English

About this handbook

This is a handbook to help you with the installation and operation of

your new menu TV.

With a menu TV, menus can be called up on the screen. These menus

provide information either about operations to be carried out or about

functions you can select.

This handbook consists of two parts :

Installation

This part helps you with installing your TV,

selecting your menu language, locating and

storing your TV channels and composing

your favourite list of programme numbers.

To do this, follow the directions of the

SYSTEM INSTALLATION menu very closely.

The installation menu is shown as it will

appear on your screen.

Operation

After you have stored the TV channels, you

can call them up on the screen. You can

adjust the picture and sound via the main

menu. The MAIN MENU is shown here as it will

appear on the screen. Feel free to try out all

the different possibilities of your TV. Use this

part of the handbook to help you do this.

MAIN MENU 2

■

recording source

■

system installation

■

>>>>>

select : a-c menu off

MAIN MENU 1

■


■

sound

■

programme list

■

special features

■

>>>>>

select : a-e menu off

SYSTEM INSTALLATION

■

language

■

tv installation

■

photo CD/CD-I

select : a-c menu off

4This circle in front of a sentence indicates that you have to do

something.

5This arrow in front of a sentence indicates the result of what you have

done.

In the stripe under each menu you are told which keys you can press

and how you can switch the menus off again.

Contents

Installation

Preparation.......................................................3

Switching TV on...............................................4

Selecting your Menu language.......................5

Searching for and Storing TV channels :

- Automatic ..................................................6

- Manual .......................................................7

Operation

Operation........................................................14

Main Menu .....................................................15

Other Functions..............................................20

Pip Picture in Picture......................................24

Teletext ...........................................................26

Peripheral Equipment....................................29

Tips..................................................................35

Index ..............................................................36

English

TVVCR

TUNER CD TAPE

SAT LD

adfgb

MeAK

TV MC

off

123

456

789

satellite selection in

combination with a

satellite tuner only

standby - switch-off

picture format

. programme selection

. favourite TV channel

selection

digit keys

previous programme

video recorder function

0...9

temporarily switch off

the sound

volume key

txt on/off

stop seeking txt page

solution to riddles

interrupt txt page

mix txt and tv picture

enlarge

time display

switch pip on/off

select connections

switching screens

still picture

moving pip screen

stop

play

record

rewind

wind

programme timer

personal preference

on screen info

bilingual choice

brightness

enter or leave a menu

selection of your

choice in the menus

switch off all menus

a...e

freeze the picture

noise reduction

mosaic screen

(for TV sets with PiP)

TV selection

source selection

connect

off

Source selection

PiP - picture in picture

(for TV sets with PiP)

TXT - Teletext

Other functions

Video recorder

English

1Preparation

Place the TV on a solid surface.

For ventilation, leave a space of at least 5 cm free all around the set.

This TV requires a mains voltage of 220 V - 240 V.

Insert the aerial plug tightly into the aerial socket gat the back

of the TV with an aerial cable of good quality.

You can improve the picture quality by using the suppressor-

aerial-cable supplied.

Remote control

This remote control has been developed to operate your TV.

However some main functions of your audio and video equipment from

our product programme are controllable as well.

Tear off the label, written in your language from the label sheet,

supplied with these instructions, click it onto the inside surface of the

door of the remote control.

Remove the cover of the battery compartment on the back of the

remote control.

Insert the 2 batteries supplied (type R03G-1,5V).

Click the cover back into place.

The Philips batteries supplied with the remote control unit of your new

TV set do not contain the heavy metals mercury and cadmium.

Nevertheless in many countries exhausted batteries may not be

disposed of with your household waste.

Please ensure you are aware of any local regulations governing the

disposal of exhausted batteries.

4Press the TV key below the display.

5In the window of the remote control the letters TV appear in a

grey block.

You can now operate your TV with your remote control.

Go on to 2.

VCR

TUNER CD TAPE

SAT LD

CABLE

Insert the mains plug in the wall socket.

Installation

5A green or red lamp lights up on the front of

your TV set.

green .........................................................or

5The TV is switched on.

The screen lights up.

Go on to 3.

red .............................................................

The TV is switched on but the screen stays

dark. Your TV is on standby.

4Press a digit key on the remote control.

5The green lamp lights up and blinks every

time you press a key on the remote control.

5The TV switches on.

The screen lights up.

Go on to 3.

Switching TV on

4Press the switch Aon the left side of your TV set.

English

Selecting your menu language

You can choose for yourself the language of the menus - the instructions and the

various possible choices - which you call up on your screen.

4Press the INSTALL key on the right side of your TV set.

If the message CHILD LOCK ON appears, the child lock should be switched

off. See Special Features, p. 18.

5The SYSTEM INSTALLATION menu appears on the screen.

It is also possible to enter the installation menu via the main menu.

See Main Menu, p. 15.

4Press the red key a on the remote control.

5The language menu appears on the screen.

4Press the colour key of your language choice.

4Press the corresponding colour key for >>>>> if the language you

want does not appear on the first language menu.

5LANGUAGE STORED appears for a moment at the top of the menu.

The language menu disappears and the SYSTEM INSTALLATION menu

appears again.

From this point on, all menus are presented in the language of your

choice.

Go on to 4.

Have you pressed the wrong key ?

Press the red key a for language again and make a new choice.

SYSTEM INSTALLATION

■

language

■

tv installation

■

photo CD/CD-I

select : a-c menu off

INSTALL

PROGRAM

VOLUME

■

ENGLISH

■

Deutsch

■

Français

■

Italiano

■

>>>>>

select : a-e menu

■

Español

■

Nederlands

■

Português

■

Svenska

■

>>>>>

select : a-e menu

■

Norsk

■

Suomi

■

Dansk

■

ENGLISH

■

>>>>>

select : a-e menu

Installation

SYSTEM INSTALLATION

■

language

■

tv installation

■

photo CD/CD-I

select : a-c menu off

4Searching for and storing

TV channels

After you have switched on your TV and selected your menu language,

you can search for and store your TV channels.

This can be done in two different ways : automatically or manually.

TV INSTALLATION

■

automatic

■

manual

■

programme name

■

programme sort

■

preselection preferences

select : a-e menu off

Automatic installation....................................

All TV channels are searched for and stored

automatically. As far as it is transmitted by

the cable company a programme number

and a name are attributed automatically as

well as filled in the programme list.

If desired you can modify the allocation of

the channel numbers and the name of one

or more stored TV channels afterwards and

delete or insert TV channels.

Manual installation.........................................

The manual installation is characterised by

the possibility to select the way of searching

with frequencies.

You yourself must assign a number and a

name of your choice to the TV channel

located.

Follow very closely and step by step the

instructions of the Manual Installation

procedure.

You must go through every step.

Go on to page 7.

4Press the green key b in the SYSTEM INSTALLATION menu.

5The TV INSTALLATION menu appears.

Automatic installation

4Press the red key a.

5AUTOMATIC lights up.

4Press MENU + to select YES.

5SEARCHING, PLEASE WAIT appears and the TV is searching all the channels

you can receive.

The automatic installation can be interrupted by pressing the

MENU or OFF key.

5Every time a channel is found it is automatically stored in the memory

under the next programme number in the programme list.

5When all channels are found the message TV INSTALLATION COMPLETED is

displayed briefly on top of the menu.

The programme list is automatically filled with all the programme

numbers of the TV channels transmitted.

When a cable company is recognised which transmits a teletext page

with the frequencies and the programme names of all the TV channels

which can be received, the searching is stopped and a programme list

appears.

The programme list is automatically filled with all the programme

numbers and names of the TV channels transmitted.

It is possible that the cable company displays an own broadcasted

selection menu. Layout and items are defined by the cable company.

Make your choice of the presented teletext pages by entering the

corresponding digit key.

5The menu TV INSTALLATION appears again.

Go on to 5, page 9.

English

Installation

step Searching for a TV channel

step Selecting the TV system

The television picture is not broadcast in the same way in all countries.

We speak of different television systems (PAL, SECAM, NTSC, ....).

Now you must select the TV system yourself.

Manual TV installation

4Press the green key b in the menu TV INSTALLATION.

5The menu MANUAL TV INSTALLATION appears.

MANUAL TV INSTALLATION

■

system

■

programme

■

store

select : - + a-d 0-9 menu off

4Press the red key a.

5The SELECTING THE SYSTEM menu appears.......

1You have your own aerial.

4Press the colour key of the country or part of

the world from where you want to select the

TV channel.

5The MANUAL TV INSTALLATION menu now

appears.

5Your selection lights up.

2You are connected to the cable system.

4Press the colour key of the country or part of

the world where you now are located.

5The MANUAL TV INSTALLATION menu now

appears.

5Your selection lights up.

Go on to step b.

ONLY ONE SYSTEM AVAILABLE appears ................

You have a set that can receive only one

system.

You do not need to make any selection.

Go on to step b.

4Press the green key b.

5SEARCHING appears and the TV is searching for a channel.

5The frequency increases until a channel is found.

Go to step cif you want to store the channel that has been found.

4Press Junder the door of the remote control to recognise which

programme is being broadcast.

5The MANUAL TV INSTALLATION menu disappears temporarily.

Do you want a different channel or is the reception poor?

4Press the green key b again.

Is the reception still poor? See Tips, p. 35.

Fine-tuning :

You may be able to improve the reception of picture and sound of a TV

channel. Adjust the frequency yourself with the MENU - or + key on the

remote control.

Direct selection of a TV channel :

If you know the frequency of a TV channel, you can enter it directly with the

digit keys on the remote control and in this way call up the TV channel.

Ask for a list of the frequencies at your cable company or at your dealer.

4Enter the 5 digits of the desired frequency.

4For frequencies under 100 MHz, first enter a 0. For example : 063.25.

Have you entered a wrong number?

First complete the frequency with arbitrary numbers and then start again.

Go on to step c.

If you have pressed the wrong key, then repeat step a.

step Entering the programme number

Now you must assign a number of your choice to the TV channel

located. In this way you decide for yourself the order of all your TV

channels.

With the assigned programme number you can call up your TV channel

again later.

4Press the yellow key c.

5Hold down the P- or + key or use the digit keys on the remote control

until the desired programme number appears in the menu.

Go on to step d.

step Storing steps a to c

Now the TV system, the located TV channel and its programme number

must be stored in the memory.

4Press the blue key d.

5PROGRAMME STORED appears briefly at the top of the menu.

5The TV channel is stored in the memory.

Do you want to store another TV channel?

4Repeat steps a to d.

Are you connected to the cable system?

4Begin immediately with step b. You have already selected the TV

system in step a for all channels.

Have you finished locating TV channels?

4Press MENU.

5The TV INSTALLATION menu appears again.

Go on to 5.

repeat

out

English

5Entering or modifying a

programme name

It is possible that to change the name transmitted by the broadcaster or

to assign a name to the TV channels of which no name is filled in yet.

A name of maximum 5 letters or numbers can be given to the

programme numbers 0 to 99. For example SUPER, BBC1, ...

4Press the yellow key c.

5The PROGRAMME NAME menu and the programme list appear.

Also the frequency of the current TV channel is displayed.

4Press Junder the door of the remote control to recognise which

programme is being broadcast.

5The menu PROGRAMME NAME disappears temporarily.

4Press the red key a.

4Select the TV channel of which you want to change the name or to

which you want to assign a name with the digit keys or with P- or +.

External sources can not be selected with P- or +.

In the list you can now modify or enter the name of the TV channel.

With the arrow under the letter and number line you select which

letter or number in the list above you wish to enter .

In the list there is a red or white block next to the chosen programme

number.

4Hold as desired , either the green key b down to move the arrow to

the left, or else the yellow key c to move the arrow to the right.

5The letter or number that you indicate with the arrow appears in the

block.

4Press the blue key d.

5The block moves over one space.

Now you can choose a following letter or number with the arrow.

4Place the arrow between Z and 0 for a space.

Did you fill in a wrong letter or number?

Press repeatedly on the blue key d until the block is back in the place

where you want to make a change.

Now choose with the arrow the correct letter or number.

Are the complete names filled in?

4Press MENU.

5The TV INSTALLATION menu appears again.

Go on to 6.

Installation

pr.name pr.name pr.name

01020

1 ... 11 21

21222

31323

41424

51525

61626

71727

81819

91929

frequency : xxx.xx MHz

ABCDEFGHIJK....XYZ 012345...89

≠

■

programme number

■

A ¨ 9

■

A Æ9

■

next character

select : a-d 0-9 menu off

PROGRAMME NAME

6Modifying the programme list

According to your preference you can modify the programme list of the

stored TV channels by swapping, deleting or inserting certain TV

channels.

4Press the blue key d.

5The PROGRAMME SORT menu appears.

a. swap

With the swap-function you can modify the allocation of the stored

TV channels.

4Press the red key a.

5FIRST SELECTION lights up.

4Select the programme number of the TV channel of which you want to

modify the programme number with the digit keys or with P- or +.

4Press the green key b.

5SECOND SELECTION lights up.

4Select the programme number of the TV channel which you want to

swap with the programme number selected in your first selection.

4Press the yellow key c.

5PROGRAMMES SWAPPED appears briefly at the top of the menu.

5The TV channels and their names selected in the first and the second

selection are swapped.

4Repeat this for all the other TV channels you want to replace.

b. delete

With the delete-function you can remove the TV channels you do not like

to have in the programme list anymore.

4Select, with the digit keys or with P- or +, the programme number you

want to delete .

4Press the blue key d.

5DELETE lights up and the programme number and name of the TV channel

to be deleted starts flickering in the FIRST or SECOND SELECTION line.

4Press MENU + to select YES.

5DELETING PROGRAMME appears briefly at the top of the menu.

5The selected TV channel is deleted , its place is taken by the next

programme and the subsequent programme numbers are shifted up one

place.

4Repeat this for all the other TV channels you want to delete.

pr.name pr.name pr.name

01020

1 .... 11 21

21222

31323

41424

51525

61626

71727

81819

91929

■

first selection

■

second selection

■

swap

■

delete

■

insert

select : a-e menu off

PROGRAMME SORT

Table des matières

Autres manuels Philips TV

Philips

Philips 8546 Series Manuel utilisateur

Philips

Philips 65PUG7408 Manuel utilisateur

Philips

Philips 50PFL5602/F8 Manuel utilisateur

Philips

Philips Cineos 29PT9020 Manuel utilisateur

Philips

Philips 40PFL6605 Manuel utilisateur

Philips

Philips 22HFL3008D/12 Manuel utilisateur

Philips

Philips 8536 Series Manuel utilisateur

Philips

Philips 3 Series Manuel utilisateur

Philips

Philips 29PT6446 Manuel utilisateur

Philips

Philips 29PT8607 Manuel utilisateur

Philips

Philips 216?2554 Manuel utilisateur

Philips

Philips 79 6 Series Manuel utilisateur

Philips

Philips Matchline 28PW960A Manuel utilisateur

Philips

Philips 25TS56C1 Manuel utilisateur

Philips

Philips 19PFL3403/10 Manuel utilisateur

Philips

Philips 28PT5008 Manuel utilisateur

Philips

Philips Magnavox TS2754 Manuel utilisateur

Philips

Philips 5100 series Manuel utilisateur

Philips

Philips TS2779C1 Manuel utilisateur

Philips

Philips OLED908 Series Manuel utilisateur

Philips

Philips 19HFL2829P/12 Manuel utilisateur

Philips

Philips 32PW9523 - annexe 1 Manuel utilisateur

Philips

Philips 21PT5321/60 Manuel utilisateur

Philips

Philips 26PW9100D - Hook Up Guide Guide de démarrage rapide

Manuels TV populaires d'autres marques

Toshiba

Toshiba 27A10 Manuel utilisateur

Hitachi

Hitachi 32FX48B Manuel utilisateur

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Manuel utilisateur

Changhong Electric

Changhong Electric uhd55b6000is Manuel utilisateur

Panasonic

Panasonic Genus TX-G10 Manuel utilisateur

Toshiba

Toshiba 19A20 Manuel utilisateur

Sony

Sony XBR-100Z9D Manuel utilisateur

Samsung

Samsung 55S9 B Series Manuel utilisateur

Sharp

Sharp LC-40FI5012E Manuel utilisateur

Loewe

Loewe Table Stand Reference 55 Manuel utilisateur

Sylvania

Sylvania 6427FB Manuel utilisateur

Sanyo

Sanyo CE19LD90N-B Manuel utilisateur

North State

North State TV2GO Manuel utilisateur

RCA

RCA RTU7877 Manuel utilisateur

Sharp

Sharp 21K-FG1RU Manuel utilisateur

Sony

Sony Esprit TAV-L1 Manuel utilisateur

Grundig

Grundig 43 VLE 4820 Manuel utilisateur

Samsung

Samsung LN26C350D1D Manuel utilisateur
