Philips 28PW6332 - annexe 1 Manuel utilisateur

Table of contents

Introduction

Installation

TV set and remote control......................................................................................2

Switching on.................................................................................................................2

The keys on the remote control.............................................................................3

The keys on theTV set .............................................................................................3

Menu installation:selecting menu language and country...................................4

Tuning-inTV channels:automatic store.................................................................5

Sort................................................................................................................................5

Manual store................................................................................................................6

Favourite programmes and naming programmes................................................7

Operation

Operating the remote control ................................................................................8

Other functions...........................................................................................................9

16/9 Function............................................................................................................10

Using the menus:adjusting the picture...............................................................12

Adjusting the sound,Dolby Surround.................................................................13

Child lock,storing adjustments.............................................................................14

Programming,message............................................................................................15

Teletext.......................................................................................................................16

Peripherals

Connecting peripheral equipment........................................................................18

Tips..............................................................................................................................21

Glossary.....................................................................................................................22

Index...........................................................................................................................22

Thank you for purchasing this television set.Every effort has been made

to simplify the operation and tuning of the receiver by the use of menus.

These menus are displayed on screen when requested giving easy access to

the various adjustments.

This handbook has been designed to help you install and operate yourTV set.

We would strongly advice you read it thoroughly.

Installation

Connecting the aerial and the mains

Insert the aerial plug into the socket Mat the rear

of the set.

Insert the mains plug into a wall socket (220-240V/50 Hz).

êSurround loudspeakers

Connect the 2 Surround loudspeakers as illustrated

opposite.The loudspeakers should be located at

the rear or on either side of the listener (always

connect 2 loudspeakers).The positive wire (the one

with the black line) to the red loudspeaker connection,

the negative wire to the black loudspeaker connection.

®Remote control

Insert the 2 LR03-type batteries (supplied) making sure

they are the right way around.

In an effort to help protect the environment the batteries

supplied with this television do not contain mercury or nickel

cadmium.If a means of recycling batteries is available,please

use this (if in doubt,contact your dealer).

†Switching on

Press the on/off key to switch on the television.

A green indicator comes on and the screen lights up.

If the indicator is red,press the key on

the remote control.

When the remote control is being used the indicator flashes

orange.

æInstalling theTV set

Place yourTV set on a solid,stable surface (please

ensure this is strong enough).Do not place anything

on theTV set which might damage it (plants or heat

sources).For ventilation allow a space of at least 5cm

around theTV set.

Remote control keys

The keys on theTV set

EXT sockets selection (p.9)

Screen information (p.9)

INSTALLATIONMenu(p . 4)

Press the and keys

Personal Preferences (p.9)

sound mode (p. 9)

16/9 formats (p.10)

Video recorder k ey (p. 9)

Menu (p . 12)

(red) picture menu

(green) sound menu

(yellow) features menu

(blue) exit from menu

use of menus

Switch teletext on/off (p . 16)

"Smart controls k eys" (p . 8)

picture pre-setting

sound pre-setting

Teletext functions (p . 16)

enlarging a page

temporary interruption

hold selected sub-page

reveal

overlay text on picture

time display or direct access

to a sub-page.

(p. 8)

programme selection

volume

/ numerical keys

mute key

previous programme

Standby (p . 8)

Programmable k eys (p . 8)

The television has 3 keys:MENU,-and +.These keys are located on the top,front or

side of the set,(if on the front or side of the set they may be concealed by a flap).

The MENU key is used to select the function to be altered.The -and +keys are used

select programmes or modify the selected MENU item.

Installation Menu

This Menu enables you to tune in the channels on theTV set.

Selecting the menu language and the country

From the INSTALLATION menu:

æSelect the LANGUAGE adjustment using the keys.

ÂSelect the language you wish to use by means of the or keys.

The text for all the menus will appear in the language you have chosen.

êSelect the COUNTRY adjustment using the keys

®Select your country using the or keys (GB for Great Britain).

Warning: It is essential for correct channel tuning that these two adjustments are set

correctly.

Open the

cover

Press the and keys at

the same time. The INSTALLATION menu

appears on the screen.

To call up the INSTALLATION menu:

To use the menus:

These 4 keys allow you to move around in the menus,make adjustments

and access the sub-menus.

To exit from the menus

Press the blue key.

If the menu display is not stable,press the key.

Tuning-in theTV channels

There are two ways the television can be tuned in :automatic store or

manual store (tuning - in channel by channel).

Automatic store

From the INSTALLATION menu ( and keys)

(after ensuring LANGUAGE and COUNTRY have been set correctly)

æSelect AUTO STORE ( keys) and press .

The AUTO STORE menu appears.Searching begins.

TheTV set searches through the complete frequency range in your local

region and stores all the programmes it finds.The search operation takes

a few minutes.When the search is complete,the INSTALLATION menu

reappears automatically.

ThisTV set is equipped with an EasyTune system which automatically

sorts the programmes by name.

ÂIf the transmitter emits the correct signal,the programmes are correctly

numbered.Go to page 7.

In certain cases, the system may ask you to indicate your local region using keys

to .

êIf no signal is emitted,the programmes will be numbered in descending

order starting from 99,98,97,..Should this occur,the SORT menu should

be used to re-number the programmes.

If no picture is found,refer to the chapter entitled "Tips" (page 21).

Sort

This menu allows you to re-number the programmes in the order you prefer.

æSelect SORT ( keys) and press .

The SORT menu appears.The menu provides a list of all the programme

numbers with their names (where provided),or frequencies or channels.

ÂUsing the keys,select the programme to be re-numbered.

If,for example,you want to re-number programme 96 as 2:Select 96

using keys (or type ).

The number chosen (96) will appear in blue in the list.

êPress the key to enter.A yellow rectangle appears on the name of the

programme (or on its frequency or channel).

®Enter the new number using keys to .

In our example,type .Programme 02 appears.The number (02)

appears in blue in the list.

†Press the key to enter ( can be used to cancel).

The exchange of numbers is now complete.In our example,programme

No.96 has become No.02 (and programme No.02 has become No.96).

Repeat this operation for other programmes you wish to re-number

To exit from the menu

Press the blue key.

Manual store

This menu allows you to store each programme manually.

From the INSTALLATION menu ( and keys).

æSelect MANUAL STORE ( keys) and press .

The MANUAL STORE menu appears.

ÂSelect CHANNEL/FREQUENCY ( ).For certain countries this

adjustment is not available.

Use the keys to select tuning mode.

FREQ.

(frequency search) or

CHAN.C

and

CHAN.S

(channel search if you

know the channel numbers on which the programmes are broadcast).

êSelect SYSTEM ( ).

Use to select EUROPE,EUR. W,EUR. E,UK or FRANCE

(according to model).

Selecting EUROPE guarantees automatic detection,with the exception

of transmissions from France (standard LL':select FRANCE) or in

certain cases of poor reception where EUR. W (BG),EUR. E (DK) or

UK (I) should be selected.

For more information see glossary on p.22.

®Select SEARCH ( ) and press .

The search begins.As soon as a programme is found,the search will stop.

Go to section Ú.

If you know the frequency (or the channel) of the programme you

wish to receive,you can enter its number in directly using keys

numbered to .

If no picture is found,refer to "Tips" chapter (page 21).

If you want to rerun the search,press again.

†Select FINE TUNE ( ).If reception is not satisfactory,you can use

the fine tuning function.

Hold down the keys to adjust.

ÚSelect PRG NUMBER ( )

Use the keys or the to keys to enter the required number.

ºSelect STORE ( ) and press .

The OK message appears.The programme and its name (if it has one)

are stored.

repeat ®,Ú,ºfor each programme to be stored.

To exit from the menu:

Press the blue key.

Favourite Programmes

This menu allows you to choose which programmes can be accessed

using the key on the remote control.

From the INSTALLATION menu:

æSelect FAVOURITE PRG ( keys) and press

The

FAVOURITE PRG

menu appears.All programmes found during

the search are automatically included in the menu and appear in green.

ÂUse the keys to select any programme you wish to remove

from the list of favourites.

êPress to de-activate (or activate) a programme.

The de-activated programmes appear in white,the activated

programmes appear in green.

Only the programmes and EXT sockets that are displayed in green in

this menu can be accessed using the key.

Warning: If all programmes are de-activated, the key will cease to

function.

To exit from the menu:

Press the blue key.

Programme names

This menu allows you to name and modify names for programmes and

EXT sockets.

From the INSTALLATION menu:

æSelect GIVE NAMES ( keys) and press .

The GIVE NAMES menu appears with the list of programmes found

automatically during installation.

Certain programmes may not be named (the signal needed for

identification is not always transmitted) or may be inappropriately

named (only 5 characters are displayed).

ÂUse the key to select the required programme.

êUse the keys to move to the area in which the programme name

appears (up to 5 characters).

A yellow rectangle appears in the chosen area.

®Use the keys to select or modify the character.

†Use the keys to move around in the next programme.

To exit from the INSTALLATION menu:

Press the blue key twice.

These allow direct access to any adjustment made in

the PICTURE and SOUND menus (see p.12)

To program the keys:

If,for example,you wished to gain direct access to the

BRIGHTNESS adjustment.Display the PICTURE menu

(red key) and select BRIGHTNESS ( ).Use

keys and to adjust,rather than the keys.

The keys are now programmed.Exit from the menu

(blue key).Press and again.This will give you

direct access to the brightness adjustment.Repeat for

any other adjustment you may wish to make.

This operation may be repeated for any other

adjustment you may wish to make (e.g.SOUND MODE:

refer to page 13).

Programmable

keys

"Smar t

Controls" k eys To access the presets of theTV set.

Smart Picture Controls:Press the key to obtain

the following settings:RICH,SOFT,NATURAL and

return to MANUAL.

Smart Sound Controls:Press the key to obtain

the following settings:CONCERT,CLASSIC,JAZZ,

POP,STADIUM and return to MANUAL.

The values corresponding to these presets are given in the

PICTURE and SOUND menus (see p.12).

TheTV set is switched off and the red indicator

lights up.To switch theTV set on again,press

or keys to .

For further information,see "Tips" (p.21).

Using the remote control

Press: Result:

Standby

SelectingTV

programmes Move up or down a programme.

N.B.:Only programmes activated in the FAVOURITE

PRGS menu can be accessed (see p.7).

Choose a programme.

For a 2 figure number,the second figure must be

entered before the dash disappears.

Numerical keys

Return to the last programme watched.

programme

Volume The volume is adjusted.

Mute key Disables or enables the sound.

Other functions

Press: Result:

Press the key and one of the following keys

simultaneously.

vrecord,

srewind,

rfast forward,

ustop,

qplay,

Gprogramming (on certain models),

31- or 2- digit programmes,

programme selection,

to enter a programme number,

standby

These keys function with video recorders in our range and with

all models which use the RC5 signalling standard.

Video recorder

keys

Screen

information

To continuous display of the programme number and

the information line on or off each time the

programme is changed,press this button for 3 seconds.

Pressing briefly displays the number, name,16:9 mode

sound mode and information line for a few seconds.

The information line displays the title of the programme at

the bottom of the screen (except in mode ZOOM 14:9 and

ZOOM 16:9).This line is only displayed for those

programmes which transmit the signal by teletext.

Sound mode Pressing this key allows you to switch from STEREO

to MONO sound (in case of stereo transmission),

or to choose between language for language g

(in case of bilingual transmissions).

ForTV sets fitted with NICAM reception,the

DIGITAL message appears when a NICAM broadcast

is received.The key allows you to switch from

DIGITAL STEREO to MONO or,for bilingual

transmissions,to choose between DIGITAL f,

DIGITAL gor MONO.

Pressing this key selects E1 (EXT1),E2 (EXT2) and

E2 Y/C in turn (see p.18).

Select EXT

sockets

Restores the settings made in the FEATURES menu

(see p.14).Keep the button pressed during 3 seconds

if you want to reset the adjustments per programme.

Personal

Preferences

The time is displayed in the top right-hand corner

of the screen.

This function only exists if the programme broadcasts teletext.

Time display

16/9 Function

The pictures you receive may be transmitted in

16:9

format (wide

screen) or

4:3

format (conventional screen).

4:3

pictures sometimes have

a black band at the top and bottom of the screen (letterbox format).

This function allows you to optimise the picture display on screen.

Automatic switching

ThisTV set is also equipped with automatic switching which will select

the correct-screen format,provided the specific signals are transmitted

with the programmes.

This automatic format can olso be modified manually.

4 : 3

4/3 Picture

4/3 Picture Result

ZOOM 14 : 9

4 : 3

ZOOM 14:9 Mode

The picture is enlarged to 14:9 format, a thin black band remains on

both sides of the picture.The keys allow you to increase or

decrease the section at the bottom of the picture where sub-titles

may be displayed.

Using the different screen formats

Press the keys to select the different modes:

4:3,ZOOM 14:9,ZOOM 16:9,SUBTITLE ZOOM,SUPER ZOOM and

WIDE SCREEN.

These settings may also be accessed using the key under the flap on your

remote-control.

4:3 Mode

The picture is reproduced in 4:3 format and a black band is displayed

on either side of the picture.The picture may be progressively

enlarged using the keys.

Autres manuels pour 28PW6332 - annexe 1

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips TV

Philips

Philips PT9000/12 Manuel utilisateur

Philips

Philips 32PFL7613D/12 Manuel utilisateur

Philips

Philips 20PT155A/07 Manuel du propriétaire

Philips

Philips 8008 Series Manuel utilisateur

Philips

Philips 5504 Series Manuel utilisateur

Philips

Philips 32PF9968/10 Manuel utilisateur

Philips

Philips Magnavox 14MS2331 Manuel utilisateur

Philips

Philips 246E8 Manuel utilisateur

Philips

Philips 8508 Series Manuel utilisateur

Philips

Philips 32PM8822 Manuel utilisateur

Philips

Philips VES2.2E LA Manuel utilisateur

Philips

Philips 42PFL3605/12 Manuel utilisateur

Philips

Philips 29PT6446 Manuel utilisateur

Philips

Philips 36PW9525 - annexe 1 Manuel utilisateur

Philips

Philips 25PT5124 Manuel utilisateur

Philips

Philips PFL4308 Manuel utilisateur

Philips

Philips 19PS 45S Manuel

Philips

Philips 32PFL5609/98 Manuel utilisateur

Philips

Philips 25PT4823/11 Manuel utilisateur

Philips

Philips 21PT3626 Manuel utilisateur

Philips

Philips 24HFL3009D/12 Manuel utilisateur

Philips

Philips 33PT912B Manuel utilisateur

Philips

Philips 19PFL5602D/05 Manuel utilisateur

Philips

Philips E Series Manuel utilisateur

Manuels TV populaires d'autres marques

Toshiba

Toshiba 27A10 Manuel utilisateur

Hitachi

Hitachi 32FX48B Manuel utilisateur

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Manuel utilisateur

Changhong Electric

Changhong Electric uhd55b6000is Manuel utilisateur

Panasonic

Panasonic Genus TX-G10 Manuel utilisateur

Toshiba

Toshiba 19A20 Manuel utilisateur

Sony

Sony XBR-100Z9D Manuel utilisateur

Samsung

Samsung 55S9 B Series Manuel utilisateur

Sharp

Sharp LC-40FI5012E Manuel utilisateur

Loewe

Loewe Table Stand Reference 55 Manuel utilisateur

Sylvania

Sylvania 6427FB Manuel utilisateur

Sanyo

Sanyo CE19LD90N-B Manuel utilisateur

North State

North State TV2GO Manuel utilisateur

RCA

RCA RTU7877 Manuel utilisateur

Sharp

Sharp 21K-FG1RU Manuel utilisateur

Sony

Sony Esprit TAV-L1 Manuel utilisateur

Grundig

Grundig 43 VLE 4820 Manuel utilisateur

Samsung

Samsung LN26C350D1D Manuel utilisateur
