POSIFLEX KB3100 Manuel utilisateur
TM
KB3100 SERIES
PROGRAMMABLE KEYBOARD
USER’S MANUAL
Rev. : A
TM
SOME IMPORTANT NOTES
FCC NOTES
This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions manual, may cause interference to radio communications.
It has been tested and found to comply with limits for a Class A digital device pursuant to subpart J of
Part 15 of FCC Rules, which are designed to provide reasonable protection against interference when
operated in a commercial environment. Operation of this equipment in a residential area is likely to
cause interference in which case the user at his own expense will be required to take whatever measures
to correct the interference.
WARRANTY LIMITS
Warranty will terminate automatically when the machine is opened by any person other than
the authorized technicians. The user should consult his/her dealer for the problem happened. Warranty
voids if the user does not follow the instructions in application of this merchandise. The manufacturer is
by no means responsible for any damage or hazard caused by improper application.
ABOUT THIS MANUAL
This manual is written in an attempt with full strength to assist the user to utilize the powerful
programmable keyboard KB-3100 series which consists of a 6 positioned electronic control key and
112 press keys which provides excellent tactile click when pressed, and an optional magnetic stripe
reader for either ISO or JIS standards. The KB-3100 not only is capable of being programmed to
transmit whatever code a standard PC or PS2 keyboard can deliver, but also provides a great variety of
programmability such that contains all capabilities of the most modern programmable keyboards.
The manufacturer of this product heartily apologizes to the user for reserving the right to
change or to modify this manual without notice due to the rapid and constant progress and improvement
on science and technology.
©Copyright Mustek Corp. 1997
All rights are strictly reserved. No part of this documentation may be reproduced, stored in a retrieval
system, or transmitted in any form or by any means, electronic, mechanical, photocopying, or otherwise,
without the prior written consent of Mustek Corp. the publisher of this documentation.
TRADE MARKS AND SERVICE MARKS
POSIFLEX is a registered trademark of Mustek Corp..
Other brand and product names are trademarks and registered trademarks and service marks of their
respective owners.
i
TM
CHAP.
1
CHAP.
2
CHAP.
3
CHAP.
4
CHAP.
5
CHAP.
6
CHAP.
7
OVERVIEW
PACKAGE CONTENTS
APPLICATION
INSTALLATION
SERVICE AND SPARE PARTS
SPECIFICATIONS
PROGRAMMING THE KEYBOARD
ii
TM
TABLE OF CONTENTS
OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1
SCOPE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1
FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1
MODEL NUMBERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 2
PACKAGE CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 - 1
OPTION LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 1
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 1
CABLE CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 1
KEYTOP LAYOUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 2
APPLICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1
KEYBOARD CONSTRUCTION . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 1
PRELOADED PATTERN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 3
MSR (Magnetic Stripe Reader) . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 5
PROGRAMMING THE KEYBOARD . . . . . . . . . . . . . . . . . . . . . . 5 - 1 - 1
EASINESS IN PROGRAMMING . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 1 - 1
ANSWER BACK CODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 1 - 2
HOT KEY PROGRAMMING . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 1 - 3
PREPARATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 1 - 3
ENTER “HOT KEY PROGRAMMING”MODE . . . . . . . . . 5 - 1 - 3
INPUT THE CONTENT TO BE PROGRAMMED . . . . . . . .5 - 1 - 4
EXIT “HOT KEY PROGRAMMING”MODE . . . . . . . . . . 5 - 1 - 4
UTILITY INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 2 - 1
WINDOWS95 INSTALLATION . . . . . . . . . . . . . . . . . . . . . .5 - 2 - 1
WINDOWS 3.1 INSTALLATION . . . . . . . . . . . . . . . . . . . 5 - 2 -10
DOS INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 2 -15
STARTING PROGRAMMING . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 3 - 1
UNDER WINDOWS95 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 3 - 1
UNDER WINDOWS 3.1 . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 3 - 2
UNDER DOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 3 - 3
SHORTCUT UTILITY (RWM.EXE) . . . . . . . . . . . . . . . . .5 - 3 - 4
STARTING KBM.EXE . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 3 - 5
COMMAND LISTING IN VIEW MODE . . . . . . . . . . . . . . 5 - 3 - 8
COMMAND LISTING IN ASCII-CODE EDITING MODE . .5 - 3 - 9
COMMAND LISTING IN SCAN-CODE EDITING MODE . .5 - 3 -10
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1
CONSTRUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1
CASE MATERIALS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1
iii
TM
POWER ON LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1
KEY SWITCH TYPE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1
KEY STROKE TRAVEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1
KEY TOP SIZE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1
PREPRINTED KEYS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1
KEY CAP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1
PROGRAMMABILITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1
POSITION CONTROL KEY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1
OUTPUT INTERFACE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1
MAGNETIC STRIPE READER . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 2
READER SPECIFICATION . . . . . . . . . . . . . . . . . . . . . . . . 6 - 2
CARD DATA FORMAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 2
POWER CONSUMPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 3
MECHANICAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 3
ENVIRONMENTAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 3
RELIABILITY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . .6 - 3
APPLICABLE CONFORMITY . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 3
SERVICE AND SPARE PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . .7 - 1
iv
TM
1 - 1
TM
CHAP.
1
OVERVIEW
SCOPE
The KB-3100 series is a series of powerful programmable keyboard suitable
for application in both IBM PC compatible system and PS2 compatible system,
programmable without TSR under DOS, Windows 3.1 and also Windows95
environment. This series provides 112 keys (max.) of a comfortable size 18 x 22 mm
in 8 x 14 matrix and a 6 position control key which is capable of sending answer back
codes according to the position of the key.
FEATURES
•Powerful programming ability (hot key programming, programming under
Windows, multiple page, multiple level, whole range key content, time delay,
position sense answer back code, etc.)
•True spill proof structure
•Reliable and pleasant key click
•Comfortable key size
•Alternative blank key, double key and quad key
•Optional preprinted numerical keys “0”, “00”, “.”, “1”to “9”
•Optional MSR (Magnetic Stripe Reader), soft dust cover
1 - 2
TM
CHAP.
1
MODEL NUMBERS
MODEL # DESCRIPTION
KB3100 Standard model (8 KB non-volatile memory)
KB3100M2 Keyboard with 2 tracks ISO7811 MSR (tracks 1 & 2)
KB3100M3 Keyboard with 3 tracks ISO7811 MSR (tracks 1, 2 & 3)
KB3100MJ Keyboard with 2 tracks JIS II MSR (JIS I track 2 & JIS II)
2 - 1
TM
CHAP.
2
PACKAGE CONTENTS
•Programmable keyboard
•Key clip x 1 (mounted at bottom of the programmable keyboard)
•Accessory bag including:
⇒Cable CCBLA-055-2 x 1
⇒Legend sheet x 4
⇒Quad key w/key cap x 1
⇒Double key w/key cap x 2
⇒Control keys 4 pcs/set x 1 (set)
⇒Utility software diskette x 1
⇒User’s manual x 1
⇒Key cap (for single key) x 104
OPTION LIST
•MSR (ISO track 1 & 2, ISO track 1, 2 &3, or JIS I track 2 + JIS II) /pc
•Soft dust cover / pc
•Numerical keys (., 00, 0 to 9) /set (preprinting durability warranted)
•Quad key with key cap / set
•Double key with key cap / set
•Blank key / pc
•Single key top and key cap / set
2 - 2
TM
CHAP.
2
