Contents

English

Your remote control 2

Preparation 3

Installation 4

Store TV channels 4

Select the menu language and country 4

Automatic installation 5

Manual installation 5

Give name 6

Reshuffle the programme list 6

Select favourite TV channels 6

Install TV setup 7-8

EasyLink features are based on the “one touch operation” approach.This

means that a sequence of actions are executed at the same time in both

the television and the video cassette recorder, provided both are fitted

with the EasyLink function and connected with the eurocable

supplied with your video recorder.

Installation

Operation

Use of the remote control 9-11

Use of the menus

Picture menu 12

Sound menu 12-15

Features menu 16

NEXTVIEW 17-21

Teletext 22-24

The keys on top of the TV 24

Connect peripheral equipment

Connecting and selecting equipment 25-28

Remote control functions for peripherals 28-29

Recording 30

Tips 31

Index 31

Glossary 32

4916.2 gb 18-01-2000 16:43 Page 1

Mha

SMART


ACTIVE

CONTROL

SMART

SOUND

213

546

879

®Ò‡π

†

æb

qÏ

Mqa

TV VCR DVD SAT

TUNER CD TAPE CDR

SMARTSMART

PICTURESOUND

¬V P

◊

pπ

®S

yÚ

INSTANT

ZOOM

2Preparation

Preparation

Your remote control

Teletext p. 23

Utime display/subpage selection

fsolution to puzzles

display PDC/VPS code

henlarge

Pno function

Smart Controls

Msmart sound p. 10

hactive control on/off p. 10

asmart picture p. 10

Bswitch to standby p. 9

ion screen info p. 9

0previous programme p. 9

◊video recorder/DVD function p. 9

Xbilingual choice/sound info p.11

TXT language group selection p. 22

EasyLink p. 11

®INSTANT recording

Sfreeze the picture p. 11

hold teletext page p. 23

bteletext on/off p. 22

Ïmain menu on/off p. 9

cursor to select

your choice p. 12

OK activate your choice

Installation p. 4

Vvolume up/down p. 9

¬sound mute p. 9

Pprogramme selection p. 9

Peripherals p. 28

wselection of EXT1,EXT2, EXT3or

FRONT

TV, video recorder (VCR), DVD,

Satellite (SAT), TUNER,CD,TAPE or

cd-recordable (CDR) selection.

Colour keys

-NEXTVIEW selection p. 17

- direct teletext page or

subject selection p. 22

Audio- and Video equipment p. 28-29

Ono function

bdual screen on p. 10

Qsurround modes p. 9

æNEXTVIEW/TXT programme

guide on/off p. 9

qpicture format p. 11

4916.2 gb 18-01-2000 16:43 Page 2

&Place the TV on a solid surface.

For ventilation, leave at least 5 cm free all around the TV.

Do not place the TV on a carpet.

To prevent any unsafe situations, do not place any objects on top of the TV.

Avoid heat, direct sunlight and exposure to rain or water.

éInsert the aerial plug firmly into the aerial socket at the back of the

TV.

“Insert the mains plug in the wall socket having a mains voltage of 220V-240V.

To prevent damaging the mains (AC) cord which could cause a fire or electric

shock, do not place the TV on the cord.

‘Remote control: Remove the cover of the battery compartment.

Insert the 2 batteries supplied (Type R6-1.5V).

Press the TV key to be sure your remote control is in the TV mode.

The batteries supplied do not contain the heavy metals mercury and cadmium.

Nevertheless in many countries exhausted batteries may not be disposed of with

your household waste. Please check on how to dispose of exhausted batteries

according to local regulations.

Note: this remote control functions with TVs which use the RC6 signalling standard.

(Switch the TV on : Press the power switch Aon the front of your TV.

A green indicator on the front of the TV lights up and the screen comes on.

If the indicator is red, press the -P+ key on the remote control.

The green lamp blinks every time you press a key on the remote control.

When you switch on your set for the first time, the menu LANGUAGE

automatically appears on the screen.The explanation appears in different languages

one at a time. Choose your own language and press the OK key on the remote

control.

Go on to page 4.

3Preparation

Preparation

CABLE

R6 / AA

æb

VCRTV DVD SAT

CDTUNER TAPE CDR

4916.2 gb 18-01-2000 16:43 Page 3

4Installation

Store TV channels

After the new or extra TV channels have been stored, the TV automatically transfers

those TV channels to the video recorder if it is equipped with the EasyLink function.

The message EasyLink : downloading ...... appears on the screen. The

programme list of the video recorder is now the same as the one of the TV. If the TV

is connected to a video recorder which supports the NEXTVIEWLink function, the TV

also automatically transfers the language and country selections to the video

recorder.

First, select your language and country.

&Select Menu language and press the OK key in the centre of the cursor.

éSelect your language and press the OK key in the centre of the cursor.

Use the cursor up/down to scroll through the list and to bring up other

languages which are not displayed on the screen at present.

“Select Country and press the OK key in the centre of the cursor.

‘Select the country where you are now located and press the OK key in the

centre of the cursor.

Use the cursor up/down to scroll through the list and bring up other

countries which are not displayed on the screen at present.

Select Other when none of the countries applies.

You can now search for and store the TV channels in two different ways:

using automatic installation or manual installation (tuning-in channel by

channel).

Select your choice and press the OK key in the centre of the cursor.

Select the menu language and country

MENU TITLE

Menu language

Country

Automatic Installation

JINSTALLATION

MENU TITLE

United Kingdom

....

JCountry

MENU TITLE

English

....

JMenu language

&Open the door of the remote control.

éPress Uand fat the same time.

Installation

Select the INSTALLATION menu

&Use the cursor in the up/down, left/right directions to select a menu item.

éPress the OK key in the centre of the cursor to activate.

“Use the Ïkey to return or to switch the menu off.

To use the menus

MENU TITLE

Subject 1

Subject 2

Subject 3

JSubject 4

Subject 5

Subject 6

JSubject 4 L M

pπ

OK OK

213

546

879

¬V P

◊

X®SP

INSTANT

ZOOM

yÚ

213

æb

qÏ

TV VCR DVD SAT

TUNER CD TAPE CDR

¬V P

select menu item

return or switch

main menu off

activate

4916.2 gb 18-01-2000 16:43 Page 4

Searching for and storing TV channels is done channel by channel.

You must go through every step of the Manual installation menu.

Selection mode is only present and lights up if the country selected also

offers the channel option (C-channels for aerial channels, S-channels for cable

channels).

You can choose either channel or frequency mode.

&Select the TV system

Select the country or part of the world from where you want to receive the

TV channel.

If you are connected to a cable system, select your country or part of the

world where you are now located.

éPress the cursor down and enter the programme number with the digit keys.

“Search for a TV channel

Press the cursor left/right.

The frequency or the channel number increases until a TV channel is found.

Direct selection of aTV channel

If you know the frequency, the C- or S-channel number, enter it directly with

the digit keys 0 to 9.

Ask for a list from your cable company or dealer, alternatively consult the

Table of frequencies on the inside backcover of this handbook.

‘Fine tune

In case of poor reception, you can improve the reception by adjusting the

frequency with the cursor left/right.

(To store your TV channel, select Store and press the OK key in the centre of

the cursor.

Repeat steps &to (to store another TV channel.

§To exit from the menu press the Ïkey on the remote control.

In the Automatic installation menu select Start and press the OK key in the

centre of the cursor to activate the searching. All TV channels are searched

for and stored automatically.

If a cable system which broadcasts ACI (Automatic Channel Installation) or a

TV channel transmitting a teletext page with the frequencies and programme

names of all the TV channels which can be received, is detected, the search is

stopped and a programme list appears.

The programme list is automatically filled with all the programme numbers

and names of the TV channels transmitted.

It is possible that the cable company or the TV channel displays a broadcast

selection menu. Layout and items are defined by the cable company or the TV channel.

Make your choice with the cursor and press the OK key in the centre of the cursor.

To exit from the menu press the Ïkey on the remote control.

Go on to page 6.

5Installation

Manual installation

Automatic installation

Start

Stop

TV is searching

One moment please ...

JStop K

Automatic installation

Start

Stop

1 BBC1

2 BBC2

3 CNN

....

JStart K

Manual installation

(Selection mode)

System

Programme no.

Fine tune

Store

JSystem K

4916.2 gb 18-01-2000 16:43 Page 5

6Installation

Give name

It is possible to change the name stored in the memory or to assign a name

to a TV channel which has not yet been entered.A name with up to 5 letters

or numbers can be given to the programme numbers 0 to 99. For example

SUPER, BBC1,... Between 99 and 0 you can also name any peripherals that

are connected to a euroconnector.

&Select Give name in the INSTALLATION menu and press the OK key in the

centre of the cursor.

éSelect the programme number.

“Press the OK key in the centre of the cursor.

‘Select the character with the cursor up/down.

(Select the following position with the cursor right.

§Select the following character.

èPress the OK key in the centre of the cursor when finished.

!Press the Ïkey to return to the INSTALLATION menu.

Space, numbers and other special characters are located between Z and A.

According to your preference you can change the order of the stored TV

channels.

&Select Reshuffle in the INSTALLATION menu and press the OK key in the

centre of the cursor.

éSelect the programme number you want to exchange.

“Press the OK key in the centre of the cursor.

‘Select the new number you want to exchange it with.

(Press the OK key in the centre of the cursor.

Repeat the operation until all TV channels are allocated as you like.

§Press the Ïkey to return to the INSTALLATION menu.

Reshuffle the programme list

After leaving the installation you can browse through the TV channels by

pressing the - P + key. Only those TV channels which are in the favourite list

will be displayed. Non-favourite TV channels can still be selected with the digit

keys. By default all stored channels are added to the favourite list.

&Select Favourite programmes in the INSTALLATION menu and press

the OK key in the centre of the cursor.

éSelect your favourite programme number.

“Select Yes or No with the cursor left/right.

‘Repeat for every TV channel you want to make a favourite or a

non-favourite TV channel.

(Press the Ïkey to return to the INSTALLATION menu.

In order for NEXTVIEW to function properly, the first TV channel from the favourite list

should also broadcast the correct local date and time via teletext.

Select FavouriteTV channels

INSTALLATION

Menu language

Country

Automatic installation

Manual installation

Give name

Reshuffle

Favourite programmes

SETUP

JGive name

Give name

EXT1

EXT2

EXT3

FRONT

1 BBC1

2 BBC2

3 ....

4 ....

5 ....

Reshuffle

EXT1

EXT2

EXT3

FRONT

1 CNN

2 BBC2

3 ....

4 ....

5 ....

J1 CNN

Favourite programmes

0 ... No

1 ... Yes

2 ... No

3 .... No

4 .... Yes

5 ....

J2 ... Yes

4916.2 gb 18-01-2000 16:43 Page 6

7Installation

The Setup menu allows you to adjust initial settings, i.e. those which are not

related to the installation of the TV channels.

The Setup menu contains items that control the settings of the TV’s functions,

features, services and peripherals you may have connected.

&Use the cursor in the up/down, left/right directions to select the menu item.

éUse the OK key in the centre of the cursor to activate.

“Use the Ïkey to return or switch menu off.

Digital sources

See Connect Peripheral Equipment, p. 26 to connect your digital equipment,

like a DVD, a digital satellite tuner or a similar digital device.

Define Decoder/Descrambler programme numbers

If a decoder or a descrambler is connected, see p. 25, you can define one or

more programme numbers as decoder programme numbers.

Press the cursor left/right to select the input used to connect to your

decoder Off,EXT1 or EXT2.

Select Off if you do not want the selected programme number being

activated as a decoder programme number.

Select EXT2 when the decoder is connected to your EasyLink video recorder.

When selecting the decoder, the message EasyLink: downloading presets....

appears on the screen.

Picture tilt (if provided)

Select Picture tilt with the cursor up/down.

Keep the cursor left/right pressed to adjust the rotation of the picture.

Information line

Select On and after the selection of a TV programme or after pressing the

ikey on the remote control, a TV channel which broadcasts teletext may

transmit the name of the TV channel, the programme name or another

message.This is displayed on screen next to information about sound and

picture format.

When selected Off, only sound and picture format information is displayed

after the selection of a TV channel or after pressing the ikey.

Factory settings

Select Factory settings and press the OK key in the centre of the cursor to

restore picture and sound settings, predefined in the factory.

Extra front speakers

See Connect Extra loudspeakers,Amplifier, p. 27.

If no extra front speakers/amplifier are connected, do not change the

predefined factory setting which is No (TV).

Rear speakers

See Connect Extra loudspeakers,Amplifier, p. 27.

If no rear speakers/amplifier are connected, do not change the predefined

factory setting which is No (TV).

Install TV Setup

INSTALLATION

Menu language

Country

Automatic installation

Manual installation

Give name

Reshuffle

Favourite programmes

SETUP

JSETUP

Decoder/Descrambler

Programme

Decoder status

JProgramme

SETUP

Digital Sources

Decoder/Descrambler

(Picture tilt)

Information line

Factory settings

Extra front speakers

Rear speakers

Auto Surround on/off

NEX

IEW

provider none, 0...99

Auto format yes/no

INSTALLATION

JDigital sources

4916.2 gb 18-01-2000 16:43 Page 7

8Installation

Auto surround

Sometimes the broadcaster transmits special signals for Surround Sound

encoded programmes.

Dependent on your speaker configuration, the TV automatically switches to

the best surround sound mode when Auto Surround is switched On.

When rear speakers are connected and selected, Dolby Pro Logic will be

reproduced.When no rear speakers are connected, 3D surround will be

reproduced. Overruling this surround mode remains possible.

NEXTVIEW provider

Most broadcasters in Europe are offering teletext pages containing the day’s

programme schedule.These pages can be requested by switching the TV to

Teletext Guide.

An increasing number of broadcasters are offering an extended programme

guide service called NEXTVIEW.

NEXTVIEW is a new way of presenting programme schedules and offers more

features than basic teletext.With NEXTVIEW it is possible to show for instance

all the movies or children programmes for tonight or the following days.

If you select None as NEXTVIEW provider, the TV will capture all data from

the available TV channels which broadcast NEXTVIEW. Broadcaster defined

menus will not be available.

If you select a programme number of a TV channel stored in the favourite list

as NEXTVIEW provider, the selected TV channel will provide NEXTVIEW data

and additional information of its own broadcasts as well as from other (non

selected) TV channels.

Normally you will select the NEXTVIEW provider that transmits most

information in your language.You can make the best selection via information

from TV announcements or from the newspapers.

Important:

In order for NEXTVIEW to function properly, the first TV channel from the favourite list

should also broadcast the correct local date and time via teletext.

Please check at startup if the time and date are correct in the NEXTVIEW screen.

Remark:

Not all TV channels support NEXTVIEW.

How to make use of NEXTVIEW, see p. 17.

Auto Format

Selecting Yes causes the screen to automatically fill as much of the picture as

possible when TV programmes are not carrying special signals detecting the

correct screen format.

With the qkey on the remote control you can still select other picture

formats. See p. 11.

Installation

Select Installation and press the OK key in the centre of the cursor to

return immediately to the INSTALLATION menu.

‘To exit from the menu press the Ïkey repeatedly.

SETUP

Digital Sources

Decoder/Descrambler

(Picture tilt)

Information line

Factory settings

Extra front speakers

Rear speakers

Auto Surround on/off

NEX

IEW

provider none, 0...99

Auto format yes/no

INSTALLATION

NEX

IEW

provider none/o...99

4916.2 gb 18-01-2000 16:43 Page 8

9Use of the remote control

Operation

Use of the remote control

Mha

SMARTACTIVESMART

PICTURESOUND

213

546

879

®Ò‡π

†

æb

qÏ

TV VCR DVD SAT

TUNER CD TAPE CDR

¬V P

◊

wSelect peripherals

Press this key repeatedly to select EXT1,

EXT2, EXT3 or FRONT, according to where

you connected the peripherals (p. 28).

TV VCR DVD SAT TUNER CD TAPE CDR

Press one of these keys to use the remote

control directly in the TV, video recorder,

DVD or satellite mode. A green indicator

lights up. Press the same key again within 3

seconds to use the remote control in the

mode indicated below the key (tuner, CD,

tape or CD-recordable).

A red indicator lights up.

Press the key again to return to the function

mentioned above the key.

BStandby

The set is switched off and the red indicator

(orange when acquiring NEXTVIEW

information) lights up.When acquiring

NEXTVIEW the TV is switched to full standby

after a period of max. 1 hour and the red

indicator lights up.

To switch the TV on again, press - P + or the

digit keys.

If your EasyLink video recorder has the

system standby function and you press the

standby key for 3 seconds, both the TV and

video recorder are switched to standby.

®Ò‡π†Video recorder see p. 28

æNEXTVIEW/TXT programme guide

on/off see p. 17

QSurround mode

Press this key repeatedly to select another

available surround mode: Pro Logic,

3D Surround, Dolby 3 Stereo, Stereo or Hall.

iScreen information

Press for 5 seconds to activate/de-activate

the extended or reduced display of TV

channel and programme information on the

screen.

Press briefly to display information about the

selected TV channel and programme, the

sound reception, picture settings and the

remaining time set with the sleeptimer.

0/9 Digit keys

To select a TV channel.

For a two digit programme number, enter the

second digit within 2 seconds.

To switch immediately to a selected one digit

TV channel, keep the digit key pressed a bit

longer.

0Previous programme

The previously selected TV channel is displayed.

The ◊indication is only video recorder/DVD.

Use of the remote control

bTeletext on/off see p. 22

ÏMain menu on/off see p. 12

VVolume

Press + or - to adjust the volume.

¬ Mute

Temporarily interrupt the sound or restore

it.

PProgramme selection

To browse through the TV channels

activated in the Favourite Programme menu.

4916.2 gb 18-01-2000 16:43 Page 9

10 Use of the remote control

Mah

213

546

879

®Ò‡π

†

æb

qÏ

TV VCR DVD SAT

TUNER CD TAPE CDR

¬V P

◊

SMART


SMART

SOUND

ACTIVE

CONTROL

hActive control

Active control is a pro-active and automatic

system.The TV continuously measures and

corrects all incoming signals in order to

provide the best picture possible.

Press the hkey to select the Active

Control values Off or On.

Off Sharpness and Dynamic Contrast are

controlled automatically

On Sharpness, Dynamic Contrast and Noise

Reduction are controlled automatically.

Press the cursor in the up/down directions

while the selected Active Control setting

information is on top of the screen.

The Active Control menu appears.

The picture settings are being adapted

continuously and automatically.

The menu items cannot be selected.

Press the cursor in the up/down directions

again to switch off the menu.

bDual screen

&Press the bkey to switch on Dual screen.

The TV screen is divided into 2 parts:

- the left side for the normal main

picture,

- the right side for teletext broadcast by

the selected TV channel or for

NEXTVIEW/Teletext Guide.

To operate NEXTVIEW/Teletext Guide, see

p. 17, to operate teletext, see p. 22.

If Dual screen is Off, the picture, teletext or

NEXTVIEW/Teletext Guide is displayed full screen.

éPress the qkey to select a vertical

squeezed or a non vertical squeezed picture

size.

“Press + P - to run through the teletext

pages.

‘When in Teletext Dual screen, press the b

key to return to a full picture screen or

press the b key to return to a full Teletext

screen.

(When in NEXTVIEW/Teletext Guide Dual

screen, press the ækey to return to a full

picture screen or press the bkey to

return to a full NEXTVIEW/Teletext Guide

screen.

Smart Keys

To select predefined picture and sound settings.

M Smart Sound

Each time it is pressed, a different sound setting is selected, corresponding

with specific factory setting of the graphic equalizer.

aSmart Picture

Each time it is pressed, a different picture setting is selected, corresponding

with specific factory settings of Contrast, Colour, Sharpness and Dynamic

Contrast.

Personal refers to the personal preference settings of picture and sound

selected in the picture and sound menu.

Remark: the moment you are in a predefined smart sound or picture setting and

you modify a setting in the picture or sound menu, all values of the menu will

overwrite the previously made settings.

4916.2 gb 18-01-2000 16:43 Page 10

Autres manuels pour 28PW9505

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips TV

Philips

Philips Essence 5000 Series Manuel utilisateur

Philips

Philips 32PHT5678 Manuel utilisateur

Philips

Philips 55PU 6794 Series Manuel utilisateur

Philips

Philips 48PFS8209 Manuel utilisateur

Philips

Philips 42PFL7562D/10 Manuel utilisateur

Philips

Philips 20PT6245/37 Manuel utilisateur

Philips

Philips 43P 8341 Manuel utilisateur

Philips

Philips 32PFL7403D/10 Manuel utilisateur

Philips

Philips 25TR15C Manuel utilisateur

Philips

Philips 32PW8806-79R Manuel utilisateur

Philips

Philips 6501 series Manuel utilisateur

Philips

Philips 14PT2116/69 Manuel utilisateur

Philips

Philips 42PFL3522D/12 Manuel utilisateur

Philips

Philips 19-CTV W-DBX STEREO-REM... Manuel utilisateur

Philips

Philips Matchline 34PW9815 Manuel utilisateur

Philips

Philips 24PT633R Manuel utilisateur

Philips

Philips 29PT6807 Manuel utilisateur

Philips

Philips 55PUS9109 Manuel utilisateur

Philips

Philips 5583 Series Manuel utilisateur

Philips

Philips 37HF7005/93 Manuel utilisateur

Philips

Philips 46PFL8606T/12 Manuel utilisateur

Philips

Philips PFL30x7H Series Manuel utilisateur

Philips

Philips 50PUS7506 Manuel utilisateur

Philips

Philips Momentum 558M1 Manuel utilisateur

Manuels TV populaires d'autres marques

Toshiba

Toshiba 27A10 Manuel utilisateur

Hitachi

Hitachi 32FX48B Manuel utilisateur

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Manuel utilisateur

Changhong Electric

Changhong Electric uhd55b6000is Manuel utilisateur

Panasonic

Panasonic Genus TX-G10 Manuel utilisateur

Toshiba

Toshiba 19A20 Manuel utilisateur

Sony

Sony XBR-100Z9D Manuel utilisateur

Samsung

Samsung 55S9 B Series Manuel utilisateur

Sharp

Sharp LC-40FI5012E Manuel utilisateur

Loewe

Loewe Table Stand Reference 55 Manuel utilisateur

Sylvania

Sylvania 6427FB Manuel utilisateur

Sanyo

Sanyo CE19LD90N-B Manuel utilisateur

North State

North State TV2GO Manuel utilisateur

RCA

RCA RTU7877 Manuel utilisateur

Sharp

Sharp 21K-FG1RU Manuel utilisateur

Sony

Sony Esprit TAV-L1 Manuel utilisateur

Grundig

Grundig 43 VLE 4820 Manuel utilisateur

Samsung

Samsung LN26C350D1D Manuel utilisateur
