Philips VC963650T Manuel utilisateur

Contents

English .........................................................................2

Français ......................................................................6

Español ....................................................................10

Português ...............................................................14

Nederlands ...........................................................18

Deutsch ...................................................................22

Italiano ....................................................................26

Dansk ........................................................................30

Svenska ....................................................................34

Norsk ........................................................................38

Suomi ........................................................................42

Eλληviká .................................................................46

Technical specifications ....................................49/50

Covert Observation Camera

PIR Covert B&W Camera -VC863650T

PIR Covert Colour Camera -VC963650T

2345

2-3 4-5

2345

2-3 4-5

2345

Fig.C

COLOUR CCD CAMERA

Pick-up device 1/3”(Solid state CCD)

No. of picture elements (HxV)

512 x 582 PAL interlaced (Europe)

Horizontal resolution 380TVL

Gain control Automatic,32 dB

Iris Electronic iris

Light sensitivity 0.3 lux (minimal acceptable picture)

3.0 lux (50 IRE,100% scene

refelection)

Signal to noise ratio 49 dB at 200-25000 lux,25˚C

Built-in microphone electret

Lens relative aperture F 2.0

Lens viewing angle 64˚(H) x 50˚(V)

Power supply 24Vdc (via system cable)

When cable length exceeds 200m

a power adaptor is required

(VCM1162/00R orVC11625)

Power consumption <2.5W

System cable 4-wire twisted pair‘telephone’cable

System connectors RJIIE modular

Ambient temperature

operating -10° ~ +45° C

storage -25° ~ + 70° C

Ambient humidity

operating 20% ~ 90%RH

storage up to 99%RH

Dimensions 69 mm (w) x 59 mm (d) x 113 mm (h)

Weight 176 g.

Specifications may be changed without notice.

Technical specification

B/W CCD CAMERA

Pick-up device 1/3”(Solid state CCD)

No. of picture elements (HxV)

512 x 582 (CCIR)

Horizontal resolution 380TVL

Gain control Automatic

Iris Electronic iris

Light sensitivity 0.2 lux (minimal acceptable picture)

0.5 lux (50 IRE,100% scene

refelection)

Spectral sensitivity range 400 ~ 1000nm

Signal to noise ratio >48 dB

Built-in microphone electret

Lens relative aperture F 2.0

Lens viewing angle 64˚(H) x 50˚(V)

Power supply 9.6 - 27Vdc (via system cable)

When cable length exceeds 300m a

power adaptor is required (VSS2904)

Power consumption <2.5 W

System cable 4-wire twisted pair‘telephone’cable

System connectors RJIIE modular

Ambient temperature

operating -20° ~ +55° C

storage -25° ~ + 70° C

Ambient humidity

operating 20% ~ 90%RH

storage up to 99%RH

Dimensions 69 mm (w) x 59 mm (d) x 113 mm (h)

Weight 115 g.

Specifications may be changed without notice.

Fig.A

Fig.B

5049

Electro Magnetic Compatibility (EMC)

The cameras comply with the EN55022 and EN500082-1 European EMC

standards and the FCC part 15 class B rules (US standard).

This device complies with part 15 of the FCC rules under test conditions

that included use of system cables and connectors between system

components.If you have any problem,contact your dealer.

Operation is subject to the following two conditions:

1 This device may not cause harmful interference.

2 This device must accept any interference received,including interference

that may cause undesired operation.

The equipment conforms with the EMC directive and low-voltage

directive.

Warnings

Any unauthorized modification to this equipment may cause violation of

the FCC rules resulting in the revocation of the authorization to operate

the equipment.

To prevent fire or shock hazard,do not expose this accessory to rain or

moisture.Do not attempt to disassemble the camera.In order to prevent

shock and fire hazard,do not remove screws or covers.There are no

user-serviceable parts inside.

The exclamation mark within a triangle is intended to alert the

user to the presence of important operating and maintenance

(servicing) instructions in the literature accompanying the

appliance.

Position

First you need to determine where the camera is to be installed.The best

results are obtained when the camera looks a little downwards and not

into a bright source of light.

●Check if the cable length compensation selector (fig.A-4) (fig.B-4) is set to

the correct length of the system cable (0-300m/900ft max.) connecting

monitor and camera.

●Open casing and push out the slotted opening in the centre of the

case back.

●Insert screw with washer (fig.A-1) (fig.B-1) from inside the case.

●Slide the bracket joint (fig.A-2) (fig.B-2) onto the screw,curved side first.

●Slide the pin through the yoke (fig.A-3) (fig.B-3) and screw the assembly

together.

Focus adjustment

The focus is preset.No further adjustment is possible.

System connection

Connect the cable to the output of the camera.

The lens

Caution: Do not touch the glass of the lens.This could damage the

delicate coating on its surface.If the lens has to be cleaned, use a

special lens cleaning tissue, available at any good camera store.

Focus range

The built-in lens provides an optimal image sharpness for objects between

1 metre and infinity (depth of field).

GB 3

Observation Camera

Introduction

Your new CCD camera is developed for use with the Philips Observation

System Monitor,registering images via the monitor,as well as input

contacts for connecting external alarm devices.

Installation

Warning: Disconnect the monitor from the mains supply before

disconnecting a camera or accessory.

Only operating the stand-by key is not sufficient.

When the mains supply is connected,all camera lines are scanned.The

monitor uses this to register the camera configuration of the system and

to check whether any modifications have been made.

Alarm inputs

N.B. B&W Cameras only

The camera has a three-pole terminal block for connecting alarm sensors,

such as door contacts.For normally open (N.O.) sensors,connect to

contacts N.O.(fig.A-6).For normally closed (N.C.) sensors,connect to

contacts N.C.(fig.A-6)

The illustrations to which this manual refers,are shown on the front and

back jacket flap

Cable

A 4-wire sytem cable (see specifications) is supplied as standard.

For optimum picture quality a standard dual‘twisted-pair’(telephone)

cable should be used (fig.C).

The maximum distance that can be bridged (without a cable extension

adapter) between the monitor and the cameras is 300 meters (200 meters

for colour cameras).

Caution: The plugs used for the observation system have the same

dimensions as standard telephone plugs.Never connect a telephone to

the camera or system monitor.

Tips for maintenance

Cleaning - The outside of the camera can be cleaned with a moist fluff-

free cloth or a chamois leather cloth.

When cleaning the lens a special lens cleaning cloth should be used.

Do NOT use cleaning fluids based on alcohol,methylated spirit,

ammonia etc..

Avoid direct contact with water.
