Plinius TOKO Manuel utilisateur
The heart of music
www.pliniusaudio.com
TOKO
Digital Audio Player
Instruction Manual
Contents
Introduction ...............................................................................................................2
Design Philosophy ...............................................................................................3
Unpacking ....................................................................................................................4
Placement & Ventilation ....................................................................................4
Care & Maintenance............................................................................................5
Precautions ................................................................................................................6
Front Panel Functions ........................................................................................7
Rear Panel Functions .........................................................................................9
Remote Control Functions .............................................................................11
Network Playback Control ..............................................................................13
Firmwire Upgrades ................................................................................................13
Installation & Operation ....................................................................................14
Product Features ..................................................................................................16
Troubleshooting .......................................................................................................18
Specifications ..........................................................................................................19
Quick Start Guide ..................................................................................................20
Index ................................................................................................................................22
All operational, technical and descriptive material in this publication
is subject to change at any time without notice. For further product
information or queries, please contact your Plinius dealer.
Plinius products are designed and manufactured by
Plinius Audio Limited, New Zealand.
2
PLINIUS TOKO
Introduction
Congratulations on your decision to become the proud owner of this
Plinius Toko Digital Audio Player.
This manual has been prepared to help you understand the operation of this product,
and to provide information about its design and the variety of ways it may be used.
We have designed and manufactured this product to reproduce your favourite music
faithfully and accurately. With a little care and a full understanding of the operating
recommendations in this manual, your Plinius Toko Digital Audio Player will provide
years of high-quality, trouble-free performance.
PLEASE TAKE THE TIME TO READ THIS MANUAL THOROUGHLY BEFORE
USING YOUR DIGITAL AUDIO PLAYER.
SERIAL NUMBER
FINAL TEST CERTIFIED BY
3
DIGITAL AUDIO PLAYER
Design Philosophy
From a distance you can see that the design of the Plinius products is more than
an applied styling exercise to the front panel. We have started from the ground up
to produce a casing for our electronics that is unrivalled in its physical strength and
visual simplicity.
Wherever possible we have reduced the number of parts needed and then invested
massively in refining and producing the remaining parts to the highest quality
achievable with state of the art computer controlled machines allied with expert
craftsman. Examples of this approach include the hydraulically formed corners on
the amplifiers giving much greater strength and the one piece housing for the remote
control that looks, feels and genuinely is robust.
As with music that you are not familiar with, truly innovative new designs can take time
to understand and enjoy. How often have you heard music that you were first unsure
of, that over repeated listening, has become a firm favourite?
Our designs are fundamentally different to many other companies, and we hope that
you will take the time to explore their unique character and qualities because we have
not made them different simply to be different. We genuinely believe that their visual
and tactile qualities do improve the experience of listening to music and that is our
design goal!
Ross Stevens
DESIGN DIRECTOR
4
PLINIUS TOKO
Unpacking
Open the box from the top and remove the accessories from the foam end caps.
You may now proceed to lift the unit from the box, Once the unit is removed you can
proceed with the removal of the foam end caps. These caps are designed to fit on
the front and back of the unit for maximum protection. Retain the packaging for future
transportation of this unit.
Placement & Ventilation
This Plinius product may operate at a moderately high temperature, especially during
extended listening sessions. With this in mind, we recommend the following guidelines
for placement and ventilation:
• The ideal location is upon a rigid stand, away from direct contact with any
temperature sensitive materials, furniture or deep pile carpets.
• Ventilation through and around the amplifier should be kept unimpeded.
• Ensure heat vents (slots in the base and lid) are not covered or restricted in any way.
• Equipment racks should be of an open type with no closed side panels and no
closed front or rear panels. Ensure a minimum of 100mm clearance on all sides of
your Plinius unit to other equipment and the shelf above. If the unit is in an enclosed
cabinet, the clearance should be greater than 400mm on all sides.
• Ensure the space between the chassis and shelf below the unit is unobstructed at
all times.
• When stacking separate audio components, apply the minimum clearances above,
as well as a minimum of 400mm clearance above the top unit for suitable airflow.
• NOTE: This unit has been designed for use in moderate climates only, not for tropical
conditions.
The design of this Plinius product incorporates a very high level of mechanical
decoupling of the input and output. It can however still be influenced by acoustical
feedback in the operating environment. The use of acoustic cones or a suitably spiked
amplifier stand or table may further enhance the performance of this digital audio
player. Consult your Plinius dealer for further advice if required.
5
DIGITAL AUDIO PLAYER
Care & Maintenance
With simple care and maintenance your Plinius product can be kept looking and
operating like new for many years to come.
MAINTAINING THE CONNECTORS
Exposed connectors such as the RCA connectors will be subject to environmental
factors, and over time the surface may degrade. This can be greatly reduced by fitting
readily available ‘RCA caps’ to reduce the effects of environmental elements on the RCA
connectors. These RCA caps or RCA shorting caps can also provide sonic benefits.
Connector cleaning products are also available to clean the RCA and cable connectors
and frequent checks and cleaning will help maintain a good signal connection.
NOTE: DO NOT use RCA shorting caps on output connectors or power amplifier input
connectors. Use RCA shorting caps on unused preamplifier stage input connectors only.
Standard RCA shielding caps can be used on any unused input or output connectors.
MAINTAINING THE SWITCHES
Switches should be maintained by using each various switch setting periodically.
Even if a switch or a switch setting is not used, it is a good idea to toggle small
switches and turn rotary switches though the full range of the switch several times in
succession to keep the contacts active. Performing this simple action will promote
longevity of the switch contacts.
SURFACE CLEANING
From time to time you may wish to clean the surface of your Plinius equipment to
remove dust, or any material build up from the atmosphere or on commonly used
controls. Your Plinius product is made up of parts that have a hard anodised or a
powder coat finish and will clean easily without being damaged.
Cleaning should be carried out using a soft cleaning cloth, dry or with either a small
amount of water or a very mild surface cleaner while observing the following guidelines:
• As a safety precaution, always switch the equipment off before cleaning
• Always use a cloth that is soft and clean
• Never use abrasives or polishing compounds anywhere on the unit
• Never apply liquid directly to the surface of the unit
• Use the cloth dry or with mild surface cleaners of either liquid or foaming type
• Apply only small amounts of cleaner to the cloth
• DO NOT rub the surface but wipe clean only. Excessive rubbing may dull powder
coat or wear the screen printed text.
6
PLINIUS TOKO
Precautions
PLEASE TAKE SPECIAL NOTE OF THE FOLLOWING PRECAUTIONS
BEFORE OPERATING YOUR NEW DIGITAL AUDIO PLAYER.
• This Digital Audio Player operates at hazardous voltage levels. We recommend
that any work requiring removal of the lid be referred to a suitably qualified and
experienced service technician.
• DO NOT earth any output terminals or connect any of these terminals together
without following the instructions in this manual or seeking qualified assistance.
• DO NOT place this Digital Audio Player in any position where liquids or any foreign
material may accidentally enter it.
• DO NOT connect any voltage source, short circuit, earth/ground or appliance
(other than suitable audio preamplifiers) to the Toko Digital Audio Player output
terminals.
• DO NOT use discs that are scratched or damaged. This may lead to unintended
operation or malfunction.
• DO NOT expose the unit to dripping or splashing.
• DO NOT place objects filled with liquids on the unit, e.g. vases.
• DO NOT place sources of naked flame on the unit, e.g. candles.
7
DIGITAL AUDIO PLAYER
Front Panel Functions
1. POWER LED
A blue LED on the centre front panel indicates that the power is on. When first
switched on, the LED will vary in brightness until the initialisation sequence is
completed, after which the LED remains lit.
2. COMPACT DISC (CD) TRANSPORT SLOT
The CD is inserted in this slot and taken in by the transport mechanism.
3. STOP/EJECT BUTTON
Press this button to stop a CD from playing. Press it a second time to eject the CD.
NOTE: Stopping the disc will automatically switch the player to Network mode. It will
return to CD mode when a disc is played.
4. NETWORK LED
This small white LED is ON when the Toko is switched to Network mode. In this mode
the audio data stream is routed from the Network input socket to the internal Digital to
Analogue Converter (DAC).
5. TRACK DISPLAY LED’S
These small white LED’s communicate the CD track details.
WHEN A CD IS INSERTED: The LED labelled ‘1’ will flash showing that the CD is
being read.
NO CD IN THE TRANSPORT: All display LEDs will be OFF.
WHEN A CD IS PLAYING: The LED associated with the track that is being
played will be lit and vary in brightness.
The state of the other LEDs depends on the total number of tracks on the CD as
described below.
20 TRACKS OR LESS: The LED labelled ‘1’ will be lit, as will the LED corresponding
to the last track on the CD. This gives a visual
representation of the total number of tracks on the CD.
Every fifth LED in between will also be lit, to make reading
1
3
4
5
2
8
PLINIUS TOKO
the display easier from a distance. For example a CD with a
total of 18 tracks, LEDs 1, 5, 10, 15 and 18 will be lit.
39 TRACKS OR LESS: LED 1 will be lit. Every fifth LED in between 1 and the final
track will also be lit. When a track above number 20 is
being played, the 20+ LED will be lit and vary in brightness
along with the appropriate LED between 1 and 20. For
example, playing track 23 on a CD containing 32 tracks
would show LEDs 20+ and 3 lit and varying in brightness in
unison to indicate the track playing, plus LED’s 1, 5, 10 and
12 are also lit to show the track quantity.
MORE THAN 40 TRACKS: When a track above number 39 is being played, all display
LEDs will go out, except for 20+, which will flash on and off.
In all cases when the track being played is paused, the
corresponding track LED will flash.
REPEAT FUNCTION: The Repeat LED will light if the repeat function is chosen.
NOTE: If a CD is in the player, track information can be displayed while in Network mode.
