PLAYNETIC KineticSwing Manuel utilisateur

KineticSwing

User Manual

KSW90017_31032020

Loohorst 3 | 7207 BL Zutphen | The Netherlands

[email protected] | www.playnetic.nl | +31(0)575-843612

Loohorst 3 | 7207 BL Zutphen | The Netherlands

[email protected] | www.playnetic.nl | +31(0)575-843612

Install the Product

Overview Product

Control the Volume

Change the Content

Maintenance

Check Interactive Elements

Play and Test

Install and Manage a Timelock

Install the Product

Install the product according to the Playnetic Installation Manual.

During the installation, make sure that the potential users can not

be exposed to hazards / dangerous situations. Check the stability

of the product.

Number of Users

Playnetic recommends you to use the product with a maximum of

two users.

Overview Product

The overview above shows where all important parts can be

found.

Check Interactive Elements

Use the product and generate energy. If applicable, check that the

interactive elements such as the music, lights, smell, electronic- and

mechanical parts are working properly.

Beam

Service hatch (2)

Service hatch (1)

Coupling part

LED

Seat

Energy box

Post

Control the Volume

1. Remove the bolts with the supplied hex key.

2. Remove the service hatch with the label.

3. Generate energy with the product.

4. Adjust the volume.

5. Close the service hatch.

Play and Test

1. Generate energy with the product.

2. Test if 4 different fragments are played by using the

different positions/movements.

*Are the tests incorrect? Then change the content. Follow

the instructions in the Playnetic User Manual.

Volume

3 4

Play and Test

3. Test if the right LED line runs in the correct direction by using

the different positions/movements.

*Are the tests incorrect? Then contact your dealer.

1122

3344

Change the Content

1. Get a USB stick. Make sure that you meet the following requirements:

a. Only use MP3-files.

b. The name of the MP3 file needs to have at least 5 characters.

c. The name of the MP3 file can’t contain any strange characters.

d. A single MP3 file can not be bigger than 2 MB.

2. Make sure you put 4 MP3-files on the USB. Place them in the correct

sequence, matched to the positions/movements.

3 4

Change the Content

2. Use the supplied hex key and unscrew the bolts.

3. Remove the service hatch with the label.

4. Put the USB stick into the computer.

5. Generate energy with the product. Wait until the update

is completed. Remove the USB stick after completion.

6. Make sure that you put the dust cover back over the USB

port.

7. Close the service hatch.

“In progress, please wait...”

“Downloading data

completed, remove USB

device”

USB port

Receive Timelock

1. Receive a USB device. Playnetic has set the

correct start- and endtime for you.

Install a Timelock

1. Remove the bolts with the supplied hex key.

2. Remove the service hatch with the label.

3. Important! The timelock must be installed at 12

o’clock local time. If the installation is being done too

late or too early, the timelock will not work properly.

4. Put the USB stick into the computer.

5. Generate energy. Wait until the update is completed.

Remove the USB stick after completion.

6. Make sure that you put the dust cover back over the

USB port.

7. Close the service hatch.

Update Your Timelock 2x a Year

For updating your timelock, use the USB device which

you received from Playnetic with the correct start- and

endtime (same USB device for install option). Repeat

step 1 to 7 from ‘install a timelock’ to complete the

update.

“In progress, please wait...”

“Downloading data

completed, remove USB

device”

Maintenance

The product must be maintained according to the Playnetic

Maintenance Advice.
