Philips BTM2056 Manuel utilisateur

www.philips.com/welcome

BTM2056

Always there to help you

User Manual

Question?

Contact

Philips

2EN

Contents

1 Important 3

2 Your Micro System 4

Introduction 4

What's in the box 4

Overview of the main unit 5

Overview of the remote control 6

3 Get started 8

Placement 8

Prepare FM antenna 8

Prepare the remote control 8

Connect power 8

Turn on 9

Set clock 9

Store FM radio stations automatically 9

4 Play 10

Play disc 10

Play from a USB storage device 10

Play from Bluetooth-enabled devices 11

Play options 11

Display different information 12

5 Listen to FM radio 13

Tune to FM radio stations 13

Program FM radio stations automatically 13

Program FM radio stations manually 13

Select a preset radio station 13

Show RDS information 13

Select stereo/mono broadcast 14

6 Other features 14

Set the alarm timer 14

Set the sleep timer 15

Play from an external device 15

Listen through the headphone 15

7 Product information 16

Specications 16

USB playability information 16

Supported MP3 disc formats 17

RDS program types 17

8 Troubleshooting 18

About Bluetooth device 18

9 Notice 20

3EN

1 Important

Warning

•Never remove the casing of this micro system.

•Never lubricate any part of this system.

•Never place this system on other electrical equipment.

•Never look into the laser beam inside this system.

•Keep this system away from direct sunlight, naked

amesorheat.

•Make sure that you always have easy access to the

power cord, plug or adaptor to disconnect the system

from the power.

• Batteries (battery pack or batteries

installed) shall not be exposed to excessive

heatsuchassunshine,reorthelike.

• Battery usage CAUTION – To prevent

battery leakage which may result in bodily

injury, property damage, or damage to the

remote control:

• Install all batteries correctly, + and - as

marked on the remote control.

• Do not mix batteries (old and new or

carbon and alkaline, etc.).

• Remove batteries when the remote

control is not used for a long time.

• Make sure that there is enough free space

around the product for ventilation.

• The system shall not be exposed to

dripping or splashing.

• Do not place any sources of danger on

thesystem(e.g.liquidlledobjects,lighted

candles).

• Where the plug of the Direct Plug-in

Adapter is used as the disconnect device,

the disconnect device shall remain readily

operable.

Hearing safety

Caution

•To prevent possible hearing damage, do not listen at

high volume levels for long periods. Set the volume to a

safe level.The louder the volume, the shorter is the safe

listening time.

Be sure to observe the following guidelines

when using your headphones.

• Listen at reasonable volumes for

reasonable periods of time.

• Be careful not to adjust the volume

continuously upwards as your hearing

adapts.

• Do not turn up the volume so high that

you can’t hear what’s around you.

• You should use caution or temporarily

discontinue use in potentially hazardous

situations.

• Excessive sound pressure from earphones

and headphones can cause hearing loss.

4EN

2 Your Micro

System

Congratulations on your purchase, and

welcometoPhilips!Tofullybenetfromthe

support that Philips offers, register your product

at www.philips.com/welcome.

Introduction

With this micro system, you can:

• enjoy audio from discs, Bluetooth-enabled

devices, USB devices, and other external

devices; and

• listen to FM radio

You can enrich sound output with these sound

effects:

• Digital Sound Control (DSC)

• Dynamic Bass Boost (DBB)

What's in the box

Check and identify the contents of your

package:

• Main unit

• Remote control

• Power adapter

• Mounting kit (2 dowels and 2 screws)

• 2 x AAA batteries

• FM antenna

• Short user manual

• Safety&noticeleaet

• Wall mounting instructions

If you contact Philips, you will be asked for the

model and serial number of this system.The

model number and serial number are on the

bottom of the system.Write the numbers here:

Model No. __________________________

Serial No. ___________________________

5EN

Overview of the main unit

• Turn the system on.

• Switch to standby mode.

ab cdefg

jkl

b SOURCE

• Select a source: CD, Bluetooth, FM

tuner, USB, or MP3 LINK.

6EN

c /

• Skip to the previous or next track.

• Search within a track or disc.

• Tune to FM radio stations.

• Adjust time.

• Conrmaselection.

• Select mono or stereo broadcast.

• Start or pause play.

• Stop play or erase a program.

f VOLUME + / -

• Adjust volume.

• Open or close the disk tray.

h Disc tray

i Display panel

• Show play information.

j MP3 LINK

• Connect an external audio device.

• Connect a USB device.

• Headphone socket.

m FM ANT

• Improve FM reception.

n DC IN

• Connect power.

Overview of the remote

control

• Turn the system on.

• Switch to standby mode.

• Mute or resume sound.

c CD

• Select CD source.

3 LINK

PRESET/ALBUM

PROG/

CLOCK SET

SLEEP/

TIMER

DSC DBB

VOL

REPEAT/

SHUFFLE

456

789

RDS

USB

DISPLAY

7EN

d /

• Skip to the previous or next track.

• Search within a track or disc.

• Tune to radio stations.

• Adjust time.

e USB/MP3 LINK

• Select USB or MP3 link source.

f RDS/DISPLAY

• For FM radio stations with RDS signals:

display RDS information.

• Show time and play information.

g OK

• Conrmaselection.

h VOL +/-

• Adjust volume.

i Numeric Keypad 0 - 9

• Select a track from a disc or USB

device directly.

• Select a preset radio station.

j PROG/CLOCK SET

• Program tracks.

• Program radio stations.

• Set time.

k SLEEP/TIMER

• Set sleep or alarm timer.

l DSC

• Select a preset sound setting.

m DBB

• Turn dynamic bass enhancement on

or off.

n REPEAT/SHUFFLE

• Play a track or all tracks repeatedly.

• Play tracks in current album repeatedly.

• Play tracks randomly.

• Stop play or erase a program.

• Select Bluetooth source.

• Start or pause play.

• Select mono or stereo broadcast.

r /

• Select a preset radio station.

• Skip to the previous or next album.

s FM

• Select FM tuner source.

8EN

3 Get started

Caution

•Use of controls or adjustments or performance of

procedures other than herein may result in hazardous

radiation exposure or other unsafe operation.

Always follow the instructions in this chapter in

sequence.

Placement

Youcanplacethesystemonaatsurfaceor

mount it on a wall.

Mount on a wall

See the wall mounting instructions included in

the package.

Prepare FM antenna

Tip

•For optimal reception, fully extend and adjust the

position of the antenna.

Connect the supplied FM antenna to the FM

ANT socket on the main unit.

Prepare the remote control

1 Open the battery compartment.

2 Insert 2 AAA batteries with correct

polarity (+/-) as indicated.

3 Close the battery compartment.

Connect power

Caution

•Risk of product damage! Make sure that the power

supply voltage corresponds to the voltage printed on

the back of the system.

•Risk of electric shock! When you unplug the AC power

adapter, always pull the plug from the socket. Never

pull the cord.

•Before connecting the AC adapter, make sure that you

have completed all other connections.

Note

•The type plate is located on the back of the system.

Connect the power adapter to:

• the DC IN socket on the system.

• the wall power socket.

9EN

Turn on

Press .

» The system switches to the last

selected source.

Tip

•To select another source, press SOURCE repeatedly or

the source selection buttons on the remote control.

Switch to standby mode

Press to switch the system to standby mode.

» The clock (if set) appears on the

display panel.

» The display backlight becomes dim.

Note

•In CD, USB, or Bluetooth mode, if the system stays

inactive for 15 minutes, it switches to standby mode

automatically.

•In MP3 link mode, if music is stopped or paused for

15 minutes and the MP3 link cable is not plugged, the

system switches to standby mode automatically.

Set clock

1 In standby mode, press and hold CLOCK

SET on the remote control for two

seconds.

» [SET CLOCK] (set clock) scrolls on

the display, then the 12/24 hour format

blinks.

2 Press / repeatedly to select an hour

format.

3 Press CLOCK SETtoconrm.

» The hour digits blink.

4 Repeat steps 2-3 to set the hour.

5 Repeat steps 2-3 to set the minute.

6 Repeat steps 2-3 to select whether to

synchronize time with RDS stations.

• [RDS TIME SYNC [Y]]: synchronize

time with RDS stations automatically.

• [RDS TIME SYNC [N]]: deactivate

time synchronization.

Note

•The accuracy of the transmitted time depends on the

RDS station that transmits the time signal.

•If the system is idle for 90 seconds, it exits clock setting

mode automatically.

Store FM radio stations

automatically

When you connect AC power and no FM

stations are stored, the system prompts you to

search and store all the available FM stations.

1 Connect the system to the power supply.

» [AUTO INSTALL - PRESS PLAY, STOP

CANCEL] (to auto install, press ;

to cancel, press ) is displayed.

10EN

2 Press and hold for 3 seconds to start

full scan.

» The system automatically stores FM

radiostationswithsufcientsignal

strength.

» Therstpresetstationisbroadcast

automatically.

Tip

•To exit storing mode, press or .

4 Play

Play disc

1 Press to open the disc tray.

2 Insert a disc with the printed side facing up.

3 Press to close the disc tray.

4 Press CD on the remote control to select

the disc source.

» [Reading] (reading) blinks for a

moment, then CD starts playing

automatically. If not, press .

Play from a USB storage

device

Note

•Make sure that the USB device contains playable audio

content.

050

Autres manuels pour BTM2056

Table des matières

Autres manuels Philips Système stéréo

Philips

Philips FWM397 Manuel utilisateur

Philips

Philips MCM395/12 Manuel utilisateur

Philips

Philips FW690/22 Manuel utilisateur

Philips

Philips MC 118 Manuel utilisateur

Philips

Philips FW-C55/25 Manuel utilisateur

Philips

Philips SBCHC120/05 Manuel utilisateur

Philips

Philips MC108/05 Manuel utilisateur

Philips

Philips MCM128B/05 Manuel utilisateur

Philips

Philips Magnavox FW 754P Manuel utilisateur

Philips

Philips FW-C870 Manuel utilisateur

Philips

Philips Essence 5000 Series Manuel utilisateur

Philips

Philips FW2019 Manuel utilisateur

Philips

Philips MCD280/30 Manuel utilisateur

Philips

Philips ST1010 Manuel utilisateur

Philips

Philips MCD135/78 Manuel utilisateur

Philips

Philips MC147 Manuel utilisateur

Philips

Philips FWD798/55 Manuel d'utilisation

Philips

Philips MCM108 Manuel utilisateur

Philips

Philips FWM663/55 Manuel utilisateur

Philips

Philips MCM233/58 Manuel utilisateur

Philips

Philips MCM279/12 Manuel utilisateur

Philips

Philips MC147 Manuel utilisateur

Philips

Philips FW 326 Manuel utilisateur

Philips

Philips FX50 Fiche d'information produit

Manuels Système stéréo populaires d'autres marques

LG CM3330B Manuel utilisateur

Sony

Sony SS-CEP50 Manuel utilisateur

Cetacea Sound

Cetacea Sound CVS-II Manuel utilisateur

Aiwa

Aiwa XR-H66MD Manuel utilisateur

Denon

Denon UCD-250 Manuel utilisateur

Sanyo

Sanyo DC-MX41i Manuel utilisateur

Sharp

Sharp CD-ES600V Manuel utilisateur

Exibel

Exibel BDX600-UK Manuel utilisateur

Sanyo

Sanyo DC-F320 Manuel utilisateur

Sharp

Sharp CD-C462 Manuel utilisateur

Onkyo

Onkyo CBX 300 - CD / MP3 Clock Radio Manuel utilisateur

Aiwa

Aiwa XR-EM70 Manuel utilisateur

Cyrus

Cyrus Lyric Manuel utilisateur

Philips/Magnavox

Philips/Magnavox Magnavox FW 62C Manuel utilisateur

RCA

RCA RS3965SB Manuel utilisateur

Sharp

Sharp XL-UH240 Manuel utilisateur

LG FB165DAB Manuel utilisateur

Sanyo

Sanyo DC-UB1475M/XE/UK Manuel utilisateur
