SD-460Z/W
UPGRADE KIT
USER’S MANUAL
Rev.: Original
I. Features
ISO 7811 Magnetic Stripe Reader with USB interface
Dual directional operation for MSR
3 tracks type MSR reads AAMVA and CA DMV card
Textured front surface
Built-in Optical Finger Print Sensor
Side-mounted on KS-62/68/69/72/77 series (SD-460Z) or KS-66/73 series (SD-460W)
FCC NOTICE
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions manual, may cause
interference to radio communications. It has been tested and found to comply with limits for a Class A digital device pursuant to subpart J of Part 15 of FCC
Rules, which are designed to provide reasonable protection against interference when operated in a commercial environment. Operation of this equipment in a
residential area is likely to cause interference in which case the user at his own expense will be required to take whatever measures to correct the interference.
WARRANTY LIMITS
Warranty will terminate automatically when the equipment is opened by any person other than the authorized technicians. The user should consult his/her
dealer for the problem happened. Warranty voids if the user does not follow the instructions in application of this merchandise. The manufacturer is by no
means responsible for any damage or hazard caused by improper application.
The hardware utility program, including instructions for its use, is provided “AS IS” without warranty of any kind. Posiflex Technology, Inc. further disclaims
all implied warranties including without limitation any implied warranties of merchantability or of fitness for a particular purpose. the entire risk arising out of
the use or performance of the software and documentation remains with you.
ABOUT THIS MANUAL
This manual is written in an attempt with full strength to assist the user to utilize the upgrade kit SD-460Z/W for the Posiflex fan free touch
terminals KS
series. This series of products incorporate 2 delicately designed POS peripherals each can be used as an excellent tool to accommodate the required security
specially involved in POS business, kiosk and hospitality operation. This manual covers the conceptual and operational aspects of these units. For technical
aspects involving opening of the unit or option implementation, it is only available to the authorized distributors.
The manufacturer of the SD-460Z/W series heartily apologizes to the user for reserving the right to change or to modify this manual without notice due to the
rapid and constant progress and improvement on science and technology. The user may always obtain the most up to date information through any of our web
sites: http://www.posiflex.com or http://www.posiflex.com.tw.
Copyright Posiflex Technology Inc. 2012
All rights are strictly reserved. No part of this documentation may be reproduced, stored in a retrieval system, or transmitted in any form or by any means,
electronic, mechanical, photocopying, or otherwise, without the prior written consent of Posiflex Technology, Inc. the publisher of this documentation
TRADE MARKS AND SERVICE MARKS
POSIFLEX is a registered trademark of Posiflex Technology, Inc. an ISO-9001 and ISO-14001 certified manufacturer.
Other brand and product names are trademarks and registered trademarks and service marks of their respective owners.
II. Installation
1. Hardware Installation
1. Release the 2 screws on the back of the right side of the terminal to remove the
protective cover. Store the protective for future use.
2. Connect the cable found under the cover with the white connector inside SD-460.
3. Attach SD-460 to the terminal with the corresponding screw holes in alignment, and
then secure the 2 screws.
2. Driver Installation
1. MSR: The magnetic stripe reader connects to the host through USB port working as a USB
KB and also requires no driver installation except setting up the USB keyboard to be
enabled in system CMOS setup if the OS does not do it automatically. Refer to “Operation
Guide” for manipulation over the reader configuration.
2. Finger Print Sensor: To include the drivers for this sensor to perform finger print
registration or verification (authentication) in an AP requires the software programmer to
purchase and utilize its SDK (software developer’s kit). However, Posiflex delivers this
optical finger print sensor with its drivers. Please find in the mini CD delivered with SD-
460Z/W series except SD-460Z/W model or Product Information CD delivered with
Posiflex POS system the folder for “Posiflex Optical Finger Print Sensor”.
III. Operation Guide
1. Magnetic Stripe Reader
The MSR in SD-460Z/W series reads an ISO magnetic stripe card without driver. Yet, there
is a “MSR.EXE” program for SD-460Z/W model and a “Posiflex USB MSR Manager”
program for other model provided to control some parameter configuration for this MSR.
Through this program, you can enable/disable track, set up Alt+Num approach for ASCII
codes, and enable/disable Leading/Stop code. Please look for “USBMSR” and “SetUp” folders
in the mini CD delivered with SD-460Z/W or Product Information CD delivered with Posiflex
POS system to install the program or download it from our web site:
http://www.posiflex.com or http://www.posiflex.com.tw.
1
2
3
P/N: 19800902010
