Philips SmartPro Active Manuel utilisateur
FC8832
English 6
Español 28
Português 51
Wheels stuck
ݓઁሂTopcover or dust container not placed properly
רۆࠋࠦӧ٦ݾBumper stuck
ߓԎሑᇆሂRobot lifted up from floor
՚ֽϴุఓᇊୃስײᆋ༏ӧచColour of floor too dark
ֽϴဂ೨ขτBattery not inserted properly/ Charging error (switch is off)
ԁሑݾԍմ༆IJܵၜܵтij
5
6
4
3
2
1
7
8
9
10
15
13
12
14
11
16
18
17
19
23
22
21
24
20
English
Introduction
Introduction
Congratulations on your purchase and welcome to Philips! To fully benefit
from the support that Philips offers, register your product at
www.philips.com/welcome.
General description
1 Handle of dust container lid
2 Dust container lid
3 Filter
4 Dust container
5 Top cover
6 Error code table
7 Fan
8 Bumper
9 Docking station sensor
10 Display
11 Front wheel
12 Side brush shafts
13 Drop-off sensors
14 Wheels
15 TriActive XL nozzle
16 Side brushes
17 Fixation blocks for dry wipes
18 Dry wipe holder
19 Dry wipes
20 AA batteries for invisible wall
21 Invisible wall
22 Docking station
23 Adapter
24 Small plug
Display
1
1110 129
2
3
4
5 6 7 8
1 Spiral mode indicator
2 Wall-following mode indicator
3 Zigzag pattern mode indicator
4 Random mode indicator
5 Cleaning time
6 Docking icon
7 WiFi icon
8 Sound sensor
9 Dust container-full indicator
10 Mode selection button
11 Start/stop button
12 WiFi button
6English
How your robot works
What your robot cleans
This robot is equipped with features that make it a suitable cleaner to help
you clean the floors in your home.
The robot is especially suitable for cleaning hard floors, such as wooden,
tiled or linoleum floors. It may experience problems cleaning soft floors,
such as carpet or rugs. If you use the robot on a carpet or rug, please stay
close by the first time to see if the robot can deal with this type of floor.
Because the robot uses infrared sensors to navigate, it may run into
difficulties on very dark and shiny floors. If you use the robot on such
surfaces, please stay close by the first time to see if the robot can deal with
such a dark and shiny floor.
How your robot cleans
Cleaning system
The robot has a 3-stage cleaning system to clean your floors efficiently.
-The two side brushes help the robot clean in corners and along walls.
They also help to remove dirt from the floor and move it towards the
suction opening.
-The suction power of the robot picks up loose dirt and transports it
through the suction opening into the dust container.
-The robot comes with a dry wipe holder that allows you to clean your
hard floor even more thoroughly with dry wipes.
Cleaning patterns
In its auto cleaning mode, the robot uses a fixed and automatic sequence of
cleaning patterns to clean each area of the room optimally. It uses a Z-
pattern (zigzag pattern), random pattern, wall-following pattern and spiral
pattern successively. It continues to move in this sequence of patterns to
clean the room until the rechargeable battery runs low, or until it is switched
off manually.
7
English
If the robot detects a particularly dirty area during its cleaning run, it
switches to spiral mode and switches to turbo fan speed to ensure thorough
dirt removal.
Note: You can also select each mode individually in the app (see 'Cleaning
mode selection').
How your robot avoids height differences
The robot has three drop-off sensors in its bottom. It uses these drop-off
sensors to detect and avoid height differences such as staircases.
Note: It is normal for the robot to move slightly over the edge of a height
difference, as its front drop-off sensor is located behind the bumper.
Caution: In some cases, the drop-off sensors may not detect a staircase or
other height difference in time. Therefore monitor the robot carefully the
first few times you use it, and when you operate it near a staircase or
another height difference. It is important that you clean the drop-off
sensors regularly to ensure the robot continues to detect height
differences properly (see 'Cleaning the robot').
Mounting the side brushes
1Unpack the side brushes and place the robot upside down on a table or
on the floor.
2Push the side brushes onto the shafts on the bottom of the robot.
Note: Make sure you attach the side brushes properly. Press them onto
the shaft until you hear them lock into position with a click.
8English
Preparing for use
Installing the docking station
1
2
1Insert the small plug of the adapter into the socket on the docking station
(1) and insert the adapter into the wall socket (2).
-The display of the docking station comes on.
2Place the docking station on a horizontal, level floor against the wall.
100cm 30cm
80cm
Note: Make sure that there are no obstacles or height differences 80 cm
in front, 30 cm to the right and 100 cm to the left of the docking station.
Tip: To ensure the docking station stays firmly in the selected spot, fasten
it to the wall with screws or with two strips of double-sided tape.
Important note: deep sleep mode
In deep sleep mode, the robot does not respond at all when you press a
button. To reactivate the robot when it is in deep sleep mode:
1Press the start/stop button on the robot for one second to switch the
robot from deep sleep mode to standby mode.
2Press the start/stop button on the robot briefly or press the start button
in the app to start cleaning.
3If the robot does not start cleaning, place it on the plugged-in docking
station to recharge its rechargeable battery.
3 sec.
The robot enters deep sleep mode when you press the start/stop button for
3 seconds. It may also enter the deep sleep mode when its battery is empty.
The battery may, for instance, run empty if the robot is unable to find its
docking station.
Note: You cannot get the robot out of its deep sleep mode with the
start/stop button in the app, press the start/button on the robot.
9
English
Charging
Charging
When charging for the first time and when the rechargeable battery of the
robot is empty, the charging time is four hours. Your robot can only be
charged on the docking station.
Charging on the docking station
1Place the robot on the plugged-in docking station.
2The start/stop button starts flashing. The charging indicator will be visible
on the display during the first 3 minutes of charging.
3When the rechargeable battery is fully charged, the start/stop button
lights up continuously.
Charging automatically during use
1When the robot has finished cleaning or when only 15% of the battery
power remains, it automatically searches for the docking station to
recharge. When the robot searches for the docking station, the light in the
start/stop button turns orange.
2When the rechargeable battery is fully charged, the start/stop button
lights up continuously.
Note: The robot only searches for the docking station automatically when it
started cleaning from the docking station.
10 English
WiFi connection and app
Operating system requirements
Minimum requirements regarding operating systems:
-iOS: 11 or higher
-Android: 5.0 or higher
WiFi specifications
-The robot is designed to be connected to standard consumer routers
that use WEP, WPA-PSK, WPA2-PSK encryption keys, or no encryption
(open WiFi network).
-Connecting the robot to public hotspots, office networks or hotel
networks is not possible in most cases.
-The robot will not work with 5 GHz routers. If you encounter problems
with connecting the robot to the router, please check if your router can
also be changed to the 2.4 GHz setting.
Connecting WiFi router and robot
1When you take the robot out of the box, the WiFi icon starts to flash
orange.
-When the WiFi icon turns solid blue, the robot is connected to the WiFi
router.
2If there is no connection between the robot and the WiFi router, check if
there is an active WiFi signal. If not, check if the WiFi router is working. If
there is a WiFi signal, start downloading the app and then connect app
and robot.
Downloading app and connecting app and robot
1Search for 'Clean Home+' in the Apple App Store or in the Google Play
Store.
2Download and install the Clean Home+ app.
11
English
3Open the app and press the 'Connect a New Device' button or press the
'+' button.
4Select 'SmartPro Robot Vacuum Cleaner' and follow the instructions in
the app.
5The app tells you when the robot is connected and ready to use.
6Press 'OK' to open the app.
7Press 'Start cleaning' to start the robot. You can press 'Return to charging
base' to make the robot return to its docking station.
What to do if connecting app to robot fails
The app will tell you what to do if connection fails.
If you are still unable to connect the app to the robot with the instructions in
the app, start all over again with pressing the 'Connect a New Device' button
or pressing the '+' button.
If you continue to have problems with connecting the robot to the app,
contact the Philips Consumer Care Center in your country or go to
www.philips.com/support.
12 English
