Pioneer PDP-R03U Guide de configuration

Product Training Guide

Media Receiver

PDP-R03U

Multimedia & Web Training Department

545 Nolan Drive Suite 100

Southlake, Texas 76092

Contents

Overview…………………………21

PCB Layout……………………………22

PC I/F Unit………………………….....23

Power Supply……………………......24

Extension Cables………………..…..25

AV Unit (Basic Signal Path)………..26-27

CC & V-Chip (Basic Signal Path)….28-29

PC I/F (Basic Signal Path)……….…30-31

Basic Audio Signal Path…………...32-33

Power On Procedure………………..34-35

DC to DC Converter (Startup)……..36-37

AV System Block (Overall)………...38-39

PC I/F Block (Overall)………………40-41

Disassembly…………………………42-43

Adjustments………………………….44-49

Trouble Shooting (Charts)………...50-56

IC Descriptions……………………...57-57

Specifications………………………..60

Preface ……………………….…….....3

Basic Operation ………………,4-20

Connecting the System.……………4

Controls & Connectors………..……5

Remote………………………..……….6

Power On………………………………7

Auto Installation…………………..….8

Basic Adjustment Settings……..…..9-10

Connections…………………………..11

V-Chip Settings………………………12-16

Multiscreen Functions………………17

Consumer Troubleshooting……….18

PC Compatibility Chart……………..19

Factory Preset………………………..20

Lead in the solder used in this product

is a known reproductive toxicant which

may cause birth defects or other reproductive

harm. (California Health and Safety Code

Section 25249.5).

When servicing this or handling circuit

boards and other components which

contain solder, avoid unprotected skin

contact with the solder. Also, when

soldering do not inhale any smoke or

fumes produced.

This technical training guide will address

the disassembly and adjustments of the

Pioneer PDP-R03U Media receiver

This guide was designed as a servicing aid

and is not intended to replace the service

manual. The student should have the

appropriate service manual on hand when

when using this guide. Data in the service

manual for this unit contains specific

information on safety, parts and adjustments.

Safety information

Important safety data for this Pioneer model

is contained in the service manual. Before

returning the unit to the customer, complete

all product safety obligations and tests.

Technicians who bypass safety features or

fail to carry out safety checks may expose

themselves and others to possible injury,

and may be liable for any resulting damages.

Preface

For more information on electronic

circuits and block diagrams refer

to Service manual ARP3113.

System cable

Media Receiver (rear view)

Power cord

Plasma Display (rear view)

Power cord

System cable

(bottom view)

For details on optional

PIONEER speaker

installation refer to the

speaker instruction

manual provided.

(GRAY)(WHITE)

(GRAY) (WHITE)

Connecting the system

1. Connecting the system cable and the power cord to the Plasma Display

2. Connecting the system cable and the power cord to the Media Receiver

•THESE SPEAKER TERMINALS CAN BE UNDER HAZARDOUS VOLTAGE WHEN YOU CONNECT OR DISCONNECT

THE SPEAKER CABLES. TO PREVENT THE RISK OF ELECTRIC SHOCK, DO NOT TOUCH UNINSULATED PARTS

BEFORE DISCONNECTING THE POWER CORD.

(GRAY)

RS-232C

IN OUT

CONTROL

AC INLET

SYSTEM

CABLE (WHITE)

S-VIDEO VIDEO R-AUDIO-L

S-VIDEO

ANT/CABLE 75ΩOUT

COMPONENT VIDEO COMPONENT VIDEO

VIDEO R-AUDIO-L

AB INPUT 1

INPUT 2

RGB INPUT

INPUT 3

MONITOR OUTPUT

(GRAY)

RS-232C

IN OUT

CONTROL

AC INLET

SYSTEM

CABLE (WHITE)

S-VIDEO VIDEO R-AUDIO-L

S-VIDEO

ANT/CABLE 75ΩOUT

COMPONENT VIDEO COMPONENT VIDEO

VIDEO R-AUDIO-L

AB INPUT 1

INPUT 2

RGB INPUT

INPUT 3

MONITOR OUTPUT

POWER

STANDBY/ON

MEDIA RECEIVER

PDP-R03U

Front view

CLEAR*

POWER button INPUT 4 terminal (S-VIDEO)

INPUT 4 terminal (VIDEO)

PC INPUT terminal (AUDIO) INPUT 4 terminals (AUDIO)

PC INPUT terminal (ANALOG RGB)

Media Receiver

*If you’re having problems operating the Media Receiver and want to return to normal screen, even when it

stays on (the indicator lights green), press CLEAR on the Media Receiver. Pressing CLEAR resets the System

as shown below.

•AV SELECTION resets to STANDARD

•TV channel returns to initial channel setting(Air:2ch, Cable:1 or 2ch)

•Multiscreen resets to normal

•Audio setting initializes

•SRS resets to Off.

•Image position initializes

•Pressing CLEAR will not work if the System is in standby mode but the indicator lights red.

•Pressing CLEAR will not delete channel preset or secret number.

Rear view

INPUT 1 COMPONENT VIDEO

terminals (Y, PB, PR)

INPUT 3 COMPONENT

VIDEO terminals (Y, PB, PR)

MONITOR OUTPUT

terminal (S-VIDEO)

SYSTEM CABLE terminal

(GRAY)

SYSTEM CABLE

terminal (WHITE)

AC INLET terminal

RS-232C terminal

(used in the factory setup)

MONITOR OUTPUT

terminal (VIDEO)

MONITOR OUTPUT

terminals (AUDIO)

CONTROL terminals

(IN/OUT)

Antenna input

terminal (A)

Antenna input

terminal (B)

Antenna output

terminal

INPUT 3

RGB INPUT

terminal

INPUT 3 terminal

(S-VIDEO)

INPUT 3 terminal

(VIDEO)

INPUT 3 terminals

(AUDIO)

INPUT 1 terminal

(S-VIDEO)

INPUT 1 terminal

(VIDEO)

INPUT 1 terminals

(AUDIO)

INPUT 2 terminal

(S-VIDEO)

INPUT 2 terminal

(VIDEO)

INPUT 2 terminals

(AUDIO)

Push CLEAR lightly with the tip

of a pointed object like a

ballpoint pen.

Remote control unit

•When using the remote control unit, point it at the Plasma

Display.

1TVa:Switch the Plasma Display power on or off.

2 FRONT SURR: Set SRS and FOCUS Sound System.

3 AV SELECTION: Select an audio or video setting.

(AV mode: STANDARD, DYNAMIC,

MOVIE, GAME, USER.

PC mode: STANDARD, USER.)

4 SCREEN MODE: Select the screen size.

5 DISPLAY: Display the channel information.

6 SLEEP: Set the SLEEP timer.

7 CH RETURN: Return to the previous channel.

8CHk/l: Select the channel.

9 MENU: Display the menu screen.

10 MENU RETURN: Return to the previous menu screen.

11 a/b/c/d: Select a desired item on the setting screen.

12ANT:Select the antenna. (A, B)

13 INPUT: Select an input source of the Plasma Display.

(TV, INPUT 1, INPUT 2, INPUT 3, INPUT 4, PC)

14 :When pressed all buttons on the remote control unit

will light. The lighting will turn off if no operations

are performed within about 5 seconds. This button

is used for performing operations in dark places.

15 MTS: Select the MTS/SAP.

16 CC: Display captions during closed-caption source.

17 Dual picture mode select buttons

SPLIT: Set the dual picture mode. Press again to return

to normal screen.

FREEZE: Set the still image. Press again to return to

normal screen.

SELECT: Select the active screen.

SUB INPUT: Select an input source of sub screen.

SUB CH k/l:Select the channel of sub screen.

18 0 –9: Set the channel.

19 CH ENTER: Execute a channel number.

20 VOL k/l: Set the volume.

21 eMUTING: Mute the sound.

22 SET/ENTER: Execute a command.

23 FAVORITE CH

A, B, C, D: Select any of four preset channels.

While watching you can toggle the set channels by

pressing A, B, C and D.

24 LED for transmission confirmation

ANT INPUT

SURR

FRONT

SELECTION

MTS CC

SPLIT

SELECT

SUB SUB CH

ⴐ

ⴑ

ⴐ

ⴑ

FREEZE

MODE

CH VOL

RETURN

MUTING

MENU TV/SAT/DVD

FAVORITE CH

RECEIVER

DTV/DVD TOP

SOURCE DTV/SAT

DTV/SAT

VCR REC

ABCD

RETURN

PLASMA DISPLAY

SET/

ENTER

GUIDE

INPUT VOL

ⴑ

VOL

ⴐ

INFO

SCREEN

SLEEP LEARNEDIT/

DISPLAY

INPUT ⴑ

TV VCRCBL

/SAT

/DTV

DVD

/LD

123

456

789

ENTER

11224 13

Mode switch

Plasma Display

Media Receiver

Off

Flashing red

Red

Green

Plasma Display status indicators

Power off

Media Receiver does not turn on or its power cord is disconnected.

The Plasma Display System is in standby mode.

The Plasma Display System turns the power on.

Media Receiver status indicators

Power off

Only the Media Receiver is in standby mode or the Plasma Display System is in standby mode.

The Plasma Display System turns the power on.

STANDBY/ON

MAIN POWER

STANDBY/ON

INPUTSTANDBY/ON VOLUMECHANNEL

Power indicator

POWER

STANDBY/ON

MEDIA RECEIVER

PDP-R03U

PUSH

PLASMA DISPLAY SYSTEM

POWER

Power indicator

ANT INPUT

SURR

FRONT

SELECTION

MTS CC

SPLIT

SELECT

SUB SUB CH

ⴐ

FREEZE

MODE

SCREEN

SLEEP LEARNEDIT/

DISPLAY

INPUT ⴑ

TV VCRCBL

/SAT

/DTV

DVD

/LD

123

456

789

ENTER

Turning on the power

1Press MAIN POWER on the Plasma Display.

•The power indicator on the Plasma Display flashes red.

2Press POWER on the Media Receiver.

•The System turns the power on.

•The power indicators on the Plasma Display and Media

Receiver lights up green.

•If the power indicators still light up red, press TV aon

the remote control unit or STANDBY/ON on the Plasma

Display to turn the System on.

First time turning on Media Receiver

1Press POWER on the Media Receiver.

•The power indicator on the Media Receiver lights up

red.

2Press MAIN POWER on the Plasma Display.

•The System turns the power on.

•The power indicators on the Plasma Display and Media

Receiver lights up green.

•If the power indicators still light up red, press TV aon

the remote control unit or STANDBY/ON on the Plasma

Display to turn the System on.

•In this manual, “System”mean the Plasma Display Panel and

Media Receiver.

Turning off the power

1Press TV aon the remote control unit or STANDBY/

ON on the Plasma Display.

•The System enters standby mode and the image on

the screen disappears.

•Both power indicators change from green to red.

2Press POWER on the Media Receiver.

•The power indicator on the Media Receiver turns off

and the one on the Plasma Display flashes red.

3Press MAIN POWER on the Plasma Display.

•The power indicator on the Plasma Display turns off

after approximately 5 seconds.

•If you are not going to use this System for a long time, be sure to

remove the Power cord from the power outlet.

Off

Red

Green

Language menu

Antenna menu

1. Setting a language

1Press a/bto select the desired language listed

on the screen.

2Press SET/ENTER to enter the setting.

2. Setting the antenna mode

1Press a/bto select “Air”or “Cable”on the screen.

2Press SET/ENTER to enter the setting.

Searching TV channels

CH Search

Air 2

Initial auto installation

When you turn on the Plasma Display System for the first time, it will automatically memorize the broadcasting

channels where you live. Perform the following steps before you press TV a.

1. Insert the batteries into the remote control unit.

2. Connect the antenna cable to the Media Receiver.

3. Plug in the power cord to the wall outlet.

3. Automatic channel searching

Channel auto search makes the Plasma Display System

look for all channels viewable in the set area.

•If no channel is found, “No program found. Is antenna

connected properly?”displays. And the auto channel

search finishes.

•Channel search function is available for ANT-A only.

•ANT-B cannot perform channel search.

•You may need to manually add the CABLE Converter

output channel setting (fixed), when connecting the CABLE

Converter output signal to the B terminal (ANT/CABLE

75q) on the Media Receiver (Rear).

Language

English

Français

Español

Air/Cable

Air

Cable

Contrast

Bright

Color

Tint

Sharp

Advanced

Reset

Basic adjustment settings

Energy Save

No Signal off

No Operation off

Description

Save power by decreasing picture

brightness.

System automatically shuts down if

no signal inputs for 15 minutes.

System automatically shuts down if

you do not operate the System for 3

hours.

Description

Adjusts the picture between light and

shade.

Adjusts picture brightness.

Adjusts color intensity.

Adjusts skin color to a more natural

tone.

Adjusts picture sharpness.

Adjusts color temperature, black,

3D-Y/C and black & white and

PureCinema.

All image adjustment settings return

to the factory preset values.

Treble

Bass

Balance

Reset

Description

Adjusts the treble weaker or stronger.

Adjusts the bass weaker or stronger.

Adjusts audio output between left

and right speakers.

All audio adjustment settings return

to the factory preset values.

Auto Installation

CH Setup

Parental CTRL

Description

Automatically memorizes the

broadcasting channels where you

live.

Sets the channel preset.

Sets a secret number to restrict

operations.

Input Select

Position

Audio Out

Demo

Language

Description

Select the kind of input signal of each

input source.

Adjusts the horizontal/vertical

position of the image displayed.

Select the type of monitor output. You

can adjust volume for the main

speaker or monitor output.

Demonstration setting for storefront

displays.

Select the on screen display

language.

First MENU

Power Control


Audio

Setup

Option

Power Control

Energy Save [Standard]

No Signal off [Disable]

No Operation off

RETURN

[Disable]


USER

Contrast

Bright

Color

Tint

Sharp

Advanced

Reset

RETURN

[+30]

[0]

–30

–7

+40

+30

Audio

USER

Treble

Bass

Balance

Reset

RETURN

[0]

–15

Left

+15

Right

AV mode menu items

List of AV menu items to help you with operations.

Setup

Auto Installation

CH Setup

Parental CTRL

RETURN

Option

Position

Audio Out

Demo

[Fixed]

[Off]

Input Select

Language

RETURN

[English]

10.

Basic adjustment settings

First MENU

Energy Save

Power

Management

Description

Save power by decreasing picture

brightness.

System automatically shuts down if

you set the time. Select Mode1 or

Mode2.

Contrast

Bright

Red

Green

Blue

Reset

Description

Adjusts the picture between light and

shade.

Adjusts picture brightness.

Adjusts red color intensity.

Adjusts green color intensity.

Adjusts blue color intensity.

All image adjustment settings return

to the factory preset values.

Treble

Bass

Balance

Reset

Description

Adjusts the treble weaker or

stronger.

Adjusts the bass weaker or stronger.

Adjusts audio output between left

and right speakers.

All audio adjustment settings return

to the factory preset values.

Auto Sync.

Fine Sync.

Audio Out

Description

Provides a clear input image.

Adjusts image H-Pos, V-Pos, clock

and phase.

After selecting type of monitor output,

adjusts the volume of the main

speaker or monitor output.

Power Control


Audio

Option

Power Control

Energy Save [Standard]

Power Management

RETURN

[Off]


USER

Contrast

Bright

Red

Green

Blue

Reset

RETURN

[+30]

[0]

–30

+40

+30

Audio

USER

Treble

Bass

Balance

Reset

RETURN

[0]

–15

Left

+15

Right

Option

Fine Sync.

Audio Out

RETURN

[Fixed]

Auto Sync.

PC mode menu items

List of PC menu items to help you with operations.

Autres manuels pour PDP-R03U

Table des matières

Autres manuels Pioneer Récepteur

Pioneer

Pioneer XV-DV525 Instructions d'utilisation

Pioneer

Pioneer Elite VSX-43TX Manuel utilisateur

Pioneer

Pioneer VSX91TXH - Elite AV Receiver Manuel utilisateur

Pioneer

Pioneer MVH-X375 Manuel utilisateur

Pioneer

Pioneer VSX-1021-K Manuel utilisateur

Pioneer

Pioneer XRE3138-A Manuel utilisateur

Pioneer

Pioneer SD-532HD5 Manuel utilisateur

Pioneer

Pioneer MVH-X189UI Manuel utilisateur

Pioneer

Pioneer SPH-C10BT Manuel utilisateur

Pioneer

Pioneer VSX-1017AV-K Manuel utilisateur

Pioneer

Pioneer VSX-423-K Manuel utilisateur

Pioneer

Pioneer AVH-X7500BT Manuel utilisateur

Pioneer

Pioneer MVH-85UB Manuel utilisateur

Pioneer

Pioneer DMH-A4450BT Manuel utilisateur

Pioneer

Pioneer Elite VSX-LX805 Manuel utilisateur

Pioneer

Pioneer MVH-210EX Manuel utilisateur

Pioneer

Pioneer XV-DV505 Manuel utilisateur

Pioneer

Pioneer VSX-D914-K Manuel utilisateur

Pioneer

Pioneer AVH-X8800BT Manuel utilisateur

Pioneer

Pioneer Elite VSX-21 Manuel utilisateur

Pioneer

Pioneer VSX-D511 - Audio/Visual Receiver Manuel utilisateur

Pioneer

Pioneer VSX-918V Manuel utilisateur

Pioneer

Pioneer VSX-828-K, VSX-828-S, VSX-528- Manuel utilisateur

Pioneer

Pioneer SX-727 Manuel technique

Manuels Récepteur populaires d'autres marques

Garmin

Garmin GA 23 Manuel utilisateur

Aiphone

Aiphone PS-12F Manuel utilisateur

IMES

IMES TCS-01CA-PMI Manuel utilisateur

BWI Eagle

BWI Eagle AIR-EAGLE SR Manuel

AMIMON

AMIMON AMN12310 WHDI Manuel utilisateur

Dual

Dual DMCPA79BT Mode d'emploi

Sound Associates

Sound Associates SA652P Manuel utilisateur

Sherwood

Sherwood NewCastle R-772 Manuel utilisateur

Audio

Audio A10-RX Series Manuel utilisateur

AllSee

AllSee PushShare PSRV1.1 Manuel utilisateur

DEMAG

DEMAG DRC-DR D2 Manuel utilisateur

Teleco

Teleco TVRCL868A02 Manuel utilisateur

Bosch

Bosch RF3222E Manuel utilisateur

Kramer

Kramer 631R Manuel utilisateur

Xpress

Xpress xmc10 Manuel utilisateur

JVC

JVC KD-MR1BTS Manuel utilisateur

Omega Engineering

Omega Engineering UWTC-REC3 Manuel utilisateur

e-survey

e-survey E300 Pro Manuel utilisateur
