Philips SWW1800/12 Manuel utilisateur

www.philips.com/welcome

SWW1800/12

EN User manual

English

Contents

1 Important 4

Safety 4

2 Your SWW1800 7

What is in the box 7

Overview 7

3 Installation 9

Connect the transmitter to your HD

devices 9

Connect the receiver to the HDTV set 9

Install remote control batteries 10

4 Activate the SWW1800 function

and set up the link 11

Turn on the power of your HDTV 11

LED indicator status of the receiver 11

Activate the wireless link 11

Enter the standby mode 13

5 Position the transmitter and

receiver 15

6 Wallmount the receiver 16

7 Technical data 17

Supported resolution 17

Product specications 17

8 Troubleshooting 19

9 Glossary 21

gDo not block any ventilation openings.

Install in accordance with the

manufacturer’s instructions.

hDo not install near any heat sources

such as radiators, heat registers, stoves,

or other apparatus (including ampliers)

that produce heat.

iProtect the power cord from being

walked on or pinched, particularly at

plugs, convenience receptacles, and

the point where they exit from the

apparatus.

jOnly use attachments/accessories

specied by the manufacturer.

kUse only with the cart, stand, tripod,

bracket, or table specied by the

manufacturer or sold with the apparatus.

When a cart is used, use caution when

moving the cart/apparatus combination

to avoid injury from tip-over.

lUnplug this apparatus during lightning

storms or when unused for long periods

of time.

m Refer all servicing to qualied service

personnel. Servicing is required when

the apparatus has been damaged in any

way, such as power-supply cord or plug

is damaged, liquid has been spilled or

objects have fallen into the apparatus,

the apparatus has been exposed to rain

or moisture, does not operate normally,

or has been dropped.

nBattery usage CAUTION – To prevent

battery leakage which may result in

bodily injury, property damage, or

damage to the unit:

Install all batteries correctly, + and -• as marked on the unit.

1 Important

Safety

Know these safety symbols

This ‘bolt of lightning’ indicates uninsulated

material within your unit may cause an

electrical shock. For the safety of everyone

in your household, please do not remove

product covering.

The ‘exclamation point’ calls attention to

features for which you should read the

enclosed literature closely to prevent

operating and maintenance problems.

WARNING: To reduce the risk of re or

electric shock, this apparatus should not be

exposed to rain or moisture and objects lled

with liquids, such as vases, should not be

placed on this apparatus.

CAUTION: To prevent electric shock, match

wide blade of plug to wide slot, fully insert.

Important Safety Instructions

aRead these instructions.

bKeep these instructions.

cHeed all warnings.

dFollow all instructions.

eDo not use this apparatus near water.

fClean only with dry cloth.

Philips is committed to develop, produce and

market products that cause no adverse health

effects. Philips conrms that if its products are

handled properly for their intended use, they

are safe to use according to scientic evidence

available today.

Philips plays an active role in the development

of international EMF and safety standards,

enabling Philips to anticipate further

developments in standardisation for early

integration in its products.

Disposal of your old product and

batteries

Your product is designed and manufactured

with high quality materials and components,

which can be recycled and reused.

When this crossed-out wheeled bin symbol

is attached to a product it means that the

product is covered by the European Directive

2002/96/EC. Please inform yourself about the

local separate collection system for electrical

and electronic products.

Please act according to your local rules and

do not dispose of your old products with your

normal household waste.

Correct disposal of your old product helps to

prevent potential negative consequences for

the environment and human health.

Your product contains batteries covered by

the European Directive 2006/66/EC, which

cannot be disposed with normal household

waste.

Please inform yourself about the local rules

on separate collection of batteries because

correct disposal helps to prevent negative

Do not mix batteries (old and new• or carbon and alkaline, etc.).

Remove batteries when the unit is• not used for a long time.

oApparatus shall not be exposed to

dripping or splashing.

pDo not place any sources of danger on

the apparatus (e.g. liquid lled objects,

lighted candles).

qThis product may contain lead and

mercury. Disposal of these materials

may be regulated due to environmental

considerations. For disposal or recycling

information, please contact your local

authorities or the Electronic Industries

Alliance: www.eiae.org.

Warning

Use only the provided power supply.•

Manufacturer: SINO-AMERICAN

Model: SA115B-05G-A

Declaration of conformity

Hereby Philips Consumer Lifestyle, P&A,

declares that the SWW1800 is in compliance

with the essential requirements and other

relevant provisions of Directive 1999/5/EC.

You can nd the Declaration of Conformity

on www.p4c.philips.com.

Compliance with EMF

Koninklijke Philips Electronics N.V.

manufactures and sells many products

targeted at consumers, which, like any

electronic apparatus, in general have the

ability to emit and receive electromagnetic

signals.

One of Philips’ leading Business Principles is to

take all necessary health and safety measures

for our products, to comply with all applicable

legal requirements and to stay well within

the EMF standards applicable at the time of

producing the products.

English

consequences for the environmental and

human health.

Environmental information

All unnecessary packaging has been omitted.

We have tried to make the packaging easy to

separate into three materials: cardboard (box),

polystyrene foam (buffer) and polyethylene

(bags, protective foam sheet.)

Your system consists of materials which can

be recycled and reused if disassembled by

a specialized company. Please observe the

local regulations regarding the disposal of

packaging materials, exhausted batteries and

old equipment.

Your product contains batteries covered by

the European Directive 2006/66/EC, which

cannot be disposed of with normal household

waste.

Please inform yourself about the local rules on

separate collection of batteries. The correct

disposal of batteries helps prevent potentially

negative consequences on the environment

and human health.

Battery disposal information

Batteries contain substances that may pollute

the environment. Always hand the appliance

in at an ofcial collection point to remove

any built-in batteries before you discard the

appliance. All batteries must be disposed of at

an ofcial collection point.

HDMI, and HDMI logo and High-Denition

Multimedia Interface are trademarks or

registered trademarks of HDMI licensing LLC.

HDMI cable

Power adaptor x 2

Quick start guide

User manual

Warranty

Overview

SWW1800 Transmitter

Quick Installation Guide

2 Your SWW1800

Congratulations on your purchase and welcome

to Philips!

To fully benet from the support that Philips

offers, register your product at www.philips.

com/welcome.

What is in the box

Note

Make sure you have all these items in the•box. Contact your dealer for any missing or

damaged items.

Transmitter

Receiver

Remote control

Transmitter

SOURCE1 SOURCE2 SOURCE3 SOURCE4

1234

Receiver

English

Top view

Rear view

1HDMI OUT connector

2Power IN connector

The SWW1800 gives you a total wireless

solution to place your HDTV set or projector

anywhere you want.With the built-in omni-

directional antenna, the transmitter can transmit

an uncompressed video content over 20m/66ft

inside the whole room area without latency.The

receiver can receive signals for viewing on your

HDTV. All you need to do is to:

Connect the transmitter to your HD• devices. Examples of HD devices are

satellite, cable, ADSL set-top box, blu-ray,

DVD player and game console.

Note

The transmitter can support two devices•running on HDMI cable and another two

running on YPbPr component video signals at

the same time.

Connect the receiver to your HDTV set.•

Control the transmitter with the remote• control.

DC IN

HDMI OUT

Front view

Power indicator

1/2/3/4 Source indicators

Top view

Power button with LED indicators

1/2/3/4 Source selection buttons

Rear view

1HDMI IN

2Component YPbPr and L/R Audio IN

3Power IN connector

SWW1800 Receiver

Front view

1Power indicator

Transmitter

1234

4321

POWER

SOURCE 1 SOURCE 2

SOURCE 3

SOURCE 4 POWER

YPb Pr

Receiver

Note

AUDIO L connection cable is often indicated•by a white color on the connector and AUDIO

R connection cable is indicated by a red color

on the connector.

3Connect the power adaptor to the

transmitter

Connect one end of the power adapter• (included) to the DC IN connector of

the SWW1800 transmitter. Connect

the other end of the power adaptor to a

mains socket.

The power LED indicator lights up in»

solid blue.

The HDMI devices and analog devices with the

component and stereo RCA start connecting.

Connect the receiver to the

HDTV set

1Connect the receiver with an additional

HDMI cable (not included):

Connect one end of the HDMI cable• to the receiver.

Connect the other end to the HDMI• OUT connector of your HDTV.

2Connect the power adaptor to the

receiver:

Connect one end of the power• adapter (included) to the DC IN

connector of the receiver.

Connect the other end of the power• adaptor to a power socket.

DC IN 5V

HDMI OUT

3 Installation

Connect the transmitter to

your HD devices

You can connect 4 video sources to the

transmitter at the same time: two with

the HDMI connection and two with the

component connection, but only one source

can be selected and played.

1Connect video source to the transmitter

using the HDMI cable.

Connect one end of the HDMI cable• (included) to the HDMI connector of the

transmitter.

2Connect the video source to the

transmitter using the component cables

Connect one end of the RCA (green,• blue and red) cables to the Y/Pb/Pr IN

connectors of the transmitter. Connect

the other end of the RCA cables to the

corresponding Y/Pb/Pr OUT connectors

of your HD devices.

Connect one end of the set of audio• cables to the AUDIO L/R IN connectors

of the transmitter. Connect the other end

to the corresponding AUDIO L/R OUT

connectors of your HD devices.

DC 5V

English

Install remote control

batteries

Caution

Risk of explosion! Keep batteries away from•

heat, sunshine or re. Never discard batteries

in re.

Risk of decreased battery life! Never mix

•different brands or types of batteries.

Risk of product damage! When the remote

•control is not used for long periods, remove

the batteries.

1Open the battery compartment.

2Insert two AAA batteries with correct

polarity (+/-) as indicated.

3Close the battery compartment.

Autres manuels pour SWW1800/12

Table des matières

Autres manuels Philips Accessoires TV

Philips

Philips SWV4000W Manuel utilisateur

Philips

Philips Flavors 22FDF1013 Manuel utilisateur

Philips

Philips SWV3561 Manuel utilisateur

Philips

Philips SWV2083W Manuel utilisateur

Philips

Philips SWS2827T Manuel utilisateur

Philips

Philips SVC2545W Manuel utilisateur

Philips

Philips SVC3500W Manuel utilisateur

Philips

Philips SCANCARD II Manuel utilisateur

Philips

Philips Flavors 22FDF6023 Manuel utilisateur

Philips

Philips 22PP1019 Manuel utilisateur

Philips

Philips Flavors 22FDF9023 Manuel utilisateur

Philips

Philips SWV2030 Manuel utilisateur

Philips

Philips SBCVL1200/05 Manuel utilisateur

Philips

Philips Flavors 22FDF6013 Manuel utilisateur

Philips

Philips Flavors 42FDF6023 Manuel utilisateur

Philips

Philips SWW1800/12 Manuel utilisateur

Philips

Philips SWW1800/27 Manuel utilisateur

Philips

Philips 22PP2152 Manuel utilisateur

Philips

Philips SBCLM1000/05 Manuel utilisateur

Philips

Philips SWV2142W Manuel utilisateur

Philips

Philips SVC2543W Manuel utilisateur

Philips

Philips SWV2020NB Manuel utilisateur

Philips

Philips SWV2198W Manuel utilisateur

Philips

Philips Flavors 22FDF1023 Manuel utilisateur

Manuels Accessoires TV populaires d'autres marques

pass & seymour

pass & seymour GFCI Manuel utilisateur

Skyvue

Skyvue SECURITY ALARM DEVICE Manuel utilisateur

Niles

Niles C5-RFWM Manuel utilisateur

Sony

Sony CRU-52X1 Manuel utilisateur

Sony

Sony BRAVIA KDL-46Z4100/S Mode d’emploi

BVE

BVE MATRIX 7xe Manuel utilisateur

Epson

Epson Moverio BT-100 Manuel utilisateur

Alcatel

Alcatel onetouch v100 Manuel utilisateur

Flow

Flow 836 ONT Manuel utilisateur

AIRIS

AIRIS G819 Manuel utilisateur

Loewe

Loewe Digital Recorder + Manuel utilisateur

Sceptre

Sceptre Stello Manuel utilisateur

Goodmans

Goodmans GD11FVRSD32 Manuel utilisateur

Serene

Serene TVDirect TV-95 Manuel utilisateur

TRUlink

TRUlink 89000 Manuel utilisateur

Panasonic

Panasonic DigiCard Manuel utilisateur

Alpine communications

Alpine communications Roku Device Manuel utilisateur

LEGRAND

LEGRAND SANUS BSA-IWP801 Manuel utilisateur
