the Anti-Tipper height: !
Pull on (4) while moving (2) to your desired position release (4) to !
lock into place!
!
*Please adjust your Anti-Tippers to a safe height (maximum 2” from the
ground). Whenever the seat height is adjusted by wheels the Anti-Tipper
height must be adjusted as well. !
#!Description!Quantity !
1!Bolt !1!
2!Height Extension
Tube!
1!
3!Housing!1!
4!Locking Pin!1!
5!Anti-Tipper Wheel !1!
4!
1!
2!
3!
5!
FOOTREST!
The footrest on your chair is designed to swing away and removes
easily. To swing away, remove feet from the footplate (1) and fold
footplates up. Then push the release handle (2) on the footrest
locking mechanism. It will swing to the side of your chair, and
could then be removed by lifting it straight up and off the locating
pins (3). To replace hold footrest at the side of your chair, locate
onto mounting pins, allowing it to drop all the way in, and then
push forward until it locks into place.!
!
Number !Description!Quantity !
1!Foot Plate!2!
2!Release Handle !2!
3!Mounting Pins !4!
4!Footrest Extension Tube!2!
1!
4
2!
3!
LEGREST!
Your legrest is designed to be removed and replaced the same as
your footrest. However, it is advisable to remove and replace your
legrest while it is in a down position. Lifting on the footplate
raises the legrest and it will automatically lock at the raised
position. !
1!
2!
3!
4!
5!
6!
7!
8!
9!
1 – Locator Pin !
2 – Front Post!
3 – Locking Pin!
4 – Locking Bushing!
5 – Release Handle!
6 – Elevating Trigger!
7 – Calf Pad Height Adjustment!
8 - Leg Length Adjustment Screw!
9 – Leg Rest Height Extension Tube!
Operating Your Legrest!
!
Locate 1 into 2 and swing into place. This should allow 3 to lock
into place with 4. (Make sure your legrest is locked into place
before using. To remove footrest, press 5 swing away and lift
legrest upwards. To raise legrest lift 9 to desired height. To lower
legrest, pull 6 upwards. Use 7 to raise or lower calf pad height. To
adjust leg length height, remove 8, slide 9 to desired height and
lock 8 back into place. !
* For low floor to seat height on chair, shorter leg rest height
extension tube is required. !
