User manual

Always there to help you

Question?

Contact

Philips

Question?

Contact

Philips

HTL2160

1EN

Contents

1 Important 2

Help and support 2

Safety 2

Care for your product 3

Care of the environment 3

Trademarks 3

2 Your SoundBar 4

Assemble your Soundbar 4

Main unit 4

Remote control 4

Connectors 5

3 Connect 6

Placement 6

Connect audio from TV and other

devices 6

4 Use your SoundBar 8

Adjust the volume 8

Choose your sound 8

MP3 player 8

USB storage devices 8

Play audio through Bluetooth 9

Apply factory settings 9

5 Wall mount 10

6 Productspecications 11

7 Troubleshooting 12

2EN

1 Important

Read and understand all instructions before you

use your product. If damage is caused by failure

to follow instructions, the warranty does not

apply.

Help and support

Philips provides extensive online support.Visit

our website at www.philips.com/support to:

• download the user manual and the quick

start guide

• watch video tutorials (available only for

selected models)

• ndanswerstofrequentlyanswered

questions (FAQs)

• email us a question

• chat with our support representative.

Follow the instructions on the website to select

your language, and then enter your product

model number.

Alternatively, you can contact Philips Consumer

Care in your country. Before you contact

Philips, note down the model number and

serialnumberofyourproduct.Youcanndthis

information on the back or bottom of your

product.

Safety

Riskofelectricshockorre!

• Never expose the product and accessories

to rain or water. Never place liquid

containers, such as vases, near the product.

If liquids are spilt on or into the product,

disconnect it from the power outlet

immediately. Contact Philips Consumer

Care to have the product checked before

use.

• Never place the product and accessories

nearnakedamesorotherheatsources,

including direct sunlight.

• Never insert objects into the ventilation

slots or other openings on the product.

• Where the mains plug or an appliance

coupler is used as the disconnect device,

the disconnect device shall remain readily

operable.

• Disconnect the product from the power

outlet before lightning storms.

• When you disconnect the power cord,

always pull the plug, never the cable.

Riskofshortcircuitorre!

• Before you connect the product to the

power outlet, ensure that the power

voltage matches the value printed on the

back or bottom of the product. Never

connect the product to the power outlet if

the voltage is different.

RiskofinjuryordamagetotheSoundBar!

• Never place the product or any objects

on power cords or on other electrical

equipment.

• If the product is transported in

temperatures below 5°C, unpack the

product and wait until its temperature

matches room temperature before

connecting it to the power outlet.

• Parts of this product can be made of

glass. Handle with care to avoid injury and

damage.

Riskofoverheating!

• Neverinstallthisproductinaconned

space. Always leave a space of at least four

inches around the product for ventilation.

Ensure curtains or other objects never

cover the ventilation slots on the product.

Riskofcontamination!

• Do not mix batteries (old and new or

carbon and alkaine, etc.).

• Danger of explosion if batteries are

incorrectly replaced. Replace only with the

same or equivalent type.

• Remove batteries if they are exhausted or

if the remote control is not to be used for

a long time.

3EN

• Batteries contain chemical substances, they

should be disposed of properly.

Riskofswallowingbatteries!

• The product/remote control may contain

a coin/button type battery, which can be

swallowed. Keep the battery out of reach

of children at all times! If swallowed, the

battery can cause serious injury or death.

Severe internal burns can occur within two

hours of ingestion.

• If you suspect that a battery has been

swallowed or placed inside any part of the

body, seek immediate medical attention.

• When you change the batteries, always

keep all new and used batteries out of

reach of children. Ensure that the battery

compartment is completely secure after

you replace the battery.

• If the battery compartment cannot be

completely secured, discontinue use of the

product. Keep out of reach of children and

contact the manufacturer.

This is CLASS II apparatus with double

insulation, and no protective earth provided.

Help and support

Philips provides extensive online support.Visit

our website at www.philips.com/support to:

• download the user manual and the quick

start guide

• watch video tutorials (available only for

selected models)

• ndanswerstofrequentlyanswered

questions (FAQs)

• email us a question

• chat with our support representative.

Follow the instructions on the website to select

your language, and then enter your product

model number.

Alternatively, you can contact Philips Consumer

Care in your country. Before you contact Philips,

note down the model number and serial number

ofyourproduct.Youcanndthisinformationon

the back or bottom of your product.

Care for your product

Useonlymicroberclothtocleantheproduct.

Care of the environment

Your product is designed and manufactured

with high quality materials and components,

which can be recycled and reused.

Never dispose of your product with other

household waste. Please inform yourself about

the local rules on the separate collection of

electrical and electronic products and batteries.

The correct disposal of these products helps

prevent potentially negative consequences on

the environment and human health.

Your product contains batteries, which cannot

be disposed of with normal household waste.

Please inform yourself about the local rules on

separate collection of batteries.The correct

disposal of batteries helps prevent potentially

negative consequences on the environment and

human health.

Trademarks

Manufactured under license from Dolby

Laboratories. Dolby and the double-D symbol

are trademarks of Dolby Laboratories.

The Bluetooth®word mark and logos are

registered trademarks owned by Bluetooth

SIG, Inc. and any use of such marks by Philips is

under license.

4EN

2 Your SoundBar

Congratulations on your purchase, and

welcometoPhilips!Tofullybenetfrom

the support that Philips offers, register your

SoundBar at www.philips.com/welcome.

Assemble your Soundbar

Assemble your SoundBar as described in the

quick start guide (Step 1).

Main unit

This section includes an overview of the main

unit.

Switch the SoundBar on or to standby.

b VOLUME +-

Increase or decrease volume.

c SOURCE

Select an audio source for the SoundBar.

d Power

Lights up when you switch on the

SoundBar.

e Source indicators

• COAX/OPT/AUX: Lights up when

you switch to coaxial, optical or analog

audio input source.

• USB: Lights up when you switch to the

USB source.

abc

fged

• AUDIO-IN: Lights up when you switch

to the audio input source.

f SURR

Lights up when you selectVirtual Surround

sound.

g Bluetooth

Lights up when you switch to the

Bluetooth mode.

Remote control

This section includes an overview of the

remote control.

5EN

a (Standby-On)

Switch the SoundBar on or to standby.

b COAX

Switch your audio source to the coaxial

connection.

c USB

Switch your audio source to the USB

connection.

d OPTICAL

Switch your audio source to the optical

connection.

e Bluetooth

Switch to Bluetooth mode.

f TREBLE +/-

Increase or decrease treble.

g SURR

Toggle between stereo and virtual

surround sound.

Mute or restore volume.

i BASS +/-

Increase or decrease bass.

j VOLUME +/-

Increase or decrease volume.

k AUDIO-IN

Switch your audio source to audio in

connection.

l AUX

Switch your audio source to the AUX

connection.

Connectors

This section includes an overview of the

connectors available on your SoundBar.

Top connectors

a (USB)

Audio input from a USB storage device.

b AUDIO-IN

Audio input from an MP3 player (3.5mm

jack).

Rear connectors

a AUDIO IN

Connect to an analog audio output on the

TV or an analog device.

b DIGITAL IN-COAXIAL

Connect to a coaxial audio output on the

TV or a digital device.

c DIGITAL IN-OPTICAL

Connect to an optical audio output on the

TV or a digital device.

d SUBWOOFER

Connect to the supplied subwoofer.

e AC MAINS~

Connect to the power supply.

b c

6EN

3 Connect

This section helps you connect your SoundBar

to a TV and other devices.

For information about the basic connections of

your SoundBar and accessories, see the quick

start guide.

Note

•Foridenticationandsupplyratings,refertothetype

plate at the back or bottom of the product.

•Before you make or change any connections, make sure

that all devices are disconnected from the power outlet.

Placement

Place the subwoofer at least 1 meter (3 feet)

away from your SoundBar, and ten centimeters

away from the wall.

For best results, place your subwoofer as shown

below.

Connect audio from TV and

other devices

Play audio fromTV or other devices through

your Soundbar speakers.

Use the best quality connection available on

yourTV, Soundbar, and other devices.

Option 1: Connect audio through a

digital optical cable

Best quality audio

1 Using an optical cable, connect the

OPTICAL connector on your SoundBar to

the OPTICAL OUT connector on the TV

or other device.

• The digital optical connector might be

labeled SPDIF or SPDIF OUT.

Option 2: Connect audio through a

digital coaxial cable

Good quality audio

1 Using a coaxial cable, connect the

COAXIAL connector on your SoundBar

to the COAXIAL/DIGITAL OUT

connector on the TV or other device.

7EN

• The digital coaxial connector might be

labeled DIGITAL AUDIO OUT.

Option 3: Connect audio through

analog audio cables

Basic quality audio

1 Using an analog cable, connect the AUX

connectors on your SoundBar to the

AUDIO OUT connectors on the TV or

other device.

DVD

8EN

4 Use your

SoundBar

This section helps you use the SoundBar to play

audio from connected devices.

Before you start

• Make the necessary connections described

in the quick start guide or download

the user manual from www.philips.com/

support.

• Switch the SoundBar to the correct source

for other devices.

Adjust the volume

1 Press VOLUME +/- to increase or

decrease a volume level.

• To mute sound, press (MUTE).

• To restore the sound, press (MUTE)

again or press VOLUME +/-.

» All Source indicators on the main unit

blink twice when a volume is set to the

maximum or minimum value.

Choose your sound

This section helps you choose the ideal sound

for your video or music.

Surround sound mode

Experience an immersive audio experience with

surround sound modes.

1 Press SURR to select a surround mode.

• [Virtual Surround]: Creates a highly

surround listening experience.The

SURR indicator on the main unit lights

up.

• [Stereo]:Two-channel stereo sound.

Ideal for listening to music.

Equalizer

Change the high frequency (treble) and low

frequency (bass) settings of the SoundBar.

1 Press TREBLE +/- or BASS +/- to change

the frequency.

» All Source indicators on the main unit

blink twice when treble or bass is set

to the maximum or minimum value.

MP3 player

Connect your MP3 player to play your audio

lesormusic.

What you need

• An MP3 player.

• A 3.5mm stereo audio cable.

1 Using the 3.5mm stereo audio cable,

connect the MP3 player to the AUDIO-IN

connector on your SoundBar.

2 Press AUDIO-IN.

3 Press the buttons on the MP3 player to

selectandplayaudiolesormusic.

USB storage devices

Enjoy audio on a USB storage device, such as an

MP3playerandUSBashmemory,etc.

What you need

• A USB storage device that is formatted

forFATlesystems,andcomplieswiththe

Mass Storage Class.

• AnMP3orWMAleonaUSBstorage

device

1 Connect a USB storage device to the

SoundBar.

2 Press USB on the remote control.

» The play starts after a few seconds.

9EN

Note

•This product may not be compatible with certain types

of USB storage device.

•If you use a USB extension cable, USB HUB, or USB

multi-reader, the USB storage device may not be

recognized.

•Digital camera PTP protocols are not supported.

•Do not remove the USB storage device while it is

being read.

•DRM-protectedmusicles(MP3,WMA)arenot

supported.

•Support a USB port: 5V , 500mA.

Play audio through Bluetooth

Through Bluetooth, connect the SoundBar with

your Bluetooth device (such as an iPad, iPhone,

iPod touch, Android phone, or laptop), and then

youcanlistentotheaudiolesstoredonthe

device through your SoundBar speakers.

What you need

• A Bluetooth device which supports

BluetoothproleA2DP,andwithBluetooth

version as 2.1 + EDR.

• The operational range between the

SoundBar and a Bluetooth device is

approximately 10 meters (30 feet).

1 Press Bluetooth on the remote control to

switch the SoundBar to Bluetooth mode.

» The Bluetooth indicator blinks at a fast

rate.

2 On the Bluetooth device, switch on

Bluetooth, search for and select Philips

HTL2160 to start connection (see the

user manual of the Bluetooth device on

how to enable Bluetooth).

• When prompted for a password, enter

"0000".

» During connection, the indicator blinks

at a lower rate.

3 Wait unitl the Bluetooth connection is

completed.

» When the Bluetooth connection

succeeds, and the Bluetooth indicator

lights up.

» If the connection fails, the Bluetooth

indicator blinks continually at a lower

rate.

4 Selectandplayaudiolesormusicon

your Bluetooth device.

• During play, if a call is coming, music

play is paused. Play resumes when the

call ends.

5 To exit Bluetooth, select other source.

• When your switch back to Bluetooth

mode, Bluetooth connection remains

active.

Note

•The music streaming may be interrupted by obstacles

between the device and SoundBar, such as wall, metallic

casing that covers the device, or other devices nearby

that operate in the same frequency.

•If you want to connect your SoundBar with another

Bluetooth device, disable the currently connected

Bluetooth device.

•Philips does not guarantee 100% compatibility with all

Bluetooth devices.

Apply factory settings

You can reset your SoundBar to the default

settings programmed at the factory.

1 In mute mode, quickly press AUX twice.

» The factory settings is restored.

Autres manuels pour HTL2160

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips Système de haut-parleurs

Philips

Philips 6000 Series Manuel utilisateur

Philips

Philips FB 652 Manuel utilisateur

Philips

Philips Fidelio E5 Manuel utilisateur

Philips

Philips MCM108 Manuel utilisateur

Philips

Philips NTX400L/55 Manuel utilisateur

Philips

Philips amBX SGC6101BD Manuel utilisateur

Philips

Philips TAB8947 Manuel utilisateur

Philips

Philips NTX400 Fiche d'information produit

Philips

Philips MMS171 - MMS 171 2.1-CH PC Multimedia Speaker... Manuel utilisateur

Philips

Philips SBA230 Manuel utilisateur

Philips

Philips SPA4270BT Manuel utilisateur

Philips

Philips Immersive HTB7530KD Manuel utilisateur

Philips

Philips Fidelio E6 Manuel utilisateur

Philips

Philips HTL2111A Manuel utilisateur

Philips

Philips CSS6530B Manuel utilisateur

Philips

Philips AECS7000E Fiche d'information produit

Philips

Philips HTL2160/77 Manuel utilisateur

Philips

Philips 4000 series Manuel utilisateur

Philips

Philips TAB8507 Manuel utilisateur

Philips

Philips HTL3325 Manuel utilisateur

Philips

Philips HTB5150D/12 Manuel utilisateur

Philips

Philips Essence 5000 Series Manuel utilisateur

Philips

Philips FB 206W Manuel utilisateur

Philips

Philips Cordless Stereo Speakers SBC BC8320 Manuel utilisateur

Manuels Système de haut-parleurs populaires d'autres marques

JVC

JVC CA-MXK5R Manuel utilisateur

LG NB4532B Manuel utilisateur

JVC

JVC CA-FSH100 Manuel utilisateur

5Core

5Core Pro Series Manuel utilisateur

EAW

EAW MQV1394e Manuel utilisateur

Lynx

Lynx GXR-LA10A Manuel utilisateur

iLive

iLive ITB066B Manuel utilisateur

RDX

RDX QuickStation 4 Manuel utilisateur

Electro-Voice

Electro-Voice S-122 Manuel utilisateur

Sven

Sven SPS-619 GOLD Manuel utilisateur

Pioneer

Pioneer CS-7070 Manuel utilisateur

EAW

EAW UB82e Manuel utilisateur

Sondpex

Sondpex Active Speaker System and Digital Music... Manuel utilisateur

JVC

JVC NX-PN7 Manuel utilisateur

Marshall Amplification

Marshall Amplification AR-DM61-BT Manuel utilisateur

Yamaha

Yamaha NX-A01 - Speaker Sys Manuel utilisateur

SE Audiotechnik

SE Audiotechnik I-LINE Manuel utilisateur

Gemini

Gemini WRX-843 Series Manuel utilisateur
