point pro Series Manuel utilisateur
16'' 2 in 1 Stand Fan
360˚Horizontal Oscillation
POFS8016WH
User Manual
GB
Thank you for purchasing your new POINT PRO SERIES Stand Fan.
These operating instructions will help you use it properly and safely. We
recommend that you spend some time reading this instruction manual
in order that you fully understand all the operational features it oers.
Read all the safety instructions carefully before use and keep this
instruction manual for future reference.
ENNO
Takk for at du kjøpte denne nye POINT PRO SERIES Stå vifte. Denne
bruksanvisningen hjelper deg med å bruke den ordentlig og sikkert. Vi
anbefaler at du tar deg tid til å lese gjennom hele bruksanvisningen for å
bli fortrolig med alle funksjonene den har. Les alle
sikkerhetsanvisningene nøye før bruk, og oppbevar bruksanvisningen for
fremtidig referanse.
FI
Kiitos, kun valitsit uuden POINT PRO SERIES Tuuletin. Nämä
käyttöohjeet opastavat sinua käyttämään laitetta oikein ja turvallisesti.
Suosittelemme, että vietät hetken tämän käyttöoppaan parissa, jotta
ymmärtäisit täysin kaikki laitteen tarjoamat toiminnalliset
ominaisuudet.
Lue kaikki turvallisuusohjeet huolellisesti ennen laitteen käyttöä ja
säilytä käyttöopas myöhempää käyttöä varten.
ENDK
Tak for købet af din nye Kedel fra POINT PRO SERIEN Stand Fan. Disse
brugsanvisninger hjælper dig med at bruge den korrekt og sikkert. Vi
anbefaler, at du læser denne brugsanvisning, så du får en fuld forståelse
af, hvordan alle funktionerne virker. Læs alle sikkerhedsinstruktioner
nøje før brug, og behold denne brugsanvisning til senere reference.
SE
Tack för att ha köpt en ny värmare från POINT PRO SERIES Ställ fläkt.
Denna bruksanvisning hjälper dig att använda den på ett korrekt och
säkert sätt. Vi rekommenderar att du spenderar lite tid att läsa denna
bruksanvisning så att du till fullo förstår alla driftsfunktioner den
erbjuder. Läs alla säkerhetsinstruktioner noga innan användning och
förvara bruksanvisningen för framtida referens.
2
Instruction manual - english .............. page
.............. sidan
Brugsanvisning - dansk
.............. side
Bruksanvisning - norsk
Käyttöohjeet - suomi
.............. side
.............. side
49-63
64-78
34-48
19-33
4-18
FI NODKSE GB
Bruksanvisning – svenska
3
Read all the instructions carefully before using the
product.
SAFETY WARNINGS
1. Check the voltage indicated on the rating label. This
product is designed for 220-240V~ 50Hz electric
supply.
2. This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision.
3. Periodically check the mains power cable of this fan. If
the mains power cable is damaged, it must be
replaced by the manufacturer, repair centre or a
similar qualified person in order to avoid a danger.
4. Do not place the mains power cable under a cover. Do
not overlay the mains power cable with little covers or
such element. Place the mains power cable in an area
where there is no risk to stumble over it.
5. Place the fan on a flat, firm, safe surface before use.
6. Disconnect the plug from the mains power socket
when not in use, seize the plug and then pull it out.
Do not pull the mains power cable to pull out the
plug.
4
GB
7. Make sure that the fan does not touch any
obstruction when oscillating.
8. Do not put your fingers or any other object into the
front grill when the fan is operating. Pay special
attention when used near children, to avoid children
playing with the fan.
9. Do not let hair, net curtains, tablecloth, clothes or
curtains etc. near the openings of the fan. They could
be entangled into the fan, causing damage or injuries.
10. Do not use the fan when the mains power cable or
plug are damaged, a fan blade fallen or any other
damages.
11. Do not use this fan outside; it is for indoor use only.
12. Do not use this fan in a damp area such as a
bathroom.
13. Do not use this fan near a window and under direct
sunshine.
14. Do not use this fan with any semi-conductors speed
control.
15. The fan should not be operated without a base nor
used when tipping over.
16. Do not operate the fan in an area where gasoline or
paint is used or stocked, or such flammable liquids.
17. Unplug the unit before moving, cleaning or storing.
18. Always unplug the fan when not in use.
5
19. Use this fan only as described in this manual.
20. Do not try to disassemble this fan; there are no parts
that can be repaired by the user. If you need
maintenance, send the fan back to the customer
service and repair centre.
21. Keep the fan clean and maintain it in good condition
(use an authorized service agent).
22. This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge. Do not let them use the appliances
without supervised by a person responsible for their
safety.
23. Do not use an extension cable.
24. Children should be supervised to ensure that they do
not play with the appliance.
6
GB
Product Characteristics
Main Body
1. Timer Function: 1, 2, 4, 8 HR
2. Infrared remote control
3. 3-Speed control: High, Med, and Low
4. Mode Options: Default, Natural Breeze, Sleep
5. LED display with button control.
6. Angle modes: 360 degrees of oscillation, adjustable
angles of 60, 90, 180, 360 degrees
7. Manually adjustable tilt: Dierent angles of elevation
from -8 degrees to 90 degrees.
8. Power-O and connection sound alert.
12
11 10 9 8 7 6 5 4 3 2 1
13
14
15
19
1 6
17
18
7
Product Characteristics
1-2. Decorative Plate
3. Front Guard Cap
4. Front Guard
5. Blade Cap
6. Fan Blades
7. Screw
8. Guard Ring Lock
9. Guard Ring
10. Guard Ring Cap
11. Rear Guard
12 Motor Unit
13. Screw
14. Power Cable
15. Ring Connector
16. Metal Pipe
17. Base Plate
18. L-Screw
19. Remote Control
Mode button
Time button
Angle button
Speed button
On/O button
8
GB
Installation
1. Open the packaging and take out the manual, remote
control, and accessories and ensure all parts are
present.
2. This fan can be used as a free standing fan or a table
top one as the height can be adjusted (No assembly
of the metal stand is needed for the table top fan)
Refer to the diagrams below for assembly
instructions.
a. Floor Standing Mode:
Insert the metal pipe inside
the baseplate and then lock in
place with the L –screw.
Free-Standing Mode:
(Table Top): Insert the Base
Unit into the Base Plate and
then lock in place with the
L-Screw. (Diagram 1)
b. Attach the metal pipe to the
unit and then secure with
screws (Diagram 2)
Diagram 1
Diagram 2
Floor Standing
Screw
Table Top
Floor Standing Table Top
9
c. Slide the rear guard onto the motor then align the
guard with the holes of the motor unit and then
fasten with the Guard Ring Cap. (Diagram 3 / Diagram
4)
d. Place the fan blades onto the motor unit axle and
then fasten tightly with the blade cap in a counter
clockwise direction. (Diagram5/ Diagram 6).
Diagram 3 Diagram 4
Diagram 5 Diagram 6
Loosen
Loosen
Fasten
Fasten
Guard Ring Cap
Blade Cap
10
