Philips MCM275/98 Manuel utilisateur

MCM 275

Quick Start Guide

What’s in the Box?

You should find these items upon opening the box.

MW antenna

Quick Start Guide

User Manual

USB

Remote control with

1 x CR2025 battery

Quick start guide User manual

Stand

140mm (5.51")

Mounting kit

(1x template, 2 x screws)

Prepare

Install

Enjoy

Step A

Step

FM wire antenna

MCM275 QSG_-98-Eng 2/17/2006, 16:271

Install

Mounting stand onto the set

Put MCM275 on a flat and firm surface, rear side facing up

As shown, align the stand to the slots at set’s bottom, 4FRONT facing

down

Push the stand down into the slots

PRESS

FRONT

PRESS

Rear connections

Connect the cable of the left speaker to LEFT (red and black) and the cable

of the right speaker to RIGHT (red and black)

Extend the wire antenna and fit it to FM ANTENNA

a. Assemble the loop antenna

b. Fit the plug of the loop antenna to AM ANTENNA

a. If your system is equipped with aVoltage Selector, set theVOLTAGE

SELECTOR to the local power line voltage

b. Connect the AC power cord to the wall socket

ANTENNA

Helpful hints:

- For wall mounting, please refer to the User Manual, Appendix: How to mount

your MCM275 onto Walls. You may need assistance from the qualified service

personnel.

MW loop

antenna

Speaker

(left)

Speaker

(right)

FM wire

antenna

AC power cord

MCM275 QSG_-98-Eng 2/17/2006, 16:272

Prepare

Setting the clock

Press DISPLAY/CLOCK to confirm

Enjoy

Playing discs

With this system, you can play all pre-recorded audio CDs (CDDA), all finalized audio CD-Rs

and CD-RWs, MP3/WMA-CDs (CD-Rs/CD-RWs with MP3/WMA files)

Press SOURCE once or more to select CD (or CD on the remote control)

Press CD OPEN•CLOSEçto open the CD compartment

Insert a disc with the printed side facing up. Press CD OPEN•CLOSEçagain

to close the compartment

Press ÉÅ to start playback

To stop playback, press STOPÇ

Notes for remote control:

– First, select the source you wish to

control by pressing one of the source

select keys on the remote control (DISC

orTUNER, for example).

–Then select the desired function

(2;,

for example).

IMPORTANT!

– Remove the

protective

plastic tab

before using

the remote

control

USB

In the standby mode, press and hold DISPLAY/CLOCK on the remote control

➜24 HR or 12 HR appears for the initial clock setting. To select 12-hour clock or

24-hour clock,

a. Press VOLUME +/- once or more

b. Press DISPLAY/CLOCK to confirm

➜ The hours digits start flashing

Hold down or press VOLUME +/- repeatedly to set the hours

Press DISPLAY/CLOCK to confirm

Hold down or press VOLUME +/- repeatedly to set the minutes

MCM275 QSG_-98-Eng 2/17/2006, 16:273

Tuning to radio stations

Check you have unfolded the control panel

Insert the USB device’s USB plug into the socket on the set ‘s foldable control panel

Press SOURCE once or more to select USB (or USB on the remote control)

PDCC-AL-0607

2006 CKoninklijie Philips Electronics N.V.

http://www.philips.com

Detailed playback features and additional functions are described in the accompanied

owner's manual.

Press SOURCE once or more to select TUNER (or TUNER on the remote control)

Press and hold PROGRAM until AUTO appears

➜ flashes. Available stations are programmed: FM stations followed by MW stations

Press the ALBUM/ PRESET buttons once or more until the desired preset station is

displayed

Playing a USB mass storage device

With the Hi-Fi system, you can use USB flash memory (USB 2.0 or USB1.1),

USB flash players (USB 2.0 or USB1.1), memory cards (requires an additional card reader to

work with this Hi-Fi system).

Play the USB’s audio files as you do with the albums/tracks on a CD

USB

Enjoy

Press STANDBY-ON y to switch off the set

MCM275 QSG_-98-Eng 2/17/2006, 16:284
