Planar WS231 Manuel utilisateur

WS231

User’s Manual

PREFACE

FCC Compliance Statement

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions:

1. this device may not cause harmful interference, and

2. this device must accept any interference received, including interference

that may cause undesired operation.

FCC WARNING

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if

not installed and used in accordance with the instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more

of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Caution:

To comply with the limits for an FCC Class B computing device, always use

the shielded signal cord supplied with this unit.

The Federal Communications Commission warns that changes or

modifications of the unit not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

User’s Manual

CE mark for Class B ITE (Following European standard EN55022/1998;

EN61000-3-2/1995; EN61000-3-3/1995, EN55024/1998,

EN60950/1992+A1+A2+A3+A4+A11)

Radio Frequency Interference Statement

Warning:

This is a Class B product. In a domestic environment, this product may cause

radio interference in which case the user may be required to take adequate

measures.

Canadian Doc Notice

For Class B Computing Devices

This digital apparatus does not exceed the Class B limits for radio noise

emissions from digital apparatus as set out in the Radio Interference

Regulation of the Canadian Department of Communications.

“Le présent appareil numérique n’èmet pas de bruits radioélectriques dépassant

les limites applicables aux appareils numériques de la class B prescrites dans le

Règlement sur le brouillage radioélectrique édicté par le ministère des

Communications du Canada”

User’s Manual

iii

Important Safety Instructions

Please read the following instructions carefully. This manual should be

retained for future use.

1. To clean the LCD Monitor screen, first, make sure the Monitor is in the

power off mode. Unplug the Monitor from its power source before

cleaning it. Do not spray liquid cleaners directly onto the unit. Stand

away from the LCD Monitor and spray cleaning solution onto a rag.

Without applying excessive pressure, clean the screen with the slightly

dampened rag.

2. Do not place your LCD Monitor near a window. Exposing the Monitor to

rain, water, moisture or sunlight can severely damage it.

3. Do not place anything on top of the Monitor-to-PC signal cord. Make sure

the cord is placed in an area where it will not be stepped on.

4. Do not apply pressure to the LCD screen. Excessive pressure may cause

permanent damage to the display.

5. Do not remove the cover or attempt to service this unit by yourself. You

may void the warranty. Servicing of any nature should be performed only

by an authorized technician.

6. Safe storage of the LCD Monitor is in a range of minus 20 to plus 65

degrees Celsius (-4°F-149°F). Storing your LCD Monitor outside this

range could result in permanent damage.

7. If any of the following occurs, immediately unplug your Monitor and call

an authorized technician.

• The power or Monitor-to-PC signal cord is frayed or damaged.

• Liquid has been spilled onto the Monitor, or it has been exposed to

rain.

• The Monitor has been dropped or the case has been damaged.

8. The appliance should be disconnected from the mains by pulling the mains

power cord/mains plug.

9. The socket-outlet shall be installed near the equipment and shall be easily

accessible.

User’s Manual

TABLE OF CONTENTS

PREFACE.................................................................................................................. I

TABLE OF CONTENTS....................................................................................... IV

CHAPTER 1 ..............................................................................................................1

Your new LCD Monitor!........................................................................ 1

Unpacking.............................................................................................. 1

Identifying Components....................................................................... 2

The LCD Monitor — Front View...................................................... 2

The LCD Monitor — Rear View....................................................... 3

Adjusting the Viewing Angle ............................................................... 4

Connecting AC Power .......................................................................... 4

Connecting Video ................................................................................. 5

6Power Management System .............................................................. 6

CHAPTER 2 ..............................................................................................................7

The LCD Monitor’s Display Controls .................................................. 7

The hotkey descriptions .................................................................... 13

APPENDIX A ..........................................................................................................16

TFT LCD Monitor Specifications ....................................................... 16

APPENDIX B ..........................................................................................................16

APPENDIX C ..........................................................................................................18

Troubleshooting Procedures............................................................. 18

CHAPTER 1

The LCD Monitor

Your new LCD Monitor!

Your LCD Monitor has been designed to be versatile, ergonomic and user-friendly.

The LCD Monitor is capable of displaying most standards, from 640 x 480 VGA to

1600 x 1200 UXGA. The digital controls located on the front panel allow the user to

easily adjust the Monitor’s display parameters. The LCD Monitor’s small footprint

allows you more room in your workspace for other peripherals. Lightweight and

compact, the LCD Monitor is the perfect solution for all type of users.

Unpacking

Before you unpack your LCD Monitor, prepare a suitable workspace for your LCD

Monitor and computer. You need a stable, level and clean surface near a wall outlet.

Even though the LCD Monitor uses very little power, you should put it in a location,

which allows sufficient airflow to ensure that the LCD Monitor and your computer

does not become too hot. Set up your LCD Monitor so that the panel doesn’t face a

window where sunlight often comes in. The glare caused by sunlight reflecting off the

LCD Monitor’s screen will make it difficult to see.

After you unpack your LCD Monitor; make sure the following items are included in

the box and in good condition:

• LCD Monitor

• AC Adapter

• Monitor-to-PC Analog signal cable (15-pin)

• Monitor-to-PC Digital signal cable (24-pin)

• Power cord

• This user’s manual

• CD Manual

• Frequently Asked Questions

• Quick Setup Guide

User’s Manual

If you find that any of these items are missing or appear damaged, contact your dealer

immediately. Do not throw away the packing material or shipping carton in case you

need to ship or store the LCD Monitor in the future.

Identifying Components

The LCD Monitor has been designed to provide easy access to all controls and

peripheral ports. The following figures will help you identify the LCD Monitor’s

controls and ports.

The LCD Monitor — Front View

Figure 1-1: The LCD Monitor Panel and Controls

1. LCD Screen

The RGB LCD Monitor Screen is capable of producing most display

standards up to a maximum resolution of 1600 x 1200 (UXGA).

2. Function Control Buttons

These two buttons allow you to select one of the control functions. Press

either the right or left control button to scroll through the menu items. Press

the left function button to activate the OSD Menu.

3. Adjustment Control Buttons

These two buttons allow you to adjust the selected control function to

accommodate your specific working environment. Press the right button to

increase the setting of the selected control function and press the left button to

decrease the setting of the selected control function.

User’s Manual

4. Power Button and Port Select

Push the button to turn the Monitor ON or OFF (push and hold the button for

2 seconds to switch between Analog or Digital input mode).

5. Power-On Indicator

This LED indicator lights when the power is on. The LED indicator will

blink when the LCD Monitor is in Power Saving mode.

The LCD Monitor — Rear View

Figure 1-2: LCD Monitor’s Rear Ports

1. Input signal ports

The monitor has one 15-pin D-sub VGA connector and one 24-pin DVI

connector (optional), the 24-pin DVI connector is for Digital signal if your

PC has a graphic card with DVI connector.

2. USB port (Optional)

Connect the USB cable from this port to PC HOST.

3. DC Power Jack

Connect the AC power Adapter output cable to this connector

User’s Manual

Adjusting the Viewing Angle

Your LCD Monitor is designed to allow you to adjust it to a comfortable viewing angle.

Please see Figure 1-3.

Figure 1-3: Angle Settings

Connecting AC Power

Please refer to the following instructions for connecting AC power to the LCD Monitor.

Plug the female end of the power cable into the AC power connector. Plug the male

end of the power cord into a wall socket. The plug on the power cable will vary

according to the electrical standard in your area. Please refer to Figure 1-4.

User’s Manual

Figure 1-4: Connecting Power to the LCD Monitor

Connecting Video

1. Turn off your PC and the LCD Monitor before connecting your LCD Monitor

to the computer.

2. Connect one end of the VGA signal cable to the PC’s D-sub VGA port and

the other end to the monitor VGA port. Please refer to Figure 1-5.
