Philips TAB5706 Manuel utilisateur

TAB5706

www.philips.com/support

User manual

5000 Series

Contents

1 Important 3

Safety 3

Care for your product 4

Care of the environment 4

FCC information 5

Help and support 6

2 Your Soundbar 6

What’s in the Box 6

Main unit 7

Connectors 7

Remote control 8

Prepare the Remote Control 8

Placement 9

Wall mount 10

3 Connect 11

Connect to HDMI Socket 11

Connect to Optical Socket 11

Connect to AUX Socket 12

Connect to Power 12

4 Use your Soundbar 13

Turn ON and OFF 13

Select Source 13

Select Equalizer (EQ) Eect 13

Adjust the Volume 14

Factory Reset 14

Bluetooth Operation 15

USB Operation 16

AUX / OPTICAL / HDMI ARC

Operation 16

5 Product specications 17

6 Troubleshooting 18

Trademarks: 19

English

1 Important

Read and understand all instructions

before you use your product. If damage

is caused by failure to follow instructions,

the warranty does not apply.

Safety

Risk of electric shock or re!

• Before you make or change any

connections, make sure that all

devices are disconnected from the

power outlet.

• Never expose the product and

accessories to rain or water. Never

place liquid containers, such as vases,

near the product. If liquids are spilt

on or into the product, disconnect it

from the power outlet immediately.

Contact Consumer Care to have the

product checked before use.

• Never place the product and

accessories near naked ames or

other heat sources, including direct

sunlight.

• Never insert objects into the

ventilation slots or other openings

on the product.

• Where the mains plug or an

appliance coupler is used as the

disconnect device, the disconnect

device shall remain readily

operable.

• Battery (battery pack or batteries

installed) shall not be exposed to

excessive heat such as sunshine, re

or the like.

• Disconnect the product from the

power outlet before lightning storms.

• When you disconnect the power cord,

always pull the plug, never the cable.

• Use the product in tropical and/or

moderate climates.

Risk of short circuit or re!

• For identication and supply ratings,

see the type plate at the back or

bottom of the product.

• Before you connect the product to

the power outlet, ensure that the

power voltage matches the value

printed on the back or bottom of the

product. Never connect the product

to the power outlet if the voltage is

dierent.

Risk of injury or damage to this product!

• For wall mounting, this product must

be securely attached to the wall

in accordance with the installation

instructions. Use only the supplied

wall mount bracket (if available).

Improper wall mounting may result

in accident, injury or damage. If you

have any query, contact Consumer

Care in your country.

• Never place the product or any

objects on power cords or on other

electrical equipment.

• If the product is transported in

temperatures below 5°C, unpack

the product and wait until its

temperature matches room

temperature before connecting it to

the power outlet.

• Parts of this product can be made

of glass. Handle with care to avoid

injury and damage.

Risk of overheating!

• Never install this product in a

conned space. Always leave a

space of at least four inches around

the product for ventilation. Ensure

curtains or other objects never cover

the ventilation slots on the product.

Risk of contamination!

• Do not mix batteries (old and new

or carbon and alkaine, etc.).

• CAUTION: Danger of explosion if

batteries are incorrectly replaced.

Replace only with the same or

equivalent type.

• Remove batteries if they are

exhausted or if the remote control is

not to be used for a long time.

• Batteries contain chemical

substances, they should be

disposed of properly.

Risk of swallowing batteries!

• The product/remote control may

contain a coin/button type battery,

which can be swallowed. Keep the

battery out of reach of children at

all times! If swallowed, the battery

can cause serious injury or death.

Severe internal burns can occur

within two hours of ingestion.

• If you suspect that a battery

has been swallowed or placed

inside any part of the body, seek

immediate medical attention.

• When you change the batteries,

always keep all new and

used batteries out of reach of

children. Ensure that the battery

compartment is completely secure

after you replace the battery.

• If the battery compartment cannot

be completely secured, discontinue

use of the product. Keep out of

reach of children and contact the

manufacturer.

This is CLASS II apparatus with

double insulation, and no

protective earth provided.

AC voltage

Follow the instructions in the

user manual!

WARNING!

Warning: risk of electric shock!

The exclamatory mark is intended

to alert the user to the presence of

important operating instructions.

Care for your product

Use only microber cloth to clean the

product.

Care of the environment

Disposal of your old product and

battery

Your product is designed and

manufactured with high quality

materials and components, which

can be recycled and reused.

This product may contain lead and

mercury. Disposal of these materials

may be regulated due to environmental

considerations. For disposal or recycling

information, please contact your local

authorities.

This product contains batteries:

* Dispose of batteries properly. Do not

incinerate. Batteries may explode if

overheated.

* Do not warp in metal or aluminum foil.

Warp in newspaper before discarding.

* it is suggested that you contact your

local town or city to determine proper

battery redemption site(s) in your area.

* Please visit www.call 2 recycle. org for

additional information on a recycling

center in your area for rechargeable

batteries.

English

FCC information

NOTE: This equipment has been tested

and found to comply with the limits for

a Class B digital device, pursuant to

Part 15 of the FCC Rules. These limits

are designed to provide reasonable

protection against harmful interference in

a residential installation. This equipment

generates, uses and can radiate radio

frequency energy and, if not installed and

used in accordance with the instructions,

may cause harmful interference to radio

communications.

However, there is no guarantee that

interference will not occur in a particular

installation. If this equipment does cause

harmful interference to radio or television

reception, which can be determined

by turning the equipment o and on,

the user is encouraged to try to correct

the interference by one or more of the

following measures:

• Reorient or relocate the receiving

antenna.

• Increase the separation between

the equipment and receiver.

• Connect the equipment into an

outlet on a circuit dierent from that

to which the receiver is connected.

• Consult the dealer or an

experienced radio/TV technician for

help.

This device complies with part 15 of the

FCC Rules. Operation is subject to the

following two conditions: (1) This device

may not cause harmful interference,

and (2) this device must accept any

interference received, including

interference that may cause undesired

operation.

IC-Canada : CAN ICES-3(B)/

NMB-3(B)

This device contains licence-exempt

transmitter(s)/receiver(s) that comply

with Innovation, Science and Economic

Development Canada’s licence-exempt

RSS(s). Operation is subject to the

following two conditions:

1. This device may not cause interference.

2. This device must accept any

interference, including interference that

may cause undesired operation of the

device.

The device for operation in the band

5150–5250 MHz is only for indoor use

to reduce the potential for harmful

interference to co-channel mobile

satellite systems.

FCC& IC Radiation Exposure Statement:

This equipmet complies with FCC and

Canada radiation exposure limits set

forth for an uncontrolled environment.

This equipment should be installed and

operated with a minimum distance of

20cm between the radiator and your

body. This transmitter.

Warning: Any changes or modications

made to this device that are not expressly

approved by MMD Hong Kong Holding

Limited may void the user’s authority to

operate the equipment.

Model number: TAB5706/37

Trade name: PHILIPS

Responsible party: TPV USA Corp.

6525 Morrison Blvd

#200 Charlotte,

NC – 28211, USA

Help and support

For extensive online support, visit

www.philips.com/support to:

• download the user manual and the

quick start guide

• watch video tutorials (available only

for selected models)

• nd answers to frequently answered

questions (FAQs)

• email us a question

• chat with our support

representative.

Follow the instructions on the website

to select your language, and then enter

your product model number.

Alternatively, you can contact Consumer

Care in your country. Before you

contact, note down the model number

and serial number of your product. You

can nd this information on the back or

bottom of your product.

2 Your Soundbar

Congratulations on your purchase, and

welcome to Philips! To fully benet from

the support that Philips oers, register

your Soundbar at

www.philips.com/support.

What’s in the Box

Check and identify the items in the

package:

• Soundbar x 1

• Remote Control x 1

• AAA Batteries x 2

• Power Cord * x 3

• Wall Mount kit x 1

(Wall Brackets x2, Screws x2, Dowels x2)

• Safety Sheet / Quick Start Guide

Warranty Card x 1

2 X

Quick start guide

* The attached items and images may vary by

region.

• Images,illustrationsanddrawingsshown

on this User Manual are for reference only,

actual product may vary in appearance.

English

Main unit

This section includes an overview of the

main unit.

123

1 +/- (Volume)

Increase or decrease volume.

2 (Source)

Select an input source for the

Soundbar.

3 (Standby-On)

Switch the Soundbar On or to

Standby.

4 Soundbar’s LED indicator

Switch the playback source and the

front indicator lights up accordingly.

The indicator light on the front of

the main unit will show which mode

is currently in use.

Status LED State

AUX [AUX/USB] Solid white

USB [AUX/USB] Blinking white

Standby [Standby] Solid red

BT (Bluetooth)

•Connected

•Connection

[BT] Solid white

[BT] Blinking white

OPTICAL [OPTICAL] Solid white

HDMI ARC [HDMI ARC] Solid white

5 Remote Control Sensor

6 Built-in Subwoofer

Connectors

This section includes an overview of the

connectors available on your Soundbar.

1 2 3 4 5

1 AC~

Connect to the power supply.

2 OPTICAL IN

Connect to an optical audio output

on the TV or a digital device.

3 USB

• Audio input from a USB storage

device.

4 AUX IN

Audio input from, for example, an

MP3 player (3.5mm jack).

5 HDMI ARC

The port supports the HDMI ARC

feature, Connect to the HDMI ARC

on the TV.

6 Wall Bracket Screws

Remote control

This section includes an overview of the

remote control.

1 (Standby-On)

Switch the Soundbar on or to

standby.

2 Source buttons

AUX: Switch your audio source to

the AUX connection (3.5mm jack).

BT / Pair: Switch to Bluetooth

mode.

Press and hold to activate the

pairing function in Bluetooth mode

or disconnect the existing paired

Bluetooth device.

HDMI ARC: Switch your source to

HDMI ARC connection.

OPTICAL: Switch your audio source

to the optical connection.

USB: Switch to USB mode.

3 +/- (Soundbar’s Volume)

Increase / decrease the soundbar’s

volume.

4 EQ

Select Equalizer (EQ) eect.

5 / (Previous/Next)

Skip to the previous or next track in

USB/BT mode.

• (Play/Pause)

Start, pause or resume play in USB/

BT mode.

6 (Mute)

Mute or restore volume.

7 +/- (Subwoofer’s Volume)

Increase / decrease the built-in

Subwoofer’s volume.

Prepare the Remote

Control

• The provided Remote Control

allows the unit to be operated from

a distance.

• Even if the Remote Control is

operated within the eective range

19.7 feet (6m), remote control

operation may be impossible if

there are any obstacles between

the unit and the remote control.

• If the Remote Control is operated

near other products which generate

infrared rays, or if other remote

control devices using infra-red

rays are used near the unit, it may

operate incorrectly. Conversely,

the other products may operate

incorrectly.

English

Replace the Remote Control

Battery

1 Press and slide the back cover to

open the battery compartment of

the remote control.

2 Insert two AAA size batteries

(included). Make sure the (+) and

(–) ends of the batteries match the

(+) and (–) ends indicated in the

battery compartment.

3 Close the battery compartment cover.

Precautions Concerning

Batteries

• Be sure to insert the batteries with

correct positive " " and negative

" " polarities.

• Use batteries of the same type.

Never use different types of

batteries together.

• Either rechargeable or non-

rechargeable batteries can be used.

Refer to the precautions on their

labels.

• Be aware of your fingernails when

removing the battery cover and the

battery.

• Do not drop the remote control.

• Do not allow anything to impact the

remote control.

• Do not spill water or any liquid on

the remote control.

• Do not place the remote control on

a wet object.

• Do not place the remote control

under direct sunlight or near sources

of excessive heat.

• Remove the battery from the

remote control when not in use for

a long period of time, as corrosion

or battery leakage may occur and

result in physical injury, and/or

property damage, and/or fire.

• Do not use any batteries other than

those specified.

• Do not mix new batteries with old

ones.

• Never recharge a battery unless it

is confirmed to be a rechargeable

type.

Placement

For best results, place your Soundbar as

shown below.

1 Drill 2 parallel holes (diameter

3-8mm each according to wall

type) on the wall. The distance

between the holes should be

646mm / 25.4".

» Secure the dowels and screws in

the holes.

2 Remove the screws (x4) from the

main unit.

» Attach the wall brackets (x2) to

the main unit with the screws

removed from the main unit.

3 Hang the Soundbar on the

fastening screws.

3.5-4mm/0.14"-0.16"

4mm/

0.16"

>25mm/0.98"

~50mm/2.0"

646 mm / 25.4"

Wall mount

Note

•Improper wall mounting may result in accident,

injury or damage. If you have any query,

contact Consumer Care in your country.

•Before wall mounting, make sure the wall can

support the weight of your Soundbar.

•Before wall mount, you need not remove the

rubber feet at the bottom of the Soundbar,

otherwise the rubber feet cannot be xed back.

•Depending on the type of wall mounting your

Soundbar, make sure that you use screws of a

suitable length and diameter.

•Please check whether the USB port on the

back of the Soundbar is connected to a USB

device. If it is found that the connected USB

device aects the wall-mount, you need to use

another USB device of the appropriate size.

Screw length/diameter

> 25mm

3.5-4mm

4mm

3.5-4mm

4mm

>25mm

Suggested wall mounting height

You are recommended to install the TV

rst before wall mounting the soundbar.

With a TV preinstalled, wall mount the

soundbar 50mm/2.0" in distance from

the bottom of the TV.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips Système de haut-parleurs

Philips

Philips SBA220 Manuel utilisateur

Philips

Philips Fidelio E6 Manuel utilisateur

Philips

Philips MMS223/00 Guide de référence

Philips

Philips HTL4110B Manuel utilisateur

Philips

Philips A3.310/05 Manuel utilisateur

Philips

Philips MMS260 Manuel utilisateur

Philips

Philips 6000 Series Manuel utilisateur

Philips

Philips HTL2161B Manuel utilisateur

Philips

Philips SS-GNX60 Manuel utilisateur

Philips

Philips MMS260/05 Manuel utilisateur

Philips

Philips HTL5140B Manuel utilisateur

Philips

Philips SBA1620 Manuel utilisateur

Philips

Philips CSS6530B Manuel utilisateur

Philips

Philips MMS222/00 Guide de référence

Philips

Philips HSB2351/F7 Manuel utilisateur

Philips

Philips AECS7000E Fiche d'information produit

Philips

Philips F1385 Manuel utilisateur

Philips

Philips A 2.300 Compact Power Manuel utilisateur

Philips

Philips RWSS125 Manuel utilisateur

Philips

Philips Cordless Stereo Speakers SBC BC8320 Manuel utilisateur

Philips

Philips amBX SGC6101BD Manuel utilisateur

Philips

Philips HTL2163B Manuel utilisateur

Philips

Philips 22RH544 /50r/65r/79r Manuel utilisateur

Philips

Philips Fidelio B1 Manuel utilisateur

Manuels Système de haut-parleurs populaires d'autres marques

JVC

JVC CA-MXK5R Manuel utilisateur

LG NB4532B Manuel utilisateur

JVC

JVC CA-FSH100 Manuel utilisateur

5Core

5Core Pro Series Manuel utilisateur

EAW

EAW MQV1394e Manuel utilisateur

Lynx

Lynx GXR-LA10A Manuel utilisateur

iLive

iLive ITB066B Manuel utilisateur

RDX

RDX QuickStation 4 Manuel utilisateur

Electro-Voice

Electro-Voice S-122 Manuel utilisateur

Sven

Sven SPS-619 GOLD Manuel utilisateur

Pioneer

Pioneer CS-7070 Manuel utilisateur

EAW

EAW UB82e Manuel utilisateur

Sondpex

Sondpex Active Speaker System and Digital Music... Manuel utilisateur

JVC

JVC NX-PN7 Manuel utilisateur

Marshall Amplification

Marshall Amplification AR-DM61-BT Manuel utilisateur

Yamaha

Yamaha NX-A01 - Speaker Sys Manuel utilisateur

SE Audiotechnik

SE Audiotechnik I-LINE Manuel utilisateur

Gemini

Gemini WRX-843 Series Manuel utilisateur
