Pico Technology PicoSource PG900 Series Manuel utilisateur

USB differential pulse generators

PicoSource®PG900 Series

Quick Start Guide

PicoSource PG900 Pulse Generators Quick Start Guide

CONTENTS

1. Introduction..........................................................................................................1

2. Safety information ................................................................................................1

2.1 Symbols...................................................................................................................................2

2.2 Maximum input and output ranges..........................................................................................2

2.3 Grounding...............................................................................................................................3

2.4 External connections...............................................................................................................3

2.5 Environment............................................................................................................................4

2.6 Care of the product ................................................................................................................4

3. System requirements ............................................................................................5

4. Included with your PicoSource PG900 pulse generator .......................................5

5. Installing the PicoSource pulse generator and software........................................6

6. Using your pulse generator ..................................................................................7

6.1 Getting started with the PicoSource PG900 software ............................................................7

6.2 Connection diagrams ..............................................................................................................9

7. Free newsletter...................................................................................................11

8. Software updates and replacement.....................................................................11

9. User’s guides ......................................................................................................11

10. Specifications ......................................................................................................11

11. Technical support................................................................................................11

12. Warranty and returns.........................................................................................11

PicoSource PG900 Pulse Generators Quick Start Guide

1. Introduction

Thank you for purchasing a PicoSource pulse generator.

The fast-transition output from the PicoSource pulse generators can stimulate a

transmission path, device, or network with a broad-spectrum signal in a single

instant. These signals, combined with dierential capability, are invaluable for

making high-speed broadband measurements in many elds such as time domain

reectometry, semiconductor testing, gigabit interconnect and port testing, and radar

systems.

Three dierential output models are available, oering extensive control over pulse

parameters including amplitude, pulse period, pulse width and deskew between

output channels.

• The PicoSource PG911 is a two-channel pulse generator based on Step

Recovery Diode (SRD) technology. It produces two pulses, up to 6 V amplitude

with 60 ps rise time.

• The PicoSource PG912 is a two-channel pulse generator based on Tunnel Diode

(TD) technology. It uses remote tunnel diode pulse heads to produce positive and

negative 200 mV pulses with 40 ps rise time.

• The PicoSource PG914 is a four-channel pulse generator beneting from both

SRD and TD technology.

For further setup information following basic installation, see the User’s Guide by

either clicking the Help menu within the PicoSource PG900 software or opening the

PDF directly from the software disk.

2. Safety information

To prevent possible electrical shock, re, personal injury, or damage to the product,

carefully read this safety information before attempting to install or use the product.

In addition, follow all generally accepted safety practices and procedures for working

with and near electricity.

The product has been designed and tested in accordance with the European standard

publication EN 61010-1:2010, and left the factory in a safe condition.

The following safety descriptions are found throughout this guide:

A WARNING identies conditions or practices that could result in injury or death.

A CAUTION identies conditions or practices that could result in damage to the

product or equipment to which it is connected.

PicoSource PG900 Pulse Generators Quick Start Guide

2.1 Symbols

These safety and electrical symbols may appear on the product or in this guide.

Symbols Description

Direct current

Alternating current

Earth (ground) terminal

This terminal can be used to

make a measurement ground

connection. It is NOT a safety or

protective earth.

Chassis terminal

Possibility of electric shock

Caution

Appearance on the product

indicates a need to read this

safety and operation instruction.

Static awareness. Static discharge

can damage parts.

Do not dispose of this product as

unsorted municipal waste

WARNING

To prevent injury or death use the product only as instructed and use only

accessories supplied or recommended. Protection provided by the product

may be impaired if used in a manner not specied by the manufacturer.

2.2 Maximum input and output ranges

Observe all terminal ratings and warnings marked on the product.

The table below indicates the maximum voltage of the outputs and the overvoltage

protection range for the trigger input on each pulse generator. The overvoltage

protection ranges are the maximum voltages that can be applied without damaging

the instrument.

Connection port Maximum voltage

(output or input) Overvoltage protection

Positive and negative

integrated pulse outputs ±8 V unterminated ±10 V

Do not connect a source

Drive outputs ±5 V DC or AC pk ±5 V DC or AC pk

Do not connect a source

Tunnel diode pulse head

outputs 250 mV 0 V

Do not connect a source

Trigger input ±2 V DC or AC pk ±2 V DC or AC pk

Trigger output +3 V DC or AC pk +4 V / −2 V DC

Do not connect a source

PicoSource PG900 Pulse Generators Quick Start Guide

WARNING

To prevent electric shock or permanent damage to the signal source, do

not connect an input voltage to the integrated pulse outputs or the tunnel

diode pulse heads.

CAUTION

Exceeding the overvoltage protection range on any connector can cause

permanent damage to the instrument and other connected equipment.

2.3 Grounding

WARNING

The instrument’s ground connection through the USB cable is for functional

purposes only. The instrument does not have a protective safety ground.

WARNING

To prevent injury or death, or permanent damage to the instrument, never

connect the ground of an input or output (chassis) to any electrical power

source. To prevent personal injury or death, use a voltmeter to check that

there is no signicant AC or DC voltage between the pulse generator’s

ground and the point to which you intend to connect it.

CAUTION

To prevent signal degradation caused by poor grounding, always use the

high-quality USB cable supplied with the instrument.

2.4 External connections

WARNING

To prevent injury or death, only use the adaptor supplied with the product.

This is approved for the voltage and plug conguration in your country.

PicoSource

model USB connection

EXT power supply

Voltage (V) Current

(A pk)

Total power

(W)

PG900 Series USB 2.0. Compatible

with USB 3.0. 5 V 1.6 A pk 8 W

CAUTION

Take care to avoid mechanical stress or tight bend radii for all connected

leads, including all coaxial leads and connectors. Mishandling will cause

deformation of sidewalls, and will degrade performance.

PicoSource PG900 Pulse Generators Quick Start Guide

2.5 Environment

WARNING

To prevent injury or death, do not use in wet or damp conditions, or near

explosive gas or vapor.

CAUTION

To prevent damage, always use and store your pulse generator in

appropriate environments.

Storage Operating

Temperature –20 °C to +50 °C +5 °C to +35 °C

+15 °C to +25 °C for quoted accuracy

Humidity ≤ 95% RH

(non-condensing)

≤ 85% RH at 35 °C

(non-condensing)

Altitude 2000 m

Pollution degree 2

2.6 Care of the product

The product and accessories contain no user-serviceable parts. Repair, servicing and

calibration require specialized test equipment and must only be performed by Pico

Technology or an approved service provider. There may be a charge for these services

unless covered by the Pico two year warranty.

WARNING

To prevent injury or death, do not use the product if it appears to be

damaged in any way, and stop use immediately if you are concerned by

any abnormal behavior.

CAUTION

To prevent damage to the device or connected equipment, do not tamper

with or disassemble the instrument, case parts, connectors, or accessories.

When cleaning the product, use a soft cloth and a solution of mild soap

or detergent in water, and do not allow liquids to enter the instrument’s

casing.

PicoSource PG900 Pulse Generators Quick Start Guide

3. System requirements

To ensure that the PicoSource pulse generator and PicoSource PG900 software

operate correctly, you must use a computer with the system requirements and one of

the operating systems shown in the table below.

Processor

As required by the operating systemMemory

Free disk space

Operating system Microsoft Windows XP (SP3), Vista, 7,

8 (not Windows RT) or 10. 32-bit or 64-bit.

Ports USB 2.0 (also compatible with USB 3.0)

4. Included with your PicoSource PG900 pulse generator

PicoSource PG900 Pulse Generator kits contain the following items:

• PicoSource PG900 Pulse Generator

• PicoSource PG900 software disk

• Storage and carry case

• AC adaptor 5 V DC at 2 A, universal input

• USB 2.0 cable, 1.8 m

•SMA/PC3.5/2.92 wrench

• Quick Start Guide

Each pulse generator is also supplied with additional accessories, as shown below.

Accessories Order

code

PicoSource model

PG911 PG912 PG914

9040 40 ps TD positive pulse head – 1 1

9041 40 ps TD negative pulse head – 1 1

12 GHz N(f) to SMA(m) adaptor

(tted to TD pulse heads) TA172 2 2

10 GHz 20 dB SMA(m-f) attenuator

(tted to SRD pulse outputs) TA173 2 2

50 Ω coaxial SMA(m-m) pulse drive cable,

60 cm – 2 2

Some product packs may contain additional items. For a full list of all available kits

and additional accessories, see the User’s Guide or visit www.picotech.com.

PicoSource PG900 Pulse Generators Quick Start Guide

5. Installing the PicoSource pulse generator and software

1. Install the PicoSource PG900 software using the software disk supplied.

Alternatively, you can download the software from picotech.com/downloads.

Follow the on-screen instructions to complete the setup.

Note: Do not connect the pulse generator until the installation is complete.

2. Connect the power cord to the power adaptor, and plug it into a mains (line)

power socket. Then connect the DC power cord to the back of the pulse

generator, and switch on the mains power.

3. Earth (ground) terminal. Some laptop power supplies can produce electrical

noise which may interfere with your measurements. If this occurs, the earth

terminal can be connected to an external ground point (for example, on the

system you are testing) to provide a ground reference for the instrument. This

can help to avoid external noise interfering with your signal. Alternatively, you

can run the laptop using battery power.

4. Connect the pulse generator to the PC using the USB cable supplied. Windows

may automatically display a New Hardware Found notication. Follow any

instructions shown. Note: If Windows asks to connect to Windows Update, select

No.

5. Run the PicoSource PG900 software.

1. Laptop or PC

2. USB cable supplied

3. USB port

4. DC power socket

5. USB port

6. PicoSource Pulse Generator

7. AC adaptor supplied

PicoSource PG900 Pulse Generators Quick Start Guide

6. Using your pulse generator

6.1 Getting started with the PicoSource PG900 software

Output menu External trigger menu

Main menu Display scaling menu Display area

Mode

Timing

Intensified zone

Main menu

Store and recall your settings, and access detailed Help information.

Display scaling

These controls allow you to adjust how information is shown in the Display area.

The Intensied zone shows a section of the waveform that can be expanded using

the Horizontal scale control. This function can be used to show the pulse train and

the pulse timing, including the timing in relation to the trigger.

Mode menu

Select a trigger source (internal or external) and operating mode. When Ext Trigger

is selected as the source, the External trigger menu will be enabled.

Timing menu

Adjust the period and width of the pulse.

PicoSource PG900 Pulse Generators Quick Start Guide

Output menu

Select the appropriate channel and adjust the related parameters. Choose from

Positive Out and Negative Out (for the integrated step recovery diode outputs) or

TD Head1 Out and TD Head2 Out (for the tunnel diode pulse heads).

Adjusting a parameter

The value of a parameter can be adjusted in a number of ways:

•Use the up and down arrows to adjust the value in Fine or Coarse increments,

or click Dto return to the default value.

• Click and drag the Range Indicator bar.

•Click the parameter box to highlight it, and directly type a precise new value

using your keyboard.

• Right click on the value to quickly access the Maximum, Middle, or Minimum

value.

• Right click on the value and select Calculator to enter a precise new value using

the on-screen keypad.

Default

Value

Range

Indicator

Coarse

Adjustment

Fine

Adjustment

Autres manuels pour PicoSource PG900 Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels pico Technology Générateur d'impulsions

pico Technology

pico Technology PicoSource PG900 Series Manuel utilisateur

Manuels Générateur d'impulsions populaires d'autres marques

HP 8082a Manuel de service

Schwarzbeck

Schwarzbeck IGUU 2916 Manuel utilisateur

Anaheim Automation

Anaheim Automation MBC10P31 Manuel utilisateur

BIOTRONIK

BIOTRONIK Philos DR-T Manuel utilisateur

BNC

BNC 575 Series Manuel utilisateur

Hioki

Hioki U8793 Manuel utilisateur

Agilent Technologies

Agilent Technologies 8114A Manuel utilisateur

HP 8012A Manuel utilisateur

Bradley

Bradley 233 Manuel utilisateur

Agilent Technologies

Agilent Technologies E4438C Manuel utilisateur

DEI

DEI PCX-7500 Manuel utilisateur

Kiepe Elektrik

Kiepe Elektrik DG Series Manuel utilisateur

Hagerman Technology

Hagerman Technology FryBaby Manuel utilisateur

BNC

BNC MOD745T Manuel utilisateur

AVTECH ELECTROSYSTEMS LTD.

AVTECH ELECTROSYSTEMS LTD. AVG-4A-B Manuel utilisateur

Avtech

Avtech AVR-G1-B Manuel utilisateur

Avtech

Avtech AVOZ-D2-B Manuel utilisateur

Tektronix

Tektronix 114 Manuel utilisateur
