Planet VIP-156 Manuel utilisateur

VIP-156/VIP-157

SIP Analog Telephone Adapter

Quick Start Guide

PLANET VIP-156/VIP-157 Quick Installation Guide

Overview

This quick installation guide describes the

objectives; organization and basic installation of

the PLANET VIP-156/VIP-157 VoIP Phone Adapter (“ATA”

in the following term), and explains how to establish

your first voice over IP communication via PLANET

product. Also, this guide shows you how to find

additional information on related products and

services.

Respective model/descriptions are shown below:

VIP-156: SIP Analog Telephone Adapter

VIP-156PE: 802.3af PoE SIP Analog Telephone Adapter

VIP-157: 1 FXS/ 1 FXO SIP Analog Telephone Adapter

VIP-157S: 2-port FXS SIP Analog Telephone Adapter

The VIP-156/VIP-157 series ATA integrates a

web-based graphical user interface that can cover

most configurations and machine status monitoring.

Via standard web browser, you can configure and check

machine status from anywhere around the world.

PLANET VIP-156/VIP-157 Quick Installation Guide

PREPARATION BEFORE BEGINNING

ADMINISTRATION ON SIPANALOG TELEPHONE

ADAPTER............................................................................ 4

PREPARATION BEFORE BEGINNING

ADMINISTRATION ON SIPANALOG TELEPHONE

ADAPTER............................................................................ 5

PHYSICAL INTERFACES ....................................................... 5

ADMINISTRATION INTERFACE ............................................. 5

Web configuration access:............................................. 6

Network Interface quick configurations........................ 7

Keypad configurations................................................... 9

VOICE COMMUNICATION SAMPLES....................... 12

ATA TOATA CONNECTION VIA IPADDRESS....................... 12

Operation steps: .......................................................... 12

(PEER-TO-PEER MODE)VIP-157S PORT 1TO PORT 2

COMMUNICATIONS ............................................................ 13

Operation steps: .......................................................... 13

VOICE COMMUNICATION VIA SIPPROXY SERVER –SIP-5015

Device configurations on the ATA:.............................. 15

VOICE COMMUNICATION VIA IPPBX SYSTEM –IPX-2000

(AUTO-CONFIG)................................................................ 17

Device configurations on the IPX-2000:..................... 17

QUICK REFERENCE IN CD-ROM GUIDE ................ 22

PLANET VIP-156/VIP-157 Quick Installation Guide

Document Objectives

This guide provides physical installation, network configurations,

and Internet access establishment information for theATA VoIP

Analog Phone Adapter.

Document Organization

This guide is organized as follows:

•Preparation before beginning VIP-156/VIP-157 administration

•Administration interface

•Network interface quick configurations

•Internet access setup guide

PLANET VIP-156/VIP-157 Quick Installation Guide

Preparation before beginning administration on

SIP Analog Telephone Adapter

Physical Interfaces

1 PC

RJ-45 connector, to maintain the existing network

structure, connected directly to the PC through

straight CAT-5 cable

2 LAN

RJ-45 connector, for Internet access, connected

directly to Switch/Hub through straight CAT-5

cable.

3 12V DC 12V DC Power input outlet

1. Use proper AC adapter for the ATA,

improper power supply will damage device

permanently.

2. For VIP-156PE, please connect IEEE802.3af

standard compliant power injector onto

the LAN interface for power resource. At

the same time, either PoE or AC adapter

can be deployed at one time.

ÍNote

Administration Interface

The ATA provides GUI (Web based, Graphical User Interface) for

machine management and. keypad administration is also available

for simple configuration.

PLANET VIP-156/VIP-157 Quick Installation Guide

Web configuration access:

To start ATA web configuration, you must have one of these web

browsers installed on computer for management

•Microsoft Internet Explorer 4.01 or higher with Java

support

Default IP address of ATA is 192.168.0.1. Please execute web

browser, and insert http://192.168.0.1 in the address bar of your

web browser to logonATA web configuration page.

VIP-156/VIP-157 will prompt for logon username/password, please

enter: root / null (no password) to continue machine

administration.

PLANET VIP-156/VIP-157 Quick Installation Guide

In order to connect machine for

administration, please locate your PC in the

same network segment (192.168.0.x) of the

ATA. If you’re not familiar with TCP/IP,

please refer to related chapter on user’s

manual CD or consult your network

administrator for proper network

configurations.

ÍNote

Network Interface quick configurations

Execute your web browser, and insert the IP address (default:

192.168.0.1) of VIP in the adddress bar.After logging on machine

with username/password (default: root / no password), browse to

“Network” --> “Network settings” configuration menu:

PLANET VIP-156/VIP-157 Quick Installation Guide

Parameter Description

IP address LAN IP address of

the ATA Default: 192.168.0.1

Mask LAN mask of the

ATA Default: 255.255.255.0

Default

Gateway Gateway of the ATA Default: 192.168.0.254

DNS The Domain Name

Server IP address Default: 168.95.192.1

Connection Type Data required.

Fixed IP The ISP will assign IPAddress, and related

information.

DHCP client In most circumstances, it is no need to

configure the DHCP settings.

PPPoE The ISP will assign PPPoE username /

password for Internet access.

After confirming the modification you’ve done, please click on the

Submit button to apply settings and browse to “Save & Reboot”

menu to reboot machine to make the settings effective.

Save Change to Flash Memory

Most of the modification on ATA will take effective after

modifications, but it is just temporary stored on RAM only, it will

disappear after your reboot or power off the VoIP PhoneAdapter, to

save the parameters into Flash ROM and let it take effective forever,

please remember to press the Save & Reboot button after you

modify the parameters.

PLANET VIP-156/VIP-157 Quick Installation Guide

Keypad configurations

The ATA series phone adapters support telephone keypad

configurations, please connect analog telephone set and refer to

the following table for machine network configurations.

Menu Choice Machine

operation

Parameter(s) Notes:

#111# Set DHCP client None ATA will change to

DHCP Client

#112xxx*xx

x*xxx*xxx#

Setup Static IP

Address

Use the * (star)

key when

entering a

decimal point.

DHCP will be

disabled and

system will change

to the Static IP type.

#113xxx*xx

x*xxx*xxx#

Set Network

Mask

Use the * (star)

key when

entering a

decimal point.

Must set Static IP

first.

#114xxx*xx

x*xxx*xxx#

Set Gateway IP

Address

Use the * (star)

key when

entering a

decimal point.

Must set Static IP

first.

#115xxx*xx

x*xxx*xxx#

Set Primary DNS

Server

Use the * (star)

key when

entering a

decimal point.

Must set Static IP

first.

PLANET VIP-156/VIP-157 Quick Installation Guide

#136# Enable

auto-config mode None For PLANET

IPX-2000 IP PBX

#137# Disable

auto-config mode None For PLANET

IPX-2000 IP PBX

#190# Unlock None

Must unlock the

protect function

before set up

network settings via

keypad.

#191# Lock None

The system will be

locked and can’t set

up network settings

via keypad.

#195# Reboot None

The system will

reboot

automatically.

#198# Factory Reset None

The system will be

reset to factory

default value and

reboot

automatically.

0＊To switch PSTN

mode None VIP-157 only
