Planar PS Series RS232

User Guide

PS4662T

PS5562

PS5562T

PS6562

Contents of this publication may not be reproduced in any form without permission of Planar

Systems, Inc.

Trademark Credits

Windows™ is a trademark of Microsoft Corp.

All other companies are trademarks or registered trademarks of their respective companies.

Disclaimer

The information contained in this document is subject to change without notice. Planar

Systems, Inc. makes no warranty of any kind with regard to this material. While every

precaution has been taken in the preparation of this manual, the Company shall not be liable

for errors or omissions contained herein or for incidental or consequential damages in

connection with the furnishing, performance, or use of this material.

Warranty and Service Plans

Planar warranty and service plans will help you maximize your investment by providing great

support, display uptime, and performance optimization. From post-sale technical support to

a full suite of depot services, our services are performed by trained Planar employees. When

you purchase a Planar product, you get more than a display, you get the service and support

you need to maximize your investment. To find the latest warranty and service information

regarding your Planar product, please visit http://www.planar.com/support

Part Number: 020-1329-00A

Planar PS Series RS232 User Guide 1

RS232 Codes

RS232 control is not necessary for operation, but is a convenient way to control

displays from a computer at a distance. Most things you can do with the remote, you

can do with RS232 commands. Plus, you can send inquiries to the displays and find

out the current settings and values.

1RS232 Command Format

STX(1byte) + IDT(1byte)+ Type(1byte)+ CMD(3bytes)+ [Value/Reply(1byte)] +

ETX(1byte)

STX: Start byte = 07

IDT: Don’t care

Type: Read or Write command, 01: read, 02: write; 00: return to host (from

monitor)

CMD: As shown in the table on the following pages

Value: Setting Value of “Write Command”

Reply: Return Value of monitor

ETX: End byte = 08

Transmit from PC (Host)

Read command: 07 IDT 01 CMD 08 (7bytes)

Write/Setting command: 07 IDT 02 CMD VAL 08 (8bytes)

Return from Monitor: Sent after receiving any valid command. The response CMD is

the same as the received CMD.

2Serial Port Setting

Baud rate can be set to 115200, 38400, 19200, or 9600 to match the monitor baud

rate setting.

Baud rate 19200 is the default setting.

Explanation of symbols

▲: Valid command in standby mode.

Note: The Wake Up from Sleep setting must be set to Wake on All for these commands to

work in standby.

Baud Rate Data Bit Parity Bit Stop Bit

19200 8 None 1

RS232 Codes

2 Planar PS Series RS232 User Guide

Main Item Control Item CMD Type

Value /

(Decimal)

Content CMD (HEX) Remark

Power Control

and Input

Source

Power Control POW R/W 00 Off (soft power) 50 4F 57 ▲

01 On (soft power) ▲

Input Source MIN R/W 00 VGA 4D 49 4E

13 DisplayPort

9HDMI1

10 HDMI2

Display

Adjustment

Color BRI R/W 0~100 Backlight Brightness 42 52 49

BRL R/W 0~100 Digital Brightness Level 42 52 4C

BLC R/W 00 Off (Backlight) 42 4C 43

01 On (Backlight)

CON R/W 0~100 Contrast 43 4F 4E

SHA R/W 0~8 Sharpness 53 48 41

HUE R/W 0~100 Hue 48 55 45

SAT R/W 0~100 Saturation 53 41 54

Scheme SCM R/W 00 User 53 43 4D

01 Sport

02 Game

03 Cinema

04 Vivid

RS232 Codes

Planar PS Series RS232 User Guide 3

Display

Adjustment

Color

Temperature

COT R/W 00 User 43 4F 54

01 6500K

02 9300K

03 3200K

06 5000K

07 7500K

Gamma GAC R/W 00 Off (Gamma) 47 41 43

01 1.85 (Gamma)

02 1.9 (Gamma)

03 1.95 (Gamma)

04 2.0 (Gamma)

05 2.05 (Gamma)

06 2.15 (Gamma)

07 2.15 (Gamma)

08 2.2 (Gamma)

09 2.25 (Gamma)

10 2.3 (Gamma)

11 2.35 (Gamma)

12 2.4 (Gamma)

13 2.45 (Gamma)

14 2.5 (Gamma)

15 2.55 (Gamma)

16 2.6 (Gamma)

Main Item Control Item CMD Type

Value /

(Decimal)

Content CMD (HEX) Remark

RS232 Codes

4 Planar PS Series RS232 User Guide

Display

Adjustment

Gain & Offset USR R/W 0~100 Red Gain (0~100) 55 53 52

USG R/W 0~100 Green Gain (0~100) 55 53 47

USB R/W 0~100 Blue Gain (0~100) 55 53 42

UOR R/W 0~100 Red Offset (0~100) 55 4F 52

UOG R/W 0~100 Green Offset (0~100) 55 4F 47

UOB R/W 0~100 Blue Offset (0~100) 55 4F 42

VGA

Adjustment

PHA R/W 0~63 Phase 50 48 41

CLO R/W 0~100 Clock 43 4C 4F

HOR R/W 0~100 Horizontal Position 48 4F 52

VER R/W 0~100 Vertical Position 56 45 52

ADJ W00 Auto Adjust 41 44 4A

RTC Current Time

Adjustment

RTY R/W 0~99 Year 52 54 59

RTM R/W 1~12 Month 52 54 4D

RTD R/W 1~31 Day 52 54 44

RTH R/W 0~23 Hour 52 54 48

RTN R/W 0~59 Minute 52 54 4E

Timer Mode TMS R/W 0Everyday Mode 54 4D 53

1Workday Mode

2User Mode

Main Item Control Item CMD Type

Value /

(Decimal)

Content CMD (HEX) Remark

RS232 Codes

Planar PS Series RS232 User Guide 5

RTC Enable AEN R/W 0~127 In User Mode:

Set bit0 to 1: Sunday

Enable

Set bit1 to 1: Monday

Enable

Set bit2 to 1: Tuesday

Enable

Set bit3 to 1:

Wednesday Enable

Set bit4 to 1: Thursday

Enable

Set bit5 to 1: Friday

Enable

Set bit6 to 1: Saturday

Enable

In Everyday Mode:

Set any bit0~6 to 1:

Mon.~Sun. Enable

In Workday Mode:

Set bit0 to 1: Sunday

Enable

Set any bit1~5 to 1:

Mon.~Fri. Enable

Set bit6 to 1: Saturday

Enable

41 45 4E

Disable AEF R/W 0~127 In User Mode:

Set bit0 to 1: Sunday

Disable

Set bit1 to 1: Monday

Disable

Set bit2 to 1: Tuesday

Disable

Set bit3 to 1:

Wednesday Disable

Set bit4 to 1: Thursday

Disable

Set bit5 to 1: Friday

Disable

Set bit6 to 1: Saturday

Disable

In Everyday Mode:

Set any bit0~6 to 1:

Mon.~Sun. Disable

In Workday Mode:

Set bit0 to 1: Sunday

Disable

Set any bit1~5 to 1:

Mon.~Fri. Disable

Set bit6 to 1: Saturday

Disable

41 45 46

Main Item Control Item CMD Type

Value /

(Decimal)

Content CMD (HEX) Remark

RS232 Codes

6 Planar PS Series RS232 User Guide

RTC Sunday SNH R/W 0~23 Sunday On Hour 49 4E 48

SNM R/W 0~59 Sunday On Minute 53 4E 4D

SFH R/W 0~23 Sunday Off Hour 53 46 48

SFM R/W 0~59 Sunday Off Minute 53 46 4D

Monday NNH R/W 0~23 Monday On Hour 4E 4E 48

NNM R/W 0~59 Monday On Minute 4E 4E 4D

NFH R/W 0~23 Monday Off Hour 4E 46 48

NFM R/W 0~59 Monday Off Minute 4E 46 4D

Tuesday ENH R/W 0~23 Tuesday On Hour 45 4E 48

ENM R/W 0~59 Tuesday On Minute 45 4E 4D

EFH R/W 0~23 Tuesday Off Hour 45 46 48

EFM R/W 0~59 Tuesday Off Minute 45 46 4D

Wednesday DNH R/W 0~23 Wednesday On Hour 44 4E 48

DNM R/W 0~59 Wednesday On Minute 44 4E 4D

DFH R/W 0~23 Wednesday Off Hour 44 46 48

DFM R/W 0~59 Wednesday Off Minute 44 46 4D

Thursday UNH R/W 0~23 Thursday On Hour 55 4E 48

UNM R/W 0~59 Thursday On Minute 55 4E 4D

UFH R/W 0~23 Thursday Off Hour 55 46 48

UFM R/W 0~59 Thursday Off Minute 55 46 4D

Friday INH R/W 0~23 Friday On Hour 49 4E 48

INM R/W 0~59 Friday On Minute 49 4E 4D

IFH R/W 0~23 Friday Off Hour 49 46 48

IFM R/W 0~59 Friday Off Minute 49 46 4D

Main Item Control Item CMD Type

Value /

(Decimal)

Content CMD (HEX) Remark

RS232 Codes

Planar PS Series RS232 User Guide 7

RTC Saturday TNH R/W 0~23 Saturday On Hour 54 4E 48

TNM R/W 0~59 Saturday On Minute 54 4E 4D

TFH R/W 0~23 Saturday Off Hour 54 46 48

TFM R/W 0~59 Saturday Off Minute 54 46 4D

Audio Volume VOL R/W 0~100 volume 56 4F 4C

Bass BAS R/W 0~12 Bass (-6 ~ 6) 42 41 53

Treble TRE R/W 0~12 Treble (-6 ~ 6) 54 52 45

Balance BAL R/W 0~12 Balance (-6 ~ 6) 42 41 4C

Internal

Speaker

INS R/W 00 Internal Speaker Off 49 4E 53

01 Internal Speaker On

Mute MUT R/W 00 Mute Off 4D 55 54

01 Mute On

OSD Transparency OST R/W 0~12 OSD Transparency 4F 53 54

H Position OSH R/W 0~100 OSD H Position 4F 53 48

V Position OSV R/W 0~100 OSD V Position 4F 53 56

OSD Rotation OSR R/W 00 Landscape 4F 53 52

01 Portrait

OSD Language OSL R/W 00 English 4F 53 4C

01 Chinese

OSD Timeout OSO R/W 5~120 OSD Timeout. The value

increments by five (5, 10,

15, 20..., 115, 120 seconds).

4F 43 4F

Splash Screen SPS R/W 0Off 53 50 53

1On

Main Item Control Item CMD Type

Value /

(Decimal)

Content CMD (HEX) Remark

RS232 Codes

8 Planar PS Series RS232 User Guide

OSD Message Box MSB R/W 0Off 4D 53 42

1On

Other Control Scaling ASP R/W 01 16:9 41 53 50

02 4:3

04 Auto

ZOM R/W 0~10 Adjust overscan ratio 41 53 50

Baud Rate

Adjustment

BRA R/W 00 115200 42 52 41

01 38400

02 19200

03 9600

Power Saving

Config

WFS R/W 0Wake on VGA 57 46 53

1Wake on All

2Never Sleep

Auto Scan ATS R/W 0Off 41 54 53

1Main

Pixel Orbit IRF R/W 0Off 49 52 46

1On

Smart Light

Control

SLC R/W 0Off 53 4C 43

1DCR

2Light Sensor

Power LED LED R/W 0Off 4C 45 44

1On

Main Item Control Item CMD Type

Value /

(Decimal)

Content CMD (HEX) Remark
