Polytel®GMA3
11-2520-2 October 2017 1
Polytel®GMA3TM
Glucose Meter Accessory
Model PWR-11-01
USER MANUAL
Version: 2
310 S. Williams Blvd. Ste. 230
Tucson, Arizona 85711
+1 (520) 747-1811
Mon-Fri 9AM-5PM MST
www.polymapwireless.com
Polytel®GMA3
11-2520-2 October 2017 2
Contents
1. Introduction...................................................4
1.1 Overview......................................................................4
1.2 Who is this for?............................................................5
1.3 Configurations ............................................................5
2 Parts of the GMA..........................................7
2.1 Visual indicators .........................................................7
2.2 Battery Compartment ...............................................10
2.3 Size of your GMA......................................................10
3 Operating Instructions ................................10
3.1 Changing the batteries .............................................10
3.2 Connecting the devices............................................12
3.3 Placement of the GMA and receiving station............14
3.4 Pairing .......................................................................15
3.5 How to use your GMA...............................................15
3.6 If the data was not sent ............................................19
3.7 Disconnected glucose meter....................................19
4 Safety Information ......................................21
4.1 Patient Safety...........................................................21
4.2 Electrical Safety.......................................................21
4.3 Compliance Information............................................22
5 Operator Maintenance................................24
5.1 Periodic Maintenance...............................................24
5.2 Cleaning your GMA .................................................24
6 Technical Specifications .............................25
6.1 Batteries ...................................................................25
6.2 Temperatures............................................................25
6.3 Compatibility with other electrical medical equipment..
Polytel®GMA3
11-2520-2 October 2017 3
25
6.4 System Availability....................................................26
7 Trademarks.................................................27
Polytel®GMA3
11-2520-2 October 2017 4
1. Introduction
1.1 Overview
Welcome to the world of wireless medical monitoring. In
this pamphlet, you will learn how to use and maintain your
Polytel® GMA Glucose Meter Accessory.
The GMA is an easy-to-use accessory that lets you send
the glucose readings you take with your glucose meter
wirelessly to a receiving station.
No more worrying about writing down the test results and
carrying them in to your doctor every visit—it is all done
automatically in your own home.
There are three parts to sending your readings wirelessly:
• You measure your glucose on the glucose meter.
• The GMA receives the reading from the meter and
sends it wirelessly to the phone or receiving station.
• The phone receives, stores, and sends your readings
to your service provider – often your doctor’s office
or a monitoring service. The receiving station is a
separate device that is either a cell phone, a self-
contained box, called an “access point,” or your
personal computer. Your monitoring service can
explain how to use the receiving station.
Polytel®GMA3
11-2520-2 October 2017 5
• To use the GMA, all you have to do is take the
reading using glucose meter as usual. For certain
meter models, removing the test strip will start the
data transmission; for others you may need to press a
button. Please see below for details
To make sure all data is sent to your provider, if the GMA
is unable to find a receiving station, it will save the reading
along with the date and time you took it. The old reading
will be sent along with the next reading.
1.2 Who is this for?
The GMA is intended for diabetic patients who want to
monitor their glucose levels remotely. It can be used by
patients in their homes and in their daily lives.
1.3 Configurations
The GMA is available in a number of different
configurations, which determine which glucose meters
are supported. Configurations are selected by inserting
the proper cable into the GMA: Cable must be firmly
inserted until flush.
Polytel®GMA3
11-2520-2 October 2017 6
• GMA3-LS for LifeScan meters using “LS” cable:
OneTouch®Ultra®
OneTouch®Ultra2®
OneTouch® UltraMini®
OneTouch®UltraEasy®
OneTouch®Select™
OneTouch®Basic™
• GMA3-BY for Bayer meters using “BY”
cable:
Contour®
Contour®TS
Contour®XT
Contour®Next EZTM
Breeze2®
• GMA3-AB for Abbott meters using “AB”
cable:
FreeStyle®Lite
FreeStyle®Freedom® Lite
GMA3-NI for Nipro meters using “NI”
cable:
TRUEresultTM
TRUEbalanceTM
TRUEtrackTM (with cradle)
TRUEmetrixTM (with cradle)
(Nipro cradle can be obtained directly from Trividia/Nipro)
Polytel®GMA3
11-2520-2 October 2017 7
GMA3-US for micro-USB type glucose
meters, using the “US” cable:
Accu-Chek®Aviva ConnectTM
2 Parts of the GMA
Your GMA is easy to maintain, set up and use.
The most important part to pay attention to is the indicator
light on the device. Different blinking patterns tell you
when the GMA is sending data, whether it was sent
successfully or not, and when it is time to change the
batteries.
2.1 Visual indicators
The GMA has small blue and red indicator lights in the
pushbutton that blink in different patterns when it is doing
different things.
Polytel®GMA3
11-2520-2 October 2017 8
Figure 1: Indicator light indicates status of the
GMA. It may appear as blue or red, depending
(see next page).
Polytel®GMA3
11-2520-2 October 2017 9
Here are the possible light patterns and their
meanings:
Light looks like Speed/Length It means...
Blue on
(no blinking) Up to 60
seconds GMA is getting data
from glucose meter
Blue blinking 1 blink per
second GMA connecting
to receiver. Please
wait.
Blue, solid steady on GMA retrieving data
from glucose meter
Blue, blinking 1 blink per
second GMA waiting for
connection from
phone
Blue, very fast
blinking 2 blinks per
second for
1-2 seconds
GMA connected
to phone, phone
retrieving data
Red and blue,
blinking 1 blink per
second GMA waiting for
connection from cell
phone, pairable
Red, very fast
blinking 2 blinks per
second for
10+ seconds
GMA connected to
phone, pairing.
Off N/A Successfully sent
data
Polytel®GMA3
11-2520-2 October 2017 10
2.2 Battery Compartment
You can open the battery compartment by sliding the lid on
the bottom open with your thumb.
Figure 2: battery lid
2.3 Size of your GMA
4.25 inches x 1.1 inches x 0.62 inches (108mm x 28mm x
16mm)
3 Operating Instructions
3.1 Changing the batteries
The GMA uses two alkaline AAA batteries that should last
a couple of months.
Tip: Your batteries will last longer if you remove them if
you will not be using the GMA for a month or longer.
It is time to change the batteries when the red light on the
GMA blinks fast immediately after waking up. Here is how
