Pioneer CD-MR70/UC Instructions de construction

ORDER NO.

PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan

PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.

PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium

PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936

PIONEER CORPORATION 2004

CD-MR70/UC

CRT3268

WIRED MARINE REMOTE CONTROL

CD-MR70

/UC

For details, refer to "Important symbols for good services".

K-ZZA. APR. 2004 printed in Japan

CD-MR70/UC

1234

SAFETY INFORMATION

CAUTION

This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.

Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely

complex products such as those covered by this manual.

Improperly performed repairs can adversely affect the safety and reliability of the product and may void the

If you are not qualified to perform the repair of this product properly and safely, you should not risk

and refer the repair to a qualified service technician.

WARNING

This product contains lead in solder and certain electrical parts contain chemicals which are known to the

of California to cause cancer, birth defects or other reproductive harm.

Health & Safety Code Section 25249.6 - Proposition 65

repair

warranty.

trying to do so

state

-Service Precaution

1. You should conform to the regulations governing

the product (safety, radio and noise, and other

regulations), and should keep the safety during

servicing by following the safety instructions

described in this manual.

[ Important symbols for good services ]

In this manual, the symbols shown-below indicate that adjustments, settings or cleaning should be made securely.

When you find the procedures bearing any of the symbols, be sure to fulfill them:

2. Adjustments

To keep the original performances of the product, optimum adjustments or specification confirmation is indispensable.

In accordance with the procedures or instructions described in this manual, adjustments should be performed.

3. Cleaning

For optical pickups, tape-deck heads, lenses and mirrors used in projection monitors, and other parts requiring cleaning,

proper cleaning should be performed to restore their performances.

5. Lubricants, glues, and replacement parts

Appropriately applying grease or glue can maintain the product performances. But improper lubrication or applying

glue may lead to failures or troubles in the product. By following the instructions in this manual, be sure to apply the

prescribed grease or glue to proper portions by the appropriate amount.For replacement parts or tools, the prescribed

ones should be used.

4. Shipping mode and shipping screws

To protect the product from damages or failures that may be caused during transit, the shipping mode should be set or

the shipping screws should be installed before shipping out in accordance with this manual, if necessary.

1. Product safety

You should conform to the regulations governing the product (safety, radio and noise, and other regulations), and

should keep the safety during servicing by following the safety instructions described in this manual.

CD-MR70/UC 3

5678

SPECIFICATIONS

Power source ..................................................................14.4 V DC (10.8 — 15.1 V allowable)

Grounding system ................................................................................................ Negative type

Max. current consumption ............................................................................................ 200 mA

Dimensions ...................................................................................... 102 (W) ⋅67 (H) ⋅46 (D)

Weight ............................................................................................................................ 0.12 Kg

Note:

• Specifications and the design are subject to possible modification without notice due to improvements.

CD-MR70/UC

1234

EXPLODEDVIEWS AND PARTS LIST

PACKING

PACKING SECTION PARTS LIST

OTES : •Parts marked by " * " are generally unavailable because they are not in our Master Spare Parts List.

• Screw adjacent to mark on the product are used for disassembly.

• For the applying amount of lobricants or glue, follow the instructions in this manual.

(In the case of no amount instructions,apply as you think it appropriate.)

Mark No. Description Part No.

1 Cord Assy CZD5385

2 Cord CZD5386

3 Accessory Assy CZE5014

4 Carton CZH5366

5 Contain Box CZH5367

6 Tape CZN7023

7 Owner's Manual CZR5017

(English, French)

8 Remote Control Assy CZX5098

Mark No. Description Part No.

CD-MR70/UC 5

5678

OPERATIONS

Buttons on the Pioneer Head Unit and remote control unit with the same name have the

same function.

1VOLUME buttons

2BAND/ESC button

(DISC/P.Ch) buttons

423(TRK/SEEK) buttons

5SRC (source) button

6ATT button

Volume is decreased about one-tenth the set volume (Attenuator).

CD-MR70/UC

1234

Connecting the Remote Control Unit

•Connect the

remote control

to the back of the Head Unit. Route the cable being careful

not to allow the cables to become entangled in surrounding objects.

•After connections are finished, check all operations of the

remote control

•Connect cables securely.

Mounting Surface (rear view)

Break Lines

7 mm nuts

1.5 m (4ft. 11 in.)

Bracket

15 cm (5-7/8 in.)

15 cm (5-7/8 in.) Pin plug cable

Connect to the wired remote input of a

Pioneer Head Unit. When connecting, use

the pin plug extension cable (supplied).

Red

Connect to the electric terminal controlled

by the boat’s ignition switch (12 V DC)

ON/OFF. When connecting, use the power

extension cable (supplied).

Black (ground)

Connect to the boat’s ground lead.

System Connections

Connect the wired remote input of a Pioneer Head Unit and the remote control pin plug.

•When connecting to the remote control pin plug’s wired remote input, use the pin plug

extension cable (supplied).

•When connecting the pin plug extension cable (supplied) and the remote control pin

plug, wrap with tape (supplied) to assure secure connection.

Pin plug extension cable (supplied)

Pin plug

CD-MR70

Remote Control

Unit

A Pioneer Head Unit with a

wired remote input

(e.g. DEH-P2600)

Wired remote input
