PLANET ECLIPSE ETHA2 Manuel utilisateur

ETHA2 PAL

PLANET ECLIPSE: ETHA2 PAL

USER MANUAL / ENGLISH .68 CAL

ETHA2 PAL

THE PLANET ECLIPSE ETHA2 IS NOT A TOY. PAINTBALL

SAFETY RULES MUST BE FOLLOWED AT ALL TIMES.

Careless or improper use of the ETHA2, including failure to follow

instructions and warnings within this User Manual could cause

serious injury or death.

Do not remove or deface any warnings attached to the ETHA2.

Paintball industry standard eye/face/ear and head protection

designed specically to stop paintballs and meeting ASTM standard

F1776 (USA) or CE standard (Europe) must be worn by the user and

any person within range. Proper protection must be worn during

assembly, cleaning and maintenance.

Hearing protection should be worn.

Never shoot at a person who is not wearing proper protection.

Never look directly into the barrel of the marker. Accidental

discharge into the eyes may cause permanent injury or death.

Never look into the barrel or breech area of the ETHA2 whilst the

marker is switched on and able to re.

Keep the ETHA2 switched o until ready to shoot.

Treat every marker as if it is loaded and ready to re.

The electronic On/O button is the marker’s disabling device, also

known as a safety. Always switch o the marker when not in use.

Always t a barrel-blocking device to the ETHA2 when not in use.

Always remove paintballs from the ETHA2 when not in use.

Do not eld strip or remove any parts while the marker is

pressurised.

Do not pressurise the ETHA2 without all the components of the

marker correctly installed, as high-pressure gas may be emitted.

Do not re the ETHA2 without the bolt correctly installed.

Never put your nger or any foreign objects into the paintball feed

tube of the ETHA2.

Never allow pressurised gas to come into contact with any part of

your body.

Always remove the rst stage regulator and relieve all residual gas

pressure from the ETHA2 before disassembly.

Always remove the rst stage regulator and relieve all residual gas

pressure from the ETHA2 for transport and storage.

Always follow guidelines given with your rst stage regulator for safe

transportation and storage.

Always store the ETHA2 in a secure place.

Observe all local and national laws, regulations and guidelines.

WARNINGS

READ CAREFULLY BEFORE USE

ETHA2 PAL

Persons under 18 years of age must have adult supervision when

using or handling the ETHA2.

Use only professional paintball elds where codes of safety are

strictly enforced.

Use compressed air/nitrogen only. Do not use any other

compressed gas or pressurised liquid including CO2.

Always follow instructions, warnings and guidelines given with any

rst stage regulator you use with the ETHA2.

Use 0.68 inch calibre paintballs only.

Always measure your marker’s velocity before playing paintball,

using a suitable chronograph.

Never shoot at velocities in excess of 300 feet (91.44 metres) per

second, or at velocities greater than local or national laws allow.

Any installations, modications or repairs should be carried out by

a qualied individual at a licensed and insured paintball facility.

This Users Manual is in English.

It contains important safety guidelines and

instructions. Should you be unsure at any

stage, or unable to understand the contents

of this manual you must seek expert advice.

Le mode d’emploi est en Anglais.

Il contient des instructions et mesures de

sécurité importantes. En cas de doute, ou

s’il vous est impossible de comprendre le

contenu du monde d’emploi, demandez

conseil à un expert.

Este manual de usuarios (operarios)

Usarios está en Inglés.Contiene importantes

normas de seguridad e instrucciones. Si no

está seguro de algùn punto o no entiende los

contenidos de este manual debe consultar

con un experto.

Diese Bedienungs - und

Benutzeranleitung ist in Englisch.

Sie enthålt wichtige Sicherheitsrichtlinen und -

bestimmungen. Solten Sie sich in irgendeiner

Weise unsicher sein, oder den Inhalte dies

Heftes nicht verstehen, lassen Sie sich bitte

von einen Experten beraten.

WARNINGS

READ CAREFULLY BEFORE USE

WARNING!

This user manual must accompany the product in the event of resale or new

ownership. Should you be unsure at any stage you must seek expert advice.

WARNING

ETHA2 PAL

CONTENTS

GAME ON!

QUICK START (06 -14)

06 Setting up the ETHA2

08 Switching the ETHA2 On/O

09 Status indicator

10 Velocity adjustment

11 Trigger adjustment

12 Unloading the ETHA2

14 Storage and transportation

MAINTENANCE

15 On-line maintenance videos

ELECTRONICS (16 -17)

16 The set-up mode

17 Presets

RESET (18 -19)

18 Factory reset

19 Installing a 9V battery

FAULT FINDING (20 - 23)

20 Fault nding tables

TECHNICAL (24 - 36)

24 Parts list

26 ETHA2 inline regulator

27 Gamma Core bolt assembly

28 Solenoid assembly

29 Push On Purge System (POPS) assembly

30 Breech Sensor (BS) assembly

31 Tournament lock button

32 ETHA2 frame assembly

33 ETHA2 circuit board

34 PAL Clamping feed neck assembly

35 Two-piece grips

36 Attaching the PAL Loader System

SUPPORT (37 - 41)

37 Index

38 Our promise

39 Warranty Registration Card

41 Notes

PLEASE NOTE

Most ETHA2 diagrams throughout this manual show the standard ETHA2 feed

neck and not the PAL feed neck. This does not aect any specic instructions.

ETHA2 PAL

FOLLOW OUR OFFICIAL PLANET ECLIPSE

SOCIAL MEDIA CHANNELS TO KEEP UP TO DATE

WITH OUR TECH SUPPORT EVENTS CALENDAR.

WE GOT

YOUR

BACK!!!

OUR ARMY OF PLANET ECLIPSE PRO

TECHS ATTEND PAINTBALL EVENTS ALL

OVER THE WORLD TO MAKE SURE THAT

YOU AND YOUR ECLIPSE MARKER ARE

FIRING ON ALL CYLINDERS, AT ALL TIMES,

IN ALL GAME SCENARIOS.

FIG-1

ETHA2 PAL

QUICK START

SETTING UP THE ETHA2

HEX

5/32

3 4

ETHA2 PAL

FIG-1

Ensure the marker is switched o before you begin.

Screw both ends of the barrel together.

Screw the barrel tip counter-clockwise onto the barrel back.

Screw the complete barrel to the marker.

The barrel back screws clockwise into the marker body.

Attach barrel blocking device for safety.

Ensure the marker is de-gassed.

Push and hold the POPS button and pull the POPS switch away

from the POPS body.

Attach the preset air system.

Screw the air system clockwise into the POPS body.

Loosen the PAL clamping feed neck.

Open the feed neck lever away from the feed neck.

Unscrew the feed neck lever screw counter-clockwise.

Attach the loader.

If the feed neck is too tight, loosen the clamping feed neck more.

Secure the loader.

Close the feed neck lever to secure.

Screw the feed neck lever screw clockwise to tighten.

Gas the marker.

Push the POPS switch into the POPS body until it engages.

Switch on the ETHA2.

IMPORTANT! To switch On/O see page 8.

DO NOT over-tighten the barrel.

IMPORTANT! Always ensure marker is de-gassed when setting up.

NEVER use CO2. Only use compressed air or Nitrogen.

DO NOT over-tighten the feed neck. This may damage the ETHA2.

QUICK START

SETTING UP THE ETHA2

WARNING!

Always make sure that the marker is o with a barrel blocking device installed

and that no paintballs are in the ETHA2 or loader before installing an air system.

Compressed air and nitrogen systems can be extremely dangerous if handled

or used incorrectly.

Only attach an air system certied for use within the country of use.

Never add lubricants or grease into the ll adaptor of the air system regulator.

Ensure that all screws are tightened and no parts are loose before installing an

air system.

Do not pressurise the ETHA2 without the bolt system correctly installed, as high

pressure gas will be emitted.

Do not install a compressed air system or load paintballs into the ETHA2 until

you feel condent with your ability to handle the marker safely and responsibly.

WARNING

FIG-1

ETHA2 PAL

The frame

houses the On/O button

and the status indicator

Use the On/O button to switch the ETHA2 On/O.

FIG-1

To switch the ETHA2 on press and hold the On/O button. Release the

On/O button when the status indicator lights up.

On power up, if the ETHA2 is unable to load its previous settings it will

restore the factory settings. If this happens, the LED will ash RED (error),

then BLUE factory reset).

To switch the ETHA2 o press and hold the On/O button. Release the

On/O button when the status indicator turns red. The ETHA2 will now

switch o.

Firing the ETHA2

Pull the trigger to re the ETHA2. If the marker is able to re then it will

do so.

QUICK START

SWITCHING THE ETHA2

ON/OFF

FIG-1

ETHA2 PAL

QUICK START

STATUS INDICATOR

FIG-1

The status indicator is visible on each side of the ETHA2 and is used to

indicate a number of dierent things.

Breech sensor status

After power up the ETHA2’s status indicator

will display the status

of the breech sensor (BS). The breech sensor (BS) is used to detect

paintballs in the breech of the marker.

The table below shows each LED colour and its relevant BS status.

LED COLOUR BREECH SENSOR (BS) STATUS

FLASHING YELLOW BS enabled. NO paintball detected.

Marker WILL NOT re.

FLASHING LIGHT BLUE BS enabled. Paintball detected.

Marker WILL re.

FLASHING PURPLE (SLOW) BS disabled. Marker WILL re.

FLASHING PURPLE (FAST) Blockage detected. BS disabled.

Marker WILL re.

RED Replace battery.

Marker may or may not re.

Battery status

Tap the On/O button

The status indicator

will indicate the status of the battery for

2 seconds (see the table below for battery status colour information).

LED COLOUR BATTERY STATUS

GREEN Battery level is good.

YELLOW Battery level is low.

RED Replace the battery.

FLASHING RED Insufcient energy, replace battery immediately.

The status indicator also indicates the various marker parameter settings.

See pages 16-17.

WARNING!

When the battery indicator is being displayed the marker is still on and will re if

the trigger is pulled - depending on the BS status.

Do not dry re/shoot the marker without paintballs. Prolonged dry ring may

lead to damage/wear of the internal components of the marker.

WARNING

FIG-1

ETHA2 PAL

QUICK START

VELOCITY ADJUSTMENT

FIG-1

Insert a 1/8 hex key

into the velocity adjuster screw

to alter the

velocity of the ETHA2.

Turn the hex key clockwise to reduce velocity.

Turn the hex key counter-clockwise to increase velocity.

Fire two clearing shots after each velocity adjustment for an

accurate velocity reading.

DO NOT turn the adjuster screw in too far. This will prevent the

ETHA2 from ring.

–+

HEX

1/8

WARNING!

DO NOT exceed 300FPS.

ALWAYS wear correct protective equipment when ring your marker.

NEVER point your marker in the direction of other people when not on the eld.

ALWAYS be aware of where the barrel is facing when adjusting the velocity.

WARNING

Table des matières

Autres manuels PLANET ECLIPSE Équipement de paintball

PLANET ECLIPSE

PLANET ECLIPSE MG 100 Manuel utilisateur

PLANET ECLIPSE

PLANET ECLIPSE GSL Manuel utilisateur

PLANET ECLIPSE

PLANET ECLIPSE 180R.68CAL Manuel d'instructions

PLANET ECLIPSE

PLANET ECLIPSE GMEK Manuel utilisateur

PLANET ECLIPSE

PLANET ECLIPSE LV1.6 Manuel utilisateur

PLANET ECLIPSE

PLANET ECLIPSE EGO TEN Manuel utilisateur

PLANET ECLIPSE

PLANET ECLIPSE CS3 Manuel utilisateur

PLANET ECLIPSE

PLANET ECLIPSE Etek STAR Frame Manuel utilisateur

PLANET ECLIPSE

PLANET ECLIPSE GEO2 Manuel utilisateur

PLANET ECLIPSE

PLANET ECLIPSE SL Series Manuel du propriétaire

PLANET ECLIPSE

PLANET ECLIPSE EGO LV2 Manuel d'instructions

PLANET ECLIPSE

PLANET ECLIPSE emek fl 3-way valve Manuel utilisateur

PLANET ECLIPSE

PLANET ECLIPSE GEO 4 Manuel utilisateur

PLANET ECLIPSE

PLANET ECLIPSE GEO CS1 Manuel utilisateur

PLANET ECLIPSE

PLANET ECLIPSE Eclipseblade E2 Manuel utilisateur

PLANET ECLIPSE

PLANET ECLIPSE GEO IV CORE Manuel utilisateur

PLANET ECLIPSE

PLANET ECLIPSE EMF100 Manuel utilisateur

PLANET ECLIPSE

PLANET ECLIPSE GTEK170R Manuel utilisateur

PLANET ECLIPSE

PLANET ECLIPSE CS3 .68CAL Manuel d'instructions

PLANET ECLIPSE

PLANET ECLIPSE GTEK M170R Manuel utilisateur

PLANET ECLIPSE

PLANET ECLIPSE EGO LV1 Manuel utilisateur

PLANET ECLIPSE

PLANET ECLIPSE ETHA3 Manuel utilisateur

Manuels Équipement de paintball populaires d'autres marques

First Endeavor Paintball

First Endeavor Paintball The Quest Manuel utilisateur

PMI

PMI Piranha VTL Manuel utilisateur

Proto

Proto SLG ULTRALITE Manuel utilisateur

Bob Long Technologies

Bob Long Technologies Alias Intimidator Manuel utilisateur

Proto

Proto REFLEX RAIL Manuel utilisateur

MCS

MCS BOX DRIVE Manuel utilisateur

Spyder

Spyder MR1 Manuel utilisateur

Evil

Evil OMEN 2.0 Manuel utilisateur

GOG

GOG Envy Mode d’emploi

Evil

Evil Pimp Kit Manuel utilisateur

Proto

Proto SWITCH EL Manuel utilisateur

Empire

Empire MINI Manuel utilisateur

Psychoballistics

Psychoballistics SILVER BULLET LCD Manuel utilisateur

Virtue

Virtue SPIRE III Manuel utilisateur

Dangerous power

Dangerous power G3 SPEC-R Manuel utilisateur

Valken

Valken Code Manuel utilisateur

Indian Creek Design

Indian Creek Design BushMaster Series Manuel utilisateur

PMI

PMI BlackMaxx Manuel utilisateur
