Positron V-114 Manuel utilisateur

3. Connect to the browser based conﬁgurator by opening the

browser to the IP address. The following is the default

connection credentials:

Username: admin

Password: password

Support

To ensure your PBX is working, try the following:

•Check the LED on the PCI bracket, the GREEN LED light is solid

• PlugananalogtelephoneintotheFXSport–isthereadialtone?

• Atthedialtone,press6000andyouwillheartheoperator’svoice

These steps do not require user conﬁguration. If you are unable to

complete them, please contact Positron TelecommunicationSystems.

V-114 PCI Quickstart

Features

•SingleCompactFlashport

•FourForeignExchangeOfce(FXO)portsforconnectiontothetelephonenetwork

•SingleForeignExchangeStation(FXS)portforconnectingaphoneorfaxmachine

•HardwarebasedG.168echocancellationchipupto128mstaillength

•PCI2.2compliantEthernetinterface

•10/100MbpsautoMDIXEthernetport

•Perchannelfax/modemG.164prG.1652100Hzphasereversaltonedisable

•ITU-TG.165,G.168(2000and2002)compliant

Installation Steps

1.InstallthePCIcardintothemachine:

-InsertcardintothedesiredslotandscrewthePCIbracketinto

the computer frame to ensure a solid ﬁt

-WhenthePCIcardissecurelyfastened,turnonthecomputer

NOTE:Whenthecardisbooting,theLEDwillashfromGREENto

REDwithashortdelay.Whentheboardhassuccessfullybooted,the

GREEN LED light will be solid.

2.ConnectRJ-45Ethernetcableprovided(orange)totheEthernet

port on the PCI bracket:

-TheEthernetcablemaybeconnectedtoahub/switchordirectlyto

alaptop/PC.Thefollowingisthedefaultcongurationforthisport:

    IPAddress:192.168.1.2

    Speed:10/100Auto

Contents of Box

•V-114PCICard

•TwoRJ-12FXOlinesplitters

•TwoRJ-12cables

•OneRJ-45Cat5eEthernetCable(orange)

Ensure the power is off on the computer before inserting

the card into the machine.

Compact Flash

SandiskCompactFlashiscurrentlytheonlysupportedmedia

2x FXO

Fax

2x FXO

PSTN PSTN

Ethernet FXS

Network

ThedefaultIPaddressofthecardis192.168.1.2–theEthernetinterfaceonthebracketisautospeeddetectandautocablecrossover.

ForcongurationyoumayconnectdirectlytotheEthernetinterfaceorthroughaswitch.Nospecialcableisrequired.

Drivers

WindowsXP/2000andLinuxsourcecodeareavailableontheCDalongwithinstallationinstructions.

IMPORTANT:IfyouwanttoconnecttothePCIcardfromtheHostPC,youneedtoensuretheIPaddressisconguredonthesame

segmentasthePCIcard.Forexample,ifthedefaultIPaddressofthecardis192.168.1.2,thenasuggestedIPaddressfortheHostPCdriver

is192.168.1.10.

LED Functionality

TheLEDonthePCIbracketprovidesstate/diagnosticinformation.Thetablebelowdescribeseachstate:

Factory Reset

Intheeventthatacongurationdoesnotallowconnectivitytothesystem,ausermayperformafactoryresetthatwillputalltheIP

addressesandpasswordsbacktothedefaultsettings.Instructions:Pushandholdtheresetbuttonforapproximately20seconds.

PositronTelecom•5101BuchanStreet,Suite200,Montreal,Quebec,CanadaH4P2R9•Tel:(514)-345-2220•Email:[email protected]•www.positrontelecom.com

Document Code: 44-00029-03

Event LED

NOTE:Whenyoupushandholdtheresetbutton,theLEDlightwillbe

GREENsolid.Whenfactoryresetiscomplete,theGREENandREDwillbe

solid and the button can then be released.

Reset Button

Card is booting GREEN to RED blinking

Operatingsystemloading OnlyGREENblinking

Systemfullyloadedandoperational GREEN solid

Hardwarefailure RED solid

Ethernet(optional-requiresdriver)

To PCI Bus

Ethernet

192.168.1.2(static)

Think Inside the Box
