Polygroup AR-P17008 Manuel utilisateur

ASSEMBLY INSTRUCTIONS MADE IN CHINA

Top view Side view

Fig. C

MODEL #: AR-P17008

1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.

2. Assemble the tree stand and place on a level surface. (See Fig. A)

TREE ASSEMBLY INSTRUCTIONS

3. Each tree section is numbered with a tag. Please identify all sections before assembling.

4. Assemble the tree from the bottom to the top.Start with the bottom section and remove protective cap

before inserting into the assembled stand.Make sure the pole is firmly inserted and secured into the stand.

5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.

6. Allow branches to fall into place or gently pull up and out.When adjusting branches, be sure that all

wires are free of branch hinges.

7. (For pre-lit trees only) Connect the light strings as per the color labels indicated in Fig. B and insert

green label plug into the wall outlet.Your entire tree should now be lit.If some bulbs do not light or

flickers, search for any loose plugs and/or broken, loose or missing bulbs. Replace bulbs promptly in

order to maintain the performance and life expectancy of your pre-lit tree.

8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from

the pole and fan out one to the right, one to the left and one at the center of the main stem. (see Fig. C)

Fig. B - Tree and Light Assembly *Electrical Rating For The Tree

(For Indoor Use Only)

Congratulations on purchasing your new tree from Polygroup®! Carefully follow the instructions

below on how to quickly and easily set up your new tree.

9. After shaping the entire tree following the previous step, slightly upsweep all branch tips for a uniform

look. Shift branches to fill any gaps.Your Christmas tree is now complete and ready to be decorated.

Section 2

Section 3

Section 1

Assemble

Red Labels

Together

Assemble

Blue Labels

Together

Assemble

Yellow Labels

Together

Insert

Green Label

Plug Into Wall

Outlet

Adaptor

To Be Plugged

Into Wall

Outlet

Insert Green

Label Extension

Cord into Adaptor

Assemble

Purple Labels

Together

Input:120V, 60Hz,0.16A

Output: 29V 0.28A 0.68A120V, 60Hz

Fig. A - Tree Stand Assembly

Unfold the legs and lay the

stand in a flat area.Then slide

the locking disc downward and

snap into place.

ASSEMBLY INSTRUCTIONS MADE IN CHINA

STORAGE INSTRUCTIONS

TROUBLE SHOOTING TIPS

SPARE PARTS

1. Remove all ornaments and decorations. For pre-lit trees, first unplug extension cord from the wall outlet

and then disconnect light extension cord between each section of the tree.

2. Disassemble the tree from the top to the bottom. Start with the tree top and gently lift straight up to

remove from section below and fold all branches toward the pole.

3. In case of difficulty separating the tree pole (trunk), apply a small amount of lubricant at the joint and

rotate the upper pole in both directions. Lift up the upper pole again.

4. Continue by gently lifting straight up each section(s) from the section below and fold all branches

toward the pole until the bottom section is removed from the tree stand.

5. Carefully place all tree sections into shipping box and tape it shut.

6. When not in use, please store your tree in a cool, dry place away from sunlight. Exposing your tree to

excessive heat or humidity may damage your tree.

For Pre-lit Trees, If The Tree Does Not Illuminate

1. Please check to make sure that all plugs are properly connected according to the color labels indicated

in Fig.B and the adaptor is firmly plug to the wall outlet. Refer to assembly guide for instructions. (If the

tree comes with a foot pedal, try stepping on the on/off button).

2. Check for loose connection between light string plugs and extension cords.

3. Please check for loose, broken or missing light bulbs and replace as needed.

Loose Hinge Pin

1. Extra hinge pins are included for repairing the hinges.Place the branch into the slot of the bracket.

2. Insert a new hinge pin through the hole and secure using the retainer washer. (See Fig. D)

Each tree includes hinge pins/washers, and for pre-lit

trees spare bulbs and fuse s are also included. If extra

parts are needed, please contact our customer service

center. Fig.D

WARNING

1. Use only power adaptor supplied with this product, using a different adaptor will damage the lights.

and cause fire, electrical shock hazards.

2. FOR INDOOR USE ONLY.

3. The external flexible cable or cord of this luminaire cannot be replaced; If the cord is damaged,

the luminaire shall be destroyed.

Press the selector button on the “Light Controller”

(1) STEADY GLOW (2) CHASER (3) SHUFFLE

(4) STARFIELD (5) RAY GUN (6) TWINKLE

(7) SPARKLE (8) 123-321 (9) SHIMMER (10) COMBO

HOW TO USE THE LIGHT CONTROLLER:

Light Controller

Selector

Button

IMPORTANT SAFETY INSTRUCTIONS

When using electrical products, basic precautions should always be followed including the following:

a. READ AND FOLLOW ALL SAFETY INSTRUCTIONS.

b. Do not use seasonal products outdoors unless marked suitable for indoor and outdoor use.When

products are used in outdoor applications, connect the product to a Ground Fault Circuit Interrupting ]

(GFCI) outlet. If one is not provided, contact a qualified electrician for proper installation.

c.This seasonal use product is not intended for permanent installation or use.

d. Do not mount or place near gas or electric heaters, fireplaces, candles or other similar sources of heat.

e. Do not secure the wiring of the product with staples or nails, or place on sharp hooks or nails.

f. Do not let lamps rest on the supply cord or on any wire.

g. Unplug the product when leaving the house, when retiring for the night, or if left unattended.

h.This is not a toy. For decorative use only! To avoid risk of fire, burns, personal injury and electric shock it

should not be played with or placed where small children can reach it.

i. Do not use this product for other than its intended use.

j. Do not hang ornaments or other objects from cord, wire, or light string.

k. Do not close doors or windows on the product or extension cords as this may damage wire insulation.

l. Do not cover the product with cloth, paper or any material not part of the product when in use.

m. Read and follow all instructions that are on the product or provided with the product.

n. The supply cord cannot be replaced. If the cord is damaged the appliance should be scrapped.

o. For led string only. Risk of fire.This product does not contain lamp shunts, which allow the product to

operate if one lamp burns out. Lamps are non-replaceble.

p. For led string only.To reduce the risk of fire or electric shock, Do not attempt to replace lamps or modify

string.

q. SAVE THESE INSTRUCTIONS.

CAUTION:

1. Risk of fire. Use only the power adapter provided with this product.

2. To reduce the risk of fire and electric shock:a) Do not install on trees having needles, leaves or branch

covering of metal or materials which look like metal, and b)Do not mount or support strings in a manner

that can cut or damage wire insulation.

3. To reduce the risk of fire and electric shock, use only the power supply that was provided with this

product.

ASSEMBLY INSTRUCTIONS MADE IN CHINA

CUSTOMER SERVICE FOR CHRISTMAS TREES

For any questions, assistance, or missing parts, Do Not Return To Place Of Purchase. Please contact

us at 1-888-919-0070 or visit our website at www.polygroup.com. One of our customer service

representatives will be happy to assist you.

TREE ID# IS LOCATED ON END PANEL OF BOX.TREE ID# IS REQUIRED WHEN REQUESTING REPLACEMENT PARTS.

Customer Name:

Address:(No P.O. Boxes)

City & State:

Zip Code:

Day Phone:

Date Purchased:

Tree ID#:

Tree UPC#:

Store Purchased:

Specify Problem:
