Polaroid PL808BM Manuel utilisateur
Boom All-Around Speaker
User Manual
PL808BM
2
Welcome
Welcome to your experience with Polaroid products.
All Polaroid products we bring to you are manufactured to the highest standards of performance and safety. As part of
our philosophy of customer service and satisfaction, your purchase is backed by a comprehensive 1 Year Warranty.
This user manual tells you all you need to know about setting up and using your new product.
Please take special note of any important safety and usage information presented with the symbol.
3
Contents
Welcome 2
Unpack and Prepare 4
Product Overview 5
Remote Control 7
Operation 9
Troubleshooting 12
Specications 13
Compliance and Responsible Disposal 14
4 | UNPACK AND PREPARE
Before setting up your new product, check you have everything:
A. Boom All-Around Speaker
B. Remote Control
C. Power Adaptor
D. Audio Cable
E. Warranty Certificate
F. General Safety Warnings
G. User Manual
Unpack and Prepare
What's in the box
H
EFG
D
C
EG
H
EFG
D
H
DEF
PRODUCT OVERVIEW | 5
Product Overview
Speaker Overview
Front Isometric View
Rear View
Control panel (see next page
for more information)
LED display screen
Woofers
Tweeters
LED lights
6 | PRODUCT OVERVIEW
DC IN 9V
Control Panel
Top View
1
2
3
4
5 6 7 8 9
10
11
12
13
8 MODE button/LED switch
9 AUX port
10 Charging light indicator
11 DC input
12 Microphone input jack
13 Power on/o/volume adjustment
1 Microphone volume adjustment
2 Echo volume adjustment
3 TF (Micro SD) card slot
4 USB port
5 /Previous button
6 /Play/Pause/TWS button
7 /Next button
REMOTE CONTROL | 7
Precautions When Using Batteries
• Do not use old and new batteries together.
• Do not use different types of batteries (e.g.
Manganese and Alkaline batteries) together.
• Remove the batteries from the remote if you do not
intend to use it for a long time.
• When discarding used batteries, follow any guidelines
for recycling and disposal of batteries that apply in
your local area.
• Keep batteries away from children and pets.
• Never throw batteries into a fire or expose them to
extreme heat.
Remote Control
Setup
Insert two AAA size batteries (not included) according to the polarity markings (+ / -) inside the compartment. Make
sure the batteries are correctly aligned and properly pushed into place.
8 | REMOTE CONTROL
Remote overview
AV IN
MIC
PRIOR
MODE : Switch between input modes
MUTE : Mute the sound. Press again to unmute
U/SD : Switch between USB/SD(TF) input modes
: Select next song/next FM channel
: Play/pause, auto scan FM channels
VOL +: Increase volume
(POWER) : Put the speaker on standby/on
NUMBER BUTTONS: Numerical input to
directly play a track.
EQ: Change the EQ mode
REP : Put the current song on repeat
: Select previous song/previous FM
channel
VOL -: Decrease volume
POWER
REP U/SD
OPERATION | 9
Operation
Charging and Power on
• Charging: plug in the supplied power adaptor to the DC input to charge the speaker for 3 hours before use.
During charging, the charging light indicator on the control panel will light up red. Once fully charged, the light
indicator will turn off.
• Power on: turn the power on/o/volume adjustment knob on the speaker or press the POWER button on the
remote control.
Control Panel Operations
• Use the and buttons to navigate between songs, use the button to play/pause.
• Use the VOLUME adjustment knob or the VOL-/VOL+ buttons on the remote control to adjust the volume
(set the volume to 0 to mute the sound).
• Use the MIC VOL knob to adjust the microphone volume (microphone not included) and the ECHO knob to
adjust the echo level.
• Use the MODE button to switch between the input modes. The LED display screen will show the current input
mode the speaker is on.
Battery Status
• You can view the battery status of the speaker on the LED display screen. When the battery is low, the battery
icon on the display screen will ash. Please plug in the supplied power adaptor to change the speaker.
LED Light
• The speakers have LED light on both the front and back. Press and hold the MODE/LED button to turn the
lights on/o.
10 | OPERATION
Bluetooth®Mode
• Press the MODE button on the speaker or remote control until Bluetooth®is selected;the LED display screen on the
speaker will flash "BLUE".
• On your smart phone, search for "PL808BM." If pairing is successful, the LED display screen will stop flashing "BLUE."
You can now play music from your smart phone.
• Press the button to play/pause music, and the /buttons on either the remote or speaker to select the
previous or next track.
Alternatively, you can control music playback from your smart phone.
AUX Mode
• Press the MODE button on the speaker or remote control until AUX is selected;the LED display screen will show "AUX".
• Use the supplied audio cable to connect your external device through the AUX port on the speaker.
USB Mode
• Press the MODE button on the speaker or remote control until USB is selected;the LED display screen on the speaker
will show "USB".
• Insert your USB device into the USB port on the speaker. The speaker will automatically play the les and will display
the play time on the LED display.
• Press the button to play/pause music, and the /buttons on either the remote or speaker to select the
previous or next track.
• Note: If a USB device is not inserted in the speaker, USB mode will not be available.
