Philips 32-REAL FLAT SDTV 32PT9005D - Hook Up Guide Manuel utilisateur

Philips

SDTV

32"

real flat

32PT9005D

Turn up your viewing experience

with integrated Standard Definition TV

Vivid, natural and razor sharp images

• Integrated SDTV to receive digital off-air and cable signals

• Real Flat picture tube technology brings you lifelike images

• Active Control optimizes picture quality whatever the source

• Scan Velocity Modulation Improves definition and contrast

Exciting and lifelike sound

• Incredible Surround™ for enhanced audio enjoyment

Designed for your convenience

• Electronic Program Guide for retrieval of program schedules

• Auto Picture to personalize your viewing

• Auto Sound uses pre-defined sound settings for better sound

• S-Video Input for better picture performance

For advanced performance

• Component Video Input for top quality playback

32PT9005D/37

Highlights

SDTV

32" real flat

SDTV

SDTV is the latest television signal available. In

order to effectively maximize the SDTV signal,

a television must incorporate signal input

connectivity and circuitry design.

Real Flat picture tube

The flatter tube provides a wider viewing angle

while minimizing reflections for the best

picture possible.

Active Control

Active Control ensure that noise and

sharpness improvements are continuously

made at a rate of 60 times per second. By

continually adjusting picture setting over 3,000

times per minute, Active Control Plus ensures

that the viewing experience is optimized.

Scavem

Scan velocity modulation varies the speed of

the electron beam for a more finely rendered

picture with improved sharpness and contrast.

Incredible Surround™

Incredible Surround is an audio technology

from Philips that dramatically magnifies the

sound field to immerse you in the audio. Using

state-of-the-art electronic phase shifting,

Incredible Surround mixes sounds from left

and right in such a way that it expands the

virtual distance between the two speakers.

This wider spread greatly enhances the stereo

effect and creates a more natural sound

dimension. Incredible Surround allows you to

experience total surround with greater depth

and width of sound, without the use of

additional speakers.

Electronic Program Guide

The Electronic Program Guide (EPG) will

provide you with an overview, listing the

program information

Auto Picture

Auto Picture button on the remote control

enables one-touch selection of various preset

optimized image settings to suit different TV

program.

Auto Sound

Auto Sound provides pre-defined sound

settings for ultra bass, bass, treble and balance

for the optimum entertainment experience.

S-Video Input

An S-video format signal preserves the video

quality better than standard video input.

Component Video Input (YPbPr)

Component Video is the highest quality

interconnection standard for analog video. It is

sharper than S-video and composite video.

Issue date 2011-01-12

Version: 1.0.10

12 NC: 8670 000 23062

UPC: 0 37849 96744 7

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

www.philips.com

32PT9005D/37

Specifications

SDTV

32" real flat

Picture/Display

• Aspect ratio: 4:3

• Visible screen diagonal (inch): 32 inch

• Display screen type: Real Flat picture tube

• Picture enhancement: 2D Combfilter, Active

Control, AutoPicture (5 modes), Black stretch,

Color, Comb Filter, Contrast Plus, Scavem,

Sharpness Adjustment, Tint, Color Temperature

Adjustment

Sound

• Output power (RMS): 2 x 5W

• Sound Enhancement: Auto Volume Leveller,

AutoSound (4 modes), Balance, Incredible

Surround, Treble and Bass Control

• Sound System: Stereo, Incredible Surround

Convenience

• Ease of Installation: Autoinstall

• Ease of Use: Auto Volume Leveller (AVL), Easy

toggle Dig/Analog modes

• Remote control type: RCLU023

• Remote Control: TV

• Teletext: Closed Captioning

• Screen Format Adjustments: 4:3 expand, 4:3

• Clock: Sleep Timer

• User convenience: AutoChron (automatic clock),

Electronic Programming Guide, Vchip and parental

lock

• On-Screen Display languages: English, French,

Spanish

Tuner/Reception/Transmission

• TV system: ATSC, NTSC

•VideoPlayback:NTSC

• Aerial Input: 75 ohm F-type

• Cable: Unscrambled Digital Cable -QAM

Connectivity

• AV 1: Component Video in, CVBS in

• AV 2: S-Video Y/C, CVBS in

•Front/Sideconnections:CVBS in, Headphone out

• Audio Output - Digital: AC3 over S/PDIF (Optical)

• Audio Output - Analog: Audio L/R (cinch)

Power

• Standby power consumption: < 1 w

• Mains power: AC 108V - 132V

• Power consumption: 127 W +/-10% W

Dimensions

• Set dimensions in inch (W x H x D):

35.24 x 27.52 x 23.11 inch

• Product weight (lb): 156.2

• Box dimensions in inch (W x H x D):

41.93x 35.16 x 30.55 inch

• Weight incl. Packaging (lb): 167.2

•
