Wired / Wireless

USB2.0 MFP Print Server

FPS-1010M / FPS-1010MG

Quick Installation Guide

Table of Contents

Package Content.............................................................................................. 4

Hardware Installation ....................................................................................... 5

Management Software Installation..................................................................... 6

Install the MFP Drivers/Utilities ........................................................................14

Using the MFP ................................................................................................19

Share Printer and Fax .....................................................................................20

Share Scanner................................................................................................21

An example: HP 5600 Series Utilities...........................................................21

Windows XP Scanning Utility.......................................................................22

Share Card Reader .........................................................................................23

Further Conguration ......................................................................................24

Thank you for purchasing and using our MFP print server. This FPS-1010M /

FPS-1010MG allows your Multi-function printer (called for short: MFP) or printer

to become a shared device on the network. Unlike many print servers, it can

communicate with MFP and printer as if it is connected directly to your computer.

Because of the features, all users can share print, scan, fax and card reader

functions through the network. Furthermore, the FPS-1010M / FPS-1010MG can

build the bi-directional communication with MFPs and Printers so that it can help to

monitor important information such as ink levels and paper levels.

Note

For other environments, or any problems, please refer to the full

User’s Manual in the CD-ROM

Package Content

1 x FPS-1010M / FPS-1010MG

1 x Quick Installation Guide

1 x User’s Manual and Utility CD

1 x Power Adapter

1 x Dipole Antenna (For FPS-1010MG)

Note

If any of the above items are missing, please contact your dealer

immediately.

Hardware Installation

1. Unpack the FPS-1010M / FPS-1010MG package and verify the items listed in the

previous section are provided.

2. Use USB cable to connect FPS-1010M / FPS-1010MG to the MFP or printer that

you want to share to your network.

3. Use a RJ-45 cable to connect the FPS-1010M / FPS-1010MG to your LAN.

4. Connect dipole antenna to FPS-1010MG antenna connector. (FPS-1010MG only)

5. Connect the bundled power adapter to FPS-1010M / FPS-1010MG. The MFP

Server will perform the Power-On-Self-Test (POST) after power on. Please wait

for 20 seconds.

Note

1. Please use the power adapter which bundled with MFP Server.

DO NOT use any other power adapter from other sources. That

may cause your FPS-1010M / FPS-1010MG damage.

2. To prevent the compatibility problem between FPS-1010M /

FPS-1010MG and a few MFP or printer, it is recommended that

you power on the FPS-1010M / FPS-1010MG before the MFP or

printer.

Management Software Installation

This FPS-1010M / FPS-1010MG management software can be run in Windows

2000 SP4 or above, Windows XP SP1 or above and Windows Vista. The following

procedures are running in Windows XP, the procedures are similar for Windows

2000 and Windows Vista.

Note

Some MFP printers will ask the user connect MFP to the PC directly

and install the printer driver, before MFP Server installation. That

may cause the MFP Server installation adds one more MFP (printer/

scanner/fax/card reader) to your PC. You can delete the devices

which the MFP driver installed after MFP Server installation, or you

can keep those devices exist in your PC.

1. Insert User’s Manual and utility CD into the CD-ROM drive to initiate the autorun

program. Once completed a menu screen will appear.

2. Click on “MFP Server Utility” hyper link to initiate the installation. Or you can

click the “Start” button and choose “Run”. (Suppose “E” is your CD-ROM drive).

When the dialog box appears, enter “E:\Utility\Setup.exe” and press enter key.

You will see the dialog box as below. Please click “Next” to continue.

3. The “MFP Server Utilities - InstallShiled Wizard” is displayed, click “Next”.

4. Click “Next” to install the MFP Server utilities in the default folder or click

“Change” to specify the destination folder where you would like to install the

MFP Server utilities.

5. The system starts installing the MFP Server Utilities.

6. The “MFP Server Conguration” screen is displayed. If you want to congure the

MFP Server, please select “Yes, I want to congure the MFP Server now.” and

click “Next”. Then refer to the following steps to congure your MFP server. Or

you can select “No, I will congure the MFP Server later” and click “Next” to

complete the installation.

7. The MFP Server List will auto search the MFP Servers in the network. Select the

MFP Server you wan to setup and click “Next” to continue.

8. Enter the “User Name” and “Password” of the MFP Server you have selected to

“OK”.

9. Set the “Alias Name” and the “MFP Server Description” to the MFP Server here.

Click “Next”.

Note

You can define the location or other information of the MFP Server

for easy to find the MFP by filling “MFP Server Description”.

10. Please set the network settings for the FPS-1010M / FPS-1010MG manually.

The default network value is as below:

IP Address: 192.168.0.1 Subnet Mask: 255.255.255.0

If you have selected “DHCP”, the FPS-1010M / FPS-1010MG will try to

determine your network settings automatically. The FPS-1010M / FPS-1010MG

will automatically obtain and congure the network settings assigned by the

DHCP server and assigned IP Address will be shown in the IP Address elds.

If no DHCP server is present within the network, please select “Manual IP” and

assign the network settings of FPS-1010M / FPS-1010MG manually. Please click

“Next” to continue.

11. The FPS-1010MG will nd available wireless network automatically. You could

also press the “Refresh” button to nd the available wireless network manually.

After refresh procedure, there will show the available wireless networks. Please

select the appropriate wireless network that you would like to connect from the

list and click “Next” to continue.

Note

Only FPS-1010MG has the “Wireless Network Settings” window.
