Installing the
PictureTel®900 Series
Collaboration System
Ready . . . Set . . . Go. . .
i
Copyright © 2000: PictureTel Corporation—Printed in U.S.A.
PictureTel Corporation, 100 Minuteman Road, Andover, MA 01810
www.picturetel.com
PictureTel and the PictureTel logo are registered trademarks of PictureTel Corporation. ImageShare, LAMB, Look-At-Me-Button, and
PowerMic are trademarks of PictureTel Corporation.
Bose is a registered trademark of Bose Corporation.
Lucent is a trademark of Lucent Technologies.
Microsoft and Windows NT are registered trademarks of Microsoft Corporation.
The information contained in this document is subject to change without notice. PictureTel assumes no responsibility for technical or
editorial errors or omissions that may appear in this document or for the use of this material. Nor does PictureTel make any commitment
to update the information contained in this document. This document contains proprietary information which is protected by copyright. All
rights reserved. No part of this document may be photocopied or reproduced in any form without the prior written consent of PictureTel
Corporation.
Edition: 800-1167-01/A
Customer order number: PT900-DOCSET-E
Do you have any suggestions or comments on the documentation you received?
ii
This booklet is divided into three sections: Ready..., Set..., and Go...
Here’s what you’ll find in each section:
Ready...
How to make sure the network is ready, where you can set up your system, and what you should find in
each of the boxes.
Set...
How to connect the cables, including monitor cables, camera and audio cables, and the PC audio
jumper cable; how to set up the microphone, receiver, remote control, keyboard, and ImageShare; how
to connect network cables (LAN, ISDN, V.35 or RS-449); how to attach the power cable; and recom-
mendations on how to set up your room.
Go...
How to insert the boot diskette and start up the system, and where you can find more information.
To install the system, follow this booklet page by page. In most cases, however, you’ll be able to skip some
pages. For example, if your system has a PictureTel 80 camera and a LAN network interface, you can skip the
pages that discuss the PictureTel 70 camera and the other network interfaces.
About This Guide
Ready . . .
1
Before you begin installing the PictureTel
®
970 or PictureTel 960 system, you should make sure that the network is
ready.
The document
Preparing Your Network for Collaboration
that you received with the system contains worksheets
that will help you get the network ready. For example, for ISDN networks, the worksheets list the ISDN BRI dialect,
the Network Number Type, and so on.
If you’ve already followed the steps in the
Preparing Your Network for Collaboration
document or the network
administrator has already taken care of the network preparation for you, then you can continue with the
installation.
Make Sure the Network Is Ready
2
Before you unpack all of the PictureTel 970 or PictureTel 960 components, decide where you want to set up the
system. You can set it up either on a tabletop or on a cart, and you can position the computer box either
horizontally or as a tower:
PIP
ZOOM
VOLUME
MUTEAUTO
CONTENT
PEOPLE
SETCANCELPRESET
7
PQRS
8
TUV
9
WXYZ
4
GHI
5
JKL
6
MNO
2
ABC
3
DEF
*0#
CALL/ANSWERHANGUP
HELPON/STANDBYOPTIONS
1
PIP
ZOOM
VOLUME
MUTEAUTO
CONTENT
PEOPLE
SETCANCELPRESET
7
PQRS
8
TUV
9
WXYZ
4
GHI
5
JKL
6
MNO
2
ABC
3
DEF
*0#
CALL/ANSWERHANGUP
HELPON/STANDBYOPTIONS
1
Choose Tabletop or Cart
3
The basic system comes packed in one carton. This carton contains the computer box, software, documentation,
camera, cables, and so on.
If you’ve ordered options with the system, such as a cart, a monitor, or another camera, the system may have
come packed in five or more cartons. This section describes the contents of both the basic system carton and the
other, optional, cartons.
Unpack the System Carton
4
The system carton contains four smaller boxes.
1. The box that contained this installation document is labeled “Open Me First.” You should have found these
items in that box:
PictureTel
900 Series
Windows NT
Power
Num Cap Scroll
boot
diskette
PictureTel 900 Series
Collaboration System
Administrator's Guide
PictureTel 900 Series
System Software
Release Bulletin
PictureTel 900 Series
Collaboration System
Quick Reference Card
Installing the PictureTel 900 Series
Collaboration System
PIP
ZOOM
VOLUME
MUTE AUTO
CONTENT
PEOPLE
SET CANCEL PRESET
7
PQRS
8
TUV
9
WXYZ
4
GHI
5
JKL
6
MNO
2
ABC
3
DEF
*0#
CALL/ANSWER HANG UP
HELP ON/STANDBY OPTIONS
1
System Software
Unpack the “Open Me First” Box
5
2. The second box in the system carton contains the power cable.
In European countries, this box may also container a Scart adapter. This adapter enables the video cables
to connect to European monitors.
OUT IN
R AUDIO L S-VHS VIDEO
Unpack the Power Cable
6
3. The third box in the system carton contains the main camera. Depending on the type of system you
ordered, you received either the PictureTel 80 or the PictureTel 70 camera. This box also contains the
camera documentation and, for the PictureTel 80 camera, some of the audio cables you will need for the
system.
Installing the
PictureTel 80
Dynamic Locating
Camera
Installing the
PictureTel 70
Room Camera
Unpack the Camera
