Philips 28PW9611 Manuel utilisateur

English

Contents

Installation

Preparation ________________________________________________3

Switch TV on ______________________________________________4

Select your Menu language____________________________________5

Search for and Store TV channels

Automatic installation ___________________________________6

Manual installation ______________________________________7

Reshuffle the programme list _________________________________9

Select favourite TV channels _________________________________10

Install TV configuration _____________________________________10

Define decoder/descrambler programme numbers _______________12

Operation

Operation ________________________________________________13

Main Menu _______________________________________________14

Adjust the picture__________________________________________14

Adjust the sound __________________________________________16

Features _________________________________________________20

Other Functions ___________________________________________24

PiP - Picture in Picture ______________________________________30

Teletext _________________________________________________32

Connect peripheral equipment ___________________________35

Tips ____________________________________________________42

Index ___________________________________________________43

English

SMART CONTROLS

PICTURE SOUND

VCR 1

VCR 2

SAT

AMP

TUNER

TAPE

DCC

selection of EXT1,

EXT2, EXT3 or FRONT.

selection of connected

peripheral equipment

TV operation

volume key

sound temporarily

switched off

picture format

bilingual choice

continuous subtitles

teletext on/off

direct txt page or

subject selection

txt index page

interrupt txt page

mix tv/txt picture

enlarge

solution to riddles

time display

menu on/off

select your choice

activate your choice

Teletext

Menu p.13

TV-channel selection

switch pip on/off

select connections

switch screens

still picture

move pip screen

channel selection of

pip screen

Picture In Picture

[for TV-sets with pip]

123

456

789

info on screen

previous programme

fhm

stop

rewind

play

wind

programme timer

record

Video recorder

Bswitch to standby

p.39

p.13

p.24

p.32

p.30

p.41

p.26,27

p.13

freeze the picture

reduce image noise

mosaic screen

personal preference

p.27

SMART

CONTROLS

picture and sound

settings

p.14, 16

Abrightness

p.27

p.26

p.28

p.29

p.28

Your remote control

English

Preparation

Place the TV on a solid surface.

For ventilation, leave a space of at least 5 cm free all around the set.

To prevent any fault and unsafe situations, please do not place any objects on

top of the set.

Insert the aerial plug tightly into the aerial socket gat the back of the TV

with an aerial cable of good quality.

4Check if the loudspeaker switch at the back of the TV is in the lposition.

Surround Sound loudspeakers

4Connect the two Surround Sound rear loudspeakers supplied to the connector

clips at the back of the TV. Always connect both Surround Sound loudspeakers.

4Connect the left rear loudspeaker at REAR L and the right rear loudspeaker at

REAR R at the back of the set.

4Push the connector clip down and insert the end of the wire into the opening :

the positive wire (the one with the black line) to the red loudspeaker

connection; the negative wire to the black loudspeaker connection. Do not

insert the wires too far.

The Surround Sound loudspeakers should always be located behind or to either

side of the listener. If preferred you can also hang the loudspeakers on the wall.

Insert the mains plug in the wall socket with a mains voltage of 220V-240V.

REAR

FRONT

CABLE

Installation

Remote control

Remove the cover of the battery compartment on the back of the remote

control.

Insert the 2 batteries supplied (Type R03G-1,5V).

Click the cover back into place.

The Philips batteries supplied do not contain the heavy metals mercury and cadmium.

Nevertheless in many countries exhausted batteries may not be disposed of with your

household waste. Please inform yourself on how to dispose of exhausted batteries

according to local regulations.

4Press the TV key next to the display.

5In the display of the remote control the letters TV appear in a black block for

a few seconds.

You can now operate your TV with the remote control.

Should your remote control be lost or broken you can still select TV channels, adjust

the volume and modify some basic picture and sound adjustments with the keys

PROGRAM, VOLUME and LOCAL MENU behind the front door of your TV. See

page 19.

cLL

VCR 1

VCR 2

SAT

AMP

TUNER

TAPE

DCC

Switch TV on

4Press the power switch Aon the front of your set.

5A green or red lamp lights up on the front of your set.

green ...................................................

5The TV is switched on.

The screen lights up after a few moments.

red .....................................................................

5The TV is switched on but the screen stays

dark. Your TV is on standby.

4Press a digit key on the remote control.

5The TV switches on.

The screen lights up.

5The green lamp blinks every time you press a key on the remote control.

English

You can now choose which language the menus are presented in.

When you switch on your set for the first time, the MENU LANGUAGE

automatically appears on the screen.

See the explanation on your screen. Alternately the explanation automatically

appears in the different languages.

If the MENU LANGUAGE menu does NOT automatically appear on the screen,

proceed as follows :

4Press MENU on the remote control.

5The MAIN MENU appears on the screen.

4Keep the key Wpressed and select INSTALLATION.

5INSTALLATION lights up.

4Press OK.

5The INSTALLATION menu appears and Menu Language lights up.

4Press OK.

5The MENU LANGUAGE appears.

4Select the language of your choice with the keys V, W, Bor Cand press OK.

5The INSTALLATION menu reappears.

From this point on, all menus are presented in the language of your choice.

Have you pressed the wrong key ?

Press OK again and make a new choice.

Select the menu language

Select Country

4Press the keys Wor V to select Country.

5Country lights up.

4Press OK.

5The COUNTRY menu appears.

4Select the country where you are now located with the keys

W, V, Cor Band press OK.

Select Other when none of the countries applies.

5The INSTALLATION menu reappears.

Menu Language

Country

Automatic Installation

Manual Installation

Give Name

Reshuffle

Favourite Programmes

TV Configuration

Decoder/Descrambler

LANGUAGE

English ••• •••

••• ••• •••

MAIN


SOUND

FEATURES

PROGRAMMES

INSTALLATION

COUNTRY

UK •••

••• •••

••• Other

VCR 1

VCR 2

SAT

AMP

TUNER

TAPE

DCC

Store TV channels

This can be done in two different ways : automatically or manually.

Automatic installation ........................

All TV channels are searched for and

stored automatically. If connected to a

cable system or a TV channel which

transmits the correct information a

programme number and a name is

attributed automatically as well and filled in

in the programme list.

If you wish the order of programme

numbers and names of stored TV channels

can be modified afterwards.

Follow very closely and step by step the

instructions of the Automatic Installation.

Manual installation

With manual installation it is possible to

select whether TV channels are searched

for by frequency or channel number.

Follow very closely and step by step the

instructions of the Manual Installation

procedure.

You must go through every step.

Go on to page 7.

4Select Automatic Installation with the keys Vor Wand press OK.

5The menu AUTOMATIC INSTALLATION appears.

4Press OK again.

4Press the keys Cor Bto select On.

5The message Searching appears as the TV searches for all the channels

available in your area.

The automatic installation can be interrupted by pressing the MENU key.

5Every time a TV channel is found it is automatically placed under the next free

programme number in the programme list.

5The message Ready appears on the screen when the automatic installation is

complete. The programmes are stored in the programme list after the message

has disappeared.

If a cable system or a TV channel transmitting a teletext page with the

frequencies and programme names of all the TV channels which can be

received, is detected, the search is stopped and a programme list appears.

The programme list is automatically filled with all the programme numbers and

names of the TV channels transmitted.

It is possible that the cable company or the TV channel displays a broadcast selection

menu. Layout and items are defined by the cable company or the TV channel. Make

your choice of the presented possibilities with the keys Wor Vand press OK.

4Press MENU.

5The INSTALLATION menu reappears.

Go on to page 9.

Automatic installation

AUTOMATIC

INSTALLATION

Automatic Installation

Searching 0 % ............. 100 %

Menu Language

Country

Automatic Installation

Manual Installation

Give Name

Reshuffle

Favourite Programmes

TV Configuration

Decoder/Descrambler

INSTALLATION

English

Manual installation

4Select Manual Installation with the keys Vor Wand press OK.

5The MANUAL INSTALLATION menu appears.

In the left upper corner of the screen a programme number, a system,

a frequency or possibly a channel number are displayed.

5Selection Mode is only present and lights up if the country you selected in

the COUNTRY menu also offers the channel option.

In this case you can choose either channel or frequency mode.

4Press the keys Cor Bto select frequency, C-channels (aerial channels) or

S-channels (broadcast by a cable company).

You have your own aerial.........................

4Select the country or part of the world

from where you want to receive the TV

channel with the keys Bor C.

Go on to 2.

You are connected to a cable system

4Select the country or part of the world

where you are now located.

Select the TV system

Television pictures are not broadcast in the same way in all countries. We

speak of different television systems (PAL, SECAM, NTSC,...).

4Select System with the keys Vor W.

Search for a TV channel

4Select Search with the keys Vor Wand press OK.

5The TV searches for a channel.

5The frequency or the channel number increases until a TV channel is found.

Dependent on the choice you made in the selection mode the searching stops

at a frequency or at a channel number.

5In the bar, which may appear briefly at the bottom of the screen, the

broadcaster may transmit its programme name or another message.

4Press Jof the remote control to recognise which programme is being

broadcast.

5The menu MANUAL INSTALLATION disappears temporarily.

Is the reception poor ?

You may be able to improve the reception of picture and sound of a TV

channel by adjusting the frequency with the P- or + key on the remote

control. The frequency is adjusted in the block shown in the upper left corner

of the screen.

Go on to 3if you want to store the channel that has been found.

Do you want a different channel ?

4Press OK again to restart the search.

No channel found ?

4Interrupt the search by pressing the keys Vor Wor the MENU key.

Check that you have selected the correct TV system or that the aerial is

connected properly. See Tips p. 42.

MANUAL

INSTALLATION

05 10

16 11

27 12

38 13

4 9 ...

Selection Mode

System

Programme No.

Store

.......

123

456

789

VCR 1

VCR 2

SAT

AMP

TUNER

TAPE

DCC

Direct selection of a TV channel

If you know the frequency, or the C- or S-channel number, it can be entered

directly with the digit keys on the remote control and in this way call up the

TV channel.

Ask for a list from your cable company or dealer, alternatively consult the

Table of frequencies on the inside backcover of this handbook.

4Select Search with the keys Vor W.

4Enter the 3 digits of the desired frequency or the 2 digits in case of

C-or S-channels.

4For frequencies under 100 MHz, first enter a 0. For example : 063.

5The frequency is automatically finetuned.

Have you entered a wrong number ?

First complete the frequency or the channel number with arbitrary numbers and then

start again.

Go on to 3.

Enter the programme number

Now assign a number of your choice to the TV channel you have located. In

this way you decide the order of all your TV channels.

4Select Programme Number with the keys Vor W.

4Select with the keys Cor Bor with the digit keys the desired programme

number.

Go on to 4.

Store steps 1 to 3

Now the steps 1 to 3 must be stored in the memory.

4Select Store with the keys Vor Wand press OK.

5Stored appears briefly at the bottom of the screen.

5The programme number and probably the programme name are stored in the

programme list after the message has disappeared.

If you want to store another TV channel.

4Repeat &to ‘.

If you are connected to a cable system.

4Begin immediately with é. You have already selected the TV system in &

for all channels.

If you have finished storing TV channels.

4Press MENU.

5The INSTALLATION MENU reappears.

repeat

end

123

456

789

VCR 1

VCR 2

SAT

AMP

TUNER

TAPE

DCC

English

It is possible to change the name stored in the memory or to assign a name to

a TV channel which has not yet been entered. A name with a maximum of 5

letters or numbers can be given to the programme numbers 0 to 99. For

example SUPER, BBC1,...

Between 99 and 0, you can also name any peripherals that are connected.

4Select Give Name with the keys Vor Wand press OK.

5The GIVE NAME menu appears.

4Select the TV channel to be modified or assigned a name with the keys V, W,

Bor Cand press OK.

5A block appears on the first position of the name.

4Select with the keys Bor Cthe position of the letter or number you want

to change or to enter.

4Select with the keys Vor Wthe letter or number you want to enter or to

correct. A space, numbers or other special characters are located between

Z and A.

Did you fill in a wrong letter or number ?

Select with the keys Bor Cthe position of the letter or number you want to modify.

Select with the keys Vor Wthe correct letter or number.

When the complete name is filled in.

4Press OK.

4Select another TV channel to be modified or assigned a name with the keys

V, W, Bor Cand press OK.

4Repeat as described above.

When you have finished entering or modifying programme names.

4Press MENU.

5The INSTALLATION menu reappears.

Reshuffle the programme list

According to your preference you can change the order of the stored TV

channels.

When you are satisfied with the order of the programme list, go to page 10.

4Select Reshuffle with the keys Vor Wand press OK.

5The menu RESHUFFLE appears.

4Select the TV channel you want to change the programme number of with the

keys V, W, Cor Band press OK.

4Use the keys Cor Bto select another column of the programme list.

5The programme number and the name of the TV channel appear in a black

block.

4Use the keys V, W, Bor Cto move to the number where you want to locate

the TV channel.

4Press OK.

5The TV channel moves to the selected programme number.

The TV channel which was located on that position automatically moves to the

programme number of the TV channel you have modified.

4Repeat this for all the other TV channels you want to swap.

When all the TV channels are allocated as you like.

4Press MENU.

5The INSTALLATION menu appears again.

GIVE NAME 90

EXT1 0

91 EXT2 1 BBC1

92 EXT3 2 BBC2

93 FRONT 3 ....

94 4 ....

95 5 ....

96 .......

RESHUFFLE 90 ...

0 ... 10 ...

91 1 BBC1 11 ...

92 2 BBC2 12 ...

93 3 ... 13 ...

94 ...... 14 ...

95 ...... 15 ...

96 ...... ......

Enter or modify a programme name

123

VCR 1

VCR 2

SAT

AMP

TUNER

TAPE

DCC

Select Favourite TV channels

During the installation all the stored TV channels have automatically been

placed into the favourite list.

This will make selection of only your favourite TV channels a lot easier and

faster.

In the Favourite Programmes menu you can indicate for each TV channel if you

want to keep that TV channel as a favourite.

You can also do this for a programme number reserved for the programmes

you receive from your decoder.

After leaving the installation you can quickly run through the TV channels by

pressing the P- or +. Only those TV channels which are in the favourite list

will be displayed. The non-favourite TV channels can still be selected with the

digit keys.

4Select Favourite Programmes with the keys Vor Wand press OK.

5The FAVOURITE PROGRAMMES menu appears.

5Programme Number lights up.

4Select the programme number of a TV channel with the digit keys.

4Select Favourite with the keys Vor W.

4Press the keys Bor Cto select Yes or No.

In this way you decide whether you want to keep the selected TV channel as a

favourite TV channel or not.

Repeat this for every TV channel you like to change into a favourite or a non-

favourite TV channel.

4Press MENU again if you have finished selecting TV channels in the favourite list.

5The INSTALLATION menu reappears.

FAVOURITE

PROGRAMMES

EXT1 0 ... 10 ...

EXT2 1 ... 11 ...

EXT3 2 ... 12 ...

FRONT 3 ... 13 ...

4 ... 14 ...

5 ... 15 ...

..... ......

Programme Number

Favourite

Install TV Configuration

Different options can be selected depending on the different peripheral

equipment you may have connected to your TV.

4Select TV Configuration with the keys Vor Wand press OK.

5The TV CONFIG. menu appears and Audio Output lights up.

Audio Output

If you have audio equipment or another external sound source connected to

your TV, you can select two types of audio output.

4Select Variable with the keys Bor Cif you want to adjust the volume of

your audio equipment via the TV.

Select Constant if you want to adjust the volume with the volume control

of your audio equipment.

Ext2 Output

See Record with your video recorder, p. 40.

CD-i/Photo CD

See Connect Peripheral Equipment, TV and a CD-i/Photo CD, p. 36.

TV CONFIG. Audio Output

Ext2 Output

CD-i/Photo CD

Surround Mode

Centre Mode

Ext. Amplifier

Information Line

VCR 1

VCR 2

SAT

AMP

TUNER

TAPE

DCC

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips TV

Philips

Philips DC146 Manuel utilisateur

Philips

Philips Magnavox PR0925B Manuel utilisateur

Philips

Philips 286NS-05 Manuel utilisateur

Philips

Philips 32PHT4132 Manuel utilisateur

Philips

Philips L04A AB Manuel utilisateur

Philips

Philips 21PT9469/44 Manuel utilisateur

Philips

Philips PUS7855 Manuel utilisateur

Philips

Philips 21HT3312 Manuel utilisateur

Philips

Philips US-24ST2200/27B Manuel utilisateur

Philips

Philips 28PW8505/58 Manuel utilisateur

Philips

Philips 43PFL6621 Manuel utilisateur

Philips

Philips 7008 Series Manuel utilisateur

Philips

Philips 47PFL5704D - 47" Class Full Hd 1080p Lcd Tv... Guide de configuration

Philips

Philips 40PUG6909 Manuel utilisateur

Philips

Philips FTP2.4E Manuel utilisateur

Philips

Philips 32PFL5008T/12 Manuel utilisateur

Philips

Philips 42PFL5403/77 Manuel utilisateur

Philips

Philips BP2.2U Manuel utilisateur

Philips

Philips 7600 series Manuel utilisateur

Philips

Philips 30PF9946 Guide de configuration

Philips

Philips 47PFL3603D Manuel utilisateur

Philips

Philips CTV S26K497 Manuel utilisateur

Philips

Philips Matchline 28ML8765 Mode d’emploi

Philips

Philips M-Link 27PT81S1 Manuel utilisateur

Manuels TV populaires d'autres marques

Toshiba

Toshiba 27A10 Manuel utilisateur

Hitachi

Hitachi 32FX48B Manuel utilisateur

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Manuel utilisateur

Changhong Electric

Changhong Electric uhd55b6000is Manuel utilisateur

Panasonic

Panasonic Genus TX-G10 Manuel utilisateur

Toshiba

Toshiba 19A20 Manuel utilisateur

Sony

Sony XBR-100Z9D Manuel utilisateur

Samsung

Samsung 55S9 B Series Manuel utilisateur

Sharp

Sharp LC-40FI5012E Manuel utilisateur

Loewe

Loewe Table Stand Reference 55 Manuel utilisateur

Sylvania

Sylvania 6427FB Manuel utilisateur

Sanyo

Sanyo CE19LD90N-B Manuel utilisateur

North State

North State TV2GO Manuel utilisateur

RCA

RCA RTU7877 Manuel utilisateur

Sharp

Sharp 21K-FG1RU Manuel utilisateur

Sony

Sony Esprit TAV-L1 Manuel utilisateur

Grundig

Grundig 43 VLE 4820 Manuel utilisateur

Samsung

Samsung LN26C350D1D Manuel utilisateur
