Philips MCM239/12 Manuel utilisateur

MCM239

Quick Start Guide

What’s in the Box?

You should find these items upon opening the box.

Prepare

Install

Enjoy

Step A

Step

CR2025

User Manual

User manual

Remote control with

1 x CR2025 battery

Stand FM wire antenna

Quick Start Guide

Quick start guide

Power adaptor

MW antenna

MCM239 QSG_-12-Eng 22/8/07, 15:251

Install

Mounting the stand onto the set

Rear connections

Connect the cable of the left speaker to LEFT (red and black) and the cable

of the right speaker to RIGHT (red and black).

Extend the wire antenna and fit it to FM ANTENNA.

Insert the MW antenna to MW ANTENNA jacks.

Connect the AC power cord to the wall socket.

Locate the bottom of the main unit and find the slot, then slide the stand

in the slot until it stops, as indicated in the figure.

Tip

– To receive optimal radio reception, put the

main unit and the antennas as far away as

possible from the power adaptor.

MCM239 QSG_-12-Eng 22/8/07, 15:252

SetupSetup

Setting the clock

In the standby mode, press and hold DISPLAY/CLOCK on the remote control.

➜24 HR or 12 HR appears for the initial clock setting. To select 12-hour clock or

24-hour clock,

1. Press VOLUME +/- once or more.

2. Press DISPLAY/CLOCK to confirm.

➜ The hours digits start flashing.

Hold down or press VOLUME +/- repeatedly to set the hours.

Press DISPLAY/CLOCK to confirm.

Hold down or press VOLUME +/- repeatedly to set the minutes.

Press DISPLAY/CLOCK to confirm.

Enjoy

Playing discs

With this system, you can play all pre-recorded audio CDs (CDDA), all finalized audio CD-Rs

and CD-RWs, MP3/WMA-CDs (CD-Rs/CD-RWs with MP3/WMA files)

Press SOURCE once or more to select CD (or CD on the remote control).

Press DOOR OPEN to open the CD compartment.

Insert a disc with the printed side facing up. Then close the CD door.

Press ÉÅ to start playback.

To stop playback, press STOPÇ.

Notes for remote control:

– First, select the source you wish to

control by pressing one of the source

select keys on the remote control (CD or

TUNER, for example).

–Then select the desired function

(2;,

for example).

IMPORTANT!

– Remove the

protective plastic tab

before using the

remote control

Press and hold STANDBY-ON/ ECO POWER y to switch the set to Standby mode.

➜The display shows the set time.

➜-- --:-- -- flashes by default if you have not set the clock.

Helpful hints:

- To set the clock automatically by using a time signal which is broadcast

together with the RDS signal, see the User Manual, RDS: Setting the RDS clock.

MCM239 QSG_-12-Eng 22/8/07, 15:253

Tuning to radio stations

Insert the USB device’s USB plug into the socket on the front panel of the main set.

Press SOURCE once or more to select USB (or USB on the remote control)

Press SOURCE once or more to select TUNER (or TUNER on the remote control).

Press and hold PROGRAM until AUTO appears

➜ Available stations are programmed in order of waveband reception strenght: RDS, FM

followed by MW.

Press the ALBUM/ PRESET buttons once or more until the desired preset station is

displayed.

Playing a USB mass storage device

With the Hi-Fi system, you can use USB flash memory (USB 2.0 or USB1.1),

USB flash players (USB 2.0 or USB1.1), memory cards (requires an additional card reader to

work with this Hi-Fi system).

Play the USB’s audio files as you do with the albums/tracks on a CD

Enjoy

Press STANDBY-ON/ ECO POWER y to switch off the set

PDCC-JH-0734

2007 CKoninklijie Philips Electronics N.V.

http://www.philips.com

Detailed playback features and

additional functions are described in the

accompanied owner's manual.

MCM239 QSG_-12-Eng 22/8/07, 15:254
