pleasant hearth HARMONY Manuel utilisateur
1
HARMONY FIRE PIT
MODEL #OFW750R
ATTACH YOUR RECEIPT HERE
Serial Number Purchase Date
Español p.9
Français p.17
1
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-877-447-4768, 8:00 a.m. – 4:30 p.m. CST, Monday – Friday, or email
30-10-207 Rev. 08/31/2020
2
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
APoker Bracket 1
BMesh Cover 1
CCooking Grid 1
DOuter Ring 4
EMesh Cover Rest 4
FFire Bowl 1
GLeg 4
HPoker 1
A
B
C
D
E
F
G
H
3
HARDWARE USED
Wrench
QTY: 1
M6 Nut
QTY: 13
M6X12mm Bolt
QTY: 20
AA BB CC
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or install
the product. If you have any questions regarding the product, please call customer service at
1-877-447-4768, 8:00 a.m. – 4:30 p.m. CST, Monday – Friday.
WARNINGS:
• DO NOT allow children or pets near the re pit without supervision.
• DO NOT touch surface of re pit while in use.
• FOR OUTDOOR USE ONLY! Burning wood or charcoal indoors can kill you. It gives off carbon
monoxide, which has no odor.
• NEVER burn in vehicles, tents, garages, other enclosed areas or indoors. CARBON
MONOXIDE HAZARD.
• NEVER LEAVE FIRE UNATTENDED!
• NEVER place a storage cover on re pit when in use. Ensure the re pit and mesh cover have
cooled before placing a storage cover over the re pit.
• When the re pit is in use, the poker bracket on the mesh cover can reach extreme temperatures
that can cause serious injury to an unprotected hand. Use a poker when handling.
• DO NOT use under overhead cables or power lines.
CAUTIONS:
• Adequate re extinguishing material should be readily available.
• Always ensure that the mesh cover is secured over re bowl while in use.
• Burn only seasoned hard wood or re logs in the re pit.
• DO NOT attempt to move the re pit while it is hot or in use.
• DO NOT use gasoline or kerosene to start the re in your re pit.
• DO NOT use this outdoor re pit under any overhead or near any unprotected combustible
constructions. Avoid using near or under overhanging trees and shrubs. DO NOT use this unit
on long or dry grass and/or leaves.
• Always use this outdoor re pit on a hard, level, non-combustible surface such as concrete,
rock or stone. An asphalt or blacktop surface may not be acceptable for this purpose. DO NOT
use on wooden decks.
• Place the re pit no closer than 10 feet / 3.05 meters from walls or combustibles during use.
• Poker handle may become hot during and after use.
• Use heat-resistant gloves to handle hot tools.
• Burn only 7LBs/3.18KG of charcoal, wood or re logs in the re pit.
4
SAFETY INFORMATION
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents above. If any part is missing or damaged, do not attempt to
assemble the product. Contact customer service for replacement parts.
Estimated Assembly Time: 30 minutes
Tools Required for Assembly:
Phillips Screwdriver (Not Included) and Wrench (Included).
WARNING
This product and the fuels used to operate this product (charcoal or wood), and
the products of combustion of such fuels, can expose you to chemicals including
carbon black, which is known to the State of California to cause cancer, and carbon
monoxide, which is known to the State of California to cause birth defects or other
reproductive harm.
For more information go to www.p65Warnings.ca.gov
1
5
ASSEMBLY INSTRUCTIONS
1. Insert two M6x12mm bolts (AA) through the
holes in the leg (G) and into the holes on the
side of the re bowl (F). Secure with two M6
nuts (BB). Then, screw one M6 x 12mm bolt (AA)
through the hole on the bottom of the re bowl
(F) and into the rivet nut in the leg (G). Repeat
these steps for the three remaining legs. Tighten
securely with a screwdriver.
AA BB F
G
AA
BB
BB
Hardware Used
M6x12mm Bolt
M6 Nut
M6 Nut
x 12
x 8
2. Attach four outer ring (D) pieces together using
four M6x12mm bolts (AA). Keep the bolts loose
during this step.
3. Slide the assembled outer ring (D) over the
re bowl (F) from the bottom to the top. Align the
holes on the outer ring (D) with the holes on the
re bowl (F). Then, slide four M6x12mm bolts
(AA) through the four mesh cover rests (E) and
the holes on the inside of the re bowl (F), then
into the holes on the outer ring (D). Secure with
four M6 nuts (BB) from the outside of the outer
ring (D). Tighten with the wrench (CC) and a
screwdriver.
Once attached to the bowl (F), tighten all bolts on
the outer ring (D) assembly.
AA
AA
Hardware Used
Hardware Used
M6x12mm Bolt
M6x12mm Bolt
x 4
x 4
x 4
2
3
AA
AA
E F
D
D
BB
CC Wrench
5
6
6
ASSEMBLY INSTRUCTIONS
5. For re pit use, place the mesh cover (B) over
the re pit as illustrated.
6. For barbeque use, remove the mesh cover
(B) and place the cooking grid (C) onto the mesh
cover rests (E). Place food onto the cooking grid
(C) and replace the mesh cover (B).
B
B
C
E
4
A
B
BB
4. Insert the poker bracket (A) into the hole in
the mesh cover (B) and secure with one M6 nut
(BB). Tighten the nut with the wrench (CC).
BB
CC
Hardware Used
M6 Nut
Wrench
x 1
7
7
ASSEMBLY INSTRUCTIONS
7. Your re pit is now ready for use. Keep the
poker (H) near the re pit for use anytime.
H
CARE AND MAINTENANCE
• Use gloves in lieu of bare hands while handling.
• To protect the re pit nish, use a soft cloth to wipe the re pit and the poker.
• Do not attempt to clean while hot.
• Store in a cool, clean, dry place.
1-YEAR LIMITED FRAME WARRANTY
If within one year from the date of original purchase, this item fails due to a defect in material
or workmanship, we will replace or repair at our option, free of charge. To order parts or to
obtain warranty service, call 1-877-447-4768, Monday - Friday, 8:00 a.m. - 4:30 p.m. CST. This
warranty does not cover defects resulting from improper or abnormal use, misuse, accident, or
alteration. Failure to follow all instructions in the owner's manual will also void this warrranty. The
manufacturer will not be liable for incidental or consequential damages, or common erosion of
outdoor products. Some states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation may not apply to you. This warranty gives you
specic legal rights, and you may also have other rights which vary from state to state.
A
B
C
D
E
F
G
H
8
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-877-447-4768, 8:00 a.m. – 4:30 p.m.,
CST, Monday – Friday.
Printed in China
Manufactured by
GHP Group, Inc.
6440 W. Howard St.
Niles, IL 60714-3302
877-447-4768
PART DESCRIPTION PART #
APoker bracket 40-07-453
BMesh Cover 30-06-174
CCooking Grid 30-06-223
DOuter Ring 30-01-324
EMesh Cover Rest 30-01-152
FFire Bowl 30-01-326
GLeg 30-01-327
HPoker 40-04-409
AA - CC
Hardware Pack 30-09-554
N/A Instruction Manual 30-10-207
AA BB CC
9
¿Preguntas, problemas, piezas faltantes?
Antes de volver a la tienda, llame a nuestro departamento de servicio al cliente al 1-877-447-4768,
de lunes a viernes de 8:00 a.m. a 4:30 p.m., hora central estándar o envíenos un correo electrónico
English p. 1
Français p.17
ADJUNTE SU RECIBO AQUÍ
Número de serie Fecha de compra
BRASERO HARMONY
MODELO #OFW750R
30-10-207 Rev. 08/17/2020
10
CONTENIDO DEL PAQUETE
PIEZA DESCRIPCIÓN CANTIDAD
ASoporte del atizador 1
BCubierta de malla 1
CLa parrilla 1
DManija exterior 4
EApoyo de la cubierta de malla 4
FTazón de fuego 1
GPierna 4
HAtizador 1
A
B
C
D
E
F
G
H
