Pioneer DEH-2700 Manuel utilisateur

Operation Manual

Mode demploi

High power CD player with FM/AM tuner

Lecteur CD de grande puissance avec syntoniseur

FM/AM

DEH-2700

English EspañolFrançais

Thank you for buying this Pioneer product.

Please read through these operating instructions so you will know how to operate

your model properly. After you have finished reading the instructions, keep this man-

ual in a safe place for future reference.

Before You Start

Information to User 4

For Canadian model 4

About this unit 4

After-sales service for Pioneer products 4

Product registration 5

Protecting your unit from theft 5

Removing the front panel 5

Attaching the front panel 5

Whats What

ead unit 6

Power ON/OFF

Turning the unit on and selecting a

source 7

Turning the unit off 7

Tuner

Listening to the radio 8

Storing and recalling broadcast

frequencies 8

Tuning in strong signals 8

Storing the strongest broadcast

frequencies 9

Built-in C Player

Playing a CD 10

Playing tracks in a random order 10

Repeating play 10

Pausing CD playback 10

Audio Adjustments

Introduction of audio adjustments 11

Using balance adjustment 11

Using the equalizer 11

Recalling equalizer curves 11

Adjusting equalizer curves 12

Fine-adjusting equalizer curve 12

Adjusting loudness 12

Front image enhancer (F.I.E.) 13

Adjusting source levels 13

Other Functions

Setting the clock 14

Turning the clock display on or off 14

Additional Information

Understanding built-in CD player error

messages 15

CD player and care 15

CD-R/CD-RW discs 15

Specifications 17

Contents

Selecting fine audio equipment such as the unit you’ve just purchased is only the start of your

musical enjoyment. Now it’s time to consider how you can maximize the fun and excitement your

equipment offers. This manufacturer and the Electronic Industries Association’s Consumer

Electronics Group want you to get the most out of your equipment by playing it at a safe level. One

that lets the sound come through loud and clear without annoying blaring or distortion—and, most

importantly, without affecting your sensitive hearing.

Sound can be deceiving. Over time your hearing “comfort level” adapts to higher volumes of

sound. So what sounds “normal” can actually be loud and harmful to your hearing. Guard against

this by setting your equipment at a safe level BEFORE your hearing adapts.

To establish a safe level:

•Start your volume control at a low setting.

•Slowly increase the sound until you can hear it comfortably and clearly, and without distortion.

Once you have established a comfortable sound level:

•Set the dial and leave it there.

Taking a minute to do this now will help to prevent hearing damage or loss in the future. After

all, we want you listening for a lifetime.

We Want You Listening For A Lifetime

Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment. Since

hearing damage from loud noise is often undetectable until it is too late, this manufacturer and the

Electronic Industries Association’s Consumer Electronics Group recommend you avoid prolonged

osure to excessive noise. This

ist of sound

eve

s is inc

uded for

our

rotection

bel

Leve

l Exampl

Quiet

rar

, soft whis

ivin

room, refri

erator,

edroom awa

from traffi

ht traffic, norma

conversation,

uiet office

60 Air conditioner at 20 feet, sewing machine

70 Vacuum cleaner, hair dryer, noisy restaurant

80 Average city traffic, garbage disposals, alarm clock at two feet

THE FOLLOWING NOISES CAN BE DANGEROUS UNDER CONSTANT EXPOSURE

90 Subway, motorcycle, truck traffic, lawn mower

100 Garbage truck, chain saw, pneumatic drill

120 Rock band concert in front of speakers, thunderclap

140 Gunshot blast, jet plane

180 Rocket launching pad

Information courtesy of the Deafness Research Foundation.

En 3

English

Information to User

Alteration or modifications carried out without

appropriate authorization may invalidate the

users right to operate the equipment.

For Canadian model

This Class B digital apparatus complies with

Canadian ICES-003.

About this unit

The tuner frequencies on this unit are allo-

cated for use in North America. Use in other

areas may result in poor reception.

WARNING:

andling the cord on this product or cords asso-

ciated with accessories sold with the product will

expose you to lead, a chemical known to the

State of California and other governmental enti-

ties to cause cancer and birth defects or other re-

productive harm. Wash hands after handling.

CAUT ON:

USE OF CONTROL OR ADJUSTMENT OR

PERFORMANCE OF PROCEDURES

OTHER THAN THOSE SPEC F ED HERE N

MAY RESULT N HAZARDOUS RAD AT ON

EXPOSURE.

CAUT ON:

THE USE OF OPT CAL NSTRUMENTS

W TH TH S PRODUCT W LL NCREASE

EYE HAZARD.

CAUTION

!Do not allow this unit to come into contact

with liquids. Electrical shock could result.

Also, this unit damage, smoke, and overheat

could result from contact with liquids.

!Keep this manual handy as a reference for op-

erating procedures and precautions.

!Always keep the volume low enough so that

you can hear sounds from outside the vehicle.

!Protect this unit from moisture.

!If the battery is disconnected or discharged,

the preset memory will be erased and must be

reprogrammed.

Important (Serial number)

The serial number is located on the top of this

unit. For your own security and convenience, be

sure to record this number on the enclosed war-

ranty card.

After-sales service for

Pioneer products

Please contact the dealer or distributor from

where you purchased this unit for after-sales

service (including warranty conditions) or any

other information. In case the necessary infor-

mation is not available, please contact the

companies listed below:

Please do not ship your unit to the companies

at the addresses listed below for repair without

advance contact.

Before You Start

Section

U.S.A.

Pioneer Electronics (USA) Inc.

CUSTOMER SUPPORT DIVISION

P.O. Box 1760

Long Beach, CA 90801-1760

800-421-1404

CANA A

Pioneer Electronics of Canada, Inc.

CUSTOMER SATISFACTION DEPARTMENT

300 Allstate Parkway

Markham, Ontario L3R OP2

1-877-283-5901

For warranty information please see the Lim-

ited Warranty sheet included with this unit.

Product registration

Visit us at the following site:

1 Register your product. We will keep the details

of your purchase on file to help you refer to

this information in the event of an insurance

claim such as loss or theft.

2 Receive updates on the latest products and

technologies.

3 Download owners manuals, order product

catalogues, research new products, and

much more.

Protecting your unit from

theft

The front panel can be detached from the

head unit to discourage theft.

Important

!Never use force or grip the display and the

buttons too tightly when removing or attach-

ing.

!Avoid subjecting the front panel to excessive

shocks.

!Keep the front panel out of direct sunlight and

high temperatures.

Removing the front panel

1 Press DETACH to release the front

panel.

Press DETACH and the right side of the panel

is released from the head unit.

2 Grab the front panel and remove.

Grab the right side of the front panel and pull

away to the left. The front panel will be de-

tached from the head unit.

Attaching the front panel

1 Place the front panel flat against the

head unit.

2 Press the front panel into the face of

the head unit until it is firmly seated.

Before You Start

En 5

English

Section

ead unit

1C OCK button

Press to change to the clock display.

2Disc loading slot

Insert a disc to play.

3EJECT button

Press to eject a CD from your built-in CD

player.

4AUDIO button

Press to select various sound quality con-

trols.

5PAUSE button

Press to turn pause on or off.

6a/b/c/dbuttons

Press to do manual seek tuning, fast for-

ward, reverse and track search controls.

Also used for controlling functions.

7OUDNESS button

Press to turn loudness on or off.

8DETACH button

Press to remove the front panel from the

head unit.

9BAND button

Press to select among three FM bands and

one AM band and to cancel the control

mode of functions.

aOCA /BSM button

Press to turn local function on or off.

Press and hold to turn BSM function on or

off.

b16 buttons

Press for preset tuning.

cSOURCE button

This unit is turned on by selecting a source.

Press to cycle through all the available

sources.

dVO UME

Rotate it to increase or decrease the vo-

lume.

eEQ button

Press to select various equalizer curves.

Whats What

Section

Turning the unit on and

selecting a source

You can select a source you want to listen to.

To switch to the built-in CD player, load a disc

in the unit (refer to page 10).

%Press SOURCE to select a source.

Press SOURCE repeatedly to switch between

the following sources:

Built-in C playerTuner

When you select a source the unit is turned

on.

Notes

!When no disc has been set in the unit, the

source will not switch to the built-in CD player.

!When this units blue/white lead is connected

to the vehicles auto-antenna relay control

terminal, the vehicles antenna extends when

this units source is turned on. To retract the

antenna, turn the source off.

Turning the unit off

%Press SOURCE and hold until the unit

turns off.

Power ON/OFF

En 7

English

Section

Listening to the radio

1 2 4 53

1Band indicator

Shows which band the radio is tuned to, AM

or FM.

2Frequency indicator

Shows to which frequency the tuner is

tuned.

3OC indicator

Shows when local seek tuning is on.

4Stereo (5) indicator

Shows that the frequency selected is being

broadcast in stereo.

5Preset number indicator

Shows which preset has been selected.

1 Press SOURCE to select the tuner.

2 Use VO UME to adjust the sound level.

3 Press BAND to select a band.

Press BAND until the desired band is dis-

played, F1,F2,F3 for FM or AM.

4 To perform manual tuning, briefly press

cor d.

5 To perform seek tuning, press and hold

cor dfor about one second and release.

The tuner will scan the frequencies until a

broadcast strong enough for good reception is

found.

#You can cancel seek tuning by briefly pressing

either cor d.

#If you press and hold cor dyou can skip sta-

tions. Seek tuning starts as soon as you release

the button.

Storing and recalling

broadcast frequencies

If you press any of the preset tuning buttons

16you can easily store up to six broadcast

frequencies for later recall with the touch of a

button.

%When you find a frequency that you

want to store in memory press one of pre-

set tuning buttons 16 and hold until the

preset number stops flashing.

The number you have pressed will flash in the

preset number indicator and then remain lit.

The selected radio station frequency has been

stored in memory.

The next time you press the same preset tun-

ing button the radio station frequency is re-

called from memory.

Notes

!Up to 18 FM stations, six for each of the three

FM bands, and six AM stations can be stored

in memory.

!You can also use aand bto recall radio sta-

tion frequencies assigned to preset tuning

buttons 16.

Tuning in strong signals

Local seek tuning lets you tune in only those

radio stations with sufficiently strong signals

for good reception.

Tuner

Section

%Press OCA /BSM repeatedly to turn

local seek tuning on or off.

When local seek tuning is on, OC appears in

the display.

Storing the strongest

broadcast frequencies

BSM (best stations memory) lets you automa-

tically store the six strongest broadcast fre-

quencies under preset tuning buttons 16and

once stored there you can tune in to those fre-

quencies with the touch of a button.

!Storing broadcast frequencies with BSM

may replace broadcast frequencies you

have saved using buttons 16.

%Press OCA /BSM and hold until the

BSM turns on.

BSM begins to flash. While BSM is flashing

the six strongest broadcast frequencies will be

stored under preset tuning buttons 16in the

order of their signal strength. When finished,

BSM stops flashing.

#To cancel the storage process, press

OCA /BSM.

Tuner

En 9

English

Section

Playing a CD

1 2 3

1RPT indicator

Shows when repeat play is turned on.

2Track number indicator

Shows the track currently playing.

3Play time indicator

Shows the elapsed playing time of the cur-

rent track.

1 Insert a CD into the CD loading slot.

Playback will automatically start.

#Be sure to turn up the label side of a disc.

#After a CD has been inserted, press SOURCE

to select the built-in CD player.

#You can eject a CD by pressing EJECT.

2 Use VO UME to adjust the sound level.

3 To perform fast forward or reverse,

press and hold cor d.

4 To skip back or forward to another

track, press cor d.

Pressing dskips to the start of the next track.

Pressing conce skips to the start of the cur-

rent track. Pressing again will skip to the pre-

vious track.

Notes

!The built-in CD player plays one, standard, 12-

cm or 8-cm (single) CD at a time. Do not use

an adapter when playing 8-cm CDs.

!Do not insert anything other than a CD into

the CD loading slot.

!If an error message such as ERROR-11 is dis-

played, refer to Understanding built-in CD

player error messages on page 15.

Playing tracks in a random

order

Random play lets you play back tracks on the

CD in a random order.

%Press 4 repeatedly to turn random play

on or off.

When random play is on, RDM appears in the

display.

Repeating play

Repeat play lets you hear the same track over

again.

%Press 5 repeatedly to turn repeat play

on or off.

When repeat play is on, RPT appears in the

display.

#If you perform track search or fast forward/re-

verse, repeat play is automatically cancelled.

Pausing CD playback

Pause lets you temporarily stop playback of

the CD.

%Press PAUSE repeatedly to turn pause

on or off.

When pause is on, PAUSE appears in the dis-

play.

Built-in CD Player

Section

Autres manuels pour DEH-2700

Table des matières

Langues :

Autres manuels Pioneer Récepteur de voiture

Pioneer

Pioneer DEH-7200SD Manuel utilisateur

Pioneer

Pioneer Super Tuner IIID DEH-P680MP Manuel utilisateur

Pioneer

Pioneer DEH-4800FD Manuel utilisateur

Pioneer

Pioneer GEX-P900XM Manuel utilisateur

Pioneer

Pioneer AVIC-D3 - Navigation System With DVD Player Manuel utilisateur

Pioneer

Pioneer AVIC-800DVD Manuel utilisateur

Pioneer

Pioneer DEH-P710BT - Premier Radio / CD Manuel utilisateur

Pioneer

Pioneer Premier DEH-P670MP Manuel utilisateur

Pioneer

Pioneer KEH-P5950 Manuel utilisateur

Pioneer

Pioneer DEH-1310 Manuel utilisateur

Pioneer

Pioneer DEH-X8700BH Manuel utilisateur

Pioneer

Pioneer Super Tuner III D DVH-P5850MP Manuel utilisateur

Pioneer

Pioneer DEH-P7800MP Manuel utilisateur

Pioneer

Pioneer DEH-P4400R Manuel utilisateur

Pioneer

Pioneer AVIC-F70DAB Manuel d'utilisation et d'entretien

Pioneer

Pioneer DEH-X8700DAB Manuel utilisateur

Pioneer

Pioneer DEH-6400BT Manuel utilisateur

Pioneer

Pioneer Super Tuner IIID DVH-P5000MP Manuel utilisateur

Pioneer

Pioneer DEH-P590IBXN Manuel utilisateur

Pioneer

Pioneer AVH-P4200DVD Manuel utilisateur

Pioneer

Pioneer CDX-P670 Manuel utilisateur

Pioneer

Pioneer DEH-P5100UB - Radio / CD Manuel utilisateur

Pioneer

Pioneer P2600 - DEH Radio / CD Player Manuel utilisateur

Pioneer

Pioneer DEH-2300UB Manuel utilisateur

Manuels Récepteur de voiture populaires d'autres marques

Motorola

Motorola VWA63 Manuel utilisateur

Nextar

Nextar D3201 Manuel utilisateur

Alpine

Alpine CDE-163BT Manuel utilisateur

Axxera

Axxera XDMA7600 Mode d'emploi

XM OnyX Manuel utilisateur

Sound Storm

Sound Storm STM93R Manuel utilisateur

Soundstream

Soundstream VIR-5000 Manuel utilisateur

Avson

Avson MKT Platform Manuel utilisateur

Sony

Sony MEX-1HD - Audio Library System Manuel utilisateur

JVC

JVC KD-AHD69 Manuel utilisateur

Blaupunkt

Blaupunkt SANTIAGO CR 87 Manuel utilisateur

Sony

Sony CDX-4160 - Cd Receiver Manuel utilisateur

XFIRE AUDIO

XFIRE AUDIO BMW42S Manuel utilisateur

VDO

VDO CD 2253 Manuel utilisateur

Volvo

Volvo 13 84 580 Manuel utilisateur

ZENEC

ZENEC ZE-160DVD Manuel utilisateur

Medion

Medion Car Audio Manuel utilisateur

Philips

Philips CEM5000 Manuel utilisateur
