3
Contents
1. Pump with 10 m
rubber cable (IP68),
Filter cover (2-piece)
& Handle
Safety regulations
The pump may only be used in garden ponds and similar water systems with no
persons in the water. Do not use in swimmingpools and other liquids than water.
Electrical installations must comply with applicable regulations. If in doubt,
consult an authorized electrician.
Before using the pump, make sure that the cable and plug have no visible damage.
The voltage on the nameplate must match your local power supply. The
pump must be connected to your power supply via a fault current protection
device with a breaking current of max. 30 mA. The electrical outlet must be
protected from water/moisture and must be located at least 2 meters from the
nearest water edge. Also make sure moisture/water cannot run along the cord
into the socket by making a "Drip Loop".
Before starting any work on the pump, unplug the power cord. For safety
reasons, the pump must only be repaired by the supplier. All unauthorized
intervention in the pump will void any warranty (this does not apply to regular
maintenance as specified in this manual).
The pump must not be used or handeled by children or persons who do not
understand how to use it.
Never lift or carry the pump in the cable.
Do not shorten or try to extend the cable. This will void any warranty.
2. Feet for vertical mounting
3. Universal connectors & gaskets
4. User manual
English
Technical data
Model 3000 5000 6500 8000 10000
Max head height 2,7 m 3,5 m 4,0 m 4,5 m 5,0 m
Flow l/h 3000 5000 6500 8000 10000
Energy
consumption 25 W 40 W 50 W 70 W 85 W
Inlet/outlet 1¼” 1¼” 1¼” 1½” 1½”
Hose adapter 19/25/32 19/25/32 19/25/32 19/25/32/40 19/25/32/40
Guarantee 3 year 3 year 3 year 3 year 3 year
Article no. 30320 30321 30322 30323 30324
A universal hose adapter up to 19-25-32 mm is included with all pumps
and 40 mm to 8000 and 10000.
