INFORMATION TO THE USER
FCC COMPLIANCE STATEMENT
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of this device.
This transmitter must not be co-located or operated in conjunction with any other
antenna or transmitter. The Bluetooth antenna cannot be removed (or replaced) by
user. This equipment complies with FCC/ IC radiation exposure limits set forth for
an uncontrolled environment and meets the FCC radio frequency (RF) Exposure
Guidelines and RSS-102 of the IC radio frequency (RF) Exposure rules. This
equipment has very low levels of RF energy that it deemed to comply without
maximum permissive exposure evaluation (MPE). But it is desirable that it should
be installed and operated keeping the radiator at least 20 cm or more away from
person’s body (excluding extremities: hands, wrists, feet and ankles). Alteration
or modications carried out without appropriate authorization may invalidate the
user’s right to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
□ Relocate or reorient the receiving antenna.
□ Increase the separation between the equipment and receiver.
□ Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
□ Consult the dealer or an experienced radio/TV technician for help.
CAUTION!!
ADJUSTMENT OR ALTERATIONS OF THIS DEVICE MAY RESULT
IN HAZARDOUS RADIATION EXPOSURE.
TROUBLE SHOOTING GUIDE
TROUBLE CAUSE SOLUTION
Unit will not turn on
The fuse is blown Check / replace the fuse
Bad accessory power
connection
Check accessory power port for
proper operational voltage
No sound is heard
Blown speaker Replace faulty speaker
Volume is low / muted Press the volume level up
Device is paused or muted
Check your devices playing /
volume status
Cannot pair Bluetooth
The Bluetooth function of your
device is not enabled
Refer to the user manual of the
your device for how to enable
the Bluetooth function
The MFC memory is full
Turn o the last paired device
BLUETOOTH
The audio quality is poor
after connection with a
Bluetooth enabled device The Bluetooth reception is poor
Move the device closer to the
audio system or remove any
obstacle between the device
and the systems antenna
Unit has become
unresponsive Power glitch or interference
Disconnect power for
10 seconds to reset
SPECIFICATIONS
BLUETOOTH
• Version: 3.0 w/ EDR
• A2DP
• Range: 33ft (10m) Class 2
SPEAKERS
• Dimensions: 8”
• Impedance: 4Ω + 4Ω
• Cone Type: PP CARBON + RUBBER SURROUND
• Tweeter Size: 1” PEI SOFT DOME
AMPLIFIER
• Maximum Output Power: 700 Watts
• Input impedance: 10kΩ
• Frequency Response: 45Hz-25kHz
CHASSIS
• Weight: 20.5lbs / 9.31Kg
• Unit Dimensions cm HxDxW: 23.3 x 37.5 x 83.3
• Unit Dimensions Inches HxDxW: 9.17 x 14.78 x 32.79
• Controller Dimensions HxDxW:
1.00”x3.22”x3.22” / 25.2mm x 80.1mm x 80.1mm
• Controller cable length: 6ft / 2m
• MFC Quick Connect DIN Harness
GENERAL
• Operational Power: 14.4VDC (10.8V ~ 16V allowable)
• Grounding System: Negative type
• MAX Current Draw: 9.7A
• Replacement Fuse: 10A AGC TYPE
• USB MAX Current: 1A
• Color: Black
• Storage Temperature: 5oF to 113oF / -15oC to 45oC
• Operation Temperature: 14oF to 140oF / -10oC to 60oC
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
