Polar Electro UA025 Manuel utilisateur

Model • Modèle • Modell • Modello • Modelo • Malli:

UA025

Fridge/Freezer

Instruction manual

EN Fridge/Freezer

Handleiding

NL Koelkasten/vrieskasten

Handleiding

Réfrigérateur/congélateur

Mode d'emploi

DE Koelkast/Vriezer

Bedienungsanleitung

IT Frigorifero/Congelatore

Manuale di istruzioni

ES Frigorífico/Congelador

Manual de instrucciones

UA025_ML_A5_v1_20221121.indb 1UA025_ML_A5_v1_20221121.indb 1 2022/11/21 16:552022/11/21 16:55

Safety Instructions

• Position on a flat, stable surface.

• A service agent/qualified technician should carry out

installation and any repairs if required. Do not remove any

components or service panels on this product.

• Consult Local and National Standards to comply with the

following:

- Health and Safety at Work Legislation

- BS EN Codes of Practice

- Fire Precautions

- IEE Wiring Regulations

- Building Regulations

• DO NOT use jet/pressure washers to clean the appliance.

• DO NOT use the appliance outside.

• DO NOT use this appliance to store medical supplies.

• DO NOT stand or support yourself on the base, drawers or

doors.

• DO NOT allow oil or fat to come into contact with the plastic

components or door seal. Clean immediately if contact occurs.

• Bottles that contain a high percentage of alcohol must be

sealed and placed vertically in the refrigerator.

• Always carry, store and handle the appliance in a vertical

position and move by holding the base of the appliance.

• Always switch off and disconnect the power supply to the unit

before cleaning.

• Keep all packaging away from children. Dispose of the

packaging in accordance with the regulations of local

authorities.

• If the power cord is damaged, it must be replaced by a POLAR

agent or a recommended qualified technician in order to avoid

a hazard.

UA025_ML_A5_v1_20221121.indb 2UA025_ML_A5_v1_20221121.indb 2 2022/11/21 16:552022/11/21 16:55

• POLAR recommend that this appliance should be periodically

tested (at least annually) by a Competent Person. Testing

should include, but not be limited to: Visual Inspection,

Polarity Test, Earth Continuity, Insulation Continuity and

Functional Testing.

• POLAR recommend that this product is connected to a circuit

protected by an appropriate RCD (Residual Current Device).

Caution: Risk of Fire

• Do not store explosive substances such as aerosol cans

with a flammable propellant in this appliance.

Warning: Keep all ventilation openings clear of

obstruction. Unit should not be boxed in without

adequate ventilation.

• Warning: Do not use mechanical devices or other means

to accelerate the defrosting process, other than those

recommended by the manufacturer.

• Warning: Do not damage the refrigerant circuit.

• Warning: Do not use electrical appliances inside the food

storage compartments of the appliance.

Introduction

Please take a few moments to carefully read through this manual. Correct maintenance and operation of

this machine will provide the best possible performance from your POLAR product.

Pack Contents

The following is included:

• Fridge/Freezer

• Keys

• Shelves

• Instruction manual

POLAR prides itself on quality and service, ensuring that at the time of unpacking the contents are

supplied fully functional and free of damage.

Should you find any damage as a result of transit, please contact your POLAR dealer immediately.

UA025_ML_A5_v1_20221121.indb 3UA025_ML_A5_v1_20221121.indb 3 2022/11/21 16:552022/11/21 16:55

Installation

Note: Not for use in vans or trailers, food

trucks or similar vehicles.

Note: If the unit has not been stored or

moved in an upright position, let it stand

upright for approximately 12 hours before

operation. If in doubt allow to stand.

1. Remove the appliance from the packaging.

Make sure that all protective plastic film and

coatings are thoroughly removed from all

surfaces.

2. To optimize performance and longevity, ensure

a minimum clearance of 2.5cm is maintained

between the unit and walls and other objects,

with a minimum 20cm clearance on the top.

NEVER LOCATE NEXT TO A HEAT SOURCE.

Note: Before using the appliance for the

first time, clean the shelves and interior

with soapy water then dry well.

3. Set the brakes on the castors to keep the

appliance in position.

Removing the Compressor Safety

Band

• The compressor is located on the top of the

appliance, and sits on rubber washers. Under

normal operating conditions the compressor is

allowed to vibrate.

• To avoid damage through excessive motion

during transit, a stainless steel safety band is

placed over the compressor and screwed into

the top of the appliance.

• This safety band and the two screws fixing it

to the appliance must be removed before the

appliance is turned on.

Compressor

Safety Band

Compressor

Screws

Lock/Unlock the Doors

A lock is fitted to the doors to ensure foodstuffs

are kept secure within your POLAR appliance.

Use the keys provided to lock/unlock the doors.

• There is a catch on the top of the lower door.

When it is rotated to the left position, only the

upper door is locked.

Catch on the lower door

• To lock both doors, rotate the catch to the right

position, then close the lower door and upper

door consecutively.

Catch on the lower door

Fitting the Shelves & Floor Guards

1. Place one set of shelf guides on either side of

the cabinet at the desired height.

2. Slide the shelf into place.

3. Repeat for the remaining shelves.

4. Place the floor guards on the floor of the

cabinet, ensuring the flat side is clear of the

floor.

Note: This is vital for ensuring correct

drainage of condensation. If this is done

incorrectly, your appliance may get wet

and/or freeze on the bottom. In the event

of a complaint, this is not covered by the

warranty.

UA025_ML_A5_v1_20221121.indb 4UA025_ML_A5_v1_20221121.indb 4 2022/11/21 16:552022/11/21 16:55

Operation

Storing Food

To get the best results from your POLAR appliance, follow these instructions:

• Only store foodstuffs in the appliance when it has reached the correct operating temperature.

• Do not place uncovered items as below inside the appliance, as this can lead to a damaged and

leaking evaporator, and thus void your warranty: hot food, hot liquids, acidic fluids, acidic products.

• Wrap or cover food where possible.

• Do not obstruct the fans inside the appliance.

• Avoid opening the doors for prolonged periods of time.

Turn On

1. Ensure the power switch is set to [O] and turn on at the socket.

2. Switch on the Power [I]. The current temperature within the appliance is displayed.

Control Panel

For upper compartment For lower compartment

To unlock / Lock the keyboard press and together for 3 seconds. Display will flash PON

(unlocked) / POF (locked).

Set the Operating Temperature

1. Press the SET button for 3 seconds. The display will flash.

2. Press the or buttons to display the required temperature.

3. Press the SET button to store the temperature.

Manual Defrost

Press and hold the defrost button “aux” for 2 seconds to begin a manual defrost. The defrost light

illuminates.

Cleaning, Care & Maintenance

• Defrost appliance at least every 3 months, more often if required.

• Switch off and disconnect from the power supply before cleaning.

• Clean the interior of the appliance as often as possible.

• Do not use abrasive cleaning agents. These can leave harmful residues.

• Clean the door seal with warm soapy water.

• Always wipe dry after cleaning.

• Do not allow water used in cleaning to run through the drain hole into the evaporation pan.

• Take care when cleaning the rear of the appliance. Sharp edges can cut.

Condensation and ice will form with frequent and prolonged opening of the doors.

Operating outside of the recommend temperature range and placing next to a heat source will also

increase the amount of ice and condensation.

Excessive ice will result in longer running times that will increase energy consumption and increase the

deterioration of components.

UA025_ML_A5_v1_20221121.indb 5UA025_ML_A5_v1_20221121.indb 5 2022/11/21 16:552022/11/21 16:55

Stainless Steel Care

To maintain the stainless steel exterior of your Polar item, please consider the following information:

Never:

• Use abrasive Scourers or scrubbing pads, etc.

• Use Chlorinated or acidic detergents

• Allow anything e.g. food, dirt, cleaning chemicals to remain on the surface for longer than necessary,

clean them off right away.

• Allow the surface to remain wet.

Do:

• Clean often.

• Use soft Cloths or plastic Scourers.

• Rub with the grain of the metal, rather than across it.

• Use detergents and polish designed for cleaning Stainless Steel.

• Ensure that the cleaning products are washed off fully and that the steel is left dry.

Routine Maintenance - Cleaning the Condensers

• The condenser is part of the refrigeration

system. The condenser requires monthly

cleaning.

• Always disconnect power supply before carrying

out Routine Maintenance.

• Failure to clean the condenser will reduce the

performance and life of your Polar unit and may

invalidate your warranty.

• The condenser is located above the refrigeration

cabinet. This appliance has 2 sets of condenser

and removable filter (which can be cleaned with

a vacuum cleaner).

Technical Specifications

Note: Due to our continuing program of research and development, the specifications herein may subject

to change without notice.

Model Voltage Power Current Dimensions H x W x D mm Weight (kg)

UA025 220-240V~ 50Hz 600W 3,5A 2000 x 680 x 810 150

Compartment Temp. Range Net usable capacity (Ltr) Gross Volume (Ltr) Refrigerant

Upper 2°C ~ 8°C 165 195 R600a

Lower -18°C ~ -22°C 153 183 R290

Note: For optimal product performance and efficiency, please ensure to mind the net usable capacity (load

limit) when filling.

UA025_ML_A5_v1_20221121.indb 6UA025_ML_A5_v1_20221121.indb 6 2022/11/21 16:552022/11/21 16:55

Troubleshooting

A qualified technician must carry out repairs if required.

Fault Probable Cause Solution

The appliance is not

working The unit is not switched on Check unit is plugged in correctly and

switched on

Plug or lead is damaged Replace plug or lead

Fuse in the plug has blown Replace the fuse

Mains power supply fault Check mains power supply

The appliance turns on,

but the temperature is

too high/low

Too much ice on the evaporator Defrost the appliance

Condenser blocked with dust Clean the Condenser

Doors are not shut properly Check doors are shut and seals are not

damaged

Appliance is located near a

heat source or air flow to the

condenser is being interrupted

Move the refrigerator to a more suitable

location

Ambient temperature is too high Increase ventilation or move appliance to a

cooler position

Unsuitable foodstuffs are being

stored in the appliance Remove any excessive hot foodstuffs or

blockages to the fan

Appliance is overloaded Reduce the amount of food stored in the

appliance

The appliance is

leaking water The appliance is not properly

levelled Adjust the screw feet to level the appliance

(if applicable)

The discharge outlet is blocked Clear the discharge outlet

Movement of water to the drain is

obstructed Clear the floor of the appliance (if

applicable)

The water container is damaged Call POLAR agent or qualified Technician

The drip tray is overflowing Empty the drip tray (if applicable)

The appliance is

unusually loud The safety band has not been

removed Remove the safety band

Loose nut/screw Check and tighten all nuts and screws

The appliance has not been

installed in a level or stable

position

Check installation position and change if

necessary

UA025_ML_A5_v1_20221121.indb 7UA025_ML_A5_v1_20221121.indb 7 2022/11/21 16:552022/11/21 16:55

Electrical Wiring

POLAR appliances are supplied with a 3 pin BS1363 plug and lead.

The plug is to be connected to a suitable mains socket.

POLAR appliances are wired as follows:

• Live wire (coloured brown) to terminal marked L

• Neutral wire (coloured blue) to terminal marked N

• Earth wire (coloured green/yellow) to terminal marked E

This appliance must be earthed.

If in doubt consult a qualified electrician.

Electrical isolation points must be kept clear of any obstructions. In the event of any emergency

disconnection being required they must be readily accessible.

Disposal

EU regulations require refrigeration product to be disposed of by specialist companies who remove or

recycle all gasses, metal and plastic components.

Consult your local waste collection authority regarding disposal of your appliance. Local authorities are

not obliged to dispose of commercial refrigeration equipment but may be able to offer advice on how to

dispose of the equipment locally.

Alternatively call the POLAR helpline for details of national disposal companies within the EU.

Compliance

The WEEE logo on this product or its documentation indicates that the product must

not be disposed of as household waste. To help prevent possible harm to human

health and/or the environment, the product must be disposed of in an approved and

environmentally safe recycling process. For further information on how to dispose of

this product correctly, contact the product supplier, or the local authority responsible for

waste disposal in your area.

POLAR parts have undergone strict product testing in order to comply with

regulatory standards and specifications set by international, independent,

and federal authorities.

POLAR products have been approved to carry the following symbol:

mechanical, photocopying, recording or otherwise, without the prior written permission of POLAR.

Every effort is made to ensure all details are correct at the time of going to press, however, POLAR reserve the right to

change specifications without notice.

UA025_ML_A5_v1_20221121.indb 8UA025_ML_A5_v1_20221121.indb 8 2022/11/21 16:552022/11/21 16:55

Veiligheidstips

• Plaatsen op een vlakke en stabiele ondergrond.

• De installatie en eventuele reparaties zijn door een

servicetechnicus/vaktechnicus uit te voeren. Verwijder geen

componenten of servicepanelen van dit product.

• Raadpleeg en volg de plaatselijke en nationale regelgeving op

m.b.t. tot het volgende:

- Wetgeving van gezondheid en veiligheid op de werkplaats

- Werkregels

- Brandpreventie

- IEE bekabelingsnormen

- Bouwverordeningen

• Dit product NIET reinigen met spuit-/drukreinigers.

• Uitsluitend geschikt voor gebruik binnenshuis.

• Dit product NIET gebruiken voor de berging van medische

producten.

• NIET op de kastbasis, lades en deuren staan of als

ondersteuning gebruiken.

• Laat NIET toe dat olie of vet in contact komt met plastic

componenten of deurafdichtingen. Onmiddellijk reinigen indien

dit wel gebeurt.

• Flessen met een hoog alcoholpercentage moeten goed worden

gesloten en verticaal in de koelkast worden bewaard.

• Dit product altijd in een verticale positie vervoeren, opbergen

en gebruiken. Het product aan de kastbasis vervoeren.

• Alvorens dit product te reinigen dient men altijd de

stroomvoorziening uit te schakelen.

• Laat verpakkingsmateriaal niet binnen handbereik van

kinderen. Verpakkingsmateriaal in overeenstemming met

de regelgeving van de plaatselijke overheden als afval laten

verwerken.

UA025_ML_A5_v1_20221121.indb 9UA025_ML_A5_v1_20221121.indb 9 2022/11/21 16:552022/11/21 16:55

• Indien de stroomkabel beschadigd raakt, dient men deze door

een Polar technicus of een aanbevolen vaktechnicus te laten

vervangen om gevaarlijke situaties te verhinderen.

• Polar beveelt aan dat dit apparaat periodiek (minstens

jaarlijks) door een bevoegd persoon wordt getest. Tests

moeten omvatten, maar zijn niet beperkt tot: visuele inspectie,

polariteit, aardings continuïteit (klasse I-apparatuur), isolatie

continuïteit en functionele test.

Voorzichtig: Risico bij open Vuur

• Bewaar geen explosieve stoffen zoals spuitbussen met een

ontvlambaar drijfgas in dit apparaat.

Waarschuwing:

Hou alle ventilatieopeningen vrij

van obstakels. De eenheid mag niet ingesloten

worden zonder geschikte ventilatie.

• Waarschuwing: mechanische apparaten of andere

middelen niet gebruiken om het ontdooien te versnellen, met

uitzondering van de door de fabrikant aanbevolen middelen.

• Waarschuwing: het koelcircuit niet beschadigen.

• Waarschuwing: Gebruik geen elektrische apparaten in de

bewaarruimten van het apparaat.

Inleiding

Neem de tijd en lees deze handleiding aandachtig door. Een correct gebruik en onderhoud van deze

machine waarborgt de beste prestaties voor uw Polar product.

Verpakkingsinhoud

De verpakking bevat het volgende:

• Koelkasten/vrieskasten

• Sleutels

• Lades

• Handleiding

POLAR gaat prat op kwaliteit en service en zorgt ervoor dat bij het uitpakken de inhoud volledig

functioneel en schadevrij wordt geleverd.

Mocht uw product door transport zijn beschadigd, neem dan onmiddellijk contact op met uw Polar dealer.

UA025_ML_A5_v1_20221121.indb 10UA025_ML_A5_v1_20221121.indb 10 2022/11/21 16:552022/11/21 16:55

Table des matières

Langues :

Autres manuels Polar Electro Réfrigérateur

Polar Electro

Polar Electro G592 Manuel utilisateur

Polar Electro

Polar Electro FA440-A Manuel utilisateur

Polar Electro

Polar Electro GL178-A Manuel utilisateur

Polar Electro

Polar Electro GD881 Manuel utilisateur

Polar Electro

Polar Electro CD080-A Manuel utilisateur

Polar Electro

Polar Electro GH261 Manuel utilisateur

Polar Electro

Polar Electro CD239 Manuel utilisateur

Polar Electro

Polar Electro G604 Manuel utilisateur

Polar Electro

Polar Electro G Series Manuel utilisateur

Polar Electro

Polar Electro CN267 Manuel utilisateur

Polar Electro

Polar Electro CE322 Manuel utilisateur

Polar Electro

Polar Electro DB109-A Manuel utilisateur

Polar Electro

Polar Electro Deli CG841-A Manuel utilisateur

Polar Electro

Polar Electro GL180-A Manuel utilisateur

Polar Electro

Polar Electro CD610 Manuel utilisateur

Polar Electro

Polar Electro U636-A Manuel utilisateur

Polar Electro

Polar Electro GJ447 Manuel utilisateur

Polar Electro

Polar Electro DM075-A Manuel utilisateur

Polar Electro

Polar Electro CM287 Manuel utilisateur

Polar Electro

Polar Electro G590/G591/G592/G593/G594/G595/U632/U633/U634/U635/CC663/CD616/GD879/GD880/ Manuel utilisateur

Polar Electro

Polar Electro UA005 Manuel utilisateur

Polar Electro

Polar Electro G Series Manuel utilisateur

Polar Electro

Polar Electro CD080-A Manuel utilisateur

Polar Electro

Polar Electro G608 Manuel utilisateur

Manuels Réfrigérateur populaires d'autres marques

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuel utilisateur

Sharp

Sharp SJ-BA31IEXW2-EU Manuel utilisateur

CORBERO

CORBERO CC2300MCW Manuel utilisateur

KitchenAid

KitchenAid 2205264 Manuel utilisateur

Stengel

Stengel KU 1101 A++ Manuel utilisateur

NEFF

NEFF KI181 Series Manuel utilisateur

Hoshizaki

Hoshizaki Reach-In Manuel utilisateur

Amana

Amana ASD2524VES00 Manuel utilisateur

BOMANN

BOMANN KGC 213 Manuel utilisateur

Danby

Danby DAR044A1SLDD Instructions de montage

Samsung

Samsung RF323TE Manuel utilisateur

Beko

Beko CSA31022 Manuel utilisateur

IKEA

IKEA FROSTIG C 185 E Manuel utilisateur

Electrolux

Electrolux ER 6821 D Manuel utilisateur

True

True TS-28 Manuel utilisateur

Frigidaire

Frigidaire FSC23R5DW9 Manuel utilisateur

Beko

Beko LSP4579W Manuel utilisateur
