Powerfix Profi 101006 Manuel utilisateur
BAT
Lindenstraße 35
72074 Tübingen
Deutschland
Last Information Update • Stan informacji • Stav informácií
• Stav informací • Stand der Informationen: 04 / 2014
EXTENSION LEAD WITH SURGE
PROTECTION
GB
EXTENSION LEAD WITH SURGE
PROTECTION
Operation and Safety Notes
PL
LISTWA ZASILAJĄCA Z OCHRONĄ
PRZEPIĘCIOWĄ
Wskazówki dotyczące obsługi i bezpieczeństwa
SK
ELEKTRICKÁ ROZVODKA S
OCHRANOU PROTI PREPÄTIU
Pokyny pre obsluhu a bezpečnostné pokyny
CZ ZÁSUVKOVÁ LIŠTA
Pokyny pro obsluhu a bezpečnostní pokyny
DE
ÜBERSPANNUNGSSCHUTZ-
STECKDOSENLEISTE
Bedienungs- und Sicherheitshinweise
0474629
IAN 101006IAN 101006 CZ SK
101006_pow_A-Alu-SteckdosenleisteFB_CZ_SK.indb 1 15.05.2014 13:02:55
ENGLISH
1
Introduction .....................................................2
Scope of supply ..............................................2
Safety instructions .........................................2
For your safety ..............................................3
Intended use .................................................4
Product overview............................................4
Structure .......................................................4
Functionality overvoltage protection device ..5
Technical data .................................................6
Operation .........................................................7
Switching on/off ............................................7
Procedure with control light off .....................7
Maintenance and cleaning .............................8
Disposal...........................................................8
Warranty and service .....................................9
Declaration of conformity ............................10
Table of conTenTs
101006_pow_A-Alu-SteckdosenleisteFB_CZ_SK.indb 1 15.05.2014 13:02:55
ENGLISH
2
InTroducTIon
Please read the operating instructions carefully.
Keep the operating instructions and give them
to each user of the multiple socket. For the
use of the multiple socket observe the safety
instructions contained in the operating instruc-
tions.
For questions on spare parts or repairs please
contact the manufacturer.
scope of supply
• 1 x multiple socket
• 1 x operating instructions
safeTy InsTrucTIons
Please observe the following safety instruc-
tions. Failure to comply with the instructions can
result in personal injury and damage.
Damages caused by failure to comply with the
operating instructions, especially the safety and
handling instructions, void the warranty. The
manufacturer cannot be held responsible for
any subsequent damage.
101006_pow_A-Alu-SteckdosenleisteFB_CZ_SK.indb 2 15.05.2014 13:02:55
ENGLISH
3
for your safeTy
DANGER
Danger to life from electric shock
Do not touch damaged, exposed or ener-
gized parts. Danger from electric shock
⇒Make sure you check the multiple socket
for damages before use. Do not use the
multiple socket if the cable insulations or
the casing are damaged.
CAUTION
Devices switching on accidentally
When switching on the multiple socket, the
connected devices might accidentally switch
on.
⇒Before switching on or off the multiple
socket, make sure you disconnect all the
connected devices.
• To avoid danger, a damaged connect-
ing line of the multiple socket should be
replaced by the manufacturer, by a Service
representative or a skilled technician only.
• Do not manipulate or alter the multiple
socket.
• Repairs should be performed by a skilled
technician only.
• Keep the multiple socket away from chil-
dren.
101006_pow_A-Alu-SteckdosenleisteFB_CZ_SK.indb 3 15.05.2014 13:02:56
ENGLISH
4
InTended use
The multiple socket should be used in dry
rooms, exclusively for private purposes. Do not
use near liquids that might leak or spout (e.g.
aquarium).
Any other use is not permitted.
producT overvIew
sTrucTure
The legend refers to the product picture in the
inner side of the package.
1 Illuminated on/off switch
2 Overvoltage protection control light
The multiple socket has 6 child-proof sockets
with an angle of 45°.
101006_pow_A-Alu-SteckdosenleisteFB_CZ_SK.indb 4 15.05.2014 13:02:56
ENGLISH
5
funcTIonalITy overvolTage proTecTIon
devIce
The multiple socket is equipped with an over-
voltage protection device. The overvoltage pro-
tection device prevents the devices connected
to the multiple socket from being damaged by
overvoltage in the main supply.
Overvoltages are caused, for instance, by
indirect lighting strikes or by the activation of
other electrical appliances (monitors, ovens,
lamps, etc.).
For a correct operation, the multiple socket
should be connected to a socket with a profes-
sionally installed protective conductor.
The protection is indicated by the control light 2.
When the control light 2 is on, the overvoltage
protection is active.
The control light goes off in case the overvolt-
age protection breaks down.
101006_pow_A-Alu-SteckdosenleisteFB_CZ_SK.indb 5 15.05.2014 13:02:56
ENGLISH
6
TechnIcal daTa
Name: Multiple socket with overvoltage protec-
tion device, type ASL 06-A FR 3516
Supply voltage: 230 V~ / 50 Hz
Highest continuous voltage UC: 250 V / 50 Hz
Total output: max. 16 A / 3680 W
SPD according to
EN 61643-11:2002+A11:2007 Type 3
Combined surge UOC (L-N): 3 kV
Combined surge UOC (L/N-PE): 3 kV
Protection level UP (L-N): 1,8 kV
Protection level UP (L/N-PE): 1,8 kV
Connecting line: H05VV-F 3G1,5
length: 1,5 m
101006_pow_A-Alu-SteckdosenleisteFB_CZ_SK.indb 6 15.05.2014 13:02:56
ENGLISH
7
operaTIon
swITchIng on/off
The multiple socket is activated and deactivated
by use of the on/off switch 1.
procedure wITh conTrol lIghT off
Generally the overvoltage protection device
works without affecting the operating connected
devices.
Control lamp 2 only goes off in case of an over-
load caused by a too high overvoltage.
⇒There is no overvoltage protection pro-
vided if control lamp 2 does not light up.
The multiple socket can still be used in
such case, however, it is highly recom-
mended to replace it due to the missing
overvoltage protection.
101006_pow_A-Alu-SteckdosenleisteFB_CZ_SK.indb 7 15.05.2014 13:02:56
ENGLISH
8
MaInTenance and cleanIng
The multiple socket is maintenance-free.
DANGER
Danger to life from electric shock
Do not touch damaged, exposed and energized
parts of the multiple socket and of the cable.
Danger to life from electric shock.
⇒Never clean the multiple socket when it is
energized.
⇒Remove the plug from the outlet before
cleaning.
⇒Never immerse the multiple socket in water.
1. Clean the multiple socket with a dry cloth.
dIsposal
Do not dispose electrical appli-
ances together with household
waste!
In accordance with the European
Guideline 2012/19/EC concerning
used electrical and electronic equipment, the
used electrical equipment must be gathered
separately and directed to an environmentally
friendly recycling facility.
For information on the disposal of old equip-
ment please contact your local authority.
101006_pow_A-Alu-SteckdosenleisteFB_CZ_SK.indb 8 15.05.2014 13:02:56
ENGLISH
9
warranTy and servIce
Warranty
This equipment comes with a warranty of
3 years from the date of purchase. Please
keep the receipt as proof of purchase. The
equipment has been carefully manufactured
and tested before the delivery. The warranty
covers material and manufacturing faults only
if the device has been used properly. In case of
unauthorized interference the warranty is void.
Your statutory rights are not affected by this
warranty. In case of a warranty claim, please
call our hotline. This is the only way to ensure
the shipment of the equipment is free of charge.
Service address
BAT, Lindenstrasse 35, D-72074 Tübingen
e-mail: [email protected]
Service Tel.: 00800 48720741
For further information, please consult the
Service/FAQ's area on our homepage
www.dvw-service.com.
101006_pow_A-Alu-SteckdosenleisteFB_CZ_SK.indb 9 15.05.2014 13:02:56
