Quick start guide

Read Me First!

ENG

Wireless Music Center + Station

WACS57

Set up Wi-Fi connection between Center and Station

Connect/Setup

Before starting the Wi-Fi connection, check your Center and Station are away

from the source of interference, for example: turn off plasma TVs, microwave

ovens, DECT phones, bluetooth devices, cordless phones and other Wi-Fi

products.

The first time you set up the Wi-Fi connection, place

WAC5 Center and WAS700 Station side by side

on a flat and firm surface.

Connect WACS57 to power supply, first the Center and then the

Station

Center/Station: • The screen lights up. Auto installation/connection

starts

•You will enter HD (Harddisk) mode when the

installation/connection is finished

Center

Station AC

HD mode (Harddisk)

Relocate Center and Station as desired: plug and stream*

•Simply unplug your Center or Station and power them up in different

rooms.

•You will be able to stream the harddisk music between Center and

Station

IMPORTANT!

•Avoid thick walls. Separating your Center and Station by 2 or more walls

may cause poor streaming connection.

•For better Wi-Fi reception, you can turn the Wi-Fi antenna, or adjust the

location of your Center and Station.

:indicates maximum reception; : indicates minimum reception

•For wall mounting, please refer to the User Manual, Appendix: How

to mount your Station onto walls. You may need assistance from

the qualified service personnel.

* Streaming is the process describing data is pulled between places, which

can be multiple places.

Connect Center to an audio system

Yo u can easily connect WAC5 Center to your existing home audio systems, such

as audio/video receivers, home theatre systems, mini/micro systems, multi-media

speaker boxes (with built-in amplifier) and audio amplifiers.

On Center:

Insert the red plug of the red/white audio cables (supplied)

to the red socket LINE OUT R and the white plug to the

white socket LINE OUT L

IMPORTANT!

•Never make or change connections with the power supply switched on.

Tips:

•WAC5 Center also provides the sound output DIGITAL OUT and

OPTICAL OUT,see the Installation chapter in User Manual.

•WAS700 Station provides sound and FM radio features unavailable in

WAC5.

To listen to music playback, select AUX mode on the connected home

audio system

On the home audio system:

Connect the other end of the audio cables to the AUX IN

(or AUDIO IN) terminals, red plug to the red socket AUX IN R

and white plug to the white socket AUX IN L (for illustration only)

Wireless Music Center WAC5

What’s in the box

Wireless Music Station WAS700

User manualQuick start guide

Station’s remote control

1xCR2025 battery

1 x Ethernet cable

1 x Mounting kit

(for Station)

1 x FM wire antenna

(for Station)

PC installer Connect to your PC

•Remove the protective plastic tab from the Station’s remote control

•Insert 4 AAA batteries into Center’s remote control as shown

Center’s remote control

Station’s remote

control

Before using the remote control:

Center’s remote control

4xAAA batteries

Audio cables

(for Center)

PHILIPS CONSUMER ELECTRONICS NORTH AMERICA

P. O. Box 671539, Marietta, GA. 30006-0026

3141 075 21171

www.philips.com

ENG

Press OK to start playback

To change your playback options,

a. Press 1once or more to enter previous option lists

b. Use the navigation controls 3 4 1 2 to select

c. Press OK or 2to confirm

To stop playback, press STOP / 9

Play HD

On WAC5 Center's 80GB* hard disk, you can centrally store up to 1,500

audio CDs. On a connected Station, you can play all the music stored on the

Center.

Press STANDBY ON to switch on the Center or Station

Press SOURCE once or more to select HD source

(or press HARDDISK or Center on the remote control)

Enjoy

Use the navigation controls 3 4 1 2 to select your playback options

(Demo tracks are stored under All tracks)

* Actual free space is 69GB or less, due to the buffer partition for MP3 compression, firmware, music CD

database and demo tracks stored.

Tips:

• By default, Center’s remote control works with Center only.

To operate Station using Center’s remote control,

a. Press and hold REFRESH until the selection screen appears on the

display of Center’s remote control

b. Press the navigation controls 3 or 4and 2to select Station

• Avoid placing your Center or Station close to the plasma TV. It may

result in improper display on your Center’s remote control.

(

RW)

Build music library on Center

Ripping CDs

Insert an audio CD into Center’s CD loader, CD graphic printed side

facing up

•Reading CD appears

•List of CD tracks appears

(For CD recorded with MP3/WMA music files:

To enter a track list, press 2 on a highlighted file folder)

In the screen of track list, press RECORD

•List of track checkboxes appears

To start recording the whole CD, press RECORD

(To rip part of the CD, press OK to select/deselect the tracks to be recorded)

• CD-Rec appears. Display shows the album name of the track being

recorded (write down the album name for your convenience)

• Center will return to CD mode when ripping is finished

(All the functions are available to you at this time)

To rip another CD, repeat the Step 1-3 above

(Up to 8 CDs can be ripped consecutively)

IMPORTANT!

•It takes some time to convert the ripped tracks to MP3 files.

•If power failure occurs during the conversion, you will lose the ripped tracks not converted yet.

•To rip a disc during playback (for audio CD only), see User Manual,HD: Building music library

on Center.

•You can edit the track information using Philips Digital Media Manager (DMM).For details, see

the manual Connect to your PC.

You can store up to 1,500 audio CDs on Center’s 80GB harddisk by Ripping

CDs, Importing MP3/WMA tracks from PC or Recording from external

source

Build music library on Center

To find your ripped tracks

After MP3 conversion is completed, you can find and playback the ripped

tracks from the HD under Albums.

Select HD source

In Albums,use the navigation controls 3 4 1 2 to find the album

of recorded tracks

Importing MP3/WMA from your PC

See the manual Connect to your PC

Recording from External source

A maximum of 3-hour recording can be made from the external source (recorded tracks

under the album AUX). See User manual, HD: Build music library on Center

Use the navigation controls 3 4 1 2 to select Albums

BROADCAST

Stream between Center and Station

MUSIC FOLLOWS ME

While playing music in HD(Harddisk) mode, move the music playback with you,

from Center to Station or from Station to Center.

On the source unit (Center or Station), where the music is

playing

a. Press OK to pause playback on the selected point

b. Press MUSIC FOLLOWS ME to activate

•The icon appears

Tips:

•Check you have switched the destination unit on or to Standby mode.

•Always press MUSIC FOLLOWS ME on the source unit before pressing MUSIC

FOLLOWS ME on the destination unit.

•MUSIC FOLLOWS ME will be automatically deactivated if you do not press

MUSIC FOLLOWS ME on the destination unit within 5 minutes

•After MUSIC FOLLOWS ME is activated on destination unit, you can select

other tracks or source for playback on the source unit.

On the destination unit (Center or Station), where the music will

continue

Press MUSIC FOLLOWS ME

•Selected music continues on the destination unit

•On the source unit, the music stops.The icon disappears

With WACS57 Center and Station, you will have the freedom to enjoy

or share your favorite music around your home.

MUSIC BROADCAST

While playing music in HD(Harddisk) mode, broadcast music from Center to Station(s).

On Center

Press MUSIC BROADCAST to activate

•The icon appears on Center and Station. 5-second countdown starts

On Center and Station(s)

•Selected music starts to play simultaneously

Tips:

•Check you have switched the Station(s) on or to standby mode.

•To broadcast again

Before you press MUSIC BROADCAST,check if you need to deactivate any

earlier broadcasting. If the icon is still active in Center or Station’s display.

Press STOP/9on Center.Then, follow the above steps 1-2.

•During MUSIC BROADCAST,other functions are unavailable

•For a station to exit MUSIC BROADCAST,press STOP / 9on Station.

Insert a CD into Center’s CD loader, CD graphic printed side facing up

Use the navigation controls 3 4 1 2 to select a track or album.

To start playback, press OK

To stop playback, press STOP / 9

To remove the CD, press EJECT

Play CDs (on Center only)

For playback on the Center you can use:

• All pre-recorded audio CDs

• All finalized audio CDR and CDRW discs

• MP3 & WMA-CDs (CD-R/CD-RW with MP3/WMA files)

Note: Discs with “Digital Rights Management” cannot be played

Listen to FM Radio (on Station only)

Connect the supplied FM wire antenna to your Station

(see User manual, Installation)

Press SOURCE once or more to select Radio source on Station

(on the remote control, press TUNER/AUX once or more)

Use the navigation controls 3or 4and 2to select your desired station

a. press MENU

b. Use the navigation controls 3or 4and 2to select Autostore radio

•

Display shows: Autostore Please wait...

•

You can store up to 40 preset radio stations in the memory.

After all stations are stored, the first autostore preset station will then

automatically play

Press 1to enter the list of presets

To find out more about product features and how to activate them please

read the supplied manual:

•

User manual:for further details and also troubleshooting

•

Connect to your PC:to connect to your PC, set up networks, transfer

and manage your music collection using the Philips Digital Media

Manager (supplied)
