Polar Electro FA854-A Manuel utilisateur

Model:

FA854-A/FA855-A/FA856-A/FA857-A/DA680-A/

AB090-A

Stainless Steel Counter

Top Servery/Prep

Refrigerators

Instruction manual

FA854-A to FA857-A_DA680-A_AB090-A_A5_v1_20210616.indb 1FA854-A to FA857-A_DA680-A_AB090-A_A5_v1_20210616.indb 1 2021/6/16 17:282021/6/16 17:28

AU Telephone Helpline: 1300225960

Safety Tips

• Position on a flat, stable surface.

• A service agent/qualified technician should carry out

installation and any repairs if required. Do not remove any

components or service panels on this product.

• Consult Local and National Standards to comply with the

following:

- Health and Safety at Work Legislation

- Fire Precautions

- Wiring Regulations

- Building Regulations

• DO NOT use jet/pressure washers to clean the appliance.

• DO NOT use the appliance outside.

• DO NOT use this appliance to store medical supplies.

• Always carry, store and handle the appliance in a vertical

position and move by holding the base of the appliance.

• Always switch off and disconnect the power supply to the unit

before cleaning.

• Keep all packaging away from children. Dispose of the

packaging in accordance with the regulations of local

authorities.

• If the power cord is damaged, it must be replaced by a POLAR

agent or a recommended qualified technician in order to avoid

a hazard.

• This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities,

or lack of experience or knowledge, unless they have been

given supervision or instruction concerning the use of the

appliance by a person responsible for their safety.

• Polar recommend that this appliance should be periodically

tested (at least annually) by a Competent Person. Testing

should include, but not be limited to: Visual Inspection,

Polarity Test, Earth Continuity, Insulation Continuity and

Functional Testing.

FA854-A to FA857-A_DA680-A_AB090-A_A5_v1_20210616.indb 2FA854-A to FA857-A_DA680-A_AB090-A_A5_v1_20210616.indb 2 2021/6/16 17:282021/6/16 17:28

AUAU

Telephone Helpline: 1300225960

Caution Risk of Fire

• Do not store explosive substances such as aerosol cans

with a flammable propellant in this appliance.

Warning: Keep all ventilation openings clear of

obstruction. Unit should not be boxed in without

adequate ventilation.

• Warning: Do not use mechanical devices or other means

to accelerate the defrosting process, other than those

recommended by the manufacturer.

• Warning: Do not damage the refrigerant circuit.

• Warning: Do not use electrical appliances inside the food

storage compartments of the appliance, unless they are the

type recommended by the manufacturer.

Introduction

Please take a few moments to carefully read through this manual. Correct maintenance and operation of

this machine will provide the best possible performance from your POLAR product.

Pack Contents

The following is included:

• POLAR Refrigerator

• Instruction manual

• Gastranorm spacer bar

• Adjustable feet x 4

• Fixings (for AB090-A)

POLAR prides itself on quality and service, ensuring that at the time of packaging the contents are

supplied fully functional and free of damage.

Should you find any damage as a result of transit, please contact your POLAR dealer immediately.

Installation

Note: If the unit has not been stored or moved in an upright position, let it stand

upright for approximately 12 hours before operation. If in doubt allow to stand.

1. Remove the appliance from the packaging. Make sure that all protective plastic film and coatings are

thoroughly removed from all surfaces.

2. To optimize performance and longevity, ensure a minimum clearance of 2.5cm is maintained between

the unit and walls and other objects, with a minimum 5cm clearance on the top. NEVER LOCATE

NEXT TO A HEAT SOURCE.

Note: Before using the appliance for the first time, clean the interior with soapy water.

• Level the appliance by adjusting the screw feet.

FA854-A to FA857-A_DA680-A_AB090-A_A5_v1_20210616.indb 3FA854-A to FA857-A_DA680-A_AB090-A_A5_v1_20210616.indb 3 2021/6/16 17:282021/6/16 17:28

AU Telephone Helpline: 1300225960

Fit Glass Panels (for AB090-A only)

1. Screw the collars to the rim of the appliance.

Note: Ensure the hole in the

collar for the grub screw faces

inwards.

2. Slot the two side panels into the collars, with

the holes in the glass at the top.

Note: Ensure the screw hole

furthest from the edge of the

panel goes to the back of the

appliance.

3. Screw a grub screw into each collar to secure

the panels.

Note: Ensure the soft end of the grub screw

is the end making contact with the glass.

Do not over-tighten the grub screws as it

will result in the glass breaking.

4. Slot the rear panel into the collars, with the

holes in the glass at the top.

5. Screw a grub screw into each collar to secure

the panel.

6. Slot the plastic plugs into each of the holes.

7. Screw the brackets to the inside of each pane

using the bolt assemblies.

Note: Ensure the short end of the bolt

assembly is on the outside of the panels.

8. Place the top panel onto the brackets, ensuring

all holes line up.

9. Insert the plugs and attach the top panel to

the brackets with the bolt assembly.

Bracket

Glass Panel

Bolt Assembly

Plug

Bolt Assembly

Operation

Storing Food

To get the best results from your POLAR appliance,

follow these instructions:

• Only store foodstuffs in the appliance when it

has reached the correct operating temperature.

• Ensure gastronorm bays are full at all times,

even if the gastronorms are unused or empty.

Empty bays will greatly reduce efficiency of the

appliance.

• Use the spacer bars provided to fill any gaps

(they are not required to support each GN

pans).

• Do not obstruct the fans inside the appliance.

• Always cover the pan with lid when not in use.

• Do not place hot food or liquid inside the

appliance.

Note: The appliance is not intended for the

long term storage of food.

Turn On

1. Ensure the power switch is set to [O] and turn

on at the socket.

2. Switch on the power switch [I]. The current

temperature within the appliance is displayed.

Set the Operating Temperature

1. Press the SET button for 3 seconds. The

display will flash.

2. Press the or buttons to display the

required temperature.

3. Press the SET button to store the temperature.

Manual Defrost

Press and hold the defrost button “aux” for 2

seconds to begin a manual defrost. The defrost

light illuminates.

FA854-A to FA857-A_DA680-A_AB090-A_A5_v1_20210616.indb 4FA854-A to FA857-A_DA680-A_AB090-A_A5_v1_20210616.indb 4 2021/6/16 17:282021/6/16 17:28

AUAU

Telephone Helpline: 1300225960

Cleaning, Care & Maintenance

• Switch off and disconnect from the power supply before cleaning.

• Clean the interior of the appliance as often as possible.

• Do not use abrasive cleaning agents. These can leave harmful residues.

• Clean the door seal with warm soapy water.

• Always wipe dry after cleaning.

• Do not allow water used in cleaning to run through the drain hole into the evaporation pan.

• Take care when cleaning the rear of the appliance. Sharp edges can cut.

• A POLAR agent or qualified technician must carry out repairs if required.

Cleaning the Condenser Filter

• The condenser is part of the refrigeration system. The

condenser filter requires monthly cleaning.

• Always disconnect power supply before carrying out Routine

Maintenance.

• Failure to clean the condenser filter will reduce the

performance and life of your Polar unit and may invalidate

your warranty.

• These models have a removable filter which can be cleaned

with a vacuum cleaner.

Troubleshooting

If your POLAR appliance develops a fault, please check the following table before making a call to the

Helpline or your POLAR dealer.

Fault Probable Cause Solution

The appliance is not

working

The unit is not switched on Check the unit is plugged in correctly and

switched on

Plug or lead is damaged Call POLAR agent or qualified Technician

Power supply Check power supply

The appliance turns on,

but the temperature is

too high/low

Too much ice on the evaporator Defrost the appliance

Condenser blocked with dust Clean the Condenser

Doors are not shut properly Check doors are shut and seals are not

damaged

Appliance is located near a

heat source or air flow to the

condenser is being interrupted

Move the appliance to a more suitable

location

Ambient temperature is too high Increase ventilation or move appliance to a

cooler position

Unsuitable foodstuffs are being

stored in the appliance

Remove any excessive hot foodstuffs or

blockages to the fan

Appliance is overloaded Reduce the amount of food stored in the

appliance

The appliance is

leaking water

The appliance is not properly

levelled

Adjust the screw feet to level the appliance

(if applicable)

The discharge outlet is blocked Clear the discharge outlet

FA854-A to FA857-A_DA680-A_AB090-A_A5_v1_20210616.indb 5FA854-A to FA857-A_DA680-A_AB090-A_A5_v1_20210616.indb 5 2021/6/16 17:282021/6/16 17:28

AU Telephone Helpline: 1300225960

Fault Probable Cause Solution

The appliance is

leaking water

Movement of water to the drain is

obstructed

Clear the floor of the appliance (if

applicable)

The water container is damaged Call POLAR agent or qualified Technician

The drip tray is overflowing Empty the drip tray (if applicable)

The appliance is

unusually loud

Loose nut/screw Check and tighten all nuts and screws

The appliance has not been installed

in a level or stable position

Check installation position and change if

necessary

Technical Specifications

Model Voltage Power Current Temperature

Range Capacity Refrigerant Dimensions

H x W x D mm

Weight

(kg)

FA854-A 230V 50Hz 110W 0.8A 2°C - 8°C 5 x gastronorm 1/4

Container

R600a 45g 330 x 1240 x 375 25

FA855-A 230V 50Hz 110W 0.8A 2°C - 8°C 7 x gastronorm 1/4

Container

R600a 45g 330 x 1540 x 375 29

FA856-A 230V 50Hz 122W 0.8A 2°C - 8°C 8 x gastronorm 1/4

Container

R600a 45g 330 x 1840 x 375 32

FA857-A 230V 50Hz 122W 0.8A 2°C - 8°C 10 x gastronorm 1/4

Container

R600a 45g 330 x 2040 x 375 34

DA680-A 230V 50Hz 110W 0.8A 2°C - 8°C 6 x gastronorm 1/4

Container

R600a 45g 330 x 1440 x 375 27

AB090-A 230V 50Hz 110W 0.8A 2°C - 8°C 6 x gastronorm 1/4

Container

R600a 45g 280 x 1440 x 375 27

Electrical Wiring

The plug is to be connected to a suitable mains socket.

POLAR appliances are wired as follows:

• Live wire (coloured brown) to terminal marked L

• Neutral wire (coloured blue) to terminal marked N

• Earth wire (coloured green/yellow) to terminal marked E

This appliance must be earthed.

If in doubt consult a qualified electrician.

Electrical isolation points must be kept clear of any obstructions. In the event of any emergency

disconnection being required they must be readily accessible.

Compliance

The product must not be disposed of as household waste. To help prevent possible harm to human

health and/or the environment, the product must be disposed of in an approved and environmentally safe

recycling process. For further information on how to dispose of this product correctly, contact the product

supplier, or the local authority responsible for waste disposal in your area.

POLAR parts have undergone strict product testing in order to comply with regulatory

standards and specifications set by international, independent, and federal authorities.

POLAR products have been approved to carry the following symbol:

recording or otherwise, without the prior written permission of POLAR.

Every effort is made to ensure all details are correct at the time of going to press, however, POLAR reserve the right to change specifications without

notice.

FA854-A to FA857-A_DA680-A_AB090-A_A5_v1_20210616.indb 6FA854-A to FA857-A_DA680-A_AB090-A_A5_v1_20210616.indb 6 2021/6/16 17:282021/6/16 17:28

DECLARATION OF CONFORMITY

• Conformiteitsverklaring • Déclaration de conformité • Konformitätserklärung • Dichiarazione di conformità •

• Declaración de conformidad • Declaração de conformidade

Equipment Type • Uitrustingstype • Type d'équipement • Gerätetyp

• Tipo di apparecchiatura • Tipo de equipo • Tipo de equipamento

Model • Modèle • Modell • Modello

• Modelo • Malli

G-Series Countertop Prep Fridge

5 x ¼ GN

6 x ¼ GN

7 x ¼ GN

8 x ¼ GN

10 x ¼ GN

(with stainless steel lids:)

5 x ¼ GN

6 x ¼ GN

7 x ¼ GN

8 x ¼ GN

10 x ¼ GN

3 x 1/3 GN & 1 x ½ GN

5 x 1/3 GN & 1 x ½ GN

8 x 1/3 GN

9 x 1/3 GN

G608 (& -E -A)

AB090 (& -E -A)

G609 (& -E -A)

G610 (& -E -A)

G611 (& -E -A)

FA854 (& -E -A)

DA680 (& -E -A)

FA855 (& -E -A)

FA856 (& -E -A)

FA857 (& -E -A)

GD875 (& -E -A)

GD876 (& -E -A)

GD877 (& -E -A)

GD878 (& -E -A)

Application of Territory

Legislation & Council

Directives(s)

Toepassing van Europese

Richtlijn(en) • Application de

la/des directive(s) du Conseil

• Anwendbare EU-

Richtlinie(n) • Applicazione

delle Direttive

• Aplicación de la(s)

directiva(s) del consejo •

Aplicação de directiva(s) do

Conselho

Machinery Directive 2006/42/EC

EN 60335-1:2012 +A11:2014 +A13:2017

EN 60335-2-89:2010 +A1:2016 +A2:2017

EN 62233:2008

Electro-Magnetic Compatibility (EMC) Directive

2014/30/EU - recast of 2004/108/EC

EN 55014-1:2017

EN 55014-2:2015

EN 61000-3-2: 2014

EN 61000-3-3: 2013

Restriction of Hazardous Substances Directive (RoHS)

2015/863 amending Annex II to Directive 2011/65/EU

Electrical Safety

IEC 60335-1:2010 +A1:2013 +A2:2016

IEC 60335-2-89:2010 +A1:2012 +A2:2015

Electromagnetic Compatibility

EN 55014-1:2017

EN 55014-2:2015

EN 61000-3-2: 2014

EN 61000-3-3: 2013

Producer Name • Naam fabrikant • Nom du producteur • Name des Herstellers

• Nome del produttore • Nombre del fabricante • Nome do fabricante

Polar

I, the undersigned, hereby declare that the equipment specified above conforms to the above Territory Legislation, Directive(s) and

Standard(s).

Ik, de ondergetekende, verklaar hierbij dat de hierboven gespecificeerde uitrusting goedgekeurd is volgens de bovenstaande Richtlijn(en)

en Standaard(en).

Je soussigné, confirme la conformité de l'équipement cité dans la présente à la / aux Directive(s) et Norme(s) ci-dessus

Ich, der/die Unterzeichnende, erkläre hiermit, dass das oben angegebene Gerät der/den oben angeführten Richtlinie(n) und Norm(en)

entspricht.

Il sottoscritto dichiara che l'apparecchiatura di sopra specificata è conforme alle Direttive e agli Standard sopra riportati.

El abajo firmante declara por la presente que el equipo arriba especificado está en conformidad con la(s) directiva(s) y estándar(es) arriba

mencionadas.

Eu, o abaixo-assinado, declaro que o equipamento anteriormente especificado está em conformidade com a(s) anterior(es) Directiva(s) e

Norma(s)

Date • Data • Date • Datum • Data •

Fecha • Data

June 2021

Signature • Handtekening •

Signature • Unterschrift Firma •

Firma • Assinatura

Full Name • Volledige naam • Nom

et prénom • Vollständiger Name •

Nome completo • Nombre completo

• Nome por extenso

Ashley Hooper

Eoghan Donnellan

Josie Holt

Position • Functie • Fonction •

Position • Qualifica • Posición •

Função

Technical & Quality

Manager

Commercial

Manager/ Importer

Commercial Manager/ Responsible

Supplier

Producer Address • Adres fabrikant •

Adresse du producteur • Anschrift

des Herstellers • Indirizzo del

produttore • Dirección del fabricante

• Morada do fabricante

Fourth Way,

Avonmouth,

Bristol,

BS11 8TB

United Kingdom

42 North Point

Business Park

New Mallow Road

Cork

Ireland

15 Bagdally Road,

Campbelltown

NSW 2560

DocuSign Envelope ID: FA45763D-FF75-471C-A572-C62D5C10D36D

FA854-A to FA857-A_DA680-A_AB090-A_A5_v1_20210616.indb 7FA854-A to FA857-A_DA680-A_AB090-A_A5_v1_20210616.indb 7 2021/6/16 17:282021/6/16 17:28

FA854-A to FA857-A_DA680-A_AB090-A_A5_v1_20210616

http://www.polar-refrigerator.com/

FA854-A to FA857-A_DA680-A_AB090-A_A5_v1_20210616.indb 8FA854-A to FA857-A_DA680-A_AB090-A_A5_v1_20210616.indb 8 2021/6/16 17:282021/6/16 17:28

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Polar Electro Réfrigérateur

Polar Electro

Polar Electro UA025 Manuel utilisateur

Polar Electro

Polar Electro G590/G591/G592/G593/G594/G595/U632/U633/U634/U635/CC663/CD616/GD879/GD880/ Manuel utilisateur

Polar Electro

Polar Electro G604 Manuel utilisateur

Polar Electro

Polar Electro G608 Manuel utilisateur

Polar Electro

Polar Electro CD610 Manuel utilisateur

Polar Electro

Polar Electro GD875-A Manuel utilisateur

Polar Electro

Polar Electro GD881 Manuel utilisateur

Polar Electro

Polar Electro CE322-A Manuel utilisateur

Polar Electro

Polar Electro CD610 Manuel utilisateur

Polar Electro

Polar Electro DL893-A Manuel utilisateur

Polar Electro

Polar Electro Deli CG841-A Manuel utilisateur

Polar Electro

Polar Electro FD169 Manuel utilisateur

Polar Electro

Polar Electro CD080-A Manuel utilisateur

Polar Electro

Polar Electro DB109-A Manuel utilisateur

Polar Electro

Polar Electro GL178-A Manuel utilisateur

Polar Electro

Polar Electro U636 Manuel utilisateur

Polar Electro

Polar Electro CC066 Manuel utilisateur

Polar Electro

Polar Electro CE322 Manuel utilisateur

Polar Electro

Polar Electro GL180-A Manuel utilisateur

Polar Electro

Polar Electro GH261 Manuel utilisateur

Polar Electro

Polar Electro G592 Manuel utilisateur

Polar Electro

Polar Electro GC870-A Manuel utilisateur

Polar Electro

Polar Electro DA546 Manuel utilisateur

Polar Electro

Polar Electro UA017 Manuel utilisateur

Manuels Réfrigérateur populaires d'autres marques

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuel utilisateur

Sharp

Sharp SJ-BA31IEXW2-EU Manuel utilisateur

CORBERO

CORBERO CC2300MCW Manuel utilisateur

KitchenAid

KitchenAid 2205264 Manuel utilisateur

Stengel

Stengel KU 1101 A++ Manuel utilisateur

NEFF

NEFF KI181 Series Manuel utilisateur

Hoshizaki

Hoshizaki Reach-In Manuel utilisateur

Amana

Amana ASD2524VES00 Manuel utilisateur

BOMANN

BOMANN KGC 213 Manuel utilisateur

Danby

Danby DAR044A1SLDD Instructions de montage

Samsung

Samsung RF323TE Manuel utilisateur

Beko

Beko CSA31022 Manuel utilisateur

IKEA

IKEA FROSTIG C 185 E Manuel utilisateur

Electrolux

Electrolux ER 6821 D Manuel utilisateur

True

True TS-28 Manuel utilisateur

Frigidaire

Frigidaire FSC23R5DW9 Manuel utilisateur

Beko

Beko LSP4579W Manuel utilisateur
