Philips MPX2 Manuel utilisateur

Instructions for Use

Data Export Test Tool

MP2/X2, MP5/20/30/40/50/60/70/80/90 & MX800

Part Number 453564254321

Printed in Germany 01/11

*453564254321*

1Table of Contents

1About this Guide 5

About the Data Export Test Tool 5

Manufacturer's Information 6

Trademark Information 6

2DETT - Instructions for Use 7

Installation of DETT 7

Un-Installation of DETT 7

Deletion of Log Files 7

System Requirements for DETT 8

How to start DETT 8

The Menu 9

System List Window 14

System Detail Window 16

Debug Information Window 21

Log Files 21

DETT overview example 22

How to connect a PC with DETT to an IntelliVue 23

Index 25

1About this Guide

These Instructions for Use are for technicians and biomedical engineers using the Data Export Test

Tool (DETT) with the Philips IntelliVue MP2 / X2 / MP5 / MP20 / MP30 / MP40 / MP50 / MP60

/ MP70 / MP80 / MP90 /MX800 (M8102A / M3002A / M8105A / M8001A / M8002A / M8003A

/ M8004A / M8005A / M8007A / M8008A / M8010A / 865240) patient monitors, hereafter referred

to as the patient monitor. They describe the functionality of the Data Export Test Tool.

IFU (Instructions for Use) is used as an abbreviation and will refer to this document.

WARNING

This Data Export Test Tool is not intended for clinical use.

In this guide

• A warning alerts you to a potential serious outcome, adverse event or safety hazard. Failure to

observe a warning may result in death or serious injury to the user or patient.

• A caution alerts you where special care is necessary for the safe and effective use of the product.

Failure to observe a caution may result in minor or moderate personal injury or damage to the

product or other property, and possibly in a remote risk of more serious injury.

About the Data Export Test Tool

DETT is used to test the communication interface protocol, which transfers data from the Philips

IntelliVue Patient Monitor via the Local Area Network (LAN) Interface or Serial Interface (MIB/

RS232) to an external Computer.

The IntelliVue Data Export Interface cannot be accessed via the Local Area Network when the

IntelliVue monitor is connected to the Philips LAN, e.g. to an Information Center (central station).

Communication via the MIB/RS232 Interface is always possible.

Please refer to the latest version of the Data Export Interface Programming Guide for further details

about the IntelliVue Data export interface specifications.

1 About this Guide

CAUTION

The computer client (the interfacing system) and/or the user of the communication system must

comply with applicable data privacy regulations.

Manufacturer's Information

The information contained in this document is subject to change without notice. Philips makes no

warranty of any kind with regard to this material, including, but not limited to, the implied warranties

of merchantability and fitness for a particular purpose.

Philips shall not be liable for errors contained herein or for incidental or consequential damages in

connection with the furnishing, performance or use of this material.

Trademark Information

Microsoft ® is a U.S. registered trademark of Microsoft Corp. Windows XP®, Windows Vista® and

Windows 7® are U.S. registered trademarks of Microsoft Corp.

2DETT - Instructions for Use

Installation of DETT

Unzip the downloaded version to the desired installation directory. The following files are unzipped to

the installation directory:

\DETT

BinaryStreamer.dll

configuration.xml

DataExportTestTool.chm

DETT.exe

MdilDataTypes.dll

Tnlscat.x

PluginInterfaces.dll

\DETT\Plugins

ConnectionStatePlugin.dll

DataStorePlugin.dll

DiscoverPlugin.dll

DiscoverSerialPlugin.dll

Un-Installation of DETT

Delete the DETT installation directory including DETT.exe.

Log files deletion: Delete DETT log files either in the default program directory or the selected log

files path (refer to "File -> Configuration").

2 DETT - Instructions for Use

Deletion of Log Files

DETT generates log files when connected to an IntelliVue monitor.

Logfiles are marked as "*.txt" - Files with DevIFTest as prefix, e.g.

DevIfTest_20100222_103626_COM1_115200.txt

To delete the log files, manually delete the files that are either stored in the default program directory

or the selected log files path (refer to "File -> Configuration").

As the log files can take up a considerable amount of disk space we recommend that you delete the log

files when they are no longer needed.

System Requirements for DETT

To use the DETT, your PC must fulfill these minimum requirements:

• Processor: 1 GHz or better is required

• Installed Memory: 512 MB RAM (required), 1GB (recommended).

• Free hard disk space:

About 2 MB for the zip file and less than 10 MB for the extracted tool excl. stored log files.

NOTE

Future releases of the DETT may require more hard disk space.

• Network Interface Card with 10BaseT half-duplex. It is recommended that you install the latest

driver available for your Network Card.

• RS-232 interface to communicate with the IV MIB/RS-232 interface or support of an USB/ RS-

232 converter

• Super VGA monitor with at least 800 x 600 pixels screen resolution (required), 1024 x 768 or

better (recommended).

• Operating System: Windows XP (32 bit version), Windows Vista (32-bit version) or Windows 7

(32- and 64-bit version).

Other compatible operating systems have not been tested.

.NET Framework 3.5 is required

NOTE

Windows Vista and Windows 7 should use 96 DPI (100%) as screen resolution to avoid DETT menu

text to be shortened or compressed.

2 DETT - Instructions for Use

How to start DETT

Double click on the "DETT.exe" file stored in the DETT installation directory to start the application.

Windows system admin rights are required.

After starting the application, the main window is displayed. No system data is displayed. The

application window consists of these main areas:

1 - Menu

2 - System List Window

3 - System Details Window

4 - Debug Information Window

5 - Status Strip

6 - Frame Border, which can be dragged to change split screen size

Refer to chapter "DETT overview example" for an example of how DETT displays connected patient

monitor devices.

2 DETT - Instructions for Use

The Menu

File -> Configuration

In the "File" pull down menu select "Configuration" to import a new NLS text catalog file, change the

default path for the log files or change the baud rate of the COM interface.

When selecting "Change path" the log file path can be adapted to any PC or network directory. The

default path for the log files is given by the installation path of the DETT.
